Total TFLI2002 User manual

1
v
BATTERY LED FLOODLIGHT

2
Security instructions
Caution
Please read the operating instructions carefully and observe the notes provided. Save
the instructions for future reference.
Use the instructions to familiarize yourself with the product, its proper use and
the safety notes. Safe operation of this machine is only possible when the
operating or safety information is fully read and the instructions contained
therein are strictly followed.
When using power tools, basic safety precautions should always be followed to reduce
the risk of fire, electric shock, and personal injury, including the following:
Product Safety Instructions
Caution
Read, understand and follow all safety rules and operating instructions in this manual
before using this product.
Be sure to read and understand all instructions in this manual before using this battery-
powered spotlight. Failure to follow all instructions may result in electrical shock, fire,
and/or serious personal injury.
•Learn about its applications and limitations, as well as the specific potential
hazards associated with this tool.
•Use only the recommended battery pack and charging cradle. Any attempt to use
another battery pack will result in explosion, fire, or personal injury.
•Remove the battery pack from the LED spotlight before replacing the bulb or
performing any routine maintenance or cleaning.
•Allow the LED work spotlight to cool down for several minutes after use before
changing the bulb.
•Do not disassemble the tool or the battery.
•Do not place the spotlight and battery pack near fire or heat. They can explode.
Also, do not dispose of a spent battery pack by incineration, even if it is severely
damaged or completely worn out. The battery can explode in flames.
•Do not use the work light or charging stand near flammable liquids or in gaseous
or explosive atmospheres. Internal sparks can cause flames.
•To reduce the risk of electric shock, do not put the tool in water or other liquid.
Do not place or store the portable spotlight where it can fall or be pulled into a
container of water.
•Do not allow children to use tools without supervision. It's not a toy. The
temperature of the bulb will warm up after being on after a period of time. This
hot temperature can cause burns if touched.
•Do not use or allow the use of this tool in bed or sleeping bags. This handheld
LED spotlight can melt fabric and cause a burn injury.
•Keep the light dry, clean and free of oil or grease. Always use a clean cloth when
cleaning. Never use brake fluid, gasoline, petroleum-based products, or any
strong solvents to clean the LED spotlight.
Battery Safety Warnings
Read all warnings and safety instructions. Failure to follow the warnings and instructions
may result in electric shock, fire, and/or serious injury.

3
•Risk of fire and burns. Do not disassemble, heat above 100°C (212°F), or
incinerate. Do not expose cells or batteries to heat or fire. Avoid storage in direct
sunlight.
•Dispose of the used battery properly. When disposing of used cells or batteries,
keep cells or batteries of different electrochemical systems separate.
•Keep the battery out of the reach of children and in the original package until
ready to use.
•The battery used in this device may present a risk of fire or chemical burn if not
treated properly. Replace the battery with original replacement parts approved by
the manufacturer. Use of another battery may present a risk of fire or explosion.
•Do not use a visibly damaged battery pack or device.
•Do not modify or attempt to repair the device or the battery pack, as applicable.
•Do not short circuit a cell or battery. Do not store cells or batteries haphazardly
in a box or drawer where they can short-circuit each other or be short-circuited
by conductive materials.
•Do not subject cells or batteries to mechanical shock.
•Keep cells and batteries clean and dry. Wipe the cell or battery terminals with a
clean, dry cloth if they become dirty.
•Do not use any charger other than the one specifically provided for use with the
equipment. Batteries must be charged before use. Always use the correct
charger and refer to the manufacturer's instructions or equipment manual for
proper charging instructions.
•Whenever possible, remove the battery from the equipment when not in use.
•Avoid accidental ignition. Make sure the switch is in the off position before
connecting the battery pack, picking up or carrying the tool.
•Disconnect battery pack from spotlight before making adjustments, changing
accessories, or storing. These preventative safety measures reduce the risk of
the tool being started accidentally.
•Under abusive conditions, fluid can be expelled from the battery; avoid contact.
If accidental contact occurs, rinse with water. If the liquid comes into contact with
the eyes, also seek medical help. Liquid expelled from the battery can cause
irritation or burns.
•Have a Total technician perform service using only identical replacement parts.
This will ensure that product safety is maintained.

4
Symbols
Technical data
Data sheet
Voltage
20V
charger voltage
100-240V ~ 50/60Hz
low level lumens
750
high level lumens
1500
*The tool is designed for use with Total's P20S range of batteries and chargers.
Note: Due to the continuous program of R&D&I, this document is subject to change without notice.
Product description
1. Handlebar/handle cover
2. Handlebar / handle
3. Adjustment wheel
4. Hook
5. Support pad
6. Supports
7. Front cover
8. On/off switch
To reduce the risk of injury, the user must read the instruction manual
Do not expose to rain or water.
Do not burn
Lithium Ion Battery, the battery must be recycled properly and must be sorted
for environmentally friendly recycling.
Class III
Do not stare at the operating light source

5
Operating instructions
Note: Before using the tool, please read the instruction book carefully.

6
Figure
Action
Before the operation
Figure A
Battery charge
Figure B
Battery Installation
Figure C
Battery removal
Set up
Figure D
Start and stop:
To turn on low beam: Press the on/off switch
To stop your high light: Press the on/off switch twice
Warning: Do not direct the light beam at the eyes.
Reflector Placement
Caution: Be sure to position the tool well to avoid the risk of falling.
Figure E
Use of the hook to hang the LED spotlight:
Warning: Do not hang the work light from any electrical
power cables.
Figure F
Using the bracket to hang the light
Adjustable lighting angle
Figure G
The searchlight head can be configured in a variety of
positions.
To change base positions, turn the adjusting wheel to
loosen the
reflector. Adjust the light to the desired
position, tighten the adjustment wheel.
Caution:
Do not put your hands or fingers between the
adjustable head and the bracket when setting up the work
light to avoid any danger.
Maintenance Tips
Replace any part or accessory with original manufacturer-approved replacement parts.
See the accessory packaging for details. The store staff can help you and offer advice.
Environment
•Do not dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities.
•Contact your local authority for information on available collection systems.
•If electrical appliances are disposed of in landfills, hazardous substances can
seep into the groundwater and enter the food chain, harming your health and
well-being.
•Recycle raw materials instead of disposing of them as waste.
•The machine, accessories and packaging must be sorted for environmentally
friendly recycling.

7
