TPI CF35-C User manual

USER’S GUIDE
AIR CURTAINS
Models: CF35-C, CF47-C, CF59-C
Thanks for purchasing this Air Curtain.
PLEASE READ AND SAVE THESE INSTRUCTIONS.

1
WARNING –TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY
TO PERSONS, OBSERVE THE FOLLOWING:
A. Always disconnect, lock and tag power source before installing or servicing. Failure to
disconnect power source can result in fire, shock or serious injury.
B. Installation work and electrical wiring must be done by qualified person(s) in
accordance with all applicable codes and standards, including fire-rated construction.
C. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other
hidden utilities.
D. To reduce the risk of fire or electric shock, do not use this fan with any solid-state
speed control device
E. Repair and maintenance operations can only be performed by qualified personnel.
F. Verify and ensure the rated voltage and frequency (please refer to the rating label) of
the air curtain is in compliance with the mains supply.
CONTENTS
1. PRODUCT INTRODUCTIONS................................................................................................2
2. INSTALLATION DIMENSIONS................................................................................................2
3. INSTALLATION CAUTIONS....................................................................................................3
4. INSTALLATION INSTRUCTIONS............................................................................................4
5. TECHNICAL PARAMETER .....................................................................................................5
6. WIRING DIAGRAM .................................................................................................................6
7. OPERATING INSTRUCTIONS................................................................................................6
8. MAINTENANCE AND CLEANING...........................................................................................6

2
1.PRODUCT INTRODUCTIONS
Air curtains are widely installed at the entrances of supermarket, theater, meeting room, hotel,
office room, storeroom etc. They can reduce penetration of insects, dust…unconditioned air into a
conditioned space by forcing an air stream over the entire entrance to create a comfortable
environment for you.
2.INSTALLATION DIMENSIONS
UNIT: inch
MODEL
A
B
C
D
E
F
G
H
I
J
CF35-C
35.43
1.18
11.42
22.05
---
2.05
5.71
10.24
8.58
5.04
CF47-C
47.24
16.93
10.63
16.93
CF59-C
59.06
22.40
10.63
22.40

3
3.INSTALLATION CAUTIONS
Must observe the following when installing air curtains:
3.1 Please install the unit on a sturdy
supporting structure to avoid shaking and
ensure its security (because the unit running
may cause the wall to become loose or
shake and make noise).
3.2 Please install the unit inside the room.
3.3 Don’t install the unit too low, no less than
2.5 meters from the ground.
ATTENTION ：INSTALLER DE SORTE
QUELES PIECES INFERIEURES SOIENT
A AU MOINS 2.5 METRES AU-DESSUS
DU PLANCHER OU DU SOL.
3.4 When the entrance is wider than the
unit, it is recommended to install two or
more units in parallel. In this case, provide
20-40mm gaps between the units.
3.5 Don’t allow gaps between the unit and
the wall.
3.6 Don’t install the unit at a place where it
is splashed by water, exposed to excessive
steam, explosive gas or corrosive gas.

4
4.INSTALLATION INSTRUCTIONS
A. Installing on the concrete wall:
4.1.1 Unscrew the mounting plate and
remove it from the back of the main body.
4.1.2 Determine the mounting location with
the mounting plate. Fix the bolts in place and
pour cement into the bolt holes.
4.1.3 Fix the mounting plate to the wall after
cement setting (use the washers and nuts
as the Fig shows).
4.1.4 Mount the main body onto the
mounting plate as the Fig shows and screw
it back to the mounting plate.
B. Installing on the wooden wall:
4.2.1 Determine the mounting location as per
the step 4.1.2 and fix the mounting plate to the
wooden wall with tapping screws.
4.2.2 Same as the step 4.1.4

5
C. Installing from the ceiling:
4.3.1 Remove the mounting plate from the main
body as per the step 4.1.1
4.3.2 Fix the ceiling brackets as the Fig shows.
4.3.3 Fix the mounting plate to the ceiling
brackets and tighten it securely as the Fig
shows. The position of the mounting plate can
be adjusted in vertical direction according to
need, but the max distance is 100mm.
4.3.4 Same as the step 4.1.4
5.TECHNICAL PARAMETER
Model
No.
Voltage
(V~Hz)
Power
(W)
Max air velocity
(FPM)
Air volume
(CFM)
Noise level
(dB)
Net
weight
(Lb)
H
L
H
L
H
L
CF35-C
120~60
300
2560
1968
1177
942
67
65
33.1
CF47-C
350
1648
1295
69
67
43.0
CF59-C
400
2119
1648
71
69
48.5

6
6.WIRING DIAGRAM
DOUBLE SPEED SWITCH WIRING DIAGRAM
C2
THERMAL CUT-OUT GREEN
WHITE
YELLOW
BLACK 3
BLUE
ORANGE
(YELLOW)
1
L
OFF
Hi K
Lo N
7.OPERATING INSTRUCTIONS
7.1 Connect power to the unit.
7.2 Push the power switch to the left/right to switch on the unit. [L] - Low speed, [H] - High speed.
7.3 Adjust the air deflector to obtain optimum effect.
8.MAINTENANCE AND CLEANING
WARNING:
A. Any service is to be performed only by qualified personnel who are familiar with local
codes and regulations and are experienced with this type of product.
B. Always unplug or disconnect the appliance from the power supply before servicing or
cleaning the unit.
C. Never use petrol, benzene, thinners or any other such chemicals for cleaning the unit.
D. Don’t allow water or any liquid to enter the motor.
8.1.Routine maintenance must be done every year.
8.2.Plastic parts should be cleaned with mild soap water, thoroughly remove soap film with a
clean damp cloth.
8.3.Wipe the exterior surfaces of the fan with a moistened cloth with a solution of mild detergent
and water.
8.4.Dry the case with a soft dry cloth before operating the unit.
