Toto PJY1724PW User manual

INSTALLATION GUIDE
To service installers
Please explain the FLOTATION TUB functions and
operation to the customers.
Please install according to all local and applicable
codes.
FLOTATION TUB
WITH RECLINE COMFORT
<INSTALLATION INSTRUCTIONS>
●Cautions and warnings 2
●Included parts 4
●Required tools 5
●6
●Dimension drawings 7
●Installation procedures 8,9
● Installing the bathtub 10,16
●Finishing 15,20

2
Cautions and warnings
WARNING When this appears next to a topic, this indicates that misoperation could result in death
or serious injury.
CAUTION When this appears next to a topic, this indicates that misoperation may result in injury
or physical damage.
●The following symbols are used to classify and explain instructions that must be followed.
Symbol example Meaning of symbol
This symbol indicates something that is "Prohibited".
This symbol indicates something that is "Required".
WARNING
Prohibited
Do not stand on bathtub while working.
●Doing so could cause a fall or injury or damage the components.
Only install the supplied parts or directed parts, and do not apply any changes to
them.
●Especially make sure not to change the dimensions of the product.
Always observe
Make sure to follow the installation guide for installation.
●
Make sure to follow the procedures for the drainage piping attachment.
●Defective construction can result in water leakage that could wet and cause damage to household
property.
After unpacking, swiftly dispose of any unnecessary packing materials.
●The wood frame, nails, cardboard boxes, vinyl bags, or sealing straps may cause an injury.
If children play with the packaging materials there is a risk of suffocation or other accidents.
Attach the faucet water supply equipment to the bathtub.
Incomplete installation can result in a leakage that could wet and cause damage to household property.

3
WARNING
Always observe
Make sure to install the bathtub according to the installation guide and in a stable
location.
●.
Ensure that you have an ergonomic working position during transport and assembly.
●Take care at every stage that your move is safe. Ensure that you have assistance to avoid risk of accident
or injury.
Observe the current local prevention of accidents and building regulations as well as
sanitary and environmental protection rules during installation.
CAUTION
Prohibited
Do not place a stepladder inside the bathtub or place heavy objects on the edge the
bathtub.
●This may cause damage.
Do not drop or bump anything hard or heavy onto the bathtub.
●This may cause the bathtub to crack and result in an injury, or leakage that could wet and cause damage
to household property.
Keep sources of heat at a distance. Do not smoke.
●Doing so could cause damage.
Do not install the bathtub outdoors or in a location that is regularly exposed to
sunlight (such as a sun room).
●This may cause the bathtub to freeze and cause damage or discoloration.
When delivering the bathtub, do not hold the hose or piping or bump anything hard
against it.
Always observe
When opening the packaging, make sure that all of the supplied parts and the
bathtub itself are not damaged. If they are, do not use the damaged parts.
●Replace any damaged parts.
When installing the bathtub in a location that could result in damage due to water
●.
Remove the bathtub's protective sheet after the construction is completed.
Secure an area that enables proper space for the usage and maintenance of the bathtub.
●If water leakage is detected, remove the cause of the leakage.
SAVE THESE INSTRUCTIONS

4
Included parts
Instruction
Manual
Installation
Guide
A-1 A-2
A-3 A-4
A-5 A-6
: Bathtub : Polyethylene foamed sheet
: Instruction manual : Installation guide
: Socket : Sleeve
(Only PJY1724PW)

5
Required tools
B-1 B-2 B-3
M12
B-4
B-8
B-10
B-9
B-5 B-6 B-7
PVC adhesive
Silicone
Soft cloth that will not
damage the bathtub
Water detection sheet
Made by OS&B Ltd:
ITD35/ITD5135 Island Tub Drain(shown)
Made by CG Air:
CG-DID Drop-in Drain
PVC primer
(Only PJY1724PW)

6
Item
PJY1724PW PPY1780PT
External dimensions 66-15/16″(L) × 31-1/2″(W) × 22-1/4″(H) 66-15/16″(L) × 29-1/2″(W) × 22-1/16″(H)
17-11/16″ (450mm)
(1700 mm (L) × 800 mm (W) × 565 mm (H)) (1700 mm (L) × 750 mm (W) × 560 mm (H))
Bathtub depth
Capacity 67.5 gallons (255 L) 53.7 gallons (203 L)
Weight 212.5 pounds (96.4 kg) 169.7 pounds (77 kg)
Materials Artificial marble made of GFRP sandwich
structure
Drainage method
Drain plug Push-operated drain plug Push-operated overflow button
Drainage rate
Overflow rate
19 gpm (72 L/min)
Normal drainage + Overflow drainage
11 gpm (41 L/min)
21 gpm (81 L/min)
12 gpm (44 L/min)
Specifications
Composed of a transparent acrylic layer on
the surface,a colored layer mixed with
alumina,and the back side is composed of
GFRP and artlficial marble

7
Dimension drawings
PJY1724PW
PPY1780PT

Installation procedures for PJY1724PW
8
>>P.7 >>P.10
>>P.10 >>P.11
>>P.12
>>P.11

Installation procedures for PPY1780PT
9
>>P.18 >>P.18
3/16”
(5mm)
13/16”
(20mm)
>>P.7 >>P.16
>>P.19

Installing the bathtub for PJY1724PW
2
1B-20
B-10
2
3
4
10

5
1
2
A-5
B-10B-6
6
11

Conduct a fill water
8
1
12

9
8
Fix the bathtub
A-6
B - 4
B-2 M12
A-2
3
2
2
1
13
3/16”(5 mm)
3/16”(5 mm)

CAUTION
Required
Fix the bathtub in place with mortar using the provided sleeves (A-6).
9
10
3
14

B-5
11
WARNING
that does not contain alcohol.
Finishing
15

Installing the bathtub for PPY1780PT
1.To confirm the drainage hole position.
Preparation prior to the installation of bathtub
①、Ensure the floor is level for placing bathtub.
If the floor is not level, pedestals can be built for placing bathtub. Location depends on the position of bathtub
feet and height depends on the drainage fittings used.
②、Detailed dimensions of drain hole depend on the dimensions of drain parts in drainage fittings.
Note: 1. After bathtub is placed, level the bathtub to ensure stable placement.
2. For detailed position of feet, refer to the dimension drawing on page 7.
Leave a 1/8”(3mm) gap between the flange and the framing.
Pedestal for vertical foot
Bathtub
dimension
Drain hole
1
1/8”(3mm)
2
16

Installing of drain tube
2 .Connecting thread pipe
G1 1/2
rubber gasket teflon tape
1 .Connecting PVC pipe
● For side draining occasions.
● For direct draining occasions.
PVC adhesive and PVC primer must be used for sticking, fixing and sealing the connected
part (A-5) between drain pipe and drain fitting to avoid water leakage.
Always do this
1. Connecting PVC pipe 2. Connecting thread pipe
3
G1 1/2
rubber gasket
teflon tape
B-6
pipe tilt 1/50 or more
A-5
B-6
A-5
17

18

6
Secure the bathtub
Place the installed bathtub on the pedestal and adjust the bathtub until level.
Keep the gap between the edge and the wall about 1/8” (3mm).
①Loosen nut A.
②Install the foot to the bathtub at C (shown below).
2. Level the bathtub and connect the drain pipe.
Level
A
1/8” (3mm)
Figure A
Adjustable height bottom foot
Note: 1. After nut A is loosened, the distance between nut B and nut A is about 2-3/4” (70mm).
2. When the foot is installed, it is not required to secure with mortar.
3. Secure the four fixed feet.
Method 2
Use universal glue to pour the all-purpose adhesive on the ground previously marked,
with an area of about 1-3/16”(30mm) in diameter.
Bottom position of bathtub
Method 1
Fix the feet of the bathtub with cement mortar.
Attention: please do not touch the mortar or strong adhesive to the body of bathtub.
The scope of the mortar
1. Install the adjustable height foot.
Nut A
Nut
B
Loosening nut Fastening nut
C
19

7
Building of ceramic tile
● Drop-in Installation
a. Bathtub without skirt: Build a low wall with brick. Build ceramic tile on the outer
side of the low wall with mortar (a clearance of at least 3/16”(5mm) is kept between
the upper edge surface and bathtub side). Buffer material is used to fill this clearance (such as soft polythene or
equiva lent material). At last sealing material is used to seal the clearance between ceramic tile and bathtub.
(Refer to the following Figure B).
A Wall edge
B
1. During the whole installation soft material is recommend to cover bathtub surface to
prevent surface scratching.
2. The bathtub cannot be hung by the rim. The bathtub weight must be transferred solely
through its feet.
3. During installation, do not allow the bathtub to collide with hard objects and do not
allow hard objects to fall into the bathtub.
4. The back of bathtub can not be filled or buried by mortar otherwise damage may be
caused.
5. During construction, never stand on the bathtub or place heavy material on the
rim of the bathtub. This may damage the bathtub.
Note: After installation of the bathtub clean the floor. Then use a sponge or cloth
with neutral detergent to clean the bathtub. After 5 minutes, rinse with water
and then wipe dry.
Warning
Drop-in Installation
Material for
stopping mortar
(sponge etc.)
3/16”(5mm)
Sealed material
Tile
Mortar
Brick
13/16”
(20mm)
20
