TP-Link TL-SG1016D User manual

User Guide
TL-SG1008
8-Port Gigabit Switch
TL-SG1016D
16-Port Gigabit Switch
TL-SG1024D
24-Port Gigabit Switch
Rev: 2.0.1
7106503502

I
COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice . is a registered
trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names
are trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or
used to make any derivative such as translation, transformation, or adaptation
without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2011
TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.
http://www.tp-link.com

II
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
CE Mark Warning
This is a class A product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
Note:
As for TL-SG1008, a fuse resistor is used in the “F1” position on the PCB of the power
module. The fuse resistor should be used with the following type: 10ohm 2W@25℃.

III
CONTENTS
Package Contents..................................................................................................................... 1
Chapter 1 Product Introduction ............................................................................................. 2
1.1 Product Overview............................................................................................... 2
1.2 Features ................................................................................................................ 2
Chapter 2 Identifying External Components....................................................................... 3
2.1 Front Panel............................................................................................................. 3
2.2 Rear Panel ............................................................................................................. 3
Chapter 3 Installation .............................................................................................................. 4
3.1 Precautions ............................................................................................................ 4
3.2 Installation .............................................................................................................. 4
3.2.1 Desktop Installation ...................................................................................... 5
3.2.2 Rack Installation............................................................................................ 5
3.3 Connect to Ground ............................................................................................... 7
3.4 Power on ................................................................................................................ 8
Appendix A: Specifications ................................................................................................... 9
Appendix B: Troubleshooting..............................................................................................11
Appendix C: Contact Information .......................................................................................11

1
Package Contents
The following contents should be found in your package:
¾One TL-SG1008/TL-SG1016D/TL-SG1024D Switch
¾One power cord
¾This User Guide
¾Rubber footpads for Desk-mount
¾Mounting screws and two “L” planks
Note:
Make sure that the package contains the above items. If any of the listed items are
damaged or missing, please contact with your distributor. TL-SG1016D and
TL-SG1024D do not include mounting screws and two “L” planks.

2
Chapter 1 Product Introduction
This chapter describes the features of the TL-SG1008/TL-SG1016D/TL-SG1024D
Switch.
1.1 Product Overview
The TL-SG1008/TL-SG1016D/TL-SG1024D Switch provides you with a high-
performance, low-cost, easy-to-use, seamless and standard upgrade to boost your
old network to 1000Mbps. Increase the speed of your network server and
backbone connections make Gigabit a reality. Power users in the home, office,
workgroup, or creative production environment can now move large, bandwidth-
intensive files faster. Transfer graphics, CGI, CAD, or multimedia files and other
applications that have to move large files across the network almost instantly.
The TL-SG1008/TL-SG1016D/TL-SG1024D Switch features a non-blocking
switching architecture that forwards and filters packets at full wire-speed for
maximum throughput, MAC address auto-learning and auto-aging, IEEE802.3x
flow control for full-duplex mode and backpressure for half-duplex mode. It is
compatible with all 10,100 and 1000Mbps Ethernet devices because it is
standard-based. It protects your existing network investments while providing you
with a straightforward migration path to faster Gigabit speeds.
The TL-SG1008/TL-SG1016D/TL-SG1024D Switch is plug-and-play and no
configuration is required. Auto MDI/MDI-X cable detection on all ports eliminate the
need for crossover cable or Uplink port. Each port can be used as general ports or
Uplink ports, and any port can be simply plugged into a server, a hub, a router or a
switch, using the straight cable or crossover cable. Diagnostic LEDs which display
link status and activity, allowing you to quickly detect and correct problems on the
network.
1.2 Features
¾Complies with IEEE802.3, IEEE802.3u, IEEE802.3ab standards
¾8/16/24 10/100/1000Mbps Auto-Sense RJ45 ports supporting Auto-MDI/MDIX
¾All ports Support Full/Half Duplex transfer mode for 10/100Mbps and Full
Duplex transfer mode for 1000Mbps
¾Supports IEEE802.3x flow control for full-duplex mode and backpressure for
half-duplex transfer mode
¾Non-blocking switching architecture that forwards and filters packets at full
wire-speed for maximum throughput
¾Supports MAC address auto-learning and auto-aging
¾LED indicators for monitoring power, link, speed and activity
¾Desktop and rack-mountable steel case
¾Internal power supply

3
Chapter 2 Identifying External Components
This Chapter describes the front panel, rear panel and LED indicators of the Switch.
TL-SG1008/TL-SG1016D/TL-SG1024D just differ in the number of LED indicators
and ports and all figures in this guide are of TL-SG1008.
2.1 Front Panel
The front panel of TL-SG1008 consists of switch model, switch LED indicators, and
8 10/100/1000Mbps RJ-45 ports.
Figure 2-1 TL-SG1008 Switch Front Panel sketch
The LED indicators include Power, Link/Act LED indicators, which are used for
monitoring and pre-troubleshooting of the Switch. The following section shows the
LED indicators of the Switch along with an explanation of each indicator.
¾POWER LED: This indicator will light solid red when the Switch powers up. If
the LED is not lit, please check the power supply and connection.
¾Link/Act LED: The LED indicates Link/Active status. The corresponding LED
indicator will light solid green when connected to a network device. It flashes
green when data is being transmitted or received on the working connection.
¾1000Mbps LED: The corresponding port LED indicator will light solid green
when it's working on 1000Mbps speed. Not lit indicates working on
10/100Mbps speed.
2.2 Rear Panel
The rear panel of TL-SG1008 features a power socket and a Grounding Terminal
(marked with ).
Figure 2-2 TL-SG1008 Switch Rear Panel sketch
¾Grounding Terminal: TL-SG1008 already comes with Lightning Protection
Mechanism. You can also ground the Switch through the PE (Protecting Earth)

4
cable of AC cord or with Ground Cable. For detail information, please refer to
section 3.3 Connect to Ground.
¾AC Power Socket: Connect the female connector of the power cord here, and
the male connector to the AC power outlet. Please make sure the voltage of the
power supply meets the requirement of the input voltage.
Chapter 3 Installation
3.1 Precautions
To ensure a long-term and stable performance of the Switch, please pay attention
to the following before the installation.
1) Safety Requirements
•Before cleaning the Switch, cut off the power supply. Do not clean it by the
waterish cloth, and never use any other liquid cleaning method.
•Take waterproof measures during storage, transportation and operation of
the equipment.
•Use only the power cord provided with the Switch.
•Make sure the voltage of the power supply meets the requirement of the
input voltage of the Switch.
•Do not push any objects into the openings of the Switch.
•Ensure the vent hole is well ventilated and unblocked.
•Do not open or remove the cover of the Switch.
2) Location Requirements
When you choose a location for the Switch, please follow these guidelines:
•Install the Switch on a flat and stable surface that can support the entire
weight of the Switch with all fittings.
•Locate the Switch far from strong electromagnetic field generators (such as
motors), vibration, dust, and direct exposure to sunlight.
•To ensure adequate air flow around the Switch. At least 10 cm (4 inches) of
space at the front and rear of the Switch is needed for ventilation.
•Make sure that the Switch will be accessible and that the cables can be
easily connected.
•Position the Switch away from water and moisture sources, be sure to
provide an acceptable temperature and humidity operating environment.
3.2 Installation
This Switch can be either installed on the standard 19-inch mountable rack or
located on the desktop.

5
Caution:
Please unplug the power cord before installing or removing the Switch.
3.2.1 Desktop Installation
To install the Switch on the desktop, please follow the steps:
1) Set the Switch on a flat surface strong enough to support the entire weight of
the Switch with all fittings.
2) Remove the adhesive backing papers from the rubber feet.
3) Turnover the Switch and attach the supplied rubber feet to the recessed areas
on the bottom at each corner of the Switch.
Figure 3-1 Attaching Rubber Feet
4) Upturn the Switch and connect it to the network devices while keep enough
ventilation space around.
5) Connect the Switch to power source with the provided power cord.
Caution:
Please avoid any heavy thing placed on the Switch.
3.2.2 Rack Installation
To install the Switch in an EIA standard-sized, 19-inch rack, follow the instructions
described below:

6
1) Secure the supplied rack-mounting brackets to each side of the Switch with
supplied screws, as illustrated in the following figure.
Figure 3-2 Attaching Brackets
2) After the brackets are attached to the Switch, use suitable screws (not provided)
to secure the brackets to the rack, as illustrated in the following figure.
Figure 3-3 Mounting Switch
3) Connect the Switch to network devices.
4) Supply power to the Switch with the provided power cord.
Note:
TL-SG1016D and TL-SG1024D do not support rack installation.

7
3.3 Connect to Ground
Connecting the Switch to ground is to quickly release the lightning over-voltage and
over-current of the Switch, which is also a necessary measure to protect the body
from electric shock.
In different environments, the Switch may be grounded differently. The following will
instruct you to connect the Switch to the ground in two ways, connecting to the
Grounding Bar or connecting to the Ground via the power cord. Please connect the
Switch to ground in the optimum way according to your specific operation
environment.
•Connecting to the Grounding Bar
If the Switch is installed in the Equipment Room, where a Grounding Bar is available,
you are recommended to connect the Switch to the Grounding Bar as shown in the
following figure.
Figure 3-4
Note:
The Grounding Bar and Ground Cable is not provided with our product.
•Connecting to the Ground via the power supply
If the Switch is installed in the normal environment, the Switch can be grounded via
the PE（Protecting Earth）cable of the AC power supply as shown in the following
figure.

8
Figure 3-5
* The figure is to illustrate the application and principle. The power plug you get from the package
and the socket in your situation will comply with the regulation in your country, so they may differ
from the figure above.
Note:
If you intend to connect the Switch to the ground via the PE (Protecting Earth)
cable of AC power cord, please make sure the PE (Protecting Earth) cable in the
electrical outlet is well grounded in advance.
3.4 Power on
The TL-SG1008/TL-SG1016D/TL-SG1024D Switch is powered by an AC Power
Supply. Connect the Switch and power outlet by power cord. Powering on the
Switch, it will be automatically initialized and the LED indicators should respond as
follows:
1) All of the LED indicators will flash momentarily for one second, which
represents a resetting of the system.
2) The Power LED indicator will light up.

9
Appendix A: Specifications
General
Standards
IEEE802.3 10Base-T
IEEE802.3u 100Base-TX
IEEE802.3ab 1000Base-T
Topology Star
Protocol CSMA/CD
Ethernet: 10Mbps (Half Duplex), 20Mbps (Full Duplex)
Fast Ethernet: 100Mbps (Half Duplex), 200Mbps (Full
Duplex)
Data Transfer
Rate
Gigabit Ethernet: 2000Mbps (Full Duplex)
10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100Base-TX: UTP category 5, 5e cable (maximum
100m)
EIA/TIA-568 100 STP (maximum 100m)
Network Media
(Cable)
1000Base-T: UTP category 5, 5e cable (maximum
100m)
EIA/TIA-568 100 STP (maximum 100m)
Number of Ports 8/16/24 10/100/1000Mbps Auto-Negotiation RJ-45 ports
LED indicators POWER, Link/Act, 1000Mbps
Transfer Method Store-and-Forward
MAC Address
Learning Automatically learning, automatically aging
10Base-T: 14881pps/Port
100Base-Tx: 148810pps/Port
Frame Filter Rate
1000Base-T: 1488095pps/Port
10Base-T: 14881pps/Port
100Base-Tx: 148810pps/Port
Frame Forward
Rate
1000Base-T: 1488095pps/Port

10
Environmental and Physical
Operating Temperature 0℃~40℃(32℉~104℉)
Storage Temperature -40℃~70℃(-40℉~158℉)
Operating Humidity 10%~90% non-condensing
Storage Humidity 5%~90% non-condensing

11
Appendix B: Troubleshooting
1. The Power LED is not lit
¾Make sure the AC power cord connected the Switch with power source
properly.
¾Make sure the power source is ON.
2. The Link/Act LED is not lit when a device is connected to the
corresponding port
¾Make sure that the cable connectors are firmly plugged into the Switch and the
device.
¾Make sure the connected device is turned on and working well.
¾The cable must be less than 100 meters long(328 feet).
Appendix C: Contact Information
For help with the installation or operation of the TP-LINK TL-SG1008/TL-SG1016D/
TL-SG1024D Switch, please contact us.
E-mail: [email protected]
Website: http://www.tp-link.com
