Tractel KS Installation instructions

1
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
KS / KSA / NK / NX / NXR
PLATE CLAMPS
Follow the instructions and warnings for inspecting, maintaining and operating this clamp.
The use of any clamp presents some risk of personal injury or property damage. That risk is
greatly increased if proper instruction and warnings are not followed. Before using this clamp,
each user should become throughly familiar with all warnings, instructions and
recommendations in this manual.
RETAIN THIS MANUAL FOR FUTURE REFERENCE AND USE.
Forward this manual to all users. Failure to operate equipment as directed in manual
may cause serious injury or death
Before installing clamp, fill in the information below.
Model Number:
Serial Number:
Purchase Date:
KS KSA NK NX / NXR
Clamps compliant with ANSI B30.20
USER OPERATING AND INSPECTION MANUAL
GENERAL WARNING

CONTENTS Page
Topal Plate Clamps Safety Symbols 3
General Warnings 4
Tractel Lifting Clamps 5
S Description and Dimensions 6
S Inspection of clamp before use 7
S Trouble Shooting Chart 8
SA Description and Dimensions 9
SA Inspection of clamp before use 10
SA Trouble Shooting Chart 11
N Description and Dimensions 12
N Inspection of clamp before use 13
N Trouble Shooting Chart 14
NX / NXR Description and Dimensions 15
NX Inspection of clamp before use 16
NX Trouble Shooting Chart 17
S / SA / N Use and Installation 18
SA Applications 19
S / SA / N Important Instructions 20
S / N Applications 21
NX / NXR Use and Installation 22
NX Important Instructions 23
NX Applications 24
General Maintenance & Labels 25
Service 26-27
2
© Tractel®P4102 NA - rev 1 - 11/2010
www.tractel.com
KS / KSA / NK / NX / NXR
PLATE CLAMPS

3
Sa ety advice
Symbol Code word Meaning Possible
non-compliance consequence
IMMEDIATE or
WARNING possibly imminent Fatal or serious injuries!
danger:
CAUTION possibly dangerous Minor injuries to persons!
situation:
Other advice
NOTE possibly dangerous Damage to equipment
situation: or its surroundings
Instruction for documentation in No recorded history
(none) writing
(i.e. record keeping)
To ensure the on-going improvement o it’s products, Tractel®
reserves the right, at any time, to apply any changes which it may
deem use ul to the clamps described in this manual. The Tractel®
group companies and their authorized dealers will provide you, on
request, with a complete documentation covering the ull range o
Tractel®products: Li ting and pulling equipment, worksite and
açade access equipment (BMUs), sa ety devices or loads,
electronic load indicators, etc. The Tractel®network also provides
a ter-sales and periodic maintenance services.
TOPAL Plate Clamps Sa ety Symbols
© Tractel®P4102 NA - rev 1 - 11/2010
www.tractel.com

4
© Tractel®P4102 NA - rev 1 - 11/2010
www.tractel.com
1) Before installing and using this clamp, you
must be familiar with the information
contained in this manual and you must comply
with the utilization and safety instructions given to
ensure safe use of the clamp. A copy of this
manual should be available to all clamp
users. Additional copies can be provided on
request.
2) Do not use the clamp if any of the labels on the
clamp are damaged or illegible, or if any of the
markings, as indicated at the end of this manual, are
no longer legible. If a damaged information plate is
observed, identical plates can be supplied on
request and should be fastened to the clamp before
continuing to use.
3) Make sure that any person to whom you have
entrusted use of this clamp is familiar with the
information contained in this manual and is able
to satisfy the safety requirements involved by the
purpose for which the clamp is used. This manual
should be in the user’s possession.
4) This clamp must only be used in compliance with
the applicable safety standards and all Federal
state, local and provincial regulations concerning
installation, use, maintenance and inspection of
materials lifting.
5) For all professional purposes, this clamp must be
placed under the responsibility of a qualified
person who is familiar with the applicable
regulations and who has the necessary authority
to ensure application of these regulations by
all users.
6) Any person using this clamp for the first time
must check, in a risk-free environment, before
applying the load, and on a limited lifting height,
that he has fully understood all the requirements
for safe, efficient operation of the clamp.
7) Setup and operation of the clamp must only be
performed under conditions ensuring installer
safety in compliance with the regulations
applicable to the clamp category.
8) Each time, before using the clamp, visually check
that the clamp are in good condition.
9) Tractel®shall not be held liable for use of this
clamp in any setup configuration not described in
this manual.
10) Any changes to the clamp not supervised by
Tractel®, including removal of parts from the clamp,
shall release Tractel®from any liability.
11) Any clamp assembly or disassembly not described
in this manual, or any repair performed outside
Tractel®supervision will release Tractel® from any
liability, especially as may concern replacement of
genuine parts by parts from another source.
12) Any alteration on the clamp aimed at modifying or
repairing it outside Tractel®supervision will
release -Tractel®from any liability subsequent to the
modification or repair performed.
13) This clamp must never be used for any operations
other than those described in this manual. The
clamp should never be used with loads exceeding
the rated load indicated on the clamp.
14) The clamp should never be used in an
explosive atmosphere.
15) Never use this clamp for lifting or moving persons.
16) When it is necessary to lift a load using several
units, a technical study by a qualified technician
must first be carried out to ensure proper installation
and operation in compliance with the technical
study, in particular to ensure an even distribution of
the load under appropriate conditions. Tractel®shall
not be held liable for use of any Tractel®device in
combination with other lifting devices of a different
manufacturer.
17) The clamp must be attached to a fixed mast and to
a structure which is sufficiently strong, consistent
with the applicable safety coefficient, to stay within
the rated load indicated in this manual. If several
units are used, the strength of the structure and the
anchor point must be consistent with the number of
clampes used in accordance with their working load
limit.
18) To ensure safe use of the clamp, it should be
visually inspected and serviced regularly.
Depending on the nature of the environment in
which the clamp is used, check regularly for any
signs of corrosion.
19) Never take position or circulate under the load. The
area located under the load should be clearly
marked out and barricaded.
20) Keeping the clamp in good condition is essential to
safety and correct operation of the clamp. Any
clamp showing any signs of damage must be
immediately and definitively removed from use.
21) When the clamp is not used, it should be placed out
of reach of all persons not authorized to
use it.
22) The clamp should be inspected periodically by a
Tractel®approved repair agent as indicated in this
manual.
23) During use, the user must ensure that the clamp is
constantly tensioned by the load and, in particular,
that the clamp is not temporarily snagged by an
obstacle when bringing a load down as this could
result in rupture of the clamp or loss of the load
when the load comes free from its obstacle.
GENERAL WARNING

5
Model Item Weight Weight WLL lbs. (t) WLL kg Opening Opening
Number lbs. kg inches mm
SA075 0-15 54768 3.3 1.5 1,650 (3/4) 750 0- 9/16 0-15
SA1 0-20 54778 7.0 3.2 2,200 (1) 1,000 0- 3/4 0-20
S075 0-15 50238 3.5 1.6 1,650 (3/4) 750 0- 9/16 0-15
S1 0-20 50248 7.7 3.5 2,200 (1) 1,000 0- 3/4 0-20
S2 0-25 50258 13.9 6.3 4,400(2) 2,000 0- 1 0-25
S3 0-30 50268 26.6 12.1 6,600 (3) 3,000 0- 1 1/8 0-30
N 1 0-20 50288 8.8 4 3,300 (1.5) 1,500 0- 3/4 0-20
N 1 20-40 50298 12.8 5.8 3,300 (1.5) 1,500 3/4 - 1 1/2 20-40
N 1 40-60 50308 13.2 6 3,300 (1.5) 1,500 1 5/8-2 5/16 40-60
N 2 0-30 50318 28.6 13 6,600 (3) 3,000 0- 1 1/8 0-30
N 2 30-60 50328 33.0 15 6,600 (3) 3,000 1 3/16- 2 5/16 30-60
N 2 60-90 50338 37.4 17 6,600 (3) 3,000 2 3/8- 3 1/2 60-90
N 3 0-40 50348 55.0 25 9,900 (4.5) 4,500 0- 1 1/2 0-40
N 3 40-80 50358 57.2 26 9,900 (4.5) 4,500 1 5/8- 3 40-80
N 3 80-120 50368 59.4 27 9,900 (4.5) 4,500 3 3/16-4 5/8 80-120
N 5 0-50 50378 93.1 42.3 16,500 (7.5) 7,500 0-2 0-50
N 5 50-100 50388 110.0 50 16,500 (7.5) 7,500 2-4 50-100
N 5 100-150 50398 132.0 60 16,500 (7.5) 7,500 4-6 100-150
N 05 0-20 50408 9.9 4.5 1,100 (.5) 500 0- 3/4 0-20
NX05 0-20 50408 9.9 4.5 1,100 (.05) 500 0- 3/4 0-20
NX1.5 0-30 50418 24.2 11 3,300 (1.5) 1,500 0- 1 3/16 0-30
NXR05 0-100 50428 13.2 6 1,100 (.05) 500 0-4 0-100
NXR05 20-120 50438 12.8 5.8 1,100 (.05) 500 3/4 - 4 1/4 20-120
NXR05 40-140 50448 13.2 6 1,100 (.05) 500 1 5/8 - 5 1/2 40-140
© Tractel®P4102 NA - rev 1 - 11/2010
www.tractel.com
Tractel®lifting clamps
Table 1

KS
Multiposition Plate Clamps
Description
Clamps fitted with a spring mechanism for a
permanent contact of the cam into the piece to be
lifted.The locking lever does not stick out so that the
clamp may be used on the bare ground. The chain
enables the revolving and makes the clamp’s
positioning easier. The cam is designed to mark only
one side of the load.
S Plate Clamp Table 2
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
6
Ref. Item WLL lbs.(t) Opening A B C D E F G Ring J L Chain Weight
min max Dia Dia
Number kg. In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm lb./kg.
S075 0-15 50238 1,650 (3/4) 0 9/16 11 13/16 5 3 3/16 1 3/4 1 1/2 3 1/8 1 9/16 3/8 1/2 1 5/16 2 1/16 1/4 3.5
750 0 15 300 129 97 45 39 80 40 10 12 34 53 6 1.6
S1 0-20 50248 2,200 (1) 0 3/4 16 3/4 6 13/16 5 6 3/8 1 15/16 4 5/16 2 3/8 1/2 5/8 1 11/16 2 5/8 9/32 7.7
1,000 0 20 426 173 128 60 49 110 60 13 16 43 67 7 3.5
S2 0-25 50258 4,400(2) 0 1 19 1/16 8 9/16 6 5/16 2 15/16 2 7/16 4 5/16 2 3/8 5/8 3/4 1 7/8 3 1/8 5/16 13.9
2,000 0 25 485 218 161 75 62 110 60 16 19 47 79 8 6.3
S3 0-30 50268 6,600 (3) 0 1 1/8 23 7/16 10 1/4 8 1/16 3 11/16 3 3/8 5 5/16 2 15/16 11/16 1 1/16 2 1/4 3 3/4 13/32 26.6
3,000 0 30 595 260 205 94 85 135 75 18 28 58 96 10 12.1

KS
Inspection of clamp before use
S clamp inspection procedure
Find on clamp: serial number, type and manufacturing year.
Clamps over 10 years old must be replaced.
GENERAL CONDITION
Perform visual inspection and check that every component is in good condition.
FUNCTIONING
Return to authorized Tractel®repair center is necessary in case of malfunction
during any of the following tests:
Position the clamp on a working surface. Operate the clamp opening lever
downwards (without triggering off the locking in the open position) then
release. The clamp should close freely.
STRUCTURE CONDITION
Cam wear: the teeth must penetrate the surface of the load to be lifted.
Visual and tactile inspection: the teeth edge should be sharp. The cam must be
replaced as soon as there appears to be a flattened tooth (as reference, see a
tooth situated at the cam extremity and still intact).
Note: in some cases, the clamp only handles one plate thickness. Wear of
teeth is then concentrated on several teeth, the others being intact. Inspection
shall therefore always be carried out on the whole of the cam teeth.
Deformation: the clamp structure must not be deformed.
Visual inspection. The clamp must be replaced, especially when any of the
following condition is not respected:
1. Clamp closed, the cam should be in contact with the limit stop, one right
facing the other.
2. No chain link deformed.
3. Check that the clamp opening dimension (A) is less than the following value:
Opening lever
Cam stop
CamStop
Type
Year - Serial number Indexed cam
Cam to be replaced:
flattened teeth
Acceptable cam
Clamp A max A max
(mm) (in)
S075 0-15 18.8 0.74
S1 0-20 25.0 0.98
S2 0-25 32.1 1.26
S3 0-30 38.9 1.53
Record the inspection results
Min-Max Opening
Capacity
A
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
7

KS
Trouble shooting chart
Item Trouble Cause Solution Remarks Action
The clamp does not The springs are damaged Check carefully that
close freely. or missing. The cocking no other component Return to a Tractel®
1lever is deformed. Yes of that lever is bent authorized repair center
The clip was sticking. and rubbing in
the clamp.
It’s normal to wear the The cam is a critical
Wear of the cam teeth, teeth of the cam. The component to
2or the cam shaft toothed cam must Yes monitor. Always Return to a Tractel®
penetrate the material replace the cam authorized repair center
of the load being lifted. shaft along with
the cam.
This is normal wear All chain products Return to a Tractel®
3Chain Wear mainly related to Yes should have an authorized repair center
movement of the plate annual inspection.
The cam and cam Return to a Tractel®
4 Deformation Very rare Yes shaft are critical authorized repair center
of a component. components to be for inspection
monitored.
Such a rupture
5The chain is broken Clamp has been No would only occur Clamp to be destroyed
or the cam is dislodged overloaded in case of overload. and replaced
The springs are damaged Check carefully that
or missing. no other component Return to a Tractel®
The cam is not in The cocking lever is Yes is damaged or the authorized repair center
6contact with the stop deformed. lever is bent and for inspection
(for clamps that have rubbing the clamp.
a minimum opening Such deformation Clamp to be destroyed
of 0) The clamp is deformed NO occurs only when and replaced
overloaded.
Such deformation occurs Such deformation Clamp to be destroyed
7Clamp body deformed only when overloaded NO occurs only when and replaced
overloaded.
Whatever the diagnosis, always plan to loosen up the clamp before return to service
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
8

KSA
Plate Clamps with Ring
Description
Clamps fitted with a spring mechanism for a
permanent contact of the cam onto the piece to
be lifted.
The locking lever does not stick out so that it is
unlikely to get damaged. The cam is designed to
mark only one side of the load.
SA Plate Clamp Table 3
Ref. Item WLL lbs. (t) Opening A* B C D E F G H I J L Weight
min max min max
Number kg. In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm lb./kg.
SA075 0-15 54768 1650 (3/4) 0 9/16 9 10 5 3 13/16 1 3/4 1 1/2 2 3/4 2 3/16 1/4 19/32 1/2 1 5/16 2 1/16 3.3
750 0 15 228 255 129 97 45 39 70 55 6 15 12 34 53 1.5
SA1 0-20 54778 2200 (1) 0 3/4 9 11/16 11 6 13/16 5 2 3/8 1 15/16 2 3/4 2 1/2 5/16 19/32 5/8 1 11/16 2 5/8 7.0
1,000 0 20 245 280 173 128 60 49 70 65 8 15 16 43 67 3.2
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
9

www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
10
KSA
Inspection of clamp before use
SA clamp inspection procedure
Find on clamp: serial number, type and manufacturing year.
Clamps over 10 years old must be replaced.
GENERAL CONDITION
Perform visual inspection and check that every component is in good condition.
FUNCTIONING
Return to authorized Tractel®repair center is necessary in case of malfunction
during any of the following tests:
Position the clamp on a working surface. Operate the clamp opening lever
downwards (without triggering off the locking in the open position) then
release. The clamp should close freely.
STRUCTURE CONDITION
Cam wear: the teeth must penetrate the surface of the load to be lifted.
Visual and tactile inspection: the teeth edge should be sharp. The cam must be
replaced as soon as there appears to be a flattened tooth (as reference, see a
tooth situated at the cam extremity and still intact).
Note: in some cases, the clamp only handles one plate thickness. Wear of
teeth is then concentrated on several teeth, the others being intact. Inspection
shall therefore always be carried out on the whole of the cam teeth.
Deformation: the clamp structure must not be deformed.
Visual inspection. The clamp must be replaced, especially when any of the
following condition is not respected:
1. Clamp closed, the cam should be in contact with the limit stop, one right
facing the other.
2. If lifting ring is deformed or damaged remove from service.
3. Check that the clamp opening dimension (A) is less than the following value:
Opening lever
Cam stop
CamStop
Type
Year - Serial number Indexed cam
Cam to be replaced:
flattened teeth
Acceptable cam
Clamp A max A max
(mm) (in)
SA075 0-15 18.8 0.74
SA1 0-20 25.0 0.98
Record the inspection results
Min-Max Opening
Capacity
A

KSA
Trouble shooting chart
Item Trouble Cause Solution Remarks Action
The clamp does not The springs are damaged Check carefully that
close freely. or missing. The cocking no other component Return to a Tractel®
1lever is deformed. Yes of that lever is bent authorized repair center
The clip was sticking. and rubbing in
the clamp.
It’s normal to wear the The cam is a critical
Wear of the cam teeth, teeth of the cam. The component to
2or the cam shaft toothed cam must Yes monitor. Always Return to a Tractel®
penetrate the material replace the cam authorized repair center
of the load being lifted. shaft along with
the cam.
ifting Ring is deformed ifting Ring has been ifting Ring is Clamp to be destroyed
3or damaged subject to drop or lifting No damaged and can and replaced
in the wrong direction not be fixed
The cam and cam Return to a Tractel®
4 Deformation Very rare Yes shaft are critical authorized repair center
of a component. components to be for inspection
monitored.
Such a rupture
5The chain is broken Clamp has been No would only occur Clamp to be destroyed
or the cam is dislodged overloaded in case of overload. and replaced
The springs are damaged Check carefully that
or missing. no other component Return to a Tractel®
The cam is not in The cocking lever is Yes is damaged or the authorized repair center
6contact with the stop deformed. lever is bent and for inspection
(for clamps that have rubbing the clamp.
a minimum opening Such deformation Clamp to be destroyed
of 0) The clamp is deformed NO occurs only when and replaced
overloaded.
Such deformation occurs Such deformation Clamp to be destroyed
7Clamp body deformed only when overloaded NO occurs only when and replaced
overloaded.
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
11

NK
Automatic Multiposition Plate Clamps
Description
Clamps fitted with a spring mechanism for a
permanent contact of the cam onto the piece to be
lifted, even when it is being put down. The NK has an
automatic locking mechanism when the plate is
correctly positioned at the back of the clamps throat.
The locking lever does not stick out so that the clamp
may be used on the bare ground. The chain enables
the revolving and makes the clamp’s position easier.
The cam is designed to mark only one side of the
load.
Ref. Item WLL lbs. (t) Opening A* B C D E F G H I J L Weight
min max min max
Numbe r kg. In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm In./ mm lb./kg.
N1-0-20 50288 3300 (1.5) 0 3/4 17 1/8 18 1/2 7 9/32 4 23/32 1 3/16 5/16 2 3/4 2 11/16 4 1/3* 5/8 2 3/8* 11/32 3 1/4 8.80
1 500 0 20 435 470 185 120 30 8 68 82.5 110* 16 60* 10.5 82 4
N 1-20-40 50298 3300 (1.5) 7/8 1 1/2 17 5/8 19 3/8 8 13/16 5 15/16 1 3/4 5/16 3 3/16 3 1/4 4 1/3* 5/8 2 3/8* 11/32 3 13/16 12.76
1 500 20 40 448 493 224 151 44 8 81 82.6 110* 16 60* 10.6 97 5.8
N 1-40-60 50308 3300 (1.5) 1 5/8 2 5/16 18 1/4 20 9 25/32 6 3/4 1 3/4 5/16 3 3/4 3 1/4 4 1/3* 5/8 2 3/8* 11/32 4 13/32 13.2
1 500 40 60 463 508 250 171 44 8 96 82.7 110* 16 60* 10.7 112 6
N 2-0-30 50318 6600 (3) 0 1 1/8 23 3/8 25 13/32 10 15/16 7 1/2 2 1/4 1/2 3 3/4 4 13/16 4 5/8 7/8 2 11/16 13/16 4 23/32 26.40
3 000 0 30 594 645 278 190 58 13 95 122 117 22 68 20.5 120 12
N 2-30-60 50328 6600 (3) 1 3/16 2 5/16 23 15/16 26 1/6 12 3/16 8 1/4 2 1/2 1/2 4 7/16 4 13/16 4 5/8 7/8 2 11/16 13/16 5 19/32 33.0
3 000 30 60 608 662 310 210 65 13 113 122 117 22 68 20.6 142 15
N 2-60-90 50338 6600 (3) 2 3/8 3 1/2 24 7/8 26 3/4 9 21/32 2 3/4 1/2 5 4 13/16 4 5/8 7/8 2 11/16 13/16 6 3/16 37.40
3 000 60 90 631 680 338 245 70 13 128 122 117 22 68 20.7 157 17
N 3-0-40 50348 9900 (4.5) 0 1 1/2 25 3/8 28 14 1/4 9 27/32 2 19/32 1/2 5 5/16 5 1/2 4 5/8 7/8 2 11/16 13/16 6 7/16 55.0
4 500 0 40 645 711 362 250 66 13 135 140 117 22 68 20.8 163 25
N 3-40-80 50358 9900 (4.5) 1 5/8 3 25 13/16 28 5/16 15 9/16 10 5/8 3 5/32 1/2 6 1/3 5 29/32 4 5/8 7/8 2 11/16 13/16 7 13/32 57.2
4 500 40 80 655 719 395 270 80 13 160 150 117 22 68 20.9 188 26
N 3-80-120 50368 9900 (4.5) 3 3/16 4 5/8 27 7/16 29 15/16 14 5/8 12 1/4 3 1/4 1/2 7 3/32 5 29/32 4 1/2 7/8 2 19/32 25/32 8 3/16 59.4
4 500 80 120 696 760 371 312 82 13 180 145 115 22 66 20.10 208 27
N 5-0-50 50378 16500 (7.5) 0239 1/8 43 5/8 15 25/32 12 27/32 3 7/8 23/32 5 29/32 9 1/4 8 1/16 1 3/8 3 15/16 1 7 7/8 93.06
7 500 0 50 993 1108 402 326 98 18 150 235 205 35 100 25 200 42.3
N 5-50-100 50388 16500 (7.5) 2441 1/4 45 3/4 17 11/16 13 3 3/4 23/32 8 3/32 9 1/4 8 1/16 1 3/8 3 15/16 1 9 5/8 110.00
7 500 50 100 1048 1162 449 330 95 18 205 235 205 35 100 25 244 50
N 5-100-150 50398 16500 (7.5) 4642 1/2 46 3/4 18 11/16 15 9/16 4 1/8 23/32 9 1/16 9 1/4 8 1/16 1 3/8 3 15/16 1 10 1/2 132.00
7 500 100 150 1080 1188 474 395 105 18 230 235 205 35 100 25 267 60
N Plate Clamp Table 4
NK1 comes with round ring
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
12

N clamp inspection procedure
Find on clamp: serial number, type and manufacturing year.
Clamps over 10 years old must be replaced.
NK
Inspection of clamp before use
FUNCTIONING
Return to authorized Tractel®repair center is necessary in case of
malfunction during any of the following tests:
Hang the clamp. Operate the clamp opening lever downwards without
bringing it at full stroke (without triggering off the locking in the open
position) then release. The clamp should close up freely.
Operate the clamp opening lever downwards at full stroke, until the locking
in the open position is triggered. Then lower the clamp and bring it home
onto a plate: the clamp must close automatically when the plate enters in
contact with the back of the throat.
STRUCTURE CONDITION
Cam wear: the teeth must penetrate the surface of the load to be lifted.
Visual and tactile inspection: the teeth edge should be sharp. The cam must
be replaced as soo as there appears to be a flatte ed tooth (as reference,
see a tooth situated at the cam extremity and still intact).
Note: i some cases, the clamp o ly ha dles o e plate thick ess. Wear of
teeth is the co ce trated o several teeth, the others bei g i tact.
I spectio shall therefore always be carried out o the whole of the cam
teeth.
Deformation: the clamp structure must not be deformed.
Visual inspection. The clamp must be replaced, especially when any of
the following condition is not respected:
1. If the min grab of the clamp is 0: the cam should be in contact with
the limit stop, one right facing the other when the clamp is at rest.
2. No chain link is deformed.
3. Check that the clamp opening dimension (A) is less than the
following value:
Clamp A max Clamp A max Clamp A max
in (mm) in (mm) in (mm)
N 1 0-20 1(23.0) N 2 30-60 2.5(63.2) N 3 80-120 4.9(124.2)
N 1 20-40 1.7(43.2) N 2 60-90 3.7(93.2) N 5 0-50 2.3(58.0)
N 1 40-60 2.5(62.8) N 3 0-40 1.7(44.2) N 5 50-100 4.2(108.0)
N 2 0-30 1.3(34.5) N 3 40-80 3.3(84.2) N 5 100-150 6.2(158.0)
Cam to be replaced:
flattened teeth
Acceptable cam
Opening lever
Cam stop
Type
Year - Serial number
Indexed cam
Contact cam-stop
Min/Max grab (mm)
A
Record the inspection results
Capacity
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
13

NK
Trouble shooting chart
Item Trouble Cause Solution Remarks Action
The springs are damaged Check carefully that
The clamp does not or missing. The cocking no other component Return to a Tractel®
1close freely. lever is deformed. Yes of that lever is bent authorized repair center
The clip was sticking. and rubbing in
the clamp.
The arming system of Fracture, deformation According to the
2the clamp does not or failure of the arming length of the clip, Return to a Tractel®
work (not blocking the system of the clamp Yes 2 fixes are available authorized repair center
opening of the clamp) (trigger) for NK1.
It’s normal to wear the The cam is a critical
Wear of the cam teeth, teeth of the cam. The component to monitor.
3or the cam shaft toothed cam must Yes Always replace the Return to a Tractel®
the load being lifted. cam shaft along with authorized repair center
the cam.
This is normal wear All chain products Return to a Tractel®
4 Chain Wear mainly related to Yes should have an authorized repair center
movement of the plate annual inspection.
The cam and cam
5Deformation of a Very rare Yes shaft are critical Return to a Tractel®
component. components to be authorized repair center
monitored. for inspection
The chain is broken Clamp has been Such a rupture would Clamp to be destroyed
6or tha cam is overloaded No only occur in case and replaced
dislodged of overload.
The springs are damaged Check carefully that
or missing. no other component Return to a Tractel®
The cam is not in The cocking lever is Yes is damaged or the authorized repair center
contact with the stop deformed. lever is bent and for inspection
7(for clamps that have rubbing the clamp.
a minimum opening Such deformation Clamp to be destroyed
of 0) The clamp is deformed NO occurs only when and replaced
overloaded.
Such deformation occurs Such deformation Clamp to be destroyed
8Clamp body deformed only when overloaded NO occurs only when and replaced
overloaded.
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
14

NX / NXR
Automatic Multiposition Non-marring Clamps
Description
Clamps fitted with jaws coated with polyurethane
enabling one to lift and rotate loads without marring
their surface. These products are equipped with a
spring mechanism and an automatic grasping which
respectively permits a permanent contact of the cam
onto the piece to be lifted, and ensures the clamp’s
closing when the plate is correctly positioned at the
back of the clamp’s throat. The chain enables the
turning and makes the clamp’s positioning easier.
NX Plate Clamp Table 5
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
15
Ref. Item
WLL lbs. (t)
Opening A B C D E F G H I J L M O P Chain
Weight
min max min max min max Dia
Number
kg. In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm In./mm lb./kg.
NX05 0-20 50408 1100 (0.5) 0 13/16 6 3/4 8 11/16 8 3/16 3 1/4 1 15/16 4 1/8 14 13/16 18 1/8 1 5/8 2 13/16 1 5/8 1/2 7/16 3 1/8 2 3/4 X 5 5/16 3/4 9.9
500 0 20 171 221 208 82 50 105 376 460 42 71 41 13 11 80 70 X 118 7 4.5
NXR05 0-100 50428 1100 (0.5) 04712 1/8 8 3/16 3 1/4 2 5/16 4 1/8 14 15/16 18 3/8 2 5/16 2 13/16 1 5/8 1/2 7/16 3 1/8 2 3/4 13/16 5 5/16 3/4 13.2
500 0 100 178 308 208 82 58 105 379 466 58 71 41 13 11 80 70 20 118 76
NXR05 20-120 50438 1100 (0.5) 13/16 4 1/4 8 12 7/8 8 3/16 3 1/4 2 5/16 4 1/8 14 15/16 17 9/16 2 5/16 2 13/16 1 5/8 1/2 7/16 3 1/8 2 3/4 13/16 5 5/16 3/4 12.8
500 20 120 203 327 208 82 58 105 380 446 58 71 41 13 11 80 70 20 118 7 5.8
NXR05 40-140 50448 1100 (0.5) 1 9/16 5 1/2 8 3/4 13 11/16 8 3/16 3 1/4 2 5/16 4 1/8 15 1/16 18 1/16 2 5/16 2 13/16 1 5/8 1/2 7/16 3 1/8 2 3/4 13/16 5 5/16 3/4 13.2
500 40 140 223 348 208 82 58 105 382 459 58 71 41 13 11 80 70 20 118 76
NX1.5 0-30 50418 3300 (1.5) 0 1 1/8 8 2/3 11 1/4 10 3/16 4 3/16 2 11/16 4 3/4 20 24 2 3/16 3 7/16 1 15/16 1/2 5/8 3 15/16 3 1/2 X 5 7/16 13/32 24
1 500 0 30 220 285 256 104 68 120 508 610 56 87 49 13 16 100 90 X 145 10 11

GENERAL CONDITION
Perform visual inspection and check that every component is clean and in good
condition.
FUNCTIONING
Return to authorized Tractel®repair centeris necessary in case of malfunction during
any of the following tests:
Position the clamp on a working surface. Operate the clamp opening handle without
bringing it at full stroke then release. The clamp should close freely. Check that the
chain is not twisted between its anchorage point and the chain guide.
Operate the clamp opening handle downwards at full stroke, until it locks in the open
position be triggered. The clamp remains in an open position. Then take the clamp
holding it by its body, and bring it home into a plate. The clamp must close
automatically when the plate enters in contact with the back of the throat.
NXR clamp: check that the cam shaft is in good condition and that the adjustment is correctly made in all
positions. The opening of the NXR models is adjustable by means of a pin in increments of 20 mm.
STRUCTURE CONDITION
Pads wear: the polyurethane coating must have a good adherence on the load.
Visual and tactile inspection: the polyurethane coating must be smooth, clean, soft and adhere when touched.
NX
Inspection of clamp before use
NX clamp inspection procedure
Find on clamp: serial number, type and manufacturing year.
Clamps over 10 years old must be replaced.
Opening
handle
Chain guide
NX
Polyurethane coated pads
Pads to be replaced Acceptable pads Brand-new pads Pads in contact with
each other
Deformation: the clamp structure must not be deformed.
Visual inspection. The clamp must be replaced, especially when any of
the following condition is not respected:
1. NX05-0-20, NX1.5-0-30 and NXR05-0-100 models: clamp closed, the pads
must be in contact with one another (adjust NXR clamp on the first position
before checking operation).
2. No chain link deformed or damaged.
Type
Year - Serial number
Min-Max Opening
Capacity
Record the inspection results
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
16

NX / NXR
Trouble shooting chart
Item Trouble Cause Solution Remarks Action
The springs are damaged Check carefully that
The clamp does not or missing. The cocking no other component Return to a Tractel®
1close freely. lever is deformed. Yes is damaged. ever is authorized repair center
The clamp is sticking. bent and rubbing
on the clamp.
The arming system of Fracture, deformation
2the clamp does not or failure of the arming Clamp need to be Return to a Tractel®
work (not blocking the system of the clamp Yes repaired. authorized repair center
opening of the clamp) (trigger)
ocking pin is bent New part required Return to a Tractel®
3or damaged Yes authorized repair center
NXR The adjustable locking The flanges of the clamp
model pin is no longer are deformed (the holes No Such deformation Clamp to be destroyed
only working do not match or are occurs only when and replaced
distorted). overloaded.
The polyurethane
coating is critical to
4Wear of the Check the wear of the be monitored. When
polyurethane on the polyurethane coating to loads start to slip the
pads ensure a good grip on Yes pads need replacing. Return to a Tractel®
the load. Degreasing is authorized repair center
recommended
regular and
systematic.
This is normal wear All chain products
5Deformation of a mainly related to link to Yes should have an Return to a Tractel®
component. link wear for the plate annual inspection authorized repair center
turning
Wear with possible Return to a Tractel®
6Poor condition of the Very Rare Yes constraints when authorized repair center
hardware lifting.
Such a rupture would Clamp to be destroyed
7Broken chain Clamp overloaded No occur in case of and replaced
overload
Do not use until a Return to a Tractel®
8Pin for the lifting ring Clamp been dropped Yes new approved pin is authorized repair center
is broken obtained
The springs are damaged Check carefully that
or missing. no component is Return to a Tractel®
Failure of the pads The cocking lever is Yes deformed and authorized repair center
9to close deformed. rubbing in the clamp
Such deformation Clamp to be destroyed
The clamp is deformed NO occurs only when and replaced
overloaded.
Wear at the joints of the Normal wear during use Yes Placement hardware Return to a Tractel®
10 assembly hardware required authorized repair center
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
17

KS / KSA / NK
Use and Installation
Clamps for lifting of steel plates, sections, welded-
plated assemblies, and structural steel.
These clamps are fitted with a spring mechanism
ensuring permanent contact of the cam against the
piece to be lifted.
N : this model is fitted with an automatic gripping
mechanism to clamp the plate when it is correctly
positioned, i.e. fully seated into the throat of the
clamp.
1) Open the clamp by pushing the red locking lever
(5/7) down ; S and SA until the trigger is
activated by locking it on the cleat. N : until the
trigger (8) is activated.
2) Fit the clamp onto the piece to be lifted, push it
home so that the throat is in contact with the
edge. Make sure the piece is fully seated.
3) S and SA: release the lever: the safety spring
is now activated, the cam (4) is locked against the
piece to be lifted.
N : the trigger (8) is released, the cam (6) comes
into contact with the plate, the red locking lever (7)
goes up: the clamp is now engaged.
4) The piece can be lifted as it is clamped by the
force of the weight.
5) Once the piece is moved and laid down, release
the clamp by opening it via the red locking
lever (5/7).
NOTE: concerning S1 t, 2 t and 3 t
models: The clamp may be held open by
pushing the red lever against the body of
the clamp, until the retainer pin on the
lever (5) is activated in its housing on the flange
(16). To release, pull the lever slightly outwards
so as to bring the lever pin out of its housing in
the flange.
S SA N
WARNING
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
18

KSA
Applications
Lifting of plates, iron beams, welded parts, steel frames
Lifting function: aways work on the axle of the clamp (Fig. 1) and never exceed the allowable
15° angle of the ring (Fig. 2).
Lifting of loads in a vertical position with 2 clamps and no lifting beam: do not exceed the 30° sling
angle and ensure the clamps are in line with the slings (Fig. 3).
Tilting or lifting of loads in a horizontal position is PROHIBITED. Use KS or NK clamps with chain for
these applications (Fig. 4).
Fig. 1
Fig. 3
Fig. 2
Fig. 4
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
19

S, SA and N Important Instructions
• Never Use on fragile loads. (For fragile items us
the NX series clamp)
• Never use for personnel lifting Strictly forbidden to
walk or be under the load.
• Never exceed the working load limit.
• Using this clamp marks the load. (For non-
marking use the NX series clamp)
• The plate or piece to be lifted must always be
driven home into the throat of the clamp.
• Surface hardness of pieces to be lifted: maxi. 300
Brinell ( S)/ 330 Brinell (N ) and minimum
29,000 PSI tensile strength (20 daN/mm²).
• Some stainless steels are particularly abrasive.
Inspect for wear of teeth of the cam in this case.
• When not in use, ensure clamps are always
unlocked (cam closed).
• Never lift more than one plate at a time.
• Apply the downgradation if necessary (see
sketch).
• The minimum weight of lifting load should be
equal to 5% of the clamp’s W (e.g. if clamps
W is 1 ton, then minimum weight is 100 lbs.).
This value is given for a clamp in new working
order and respecting Tractel®Inc. conditions of
use and recommendations. Consult Tractel®in
case of loads with weight less than the minimum
recommended value.
• ifting clamps are not suitable for creating
permanent joints. Working temperature: -20° to
+100°C.(-10º to +212ºF)
After an intensive period of use, the chain or ring
may show signs of elongation, wear, or other
damage which could cause the chain or ring to
break. It is therefore recommended that the lifting
chain is inspected regularly Corroded or cracked
links, distorted or twisted links, worn or
stretched links require that the unit be taken out
of service until replaced. A written inspection log
should be maintained.
WARNING
WARNING
SA
www.tractel.com
© Tractel®P4102 NA - rev 1 - 11/2010
20
