TP-Link TL-SG2424P User manual

The TL-SG2424P provides 24 10/100/1000Mbps ports that supports 802.3at/af-compliant
PoE , with a total PoE power supply up to 180W, powerful and exible enough for users to
deploy wireless access points or IP-based network surveillance cameras. The switch also
comes equipped with 4 combo SFP slots, expanding your network exibly. In addition, it
provides high performance, enterprise-level QoS, useful security strategies and rich layer 2
management features. With all these advanced features, the Gigabit Smart PoE Switch is an
ideal choice for small and medium business networking.
TL-SG2424P has useful security features. The Storm Control feature protects against
Broadcast, Multicast and Unknown unicast Storm. Quality of Service (QoS, L2 to L4) provides
enhanced trac management capabilities to move your data smoother and faster.
Anymore, the easy-to-use web management interfaces, along with CLI, SNMP and RMON,
mean faster setup and conguration with less downtime. For workgroup and departments
requiring cost-sensitive layer 2 switch and gigabit capability, TP-LINK Gigabit Smart PoE
Switch TL-SG2424P provides you the ideal access-edge solution.
Overview
Datasheet
www.tp-link.com Copyright © 2013 TP-LINK Technologies Co., Ltd. All rights reserved.
TL-SG2424P
24-Port Gigabit Smart PoE Switch
with 4 Combo SFP Slots
TP-LINK
Power Budget

TL-SG2424P
24-Port Gigabit Smart PoE Switch
with 4 Combo SFP Slots
IEEE 802.3at/af-compliant Power over Ethernet
The TL-SG2424P supports 24 ports of IEEE 802.3at/af-compliant PoE and has a total power supply of 180W
to power any 802.3at or 802.3af compliant power device. It’s an ecient and cost-eective choice to work
with wireless access points, surveillance cameras, IP phones and other PoE supported devices, while
getting rid of cables or power lines running around. Compact and exible, the TL-SG2424P is ideal to
exibly use PoE to deploy wireless access points or IP-based network surveillance cameras for projects or
small business networks.
Advanced QoS features
To integrate voice, data and video service on one network, the switch applies rich QoS policies.
Administrator can designate the priority of the trac based on a variety of means including Port Priority,
802.1P Priority and DSCP Priority, to ensure that voice and video are always clear, smooth and jitter free.
Abundant Layer 2 features
For more application of layer 2 switches, TL-SG2424P provides comprehensive layer 2 features, including
802.1Q tag VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol and 802.3x Flow
Control function. Any more, the switch provides advanced features for network maintenance. Such as
Loop Back Detection, Cable Diagnostics and IGMP Snooping. IGMP snooping ensures the switch intelligently
forward the multicast stream only to the appropriate subscribers while IGMP throttling & ltering restrict
each subscriber on a port level to prevent unauthorized multicast access.
Enterprise Level Management Features
TL-SG2424P is easy to use and manage. It supports various user-friendly standard management features,
such as intuitive web-based Graphical User Interface(GUI) or industry-standard Command Line Interface
(CLI), SNMP (v1/2/3) and RMON support enables the switch to be polled for valuable status information
and send traps on abnormal events.
Layer 2 Features
Link Aggregation Control
Protocol (LACP)
512 VLANs
STP/RSTP/MSTP
IGMP Snooping
LLDP (LLDP-MED)
Security Strategies
Access Control List(L2~L4 ACL)
Storm Control
Port Security
SSL and SSH encryptions
Quality of Service
4 priority queues
IEEE 802.1P
DSCP QoS
Management
Web-based GUI
Command Line Interface
SNMP v1/v2c/v3
RMON (1, 2, 3, 9 group)
Datasheet
www.tp-link.com Copyright © 2013 TP-LINK Technologies Co., Ltd. All rights reserved.
24 / 7
Global technical support
Details:http://www.tp-link.com/
support/Localesupport.asp
German/Austrian/Swiss users are
not included
24-Port Gigabit Smart PoE Switch
PoE Features
Standard: 802.3at/af compliant with
up to 30W per port
PoE+ Ports: 24 Ports
Power Supply: 180W
PoE Schedule (Time-based Settings)

www.tp-link.com Copyright © 2013 TP-LINK Technologies Co., Ltd. All rights reserved.
Specifications
Datasheet
TL-SG2424P
24
4
100-240VAC, 50/60Hz
3
CE, FCC
Standard: 802.3at/af compliant
PoE Ports: 24 Ports
PoE Power Supply: 180W
17.3 × 13 × 1.7 in. (440 × 330 × 44 mm)
19-inch Rack mount Steel Case, 1U Height
48Gbps
35.7Mpps
8k
10KB
Product Picture
Model
Hardware Features
Connector
Power Supply
FAN Quantity
Certications
PoE Features
Dimensions (W × D × H)
Environment
Performance
Switch Capacity
Forwarding Rate
MAC Address Table
Jumbo Frame
Hardware Features & Performance
Software Features
10/100/1000Mbps
Base-T Ports
Combo
100/1000Mbps
SFP slots*
Operating Temperature: 0°C~40°C (32°F~104°F), Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing, Storage Humidity: 5%~90% non-condensing
TL-SG2424P
L2 Switching Features
Link Aggregation
– Support 802.3ad LACP
– Support static link aggregation
– Up to 6 aggregation groups, containing 4 ports per
group
Spanning Tree Protocol(STP)
– IEEE 802.1D Spanning Tree Protocol
– IEEE 802.1W Rapid Spanning Tree Protocol
– IEEE 802.1S Multiple Spanning Tree Protocol
– STP Security: Loop back detection, TC Protect, BPDU
Filter/Protect, Root Protect
Multicast
– Support IGMP Snooping V1/V2/V3, up to 256 groups
– Support multicast VLANs, IGMP Immediate Leave,
Unknown IGMP Throttling, IGMP Filtering, Static
Multicast IP
VLAN
– Support IEEE802.1Q with 512 VLANs simultaneously
(out of 4K VIDs)
IEEE 802.3x ow control for Full Duplex mode and
backpressure for Half Duplex mode

www.tp-link.com Copyright © 2013 TP-LINK Technologies Co., Ltd. All rights reserved.
Datasheet
Ordering Information
Host Switch
Product Model
TL-SG2424P
SFP Modules
Product Model
TL-SM311LS
TL-SM311LM
TL-SM321A
TL-SM321B
Description
24-Port Gigabit Smart PoE Switch with 4 Combo SFP Slots
Description
Gigabit SFP module, Single-mode, LC interface, Up to 10km distance
Gigabit SFP module, Multi-mode, LC interface, Up to 550m distance
Gigabit WDM Bi-Directional SFP Module, single-mode, LC connector, TX:1550nm/RX:1310nm, 10km
Gigabit WDM Bi-Directional SFP Module, single-mode, LC connector, TX:1310nm/RX:1550nm, 10km
Quality of Service (QoS)
Support 802.1p CoS/DSCP priority
Support 4 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow- based Rate Limiting
Voice VLAN assure voice applications much smoother
performance
Advanced Security Strategies
Support Broadcast, Multicast and Unknown unicast Storm
Control
Static/Dynamic Port Security (MAC-based)
Access Control List (ACL)
- L2~L4 package ltering based on source and destination
MAC address, IP address, TCP/UDP Ports
- Time based ACL
Secure web management through HTTPS and
SSLv2/v3/TLSv1
Secure remote command line interface(CLI)
management with SSH v1/v2
Management
Support Web-based GUI management mode
Support Command Line Interface(CLI) through telnet
management mode
SNMP v1/v2c/v3
RMON (1, 2, 3, 9 groups)
DHCP/BOOTP Client
DHCP Filtering
CPU Monitoring
Port Mirroring (Many to One)
Cable Diagnostics feature
Ping/Tracert feature
SNTP
System Log
Ethernet Protocols
IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-TX/FX
IEEE 802.3ab 1000BASE-T
IEEE 802.3z 1000BASE-X
IEEE 802.3ad Link Aggregation
IEEE 802.3x Flow control
IEEE 802.1p QoS
IEEE 802.1q VLANs / VLAN tagging
IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1W Rapid Spanning Tree (RSTP)
IEEE 802.1S Multiple Spanning Tree (MSTP)
MIBs
MIB II (RFC1213)
Interface MIB (RFC2233)
Ethernet Interface MIB (RFC1643)
Bridge MIB (RFC1493)
P/Q-Bridge MIB (RFC2674)
RMON MIB (RFC2819)
RMON2 MIB (RFC2021)
Remote Ping, Traceroute MIB (RFC2925)
Support TP-LINK private MIBs

www.tp-link.com Copyright © 2013 TP-LINK Technologies Co., Ltd. All rights reserved.
Datasheet
* The switch supports 100/1000Mbps SFP module at full-duplex mode. When using the SFP port with a 100M module or a gigabit
module, you need to congure its corresponding Speed and Duplex mode through rmware.
By factory default, the Speed and Duplex mode of SFP port is 1000Mbps Full-duplex.
Media Converter
Product Model
MC210CS
MC200CM
MC220L
MC1400
Description
Gigabit single-mode SC SFP Transceiver, up to 15Km, chassis mountable
Gigabit multi-mode SC SFP Transceiver, up to 550m, chassis mountable
Gigabit SFP slot supporting mini-GBIC modules, chassis mountable
14-slot power supply chassis for TP-LINK Media Converter, 19-inch rack-mountable
