TP-Link MC200CM User manual

© 2022 TP-Link 7106509775 REV4.0.2
Gigabit Ethernet Media Converter
Note: MC220L needs to be plugged in with an SFP module to work normally. It is recommended to use a TP-Link SFP module on MC220L, because other vendors’
SFP modules may be incompatible.
LC-SC Fiber Cable
Package Contents: Media Converter, Power Adapter, User Guide
Scenario 1: Connect Devices with and without Optical Interfaces
Ethernet device
with optical interfaces
Media Converter
1000Base-SX interface
Ethernet device
without optical interfaces
Gigabit Ethernet interface
Twisted-Pair Cable
Note:
1. Either two MC200CM converters or two MC210CS converters can work cooperatively. Two MC220L converters with the same SFP module can work cooperatively.
2. One MC220L can also cooperate with one MC200CM or one MC210CS. However, the mode and wavelength of the SFP module used in MC220L must be the same as the opposite end.
3. Connect the TX port of one converter to the RX port of the other using a ber cable.
Scenario 2: Connect Devices without Optical Interfaces
Fiber CableTwisted-Pair Cable Twisted-Pair Cable
Ethernet device
without optical interfaces
Media Converter Media Converter Ethernet device
without optical interfaces
Enlarge Your Ethernet Network
For technical support and other information, please visit
http://www.tp-link.com/support, or simply scan the QR code.
MC200CM/ MC210CS/ MC220L
Note: MC200CM is used as an example throughout this guide. Other models may dier in appearance.
Gigabit Ethernet interface
Gigabit Ethernet interface

LED Explanation
On: Power on.
O: Power o.
PWR
On: There is a valid link for FX Port.
O: There is no valid link for FX Port.
Flashing: FX Port is transmitting or receiving data.
Link/Act
FX
On: There is a valid link for TP Port.
O: There is no valid link for TP Port.
Flashing: TP Port is transmitting or receiving data.
Link/Act
TP
Specications
Operation Temperature 0˚C to 40˚C (32˚F to 104˚F)
Storage Temperature -40˚C to 70˚C (-40˚F to 158˚F)
Storage Humidity 5% to 90%RH non-condensing
Operation Humidity 10% to 90%RH non-condensing
Environmental and Physical Specifications
IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3zStandards
PWR, FX Link/Act, TP Link/Act
For MC200CM/MC210CS: SC ber connector, RJ-45 jack
For MC220L: SFP port, RJ-45 jack
LED
Twisted-Pair
Interface
General Specifications
External Power Adapter: 9V/0.6A
Wave Length
Fiber
Power
For MC200CM: 850nm
For MC210CS: 1310nm
For MC220L: depends on the used SFP module
For MC200CM: 62.5/125μm multi-mode ber (≤220m);
50/125μm multi-mode ber (≤550m)
For MC210CS: 9/125μm single-mode ber (≤15km)
For MC220L: depends on the used SFP module
10Base-T: 2-pair UTP/STP of Cat. 3 or above (≤100m)
100Base-TX: 2-pair UTP/STP of Cat. 5 or above (≤100m)
1000Base-T: 4-pair UTP/STP of Cat. 5e or above (≤100m)
This is a class A product. In a domestic environment, this product may cause radio interference, in which case the user
may be required to take adequate measures.
CE Mark Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
FCC STATEMENT
Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам нормативних документів
та вимогам, що передбачені чинними законодавчими актами України.
CAN ICES-3 (A)/NMB-3(A)
Industry Canada Statement
EU declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of
directives 2014/53/EU, 2009/125/EC, 2011 /65/EU and (EU) 2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/support/ce/
この装置は、クラスA情報技術装置です。この装置を家庭環境で使用すると電波妨害を引き起こすことがあります。この場
合には使用者が適切な対策を講ずるよう要求されることがあります。 VCCI-A
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Adapter shall be installed near the equipment and shall be easily accessible.
Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning.
Do not point or stare directly into the beam or into the optical port of the transceiver when it is operating, as this can injure
your eyesight.
BSMI Notice
安全諮詢及注意事項
請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。
清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。
注意防潮，請勿將水或其他液體潑灑到本產品上。
插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。
請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。
請不要私自打開機殼，不要嘗試自行維修本產品，請由授權的專業人士進行此項工作。
為避免電磁干擾，本產品不應安裝或使用於住宅環境。
限用物質含有情況標示聲明書
產品元件名稱
PCB
外殼
產品元件名稱
PCB
外殼
電源適配器
限用物質及其化學符號
備考1："○"系指該項限用物質之百分比含量未超出百分比含量基準值。
備考2："—" 系指該項限用物質為排除項目。
鉛
Pb
○
○
—
鎘
Cd
○
○
○
汞
Hg
○
○
○
六價鉻
CrVI
○
○
○
多溴聯苯
PBB
○
○
○
多 溴二苯醚
PBDE
○
○
○
UK declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the
Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016.
The original UK declaration of conformity may be found at https://www.tp-link.com/support/ukca/
Explanation of the symbols on the product label
DC voltage
Indoor use only
RECYCLING
This product bears the selective sorting symbol for Waste electrical and electronic equipment
(WEEE). This means that this product must be handled pursuant to European directive
2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment.
User has the choice to give his product to a competent recycling organization or to the retailer
when he buys a new electrical or electronic equipment.
Polarity of output terminals
Class II equipment
Caution
Operator’s manual
AC voltage
