Tower Hobbies T17023 Operator's manual

T17023
2.2 Litre Air Fryer
SAFETY AND INSTRUCTION MANUAL
PLEASE READ CAREFULLY
*Subject to registering your Extended Guarantee online at www.towerhousewares.co.uk.

2
GREAT BRITISH DESIGN, INNOVATION
AND EXCELLENCE SINCE 1912
Since the turn of the 20th century, Tower has been designing,
developing and manufacturing housewares and small appliances
used by millions of households throughout the UK and beyond.
During the 1960s, the rise in popularity of pressure cooking saw
Tower become the UK’s largest producer of pressure cookers, right
through into the late 1980s. In recent years the Tower brand has
been reborn with an exciting and varied range of housewares and
electrical appliances that have quickly reinstated the brand’s richly
deserved status as a household name.
Visit
www.towerhousewares.co.uk
for more fantastic products.

3
Contents:
Thank you for purchasing this appliance from the Tower
range.
Please read this manual carefully BEFORE using the
appliance for your own safety.
It has been designed to provide many years of
trouble-free use.
There are many benets to using a Tower Air Fryer:
• Simple to use controls for cooking quick, healthy meals.
• Rapid air circulation system to cook food fast and save
energy.
• Healthy alternative to cooking deep fried food with no
oil.
• Air fried food retains its nutritional value, but still has
the taste of delicious fried food.
1. Specications
Components and
structure
2. Technical data
3. Important Safety Information
4. Before First Use
5. Using your Appliance
6. Troubleshooting
7. Cleaning & Care
8. Recycling
9. Wiring Safety
10. Warranty Information
11. Weights & Measures
12. Recipes
• Homemade Fries
• Bacon and Egg Breakfast
Mufn
• Prosciutto and Mozzarella
Sandwich
See back page for Customer
Service Information.

4
1. Timer Dial
2. Temperature Dial
3. Power Indicator
4. Air Inlet
5. Air Outlet
6. Frying Drawer
7. Handle
8. Cooking Grille
1 - Specications:
Structure of your appliance:
7
3
4
5
2
1
8
6

5
Description: 2.2 Litre Air Fryer
Model: T17023
Rated Voltage: 220-240V 50/60Hz
Power Consumption: 1000W
Documentation
We declare that this product conforms to the following product legislation in
accordance with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
1935/2004/EC Materials & Articles in Contact With Food
(LFGB section 30 & 31).
2009/125/EC Eco-Design of Energy Related Products.
RK Wholesale LTD Quality Assurance, United Kingdom.
2 - Technical Data:
Should you encounter problems or require a replacement part, contact the Tower
Customer Support Team: [phone].
Some spare parts may be ordered from the Tower website.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from www.towerhousewares.co.uk
Guarantee for spare parts:
The spares and accessories are guaranteed for 1 year from date of purchase.
The main body and housing are guaranteed for the extended free warranty subject
to registration.
If any defect arises due to faulty materials of workmanship, the faulty products must
be returned to the place of purchase within 12 months from the date of purchase.
Refund or replacement is at the discretion of the retailer.

6
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and
seek advice from the
manufacturer, its service
agent or a similarly
qualied person.
• WARNING: DO NOT let
the cord hang over the
edge of a table or counter,
serious burns may result
from the Air Fryer being
pulled off the counter
where it may be grabbed
by children or become
entangled with the user.
• DO NOT carry the
appliance by the power
cord.
• DO NOT use any
extension cord with this
appliance.
• DO NOT pull the plug out
by the cord as this may
damage the plug and/or
the cable.
• Switch off at the wall
socket then remove the
plug from the socket
when not in use or before
cleaning.
• Switch off and unplug
before tting or removing
tools/attachments, after
use and before cleaning.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Children should not play
with the appliance.
• This appliance can be
used by children aged
from 16 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any
appliance is used near
pets.
• DO NOT use this product
for anything other than its
intended use.
• This appliance is for
household use only.
Please read these notes carefully BEFORE using your
Tower appliance
3 - Important Safety Information:

7
• This appliance includes a
heating function. Please
ensure that the appliance
is used on a stable, level,
and heat resistant surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT use the
appliance outdoors.
• DO NOT place the
Air Fryer on or near
combustible materials
such as a tablecloth or
curtain.
• DO NOT place the Air
Fryer against a wall or
against other appliances.
Leave at least 10cm free
space on the back and
sides and 10cm free space
above the appliance.
• Allow the Air Fryer to
cool down for approx. 30
minutes before you handle
or clean it.
• Make sure the food
prepared in the Air Fryer
comes out golden-yellow
instead of dark brown.
Remove burnt remnants.
• During hot air frying, hot
steam is released through
the air outlet openings.
Keep your hands and face
at a safe distance from the
steam and from the air
outlet openings.
• Hot steam and air may
escape when you remove
the drawer from the Air
Fryer.
• Any baking trays or
oven dishes used in the
Air Fryer will become
hot. Always use oven
gloves when handling or
removing anything from
the Air Fryer.
• WARNING! DO NOT ll
the Air Fryer drawer with
oil as this may cause a re
hazard.
• Always put ingredients to
be fried in the drawer.
• DO NOT place anything
on top of the Air Fryer.
• Ensure that food is
completely dry before
putting it in the Air Fryer.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team:
[phone]

8
1. Remove your appliance from the packaging.
2. Check that there is no damage to the cord or any visible damage to the body.
3. Your appliance is now ready for normal use.
4. Dispose of the packaging in a responsible manner.
5. The Air Fryer uses hot air technology. Never pour oil or fat into the fryer.
4 - Before First Use

9
Automatic Switch Off:
• This Tower Air Fryer has a built in timer, which will automatically shut down the Air Fryer
when the timer reaches zero. You can manually switch off the Air Fryer by turning the
temperature and timer knob anti-clockwise to zero.
Air Fryer Drawer Safety Switch:
• For your safety, this Air Fryer contains a safety switch in the drawer designed to keep
if from accidentally turning on when the drawer is not properly situated inside the
appliance and the timer is not set. Before using the air fryer, please ensure that the
drawer is fully closed and that the cooking timer has been set.
Removing the Drawer:
• The frying drawer can be removed fully from the Air Fryer.
• Pull on the handle to slide the drawer out of the Air Fryer.
• Lift the frying drawer upwards to remove it from the fryer.
Preparing For Use:
1. Place the appliance on a stable, horizontal and even surface. Do not place the appliance
on a non-heat-resistant surface.
2. Do not ll the drawer with oil or any other liquid.
3. Pre-heat the Air Fryer for 3 minutes when it is cold. After warming up, carefully pull the
drawer out of the Air Fryer. The Air Fryer will stop heating after the drawer is pulled out.
4. Place the ingredients into the frying drawer, then place the drawer back into the Air
Fryer.
5. Select the correct timings and temperature for the ingredients. Consult the reference
table below to determine the correct temperature.
6. To start the Air Fryer, turn the timer dial to the required time.
Note: If the Air Fryer has not been pre-heated, add 3 minutes onto the required time
setting.
7. The power light and heat indicator light will come on, and the timer will begin counting
down the set cooking time.
8. During the cooking process the heat indicator light will cycle on and off as it maintains
the set temperature.
9. Some ingredients may require shaking in the drawer during cooking. Check the
reference table for additional notes on this. To shake ingredients during cooking, pull
the drawer out of the Air Fryer using the handle.
CAUTION: Do not press the button on the handle during shaking.
10. When cooking is nished, the timer bell will ring. Pull the drawer out of the Air Fryer
using the handle and place it on a heat-resistant surface.
5 - Using Your Appliance

10
11. If the food is ready, serve. To remove small ingredients (e.g. fries), pull out the drawer
by the handle, lift it out of the fryer and pour. Lift large or fragile ingredients out of the
drawer using a pair of tongs.
12. If the food is not quite cooked enough, simply put the drawer back into the Air Fryer
and set the timer for a few extra minutes.
Timer:
The Air Fryer has a 30 minute manual timer with a bell. Turn the dial to set the required cooking
time. When the cooking time has elapsed, a bell will sound to indicate that the cooking has
nished.
Settings:
The table on the next page will help you select the basic settings for a variety of common
ingredients.
Note: Keep in mind that these settings are indications, as ingredients differ in origin, size,
shape and brand. We cannot guarantee the best settings for your ingredients. Because the
Rapid Air technology instantly reheats the air inside the appliance, pulling the drawer briefly
out of the appliance during hot air frying barely disturbs the process.
Tips:
• The preparation time will depend on the size of your ingredients. Smaller sizes may
require a shorter cooking time.
• Shake the ingredients halfway through cooking time to optimise the end result. This can
help prevent unevenly fried ingredients.
• Be cautious of using greasy foods such as sausages in the Air Fryer.
• Any snacks that can be cooked in a conventional oven can also be cooked in the Air
Fryer.
• You can use your Tower Air Fryer to easily reheat food. To do this, simply set the
temperature to 150°C for up to 10 minutes.

11
Food Type Min – Max (g) Time (min) Temp (°C) Shake Remark
Thin frozen fries 100-400 9-16 200 shake
Thick frozen fries 100-400 11-12 200 shake
Homemade fries 8x8mm 100-400 10-16 200 shake Add 1/2 tbsp oil
Homemade wedges 100-400 18-22 180 shake Add 1/2 tbsp oil
Homemade potato cubes 100-350 12-18 200 shake Add 1/2 tbsp oil
Rosti 250 15-18 180 shake
Potato gratin 400 15-18 200 shake
Steak 100-400 8-12 180
Pork chops 100-400 8-12 180
Hamburger 100-400 10 -15 180
Sausage roll 100-400 13-15 200
Drumsticks 100-400 18-22 180
Chicken breast 100-400 10-15 180
Spring rolls 100-400 8-10 200 shake Use oven-ready
Frozen chicken nuggets 100-400 6-10 200 shake Use oven-ready
Frozen sh ngers 100-400 6-20 200 Use oven-ready
Frozen bread crumbed
cheese snacks 100-400 8-10 180 Use oven-ready
Stuffed vegetables 100-400 10 160
Cake 300 20-25 160 Use baking tin
Quiche 300 20-22 180 Use baking tin/oven
dish
Mufns 300 15-18 200 Use baking tin
Sweet snacks 400 20 160 Use baking tin/oven
dish
Note: The Air Fryer uses hot air heating technology. Never pour oil or fat into the fryer.
Tips:
• Try soaking your raw cut fries in cold water for 30 minutes. Dry the fries thoroughly before
putting them in the Air Fryer.
• Be careful not to overll the Air Fryer drawer with food.
• For a great, even brown crisp, toss your fries multiple times during cooking.
• Remove the fries quickly once the cooking process is complete to ensure they stay crispy
• Thinly slice and separate onions.
• Cut all vegetables into small pieces to make sure they cook properly.

12
6 - Troubleshooting
Questions Answers
How long should I leave
the Air Fryer to cool before
storing it?
We recommend leaving the Air Fryer to cool for 30-45 minutes before
storing.
My homemade fries are not
crispy enough.
Ensure that the fries are completely dry before adding oil to them and
putting them in the Air Fryer.
Try cutting the potatoes into thinner, smaller fries and adding slightly
more oil for a crispier result.
The drawer will not t in
place correctly.
You may have placed too many ingredients in the drawer. Make sure you
do not ll the drawer beyond the maximum ll line.
How big is the Air Fryer
pot? The Air Fryer pot has a 2.2 litre capacity.
My food has not cooked
uniformly.
The food may not be cut uniformly. Make sure everything is cut to the
same shape and size for even cooking.
How much cooking oil do I
need to use?
Frozen part fried foods require no added oils.
You only need to add ½ - 1 tbsp. of oil for other foods.
White smoke is coming out
of the Air Fryer.
This is normal if you are preparing greasy ingredients, because a large
amount of oil leaks into the drawer. This does not affect the appliance or
the end result.
The Air Fryer will not turn
on after it’s been plugged
in.
For your safety, this Air Fryer contains a safety switch designed to keep
it from accidentally turning on when the drawer is not properly situated
inside the appliance and when the timer is not set. Before using the Air
Fryer, please ensure that the drawer is inside of the appliance, and that
it is fully closed once the cooking timer has been set.

13
WARNING! DO NOT IMMERSE THE APPLIANCE IN WATER OR ANY OTHER LIQUID.
• Clean the appliance after every use.
1. Remove the plug from the mains socket, and allow the appliance to cool down before
cleaning.
Note: Removing the frying drawer from the Air Fryer will help the appliance cool faster.
2. Do not immerse the unit’s lid in water and ensure no water enters the appliance.
3. Clean the base unit by wiping it with a damp cloth. A little detergent can be added if the
appliance is heavily soiled.
4. Do not use scouring pads, steel wool or any form of strong solvents or abrasive cleaning
agents to clean the appliance, as they may damage the outer surfaces.
5. Clean all accessories in warm soapy water. Do not use any scouring pads, steel wool or
any strong solvents or abrasive cleaning agents when cleaning accessories.
6. To remove stubborn dirt or oil from the frying drawer, soak them in hot water with some
detergent for 10 minutes.
7. Make sure that the appliance is cleaned after every use.
Note: The pan and basket are hand-wash only. DO NOT place any part of this appliance in
the dishwasher.
IMPORTANT!
• After cleaning, allow the appliance to dry fully before using it again.
• Do not use the appliance if damp. Ensure the appliance is completely clean and dry
before storing.
To store your appliance:
• Unplug the power cord from the power outlet and clean as instructed.
• Allow the appliance to dry fully.
• Store on a at, dry level surface out of reach of children.
8 - Cleaning & Care
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your local Civic Amenity site
for recycling, once it has reached the end of its life.
7 - Recycling

14
9 - Wiring Safety for UK Use Only
IMPORTANT
As the colours in the mains lead of this
appliance may not correspond with the
coloured markings identifying the terminals
in your plug, please proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable). The
wire labelled blue is the neutral and must be
connected to the terminal marked [N].
The wire labelled brown is the live wire and
must be connected to the terminal marked
[L].
The wire labelled green/yellow must be
connected to the terminal marked with the
letter [E].
On no account must either the brown or
the blue wire be connected to the [EARTH]
terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the
same rating already tted and conforming to
BS 1362 and be ASTA approved.
If in doubt consult a qualied electrician who
will be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must
use an ASTA approved one (conforming to
BS 1362 of the same rating).
If in doubt, consult a qualied electrician
who will be pleased to do this for you.
If you need to remove the plug - disconnect
it from the mains - then cut it off of the mains
lead and immediately dispose of it in a safe
manner. Never attempt to reuse the plug
or insert it into a socket outlet as there is a
danger of an electric shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neautral
(Blue)
Live
(Brown)
WARNING:
This appliance MUST be earthed!

15
This product is guaranteed for 12 months from
the date of original purchase.
If any defect arises due to faulty materials of
workmanship, the faulty products must be
returned to the place of purchase.
Refund or replacement is at the discretion of the
retailer.
The Following Conditions Apply:
• The product must be returned to the
retailer with proof of purchase or a receipt.
• The product must be installed and
used in accordance with the instructions
contained in this instruction guide.
• It must be used only for domestic
purposes.
• It does not cover wear and tear, damage,
misuse or consumable parts.
• Tower has limited liability for incidental
or consequential loss or damage.
This guarantee is valid in the UK and Eire only.
The standard one year guarantee is only
extended to the maximum available for each
particular product upon registration of the
product within 28 days of purchase. If you do
not register the product with us within the 28
day period, your product is guaranteed for 1
year only.
To validate your extended warranty, please visit
www.towerhousewares.co.uk and register with
us online.
Please note that length of extended warranty
offered is dependent on product type and that
each qualifying product needs to be registered
individually in order to extend its warranty past
the standard 1 year.
Extended warranty is only valid with proof of
purchase or receipt.
As a thank you for purchasing
one of our fantastic products,
we are offering you an extra
2 years peace of mind in
addition to your 1 year
guarantee.
To receive your extra 2 year
guarantee, register your
appliance online within 28
days of purchase by visiting
www.towerhousewares.co.uk
10 - Warranty

16
Check these charts for basic imperial to metric conversions
of weights.
Food Allergies
Important Note: Some of the recipes contained in this document may contain nuts and/
or other allergens. Please be careful when making any of our sample recipes that you ARE
NOT allergic to any of the ingredients. For more information on allergies, please visit the
Food Standards Agency’s website at: www.food.gov.uk
11 - Weights & Measures
Metric Imperial US cups
250ml 8 oz 1 cup
180ml 6  oz 3/4 cup
150ml 5 oz 2/3 cup
120ml 4 oz 1/2 cup
75ml 2 1/2 oz 1/3 cup
60ml 2 oz 1/4 cup
30ml 1 oz 1/8 cup
15ml 1/2 oz 1 tablespoon
Imperial Metric
1/2 oz 15g
1 oz 30g
2 oz 60g
3 oz 90g
4 oz 110g
5 oz 140g
6 oz 170g
7 oz 200g
8 oz 225g
9 oz 255g
10 oz 280g
11 oz 310g
12 oz 340g
13 oz 370g
14 oz 400g
15 oz 425g
1 lb 450g

17
For more great recipes and inspiration from the
Tower Kitchen, visit
www.towerhousewares.co.uk/blog
Recipes
Recipes for use with the T17023 2.2L Air Fryer.

18
Ingredients
2 large potatoes
½ tbsp. paprika
Pinch of salt
Pinch of pepper
1 tbsp. sunower oil
Ingredients
1 free range egg
1 strip of bacon
1 English mufn
Cheese to slice
Pinch of pepper and salt to
taste
Homemade Fries
Bacon and Egg Breakfast Mufn
Method
1. Wash, peel and slice the potatoes.
2. Dry with kitchen paper.
3. Cut the potatoes into your desired length and thickness.
4. Bring a large pot of water to the boil with a pinch of salt. Add
the chips and allow to part boil for 10 minutes.
5. Strain the fries and immediately run under cold water to stop
them from cooking any more.
6. Pour the oil in a bowl, with the paprika, salt and pepper. Put the
fries on top and mix until all the fries are coated.
7. Remove the fries from the bowl with your ngers or kitchen
utensil so that the excess oil stays behind in the bowl.
8. Place the fries in the Air Fryer drawer, and then set the time and
temperature as shown on the reference table.
Variations: Try replacing ½ tbsp. of paprika with ½ tbsp. garlic powder,
or ½ tbsp. of grated parmesan cheese.
Method
1. Crack the egg into a small ramekin or oven proof dish.
2. Cut the English mufn in half and layer cheese on one half.
3. Place the mufn, bacon and egg (in the ramekin) into the Air
Fryer drawer.
4. Turn the Air Fryer to 200°C for 6 minutes.
5. Once it’s cooked, assemble your breakfast mufn and enjoy.
Tip: Try adding some mustard on the mufn for extra avour.

19
Ingredients
2 slices of bread
2 slices of prosciutto
2 slices of tomato
2 slices of mozzarella cheese
2 basil leaves
½ pinch of salt and pepper
1 tsp. of olive oil
Prosciutto and Mozzarella Sandwich
Method
1. Lay the prosciutto and mozzarella cheese on top of one slice
of bread. Add the second slice of bread on top, making a
sandwich.
2. Put the sandwich into your Air Fryer for 5 minutes at 200°C
3. Once the timer bell has rung, carefully remove the sandwich.
4. Remove the top slice of bread and drizzle the teaspoon of olive
oil over the mozzarella.
5. Add the pinch of salt and pepper to season and top with
tomato and basil.
6. Put the second slice of bread on top and serve.

thank you!
We hope you enjoy your appliance for many years. As a thank you for purchasing
one of our fantastic products, we are offering you an extra
2 years peace of mind.
*To receive your extra 2 years guarantee, register your appliance online within
28 days of purchase by visiting:
www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team on:
[phone]
0120.V7
Your warranty becomes void should you decide
to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
great british design, innovation and excellence since 1912
