Toto MERCER TS756PSW Installation instructions

ENGLISH ESPAÑOL FRANÇAIS
Installation and Owner’s Manual
Manual de Instrucciones y del Propietario
Manuel d’Installation et d’Utilisation
TS756PSW TS756PVSW
TS756A TS756A
TS756P TS756PV
TS756E
MERCER ®
TS784PSW TS784PVSW
TS784A TS784A
TS784P TS784PV
TS784E
CLAYTON ®
TS794PSW TS794PVSW
TS794A TS794A
TS794P TS794PV
TS794E
NEXUS ®
TS930PSW TS930PVSW
TS930A TS930A
TS930P TS930PV
TS930E
LLOYD ®

2
ENGLISH
THANKS FOR CHOOSING TOTO®!
CARE AND CLEANING
WARNING
TOOLS YOU WILL NEED
TOTO's mission is to provide the world with healthy, hygienic and
more comfortable lifestyles. We design every product with the balance
of form and function as a guiding principle. Congratulations on your
choice.
If using solder for the installation of the shower faucet, the pressure
blance cartridge, rubber seats, and plaster guard must be removed
before heating. Otherwise, the warranty will be voided on these parts
Your new faucet is designed for years of trouble-free performance.
Keep it looking new by cleaning it periodically with mild soap, rinse
thoroughly with warm water and dry with a clean, soft cloth. Do not use
abrasive cleaners, steel wool or harsh chemicals, as these will dull the
¿QLVK)DLOXUHWRIROORZWKHVHLQVWUXFWLRQVPD\YRLG\RXUZDUUDQW\

3
ENGLISH
BEFORE INSTALLATION
MERCER®TS756, CLAYTON®TS784, NEXUS®TS794
TS7__PSW TS7__PVSW TS7__A TS7__E TS7__P TS7__PV
XXX
XX XX
XX
XX X X
XX

4
ENGLISH
BEFORE INSTALLATION
LLOYD®TS930
TS930PSW TS930PVSW TS930A TS930E TS930P TS930PV
XXX
XX XX
XX
XX XXX
XX

5
ENGLISH
INSTALLATION PROCEDURES
Shower Trim Installation
1. Make sure the gasket is in the escutcheon
and the notch of the gasket is aligned with the
notch of the escutcheon.
)RU76BBB396:DQG76BBB39
Attach diverter lever to escutcheon using
supplied hex wrench
2. Remove the plastic cover from the valve by
twisting it clockwise.
)DVWHQHVFXWFKHRQWRSUHVVXUHEDODQFH
valve using two supplied screws.
4a. Thread canopy to pressure balnce valve.
Hand tighten only. (See 4b for Lloyd).

6
ENGLISH
4b. Attach nut securely into the pressure
balance valve.
Secure the canopy onto the
coverplate with set screw.
Temporarily install the handle adapter
onto the valve stem and the handle
onto the adapter.
5. Install the handle onto the valve stem using
supplied screw. Measure the distance from
point A on the lever to point B on the canopy.
Subtract 1/16" from this measurement to obtain
the amount of valve stem to cut off
6. Ex. If the distance between A & B is 1",
Amount to cut off = 1"–1/16" = 15/16"
Mark the amount to cut off from the end of the
valve stem.

7
ENGLISH
7. Cut the valve stem at the mark with a hack
VDZ5HPRYHDQ\EXUUVZLWKD¿OH
8a. Using handle, turn shaft fully clockwise.
Reposition handle so that it is in vertical
SRVLWLRQ7KLVLVWKH2))SRVLWLRQ)DVWHQ
handle with screw. Screw cap onto handle.
(See 8b for Lloyd)
8b. Rotate the valve stem clockwise to a stop.
Re-install the handle adapter onto the valve
stem
Install the handle onto the handle adapter,
positioning it so it is in vertical position (the
2))SRVLWLRQ6HFXUHWKHKDQGOHZLWKVHW
screw. Replace the handle end cap at the
end of the handle.

8
ENGLISH
Shower Installation
Install canopy onto shower arm. Wrap
threads with supplied thread tape. To
prevent marring the surface, use a strap
wrench or use the end of the arm for
leverage.
Install shower head with wrench. Hand
tighten only
Spout Installation
Note:
The Lloyd spout can only be installed via slip-
on.
)RUVOLSRQLQVWDOODWLRQ
Place pipe tape onto thread. Install the slip-
on adapter on to the elbow. Remove the
existing nipple if necessary.
Slide the spout into position and secure with
set screw.
)RU,36LQVWDOODWLRQ
Remove the slip-on adapter. Apply pipe
tape onto the nipple threads and screw the
spout into a secure position.

9
ENGLISH
TROUBLESHOOTING

10
ENGLISH
TS756A
TS756P/PV
TS756E
ROUGH-IN
MERCER®TS756

11
ENGLISH
TS784A
TS784P/PV
TS784E
ROUGH-IN
CLAYTON®TS784

12
ENGLISH
TS794A
TS794P/PV
TS794E
ROUGH-IN
NEXUS®TS794

13
ENGLISH
TS930A
TS930P/PV
TS930E
ROUGH-IN
LLOYD®TS930

14
ENGLISH
REPLACEMENT PARTS
MERCER®
TS756A * SHOWER HEAD ASSEMBLY
THU4208 * SHOWER ARM
THU4211 * ESCUTCHEON
THU4198 O-RING
THU4214 * SHOWER HEAD
THU4132 * METAL HANDLE ASSEMBLY
3EU4022 * HANDLE CAP
6BU4003 SCREW
3EU4013 * HANDLE JOINT
 THU4142 * HANDLE ASSEMBLY
 THU4145 * CANOPY ASSEMBLY
 THU4172 * )$&(3/$7($66(0%/<
 THU4106 * DIVERTER HANDLE
 6BU4009 SCREW
 7EU4000 * COVER PLATE
 6BU4006 SET SCREW
 TS756E * SPOUT ASSEMBLY
 THU4122 * STREAM BREAKER
 9BU4011 O-RING
 THU4175 * SPOUT ASSEMBLY
 THU4116 * SPOUT BASE
 6BU4008 SET SCREW
 THU4130 SPOUT ADAPTER
 2BU4004 RING
 ** HEX WRENCH 5/64"
 ** PIPE TAPE
 ** HEX WRENCH 25MM
 ** HEX WRENCH 1/8"
 ** CARDBOARD TUBE 1-3/8" OD X 1-1/4" ID X 6" L
 THU4238 * )$&(3/$7($66(0%/<:2',9(57(5
 THU4229 * COVER PLATE (W/O DIVERTER)
63(&,)<),1,6+&2'(:+(125'(5,1*
3529,'(')255()(5(1&(21/<127$9$,/$%/($663$5(3$576

15
ENGLISH
REPLACEMENT PARTS
MERCER®
29
TS756A
TS756PSW
TS756PVSW
TS756P
TS756PV
TS756E

16
ENGLISH
REPLACEMENT PARTS
CLAYTON®
1 TS784A * SHOWER HEAD ASSEMBLY
2 THU4199 * SHOWER ARM
3 THU4202 * ESCUTCHEON
4 9BU4007 O-RING
5 THU4205 * SHOWER HEAD
6 THU4138 * METAL HANDLE ASSEMBLY
7 3EU4007 * HANDLE CAP
8 6BU4003 SCREW
9 3EU4013 * HANDLE JOINT
10 THU4157 * HANDLE ASSEMBLY
11 THU4154 * CANOPY ASSEMBLY
12 THU4184 * )$&(3/$7($66(0%/<
13 THU4103 * DIVERTER HANDLE
14 6BU4009 SCREW
15 7EU4003 * COVER PLATE
16 6BU4005 SET SCREW
17 TS784E * SPOUT ASSEMBLY
18 THU4160 * STREAMBREAKER & O-RING
19 6BU4008 SET SCREW
20 THU4130 SPOUT ADAPTER
21 ** HEX WRENCH 5/64"
22 ** PIPE TAPE
23 ** HEX WRENCH 25MM
24 ** HEX WRENCH 1/8"
25 ** CARDBOARD TUBE 1-3/8" OD X 1-1/4" ID X 6" L
26 THU4235 * )$&(3/$7($66(0%/<:2',9(57(5
27 THU4226 * COVER PLATE (W/O DIVERTER)
63(&,)<),1,6+&2'(:+(125'(5,1*
3529,'(')255()(5(1&(21/<127$9$,/$%/($663$5(3$576

17
ENGLISH
REPLACEMENT PARTS
CLAYTON®
25
TS784A
TS784PSW
TS784PVSW
TS784P
TS784PV
TS784E
26
27

18
ENGLISH
REPLACEMENT PARTS
NEXUS®
1 TS794A * SHOWER HEAD ASSEMBLY
2 THU4217 * SHOWER ARM
3 THU4220 * ESCUTCHEON
4 THU4198 O-RING
5 THU4223 * SHOWER HEAD
6 THU4135 * METAL HANDLE ASSEMBLY
7 3EU4019 * HANDLE CAP
8 6BU4003 SCREW
9 3EU4016 * HANDLE JOINT
10 THU4151 * HANDLE ASSEMBLY
11 THU4148 * CANOPY ASSEMBLY
12 THU4178 * )$&(3/$7($66(0%/<
13 THU4103 * DIVERTER HANDLE
14 6BU4009 SCREW
15 7EU4006 * COVER PLATE
16 6BU4005 SET SCREW
17 TS794E * SPOUT ASSEMBLY
18 THU4122 * STREAM BREAKER
19 9BU4011 O-RING
20 THU4181 * SPOUT ASSEMBLY
21 THU4119 * SPOUT BASE
22 6BU4008 SET SCREW
23 THU4130 SPOUT ADAPTER
24 2BU4004 RING
25 ** HEX WRENCH 5/64"
26 ** PIPE TAPE
27 ** HEX WRENCH 25MM
28 ** HEX WRENCH 1/8"
29 ** CARDBOARD TUBE 1-3/8" OD X 1-1/4" ID X 6" L
30 THU4241 * )$&(3/$7($66(0%/<:2',9(57(5
31 THU4232 * COVER PLATE (W/O DIVERTER)
63(&,)<),1,6+&2'(:+(125'(5,1*
3529,'(')255()(5(1&(21/<127$9$,/$%/($663$5(3$576

19
ENGLISH
REPLACEMENT PARTS
NEXUS®
TS794A
TS794PSW
TS794PVSW
TS794P
TS794PV
TS794E
29

20
ENGLISH
REPLACEMENT PARTS
LLOYD®
 65#  5*19'4*'#&#55'/$.;
 (7  5*19'4537#4'67$'#55;#4/
 6*7  '5%76%*'10
 $7 1Ä4+0)
 6*7  5*19'4*'#&
 6*7  /'6#.*#0&.'#55'/$.;
 6*7  %#012;#55'/$.;
 $7 5'65%4'9
 $7 1Ä4+0)
 6*7  *#0&.'#55'/$.;
 (7  #&#2614
 $7 5%4'9
 $7 5'65%4'9
 $7 1Ä4+0)
 (7  (#%'2.#6'#55'/$.;
 (7  %18'42.#6'
 $7 5%4'9
 #7 9#5*'4
 $7 5%4'9
 65'  52176#55'/$.;
 $7 1Ä4+0)
 $7 5%4'9
 '7 564#+0'4
 $7 1Ä4+0)
 6*7 #'4#614#55'/$.;
 *7 (+66+0)5
 (7  (#%'2.#6'#55'/$.;91&+8'46'4
 (7  %18'42.#6'91&+8'46'4
63(&,)<),1,6+&2'(:+(125'(5,1*
3529,'(')255()(5(1&(21/<127$9$,/$%/($663$5(3$576
