Toto EGO II TX494SELV1BR User manual

SPECIFICATIONS
TROUBLESHOOTING
TX494SELV1BR
S06725-1BN
CHECK
POINT
Water leaks around the handle 1 Tighten
Handle is loose 2 Tighten
PROBLEM
SOLUTION
1. CONNECTING NUT
2. BOLT
230
700+20
0
45°
55+0
-20

Ø95
67
75+0
-20 894+20
0
637+20
0
30
R9
INSTALLATION
1
3
Sleeve
Anchor
* Cut thecover after the
mortar dry
5
2
Screw
4
* Plastic
Cover
6 X Ø6
Holes
Floor
Water Pass
Make sure floor is flat
Hot Water
Supply *
Cold Water
Supply *
Mortar
Minimum
Mortar Level
Maximum
Mortar Level
Base
COLD
Cover
a
b
HOT
* Pipe supplied by owner
"EGO II"LEVER HANDLE FLOOR STANDING
SINGLE LEVER BATH FILLER
OPERATING CONDITIONS
MAINTENANCE
ATTENTION
1. Watersupply pressure : 0.05 ~ 0.75MPa.
2. Ensure that water supply is clean ( NoSand, Dirt, Etc.).
All Finishes : Clean the finish with mild soapand warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toiletcleaneretc. which could adversely affect the finish and
are not recommended for cleaning.
1.Don t use abrasive cleaners or solvents on faucets and fittings.
As the product model is constantly updated, the actual product
maynot look the same as it shown in the diagram, but the
basic installation principles are thesame.
2.
6
Bolt*
Hex. Key
Base
Cover
* Remove the Base Cover
, keep the Bolt & Washer
Washer*
7
Hex. Key
Cover
Body
Swivel
Ring
Bolt & Washer
(Dari step 6)

SPESIFIKASI
PENYELESAIAN MASALAH
TX494SELV1BR
S06725-1BN
Air bocor disekitar handle 1 Kencangkan
Handle longgar 2 Kencangkan
MASALAH
SOLUSI
POIN
PERIKSA
1. CONNECTING NUT
2. BOLT
230
700+20
0
45°
55+0
-20

Ø95
67
75+0
-20 894+20
0
637+20
0
30
R9
PEMASANGAN
1
3
Sleeve
Anchor
* Potong cover setelah
mortar mengering
5
2
Screw
4
* Plastic
Cover
6 X Ø6
Holes
Floor
Water Pass
Pastikan lantainya rata
Hot Water
Supply *
Cold Water
Supply *
Mortar
Minimum
Mortar Level
Maximum
Mortar Level
Base
COLD
Cover
a
b
HOT
* Pipadiseidakan oleh pemilik
"EGO II"LEVER HANDLE FLOOR STANDING
SINGLE LEVER BATH FILLER
KONDISI OPERASIONAL
PEMELIHARRAN
PERHATIAN
1. Tekanan sumber air: 0.05 ~ 0.75 MPa.
2. Pastikan kondisi sumberair adalah bersih (tidak ada pasir,
kotoran dan lain lain)
1.Jangan gunakan pembersih atau pelarut abrasif pada faucet
dan fitting.
Karena model produk terus mengalami pembaharuan, aktual
produk mungkin tidak samadengan gambar, tapi prinsip dasar
pemasangan adalah sama.
2.
Seluruh lapisan: Bersihkan lapisan akhir dengan sabun lembut
dan air hangat. Lap seluruh permukaan hingga benar-benarkering
dengan kain lembut yang bersih. Kebanyakanbahan pembersih
mungkin mengandung bahan kimia, seperti amonia, klorin,
pembersih toilet,dll. yang dapat mempengaruhi hasil akhir dan
tidak disarankan untuk membersihkannya.
6
Bolt*
Hex. Key
Base
Cover
* Lepas BaseCover,
simpan Bolt & Washer
Washer*
7
Hex. Key
Cover
Body
Swivel
Ring
Bolt & Washer
(Dari step 6)
