MODEL T16004
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
5LTR
ELECTRIC
PRESSURE COOKER

2
TECHNICAL DATA
Description: Electric Pressure Cooker
Model: T16004
Rated Voltage: 220-240V ~50Hz
Input Power: 900W
DOCUMENTATION
We declare that this product conforms to the following product
legislation in accordance with the following directive(s):
2004/108/EC Electromagnetic Compatibility Directive.
2006/95/EC Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
1935/2004/EC Materials & Articles in Contact With Food
(LFGB section 30 & 31).
RKW Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original
purchase. If any defect arises due to faulty materials of workmanship,
the faulty products must be returned to the place of purchase. Refund
or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the
instructions contained in this instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable
parts.
• RKW has limited liability for incidental or consequential loss or
damage.
• This guarantee is only Valid in the UK and Eire Only.
AN EXTENDED WARRANTY IS AVAILABLE FOR THIS
APPLIANCE. SEE BACK PAGE FOR DETAILS.

3
Wiring safety for UK use only
Important
As the colours in the mains lead of this appliance
may not correspond with the coloured markings
identifying the terminals in your plug, please
proceed as follows:
The wires in the mains lead are coloured in
accordance with the following code:
Plug tting details (where applicable).
The wire coloured blue is the neutral and must be connected to the
terminal marked [N] or coloured black.
The wire coloured brown is the live wire and must be connected to the
terminal marked [L] or coloured red.
The wire coloured green/yellow must be connected to the terminal
marked with the letter [E] or marked .
On no account must either the brown or the blue wire be connected to
the [EARTH] terminal .
Always ensure that the cord grip is fastened correctly.
The plug must be tted with a fuse of the same rating already tted and
conforming to BS 1362 and be ASTA approved.
If in doubt consult a qualied electrician who will be pleased to do this
for you.
Non-rewireable mains plug
If your appliance is supplied with a non-rewireable plug tted to the
mains lead and should the fuse need replacing, you must use an ASTA
approved one (conforming to BS 1362 of the same rating).
If in doubt, consult a qualied electrician who will be pleased to do this
for you.
If you need to remove the plug - disconnect it from the mains - and then
cut it o the mains lead and immediately dispose of its safely. Never
attempt to reuse the plug or insert it into a socket outlet as there is a
danger of an electric shock.
Warning: this appliance must be earthed
Blue neutral [N] Brown live [L] Green/yellow [EARTH]
FUSE

4
Product safety
Safety Information
• Check that the voltage of the main circuit corresponds with the rating
of the appliance before operating.
• Please ensure that the appliance is used on a stable, level, and heat
resistant surface.
• Do not immerse cords, plugs or any part of the appliance in water or
any other liquid.
• Do not leave the appliance unattended while it is operating.
• Close supervision is necessary when any appliance is used by or
near children or pets.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children
without supervision.
• Switch o at the wall socket then remove the plug from the socket
when not in use or before cleaning.
• If the supply cord or appliance is damaged, stop using the appliance
immediately and seek advice from the manufacturer or its service
agent or a similarly qualied person.
• Do not let the cord hang over the edge of a table or counter or let it
come into contact with any hot surfaces.
• The use of accessory attachments is not recommended by the
appliance manufacturer, apart from those supplied with this product.
• Do not pull the plug out by the cord as this may damage the plug
and/or the cable.
• Do not use this product for anything other than its intended use.
• This appliance is for household use only.
• Do not carry the appliance by the power cord.
• Do not use the appliance outdoors.

5
• Do not touch hot surfaces. Use handles and pot holders.
• Do not place the pressure cooker in a heated oven.
• Extreme caution must be used when moving a pressure cooker
containing hot liquids.
• This appliance cooks under pressure. Improper use may result in
scalding injury. Make certain unit is properly closed before operating.
See Operating Instructions beginning.
• Never ll the unit over 2⁄3 full when cooking; however, when cooking
foods that expand such as dried fruits, or vegetables, the unit must
never be over 1⁄2 full. One-half full means the food, as well as all
other ingredients and liquids combined.
• Do not cook foods such as apple sauce, beans, cranberries, pearl
barley, oatmeal or other cereals, rice, split peas, noodles, macaroni,
rhubarb, or spaghetti. These foods tend to foam, froth, and spatter,
and should only be cooked using the plastic lid provided with the
appliance.
• Always check the pressure release devices for clogging before use.
• Do not open the pressure cooker until the unit has cooled and
internal pressure has been released. Remove pressure regulator
weight. Any pressure in the cooker can be hazardous.
• Do not use this pressure cooker for pressure frying with oil.
• Do not subject your cooker to sudden extreme temperature changes
as this will cause expansion or contraction which can crack a cast
aluminium utensil. Do not move a cooker from a cold storage area
directly onto a hot ame or element. Do not add cold water to a
cooker which has boiled dry and is still hot. Do not cool a hot cooker
suddenly by pouring cold water on it or wrapping cold wet towels
around it.
• When normal operating pressure is reached, turn the heat down so
all the liquid, which creates steam, does not vent out. In the unlikely
event the appliance develops a fault, stop using it immediately and
seek advice from the service department: 0844 984 0055
H
I
G
H
V
O
L
T
A
G
E
H
O
T
S
U
R
F
A
C
E
H
I
G
H
P
R
E
S
S
U
R
E

6
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be
disposed of in domestic rubbish. You are required to
dispose of old electrical and electronic appliances like this
separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk for access to information about the recycling
of electrical items. Please visit www.weeeireland.ie for access to
information about the recycling of electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical
items must be recycled, rather than taken to landll.
Please arrange to take this appliance to your local Civic Amenity site for
recycling, once it has reached the end of its life.
WHAT’S IN THE BOX
Instruction Manual
1. Handles
2. Lid
3. Float Valve Outlet
4. Lid Handle
5. Pressure Valve
6. Control Panel
7. Plastic Lid
8. Inner Pot
9. Scoop
10.Steam Rack
BEFORE YOUR FIRST USE:
1. Remove the parts from the packaging.
2. Wash and dry any parts that will come into
contact with food.
3. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
WARNING: DO NOT IMMERSE THE UNIT IN WATER.
1 2 3 4 5
6
7
8
9
10

7
USING YOUR APPLIANCE
Opening the appliance
Hold the pot lid handle and turn in a clockwise direction until the lid is
released. Lift the lid upwards.
Fill the inner pot
Put food and water into the inner pot. Do not exceed 4/5 of the inner
pot height. The expansive food in water should not exceed 3/5 of the
inner pot height. The food and water should not be less than 1/5 of the
inner pot height.
The maximum rice cooking volume for the pot is 5 litres = 10 glasses of
water
A cup of rice needs a cup of water. Adjust the water accordingly
depending on the type of rice or taste.
Fitting the inner pot
Before tting, clean the heating disc making sure there is no food on it.
locate the inner pot rotate slightly to make sure it has a cood contact
with the heating disc.
4/5 3/5 1/5

8
Fitting the lid
Before tting, check the gasket ring is in place and turn slightly to ensure
it has a good seating.
Place the lid on the pressure cooker and rotate counter clockwise and
locate into the clasp on the body of the pressure cooker.
Fitting the pressure release valve
Pull the valve to the sealing position. Make sure the oat has dropped
before starting to heat the unit.
Switch on the unit. The heating light will illuminate. If the pressure
holding time is not set, the heating light will not go out and the holding
light will illuminate in the temperature holding mode.
The corresponding cooking time range is also displayed on the control
panel. You can adjust the time according to your personal taste.
Make sure that the food is thoroughly cooked.
FOOD / FILL LEVEL 1/5 2/5 3/5 4/5
Rice 15min 20min 25min 30min
Chicken 20min 25min 30min 35min
Porridge/Soup 20min 28min 35min 40min
Casserole 30min 35min 40min 45min
Beef 35min 40min 45min 50min

9
Troubleshooting
FAULT POSSIBLE CAUSES SOLUTIONS
The indicating light
does not light up
The power supply has not
been connected.
Is it power failure
Is the plug fallen o
Has the switch turned on
Diculty in
covering
The gasket ring has not
been placed properly.
The oat valve blocks push
bar.
Place the gasket ring
properly.
Push the push bar lightly with
hand.
Diculty in opening The oat valve does not
drop after air discharge.
Press the oat valve lightly
Air leakage for pot lid The cover has not been
closed properly.
The gasket ring has not
been placed.
The gasket ring is stuck
food dregs.
The gasket ring has been
worn.
Cover the pot according to
stipulation.
Place the gasket ring
Clean the gasket ring
Replace the gasket ring
Air leakage for oat
valve
The gasket ring of oat
valve is stuck with food
dregs.
The gasket ring of oat
valve has been worn.
Clean the gasket ring of oat
valve
Replace the gasket ring of oat
valve
Float valve cannot rise The air discharge valve has
not been pulled to “seal-
ing” position
The food and water in the
pot are in low level
Air leakage for pot lid or air
discharge valve
Pull it to a suitable position
Add food and water
according to stipulation.
Send for repair
Rice is not cooked
correctly
The cooking time is too
short.
There are foreign materials
between the inner pot and
the heating disc.
The inner pot or heating
disc is deformed.
the heting disc has low
power
Extend cooking time properly
Check and eliminate foreign
materials
Send for repair
Send for repair
It fails to hold
temperature
automatically
The temperature holding
device is damaged
Send for repair
There is a hand
numbing feeling on
the shell.
Creepage of the product Send for repair

10
Cleaning and storage
• Ensure the product is disconnected from the mains and cool enough to
handle before cleaning.
• Fill the inner pot with warm water. Add a little detergent
• Rinse and dry thoroughly
• The outside of the product can be cleaned using a soft cloth moistened
with a mild detergent solution.
Store your appliance after it has cooled down.
When not in use, store the appliance in a safe, dry place, out of reach of
children.
NEVER IMMERSE THE UNIT IN WATER.

11
Notes:

We hope you enjoy your
appliance for many years.
As a thank you for purchasing
one of our fantastic products,
we are giving you an extra
2 years peace of mind.
To receive your extra 2 years
guarantee, register your
appliance online by visiting
www.towerhousewares.co.uk
Thank You!
Should you have a problem
with your appliance or need any
spare parts please call our
Service Department on:
0844 984 0055
Distributed throughout the UK
by RKW ltd
