TP-Link JetStream TL-SG2008 User manual

TL-SG2008
8-Port Gigabit Smart Switch
REV1.0.0
1910010984

I
COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice. is a registered trademark of
TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or
registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from TP-LINK
TECHNOLOGIES CO., LTD. Copyright © 2014 TP-LINK TECHNOLOGIES CO., LTD. All rights
reserved.
http://www.tp-link.com
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may cause
undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
CE Mark Warning
This is a class A product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
Продукт сертифіковано згідно справилами системи УкрСЕПРО на відповідність вимогам
нормативних документів та вимогам, що передбачені чинними законодавчими актами
України.

II
Safety Information
zWhen product has power button, the power button is one of the way to shut off the product;
When there is no power button, the only way to completely shut off power is to disconnect the
product or the power adapter from the power source.
zDon’t disassemble the product, or make repairs yourself. You run the risk of electric shock
and voiding the limited warranty. If you need service, please contact us.
zAvoid water and wet locations.
This product can be used in the following countries:
AT BG BY CA CZ DE DK EE
ES FI FR GB GR HU IE IT
LT LV MT NL NO PL PT RO
RU SE SK TR UA

III
CONTENTS
Package Contents..........................................................................................................................1
Chapter 1 About this Guide...........................................................................................................2
1.1 Intended Readers .........................................................................................................2
1.2 Conventions..................................................................................................................2
1.3 Overview of This Guide ................................................................................................2
Chapter 2 Introduction ..................................................................................................................5
2.1 Overview of the Switch .................................................................................................5
2.2 Main Features...............................................................................................................5
2.3 Appearance Description ...............................................................................................5
2.3.1 Front Panel ........................................................................................................5
2.3.2 Rear Panel .........................................................................................................6
Chapter 3 Login to the Switch.......................................................................................................7
3.1 Login.............................................................................................................................7
3.2 Configuration ................................................................................................................7
Chapter 4 System .........................................................................................................................9
4.1 System Info...................................................................................................................9
4.1.1 System Summary...............................................................................................9
4.1.2 Device Description ...........................................................................................10
4.1.3 System Time .................................................................................................... 11
4.1.4 Daylight Saving Time .......................................................................................12
4.1.5 System IP.........................................................................................................13
4.2 User Management ......................................................................................................14
4.2.1 User Table........................................................................................................14
4.2.2 User Config ......................................................................................................15
4.3 System Tools ..............................................................................................................16
4.3.1 Config Restore .................................................................................................16
4.3.2 Config Backup..................................................................................................17
4.3.3 Firmware Upgrade ...........................................................................................17
4.3.4 System Reboot ................................................................................................18
4.3.5 System Reset...................................................................................................18
4.4 Access Security ..........................................................................................................19
4.4.1 Access Control.................................................................................................19
4.4.2 SSL Config.......................................................................................................20
4.4.3 SSH Config ......................................................................................................22
Chapter 5 Switching....................................................................................................................28
5.1 Port .............................................................................................................................28

IV
5.1.1 Port Config .......................................................................................................28
5.1.2 Port Mirror ........................................................................................................29
5.1.3 Port Security ....................................................................................................31
5.1.4 Port Isolation ....................................................................................................32
5.1.5 Loopback Detection .........................................................................................33
5.2 LAG ............................................................................................................................34
5.2.1 LAG Table ........................................................................................................35
5.2.2 Static LAG ........................................................................................................36
5.2.3 LACP Config ....................................................................................................37
5.3 Traffic Monitor .............................................................................................................39
5.3.1 Traffic Summary...............................................................................................39
5.3.2 Traffic Statistics ................................................................................................40
5.4 MAC Address..............................................................................................................41
5.4.1 Address Table ..................................................................................................42
5.4.2 Static Address ..................................................................................................43
5.4.3 Dynamic Address .............................................................................................44
5.4.4 Filtering Address ..............................................................................................46
5.5 DHCP Filtering............................................................................................................47
Chapter 6 VLAN..........................................................................................................................51
6.1 802.1Q VLAN..............................................................................................................52
6.1.1 VLAN Config ....................................................................................................53
6.2 Application Example for 802.1Q VLAN .......................................................................55
Chapter 7 Spanning Tree ............................................................................................................57
7.1 STP Config .................................................................................................................62
7.1.1 STP Config.......................................................................................................62
7.1.2 STP Summary..................................................................................................64
7.2 Port Config..................................................................................................................64
7.3 MSTP Instance ...........................................................................................................66
7.3.1 Region Config ..................................................................................................66
7.3.2 Instance Config ................................................................................................66
7.3.3 Instance Port Config.........................................................................................68
7.4 STP Security...............................................................................................................69
7.4.1 Port Protect ......................................................................................................69
7.4.2 TC Protect........................................................................................................71
7.5 Application Example for STP Function .......................................................................72
Chapter 8 Multicast.....................................................................................................................76
8.1 IGMP Snooping ..........................................................................................................78

V
8.1.1 Snooping Config ..............................................................................................79
8.1.2 Port Config .......................................................................................................80
8.1.3 VLAN Config ....................................................................................................81
8.1.4 Multicast VLAN ................................................................................................82
8.2 Multicast IP .................................................................................................................85
8.2.1 Multicast IP Table .............................................................................................85
8.2.2 Static Multicast IP.............................................................................................86
8.3 Multicast Filter.............................................................................................................87
8.3.1 IP-Range..........................................................................................................88
8.3.2 Port Filter .........................................................................................................88
8.4 Packet Statistics..........................................................................................................90
Chapter 9 QoS............................................................................................................................92
9.1 DiffServ.......................................................................................................................95
9.1.1 Port Priority ......................................................................................................95
9.1.2 802.1P/CoS Mapping.......................................................................................96
9.1.3 DSCP Priority...................................................................................................97
9.1.4 Schedule Mode ................................................................................................98
9.2 Bandwidth Control ......................................................................................................99
9.2.1 Rate Limit.........................................................................................................99
9.2.2 Storm Control .................................................................................................100
9.3 Voice VLAN ..............................................................................................................101
9.3.1 Global Config .................................................................................................103
9.3.2 Port Config .....................................................................................................104
9.3.3 OUI Config .....................................................................................................105
Chapter 10 ACL ..........................................................................................................................107
10.1 ACL Config ...............................................................................................................107
10.1.1 ACL Summary................................................................................................107
10.1.2 ACL Create ....................................................................................................107
10.1.3 MAC ACL .......................................................................................................108
10.1.4 Standard-IP ACL ............................................................................................109
10.1.5 Extend-IP ACL ...............................................................................................109
10.2 Policy Config............................................................................................................. 110
10.2.1 Policy Summary ............................................................................................. 110
10.2.2 Policy Create.................................................................................................. 111
10.2.3 Action Create ................................................................................................. 111
10.3 Policy Binding ........................................................................................................... 112
10.3.1 Binding Table ................................................................................................. 112

VI
10.3.2 Port Binding ................................................................................................... 113
10.3.3 VLAN Binding................................................................................................. 113
10.4 Application Example for ACL .................................................................................... 114
Chapter 11 SNMP....................................................................................................................... 117
11.1 SNMP Config ............................................................................................................ 119
11.1.1 Global Config ................................................................................................. 119
11.1.2 SNMP View....................................................................................................120
11.1.3 SNMP Group..................................................................................................120
11.1.4 SNMP User ....................................................................................................122
11.1.5 SNMP Community..........................................................................................124
11.2 Notification................................................................................................................126
11.3 RMON.......................................................................................................................127
11.3.1 History Control ...............................................................................................128
11.3.2 Event Config ..................................................................................................129
11.3.3 Alarm Config ..................................................................................................129
Chapter 12 Maintenance ............................................................................................................132
12.1 System Monitor.........................................................................................................132
12.1.1 CPU Monitor ..................................................................................................132
12.1.2 Memory Monitor .............................................................................................133
12.2 Log............................................................................................................................133
12.2.1 Log Table .......................................................................................................134
12.2.2 Local Log .......................................................................................................135
12.2.3 Remote Log ...................................................................................................136
12.2.4 Backup Log ....................................................................................................136
12.3 Device Diagnostics ...................................................................................................137
12.3.1 Cable Test ......................................................................................................137
12.3.2 Loopback.......................................................................................................138
12.4 Network Diagnostics .................................................................................................138
12.4.1 Ping................................................................................................................139
12.4.2 Tracert............................................................................................................139
Appendix A: Specifications .........................................................................................................141
Appendix B: Configuring the PCs ...............................................................................................142
Appendix C: Glossary.................................................................................................................144

1
Package Contents
The following items should be found in your box:
¾One TL-SG2008 8-Port Gigabit Smart Switch
¾One power adapter
¾Four rubber cushions
¾Quick Installation Guide
¾Resource CD for TL-SG2008 switch, including:
•This User Guide
•Other Helpful Information
Note:
Make sure that the package contains the above items. If any of the listed items are damaged or
missing, please contact your distributor.

2
Chapter 1 About this Guide
This User Guide contains information for setup and management of TL-SG2008 8-Port Gigabit
Smart Switch. Please read this guide carefully before operation.
1.1 Intended Readers
This Guide is intended for network managers familiar with IT concepts and network terminologies.
1.2 Conventions
In this Guide the following conventions are used:
¾The switch or TL-SG2008 mentioned in this Guide stands for TL-SG2008 8-Port Gigabit
Smart Switch without any explanation.
¾Menu Name→Submenu Name→Tab page indicates the menu structure. System→System
Info→System Summary means the System Summary page under the System Info menu
option that is located under the System menu.
¾Bold font indicates a button, a toolbar icon, menu or menu item.
Symbols in this Guide：
Symbol Description
Note: Ignoring this type of note might result in a malfunction or damage to the device.
Tips:
This format indicates important information that helps you make better use of
your device.
1.3 Overview of This Guide
Chapter Introduction
Chapter 1 About This Guide Introduces the guide structure and conventions.
Chapter 2 Introduction Introduces the features, application and appearance of
TL-SG2008 switch.
Chapter 3 Login to the Switch Introduces how to log on to the Web management page.

3
Chapter Introduction
Chapter 4 System This module is used to configure system properties of the
switch. Here mainly introduces:
zSystem Info: Configure the description, system time and
network parameters of the switch.
zUser Management: Configure the user name and password
for users to log on to the Web management page with a
certain access level.
zSystem Tools: Manage the configuration file of the switch.
zAccess Security: Provide different security measures for the
login to enhance the configuration management security.
Chapter 5 Switching This module is used to configure basic functions of the switch.
Here mainly introduces:
zPort: Configure the basic features for the port.
zLAG: Configure Link Aggregation Group. LAG is to combine a
number of ports together to make a single high-bandwidth
data path.
zTraffic Monitor: Monitor the traffic of each port.
zMAC Address: Configure the address table of the switch.
zDHCP Filtering: Monitor the process of the host obtaining the
IP address from DHCP server.
Chapter 6 VLAN This module is used to configure VLANs to control broadcast in
LANs. Here mainly introduces:
z802.1Q VLAN: Configure port-based VLAN.
Chapter 7 Spanning Tree This module is used to configure spanning tree function of the
switch. Here mainly introduces:
zSTP Config: Configure and view the global settings of
spanning tree function.
zPort Config: Configure CIST parameters of ports.
zMSTP Instance: Configure MSTP instances.
zSTP Security: Configure protection function to prevent
devices from any malicious attack against STP features.
Chapter 8 Multicast This module is used to configure multicast function of the switch.
Here mainly introduces:
zIGMP Snooping: Configure global parameters of IGMP
Snooping function, port properties, VLAN and multicast
VLAN.
zMulticast IP: Configure multicast IP table.
zMulticast Filter: Configure multicast filter feature to restrict
users ordering multicast programs.
zPacket Statistics: View the multicast data traffic on each port
of the switch, which facilitates you to monitor the IGMP
messages in the network.

4
Chapter Introduction
Chapter 9 QoS This module is used to configure QoS function to provide
different quality of service for various network applications and
requirements. Here mainly introduces:
zDiffServ: Configure priorities, port priority, 802.1P priority and
DSCP priority.
zBandwidth Control: Configure rate limit feature to control the
traffic rate on each port; configure storm control feature to
filter broadcast, multicast and UL frame in the network.
zVoice VLAN: Configure voice VLAN to transmit voice data
stream within the specified VLAN so as to ensure the
transmission priority of voice data stream and voice quality.
Chapter 10 ACL This module is used to configure match rules and process
policies of packets to filter packets in order to control the access
of the illegal users to the network. Here mainly introduces:
zACL Config: ACL rules.
zPolicy Config: Configure operation policies.
zPolicy Binding: Bind the policy to a port/VLAN to take its
effect on a specific port/VLAN.
Chapter 11 SNMP This module is used to configure SNMP function to provide a
management frame to monitor and maintain the network
devices. Here mainly introduces:
zSNMP Config: Configure global settings of SNMP function.
zNotification: Configure notification function for the
management station to monitor and process the events.
zRMON: Configure RMON function to monitor network more
efficiently.
Chapter 12 Maintenance This module is used to assemble the commonly used system
tools to manage the switch. Here mainly introduces:
zSystem Monitor: Monitor the memory and CPU of the switch.
zLog: View configuration parameters on the switch.
zDevice Diagnostics: Test the connection status of the cable
connected to the switch, test if the port of the switch and the
connected device are available.
zNetwork Diagnostics: Test if the destination is reachable and
the account of router hops from the switch to the destination.
Appendix A Specifications Lists the hardware specifications of the switch.
Appendix B Configure the PCs Introduces how to configure the PCs.
Appendix C Glossary Lists the glossary used in this manual.
Return to CONTENTS

5
Chapter 2 Introduction
Thanks for choosing the TL-SG2008 8-Port Gigabit Smart Switch!
2.1 Overview of the Switch
Designed for workgroups and departments, TL-SG2008 from TP-LINK provides wire-speed
performance and full set of layer 2 management features. It provides a variety of service features
and multiple powerful functions with high security.
The EIA-standardized framework and smart configuration capacity can provide flexible solutions
for a variable scale of networks. QoS and IGMP snooping/filtering optimize voice and video
application. Link aggregation (LACP) increase aggregated bandwidth, optimizing the transport of
business critical data. SNMP, RMON, WEB/Telnet Log-in bring abundant management policies.
TL-SG2008 switch integrates multiple functions with excellent performance, and is friendly to
manage, which can fully meet the need of the users demanding higher networking performance.
2.2 Main Features
•Resiliency and Availability
+ IEEE 802.1s Multiple Spanning Tree provides high link availability in multiple VLAN
environments.
+ Multicast snooping automatically prevents flooding of IP multicast traffic.
+ Root Guard protects root bridge from malicious attack or configuration mistakes
•Layer 2 Switching
+ Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs).
•Quality of Service
+ Supports L2/L3 granular CoS with 4 priority queues per port.
+ Rate limiting confines the traffic flow accurately according to the preset value.
•Manageability
+ Supports Telnet, SNMP v1/v2c/v3, RMON and web access.
+ Port Mirroring enables monitoring selected ingress/egress traffic.
2.3 Appearance Description
2.3.1 Front Panel
The front panel of TL-SG2008 is shown as Figure 2-1.
Figure 2-1 Front Panel of TL-SG2008

6
The following parts are located on the front panel of the switch:
¾Reset: Press this button for five seconds or above to reset the software setting back to factory
default setting.
¾LEDs
Name Status Indication
On(Green) The switch is powered on.
Power
Flashing/Off The switch is powered off or power supply is abnormal.
Flashing The switch is working normally.
System
On/Off The switch is working abnormally.
On A 1000Mbps device is connected to the corresponding port, but
no activity.
Green
Flashing Data is being transmitted or received.
On A 10/100Mbps device is connected to the corresponding port, but
no activity.
Link/Act
Yellow
Flashing Data is being transmitted or received.
2.3.2 Rear Panel
The rear panel of TL-SG2008 features a power socket and eight ports. Its rear panel is shown as
the following figure.
Figure 2-2 Rear Panel of TL-SG2008
¾1000Mbps Ports: Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or
1000Mbps. Each has a corresponding LED on the front panel.
¾Power Socket: Connect the female connector of the power cord here, and the male connector
to the DC power outlet. Please make sure the voltage of the power supply meets the
requirement of the input voltage (12V/1A for TL-SG2008).
Return to CONTENTS

7
Chapter 3 Login to the Switch
3.1 Login
1) To access the configuration utility, open a web-browser and type in the default address
http://192.168.0.1 in the address field of the browser, then press the Enter key.
Figure 3-1 Web-browser
Tips:
To log in to the switch, the IP address of your PC should be set in the same subnet addresses of
the switch. The IP address is 192.168.0.x ("x" is any number from 2 to 254), Subnet Mask is
255.255.255.0. For the detailed instructions as to how to do this, please refer to Appendix B.
2) After a moment, a login window will appear, as shown in Figure 3-2. Enter admin for the User
Name and Password, both in lower case letters. Then click the Login button or press the Enter
key.
Figure 3-2 Login
3.2 Configuration
After a successful login, the main page will appear as Figure 3-3, and you can configure the
function by clicking the setup menu on the left side of the screen.

8
Figure 3-3 Main Setup-Menu
Note:
Clicking Apply can only make the new configurations effective before the switch is rebooted. If
you want to keep the configurations effective even the switch is rebooted, please click Save
Config. You are suggested to click Save Config before cutting off the power or rebooting the
switch to avoid losing the new configurations.
Return to CONTENTS

9
Chapter 4 System
The System module is mainly for system configuration of the switch, including four submenus:
System Info, User Management, System Tools and Access Security.
4.1 System Info
The System Info, mainly for basic properties configuration, can be implemented on System
Summary, Device Description, System Time,Daylight Saving Time and System IP pages.
4.1.1 System Summary
On this page you can view the port connection status and the system information.
The port status diagram shows the working status of 8 1000Mbps RJ45 ports of the switch.
Choose the menu System→System Info→System Summary to load the following page.
Figure 4-1 System Summary
¾Port Status
Indicates the corresponding port is not connected to a device.
Indicates the corresponding port is at the speed of 1000Mbps.
Indicates the corresponding port is at the speed of 10/100Mbps.
When the cursor moves on the port, the detailed information of the port will be displayed.

10
Figure 4-2 Port Information
¾Port Info
Port: Displays the port number of the switch.
Type: Displays the type of the port.
Rate: Displays the maximum transmission rate of the port.
Status: Displays the connection status of the port.
Click a port to display the bandwidth utilization on this port. The actual rate divided by theoretical
maximum rate is the bandwidth utilization. The following figure displays the bandwidth utilization
monitored every four seconds. Monitoring the bandwidth utilization on each port facilitates you to
monitor the network traffic and analyze the network abnormities.
Figure 4-3 Bandwidth Utilization
¾Bandwidth Utilization
Rx: Select Rx to display the bandwidth utilization of receiving packets
on this port.
Tx: Select Tx to display the bandwidth utilization of sending packets
on this port.
4.1.2 Device Description
On this page you can configure the description of the switch, including device name, device location
and system contact.
Choose the menu System→System Info→Device Description to load the following page.

11
Figure 4-4 Device Description
The following entries are displayed on this screen:
¾Device Description
Device Name: Enter the name of the switch.
Device Location: Enter the location of the switch.
System Contact: Enter your contact information.
4.1.3 System Time
System Time is the time displayed while the switch is running. On this page you can configure the
system time and the settings here will be used for other time-based functions.
You can manually set the system time or synchronize with PC’s clock as the system time.
Choose the menu System→System Info→System Time to load the following page.
Figure 4-5 System Time
The following entries are displayed on this screen:
¾Time Info
Current System Date: Displays the current date and time of the switch.
Current Time Source: Displays the current time source of the switch.

12
¾Time Config
Manual: When this option is selected, you can set the date and time
manually.
Get Time from NTP
Server:
When this option is selected, you can configure the time zone
and the IP Address for the NTP Server. The switch will get UTC
automatically if it has connected to an NTP Server.
zTime Zone: Select your local time.
zPrimary/Secondary NTP Server: Enter the IP Address for
the NTP Server.
zUpdate Rate: Specify the rate fetching time from NTP server.
Synchronize with
PC’S Clock:
When this option is selected, the administrator PC’s clock is
utilized.
Note:
1. The system time will be restored to the default when the switch is restarted and you need to
reconfigure the system time of the switch.
2. When Get Time from NTP Server is selected and no time server is configured, the switch will
get time from the time server of the Internet if it has connected to the Internet.
4.1.4 Daylight Saving Time
Here you can configure the Daylight Saving Time of the switch.
Choose the menu System→System Info→Daylight Saving Time to load the following page.
Figure 4-6 Daylight Saving Time
The following entries are displayed on this screen:
¾DST Config
DST Status: Enable or disable the DST.

13
Predefined Mode: Select a predefined DST configuration.
zUSA: Second Sunday in March, 02:00 ~ First Sunday in
November, 02:00.
zAustralia: First Sunday in October, 02:00 ~ First Sunday in
April, 03:00.
zEurope: Last Sunday in March, 01:00 ~ Last Sunday in
October, 01:00.
zNew Zealand: Last Sunday in September, 02:00 ~ First
Sunday in April, 03:00.
Recurring Mode: Specify the DST configuration in recurring mode. This
configuration is recurring in use.
zOffset: Specify the time adding in minutes when Daylight
Saving Time comes.
zStart/End Time: Select starting time and ending time of
Daylight Saving Time.
Date Mode: Specify the DST configuration in Date mode. This configuration is
recurring in use.
zOffset: Specify the time adding in minutes when Daylight
Saving Time comes.
zStart/End Time: Select starting time and ending time of
Daylight Saving Time.
Note:
1. When the DST is disabled, the predefined mode, recurring mode and date mode cannot be
configured.
2. When the DST is enabled, the default daylight saving time is of Europe in predefined mode.
4.1.5 System IP
Each device in the network possesses a unique IP Address. You can log on to the Web
management page to operate the switch using this IP Address. The switch supports three modes
to obtain an IP address: Static IP, DHCP and BOOTP. The IP address obtained using a new mode
will replace the original IP address. On this page you can configure the system IP of the switch.
Choose the menu System→System Info→System IP to load the following page.
Figure 4-7 System IP
The following entries are displayed on this screen:
