TP-Link TL-SG108E User manual

Installation Guide
7106508401 REV4.1.0
1000 Mbps (Green)
On: Running at 1000 Mbps
Flashing: Transmitting/receiving data
10/100 Mbps (Yellow)
On: Running at 10/100 Mbps
Flashing: Transmitting/receiving data
LED Explanation
Power
On: Power on
O: Power o
Link/Act
Note: For simplicity, we will take TL-SG108E for example throughout this Guide.
Connection
Ethernet Ports (1-8)
TL-SG108E
PC PC
Router
LAN PortWAN Port
Internet
Conguration
The switch is plug and play. To congure the switch, you can use the Web-based GUI or
the conguration utility.
The utility is only supported on Windows now.
Using the Conguration Utility
1. Go to https://www.tp-link.com/support and search the model number of your switch.
Download the Easy Smart Conguration Utility from the product Support web page
on your PC.
Using the Web-based GUI
Note: If the switch gets a new IP address from the DHCP server, your connection to the
switch will be lost. Enter the new IP address in your browser to access the switch again.
1. Find out the IP address of the switch.
By default, the switch receives an IP addess from a DHCP server (or a router that
functions as a DHCP server) in your network. You can nd out this IP address on the
DHCP server.
If the switch cannot receive an IP address from a DHCP server, it uses the static IP
address of 192.168.0.1, with a subnet mask of 255.255.255.0.
2. Congure IP address on your PC to make sure the switch and PC are in the same
subnet.
If the switch uses an IP address assigned by a DHCP server, set your PC to obtain
an IP address automatically from the DHCP server.
If the switch uses 192.168.0.1 as the IP address, congure your PC’s IP address as
192.168.0.x (”x” ranges from 2 to 254), and subnet mask as 255.255.255.0.
Launch a web browser on your PC, enter the IP address of the switch in the address
bar and press Enter. Log in with admin as both user name and password.
3.
Now you can congure the switch using the Web-based GUI. For further information,
refer to the User Guide.
Go to https://www.tp-link.com/support, search the model number of your switch, and
you can nd this guide on the product Support web page. Now you can congure the switch using the conguration utility. For further information,
refer to the Easy Smart Conguration Utility User Guide.
Go to https://www.tp-link.com/support, search the model number of your switch, and you
can nd this guide on the product Support web page.
Double click the icon on the desktop, and the utility
Home page will display a list of TP-Link switches on
the local network.
3.
2. Decompress the downloaded le, run the installation
wizard and follow the prompts to install the Easy
Smart Conguration Utility.
4.
If the switch uses an IP address assigned by a
DHCP server, set your PC to obtain an IP address
automatically from the DHCP server.
If the switch uses 192.168.0.1 as the IP address,
congure your PC’s IP address as 192.168.0.x (”x”
ranges from 2 to 254), and subnet mask as
255.255.255.0.
Click to nd out IP parameters of the switch.
Double click the switch that you want to congure. Log in with admin as both user
name and password.
5.
5/8/16-Port Gigabit Easy Smart Switch

© 2019 TP-Link
Explanation of the symbols on the product label
DC voltage
RECYCLING
This product bears the selective sorting symbol for Waste electrical and electronic equipment
(WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU
in order to be recycled or dismantled to minimize its impact on the environment.
User has the choice to give his product to a competent recycling organization or to the retailer
when he buys a new electrical or electronic equipment.
Indoor use only
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Adapter shall be installed near the equipment and shall be easily accessible.
Use only power supplies which are provided by manufacturer and in the origin packing of
this product. If you have any questions, please don’t hesitate to contact us.
Frequently Asked Questions (FAQ)
Q1. Why is the Power LED not lit?
The Power LED should be lit when the power system is working normally. If the
Power LED is not lit, please try the following:
A1: Make sure the power adapter is connected to the switch with power source
properly.
A2: Make sure the voltage of the power supply meets the requirements of the
input voltage of the switch.
A3: Make sure the power source is ON.
Q2. Why is the Link/Act LED not lit while a device is connected
to the corresponding port?
For technical support, the user guide and other information, please visit
https://www.tp-link.com/support, or simply scan the QR code.
Please try the following:
A1: Make sure that the cable connectors are rmly plugged into the switch and
the device.
A2
: Make sure the connected device is turned on and works normally.
A3
: The cable must be less than 100 meters long (328 feet).
Some models featured in this guide may be unavailable in your country or region. For local
sales information, visit https://www.tp-link.com.
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
0 ˚C to 40 ˚C (32 ˚F to 104 ˚F)
-40 ˚C to 70 ˚C (-40 ˚F to 158 ˚F)
10% RH to 90% RH non-condensing
5% RH to 90% RH non-condensing
Environmental and Physical Specications
Specications
Standard
Protocol
Interface
LED indicators
Transfer Method
IEEE802.3i, IEEE802.3u, IEEE802.3ab,
IEEE802.3x, IEEE802.1p, IEEE802.1q
CSMA/CD
Ethernet: 10 Mbps (Half Duplex), 20 Mbps (Full Duplex)
Fast Ethernet: 100 Mbps (Half Duplex), 200 Mbps (Full
Duplex)
Gigabit Ethernet: 2000 Mbps (Full Duplex)
10Base-T:
UTP category 3, 4, 5 cable (maximum 100 m)
EIA/TIA-568 100
Ω STP (maximum 100 m)
100Base-TX:
UTP category 5, 5e cable (maximum 100 m)
EIA/TIA-568 100
Ω STP (maximum 100 m)
1000Base-T:
UTP category 5e cable (maximum 100 m)
EIA/TIA-568 100 Ω STP (maximum 100 m)
5/8/16 10/100/1000 Mbps Auto-Negotiation RJ45
Ports
Power, 10/100 Mbps LED, 1000 Mbps LED
Store-and-Forward
Automatically learning, automatically aging
10Base-T: 14881 pps/Port
100Base-TX: 148810 pps/Port
1000Base-T: 1488095 pps/Port
Ye s
TL-SG105E: 52 mm
TL-SG108E: 110 mm
TL-SG116E: 200 mm
MAC Address Learning
Frame Forward Rate
General Specications
Data Transfer Rate
Network Media (Cable)
Wall Mountable
Distance Between
Mounting Holes
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of directives 2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/ce
EU Declaration of Conformity
