TradeQuip 2037T User manual

05/20 Product Code: 2037T
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment by professional users. With proven and trusted “Made for the
Trade” reliability, 'TradeQuip' branded products offer the very best in performance for an
affordable price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
Product Code: 2037T
HYDRAULIC PRESS
Specifications:
Safe Working Capacity: 50,000kg
Working Range: 0-1035mm
Overall Height: 1600mm
Overall Width: 1220mm
Overall Depth: 800mm
Bed Outside: 325mm
Bed Inside: 126mm
Bed Width: 650mm
Piston Ram Stroke: 235mm
Ram Diameter: 65mm
Bed Height Settings: 6
Nett Weight: 236kg
Carton: 1860 x 930 x 390mm
Gross Weight: 276kg

Product Code: 2037T
Made in China to TQB Brands Pty Ltd specifications Page 2
Visit us at www.tqbbrands.com.au
WARNING
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
WARNING
The instructions and warnings contained in this manual should be read and understood before using or operating this equipment.
Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough
understanding of how this equipment works. Failure to observe any of the instructions contained in the manual could result in
severe personal injury to the user or bystanders, or cause damage to the equipment and property. Keep this manual in a
convenient and safe place for future reference.
Whilst every effort has been made to ensure accuracy of information contained in this manual, the TQB Brands Pty Ltd policy of
continuous improvement determines the right to make modifications without prior warning.
CONTENT
WARNING............................................................................................................................................................................................ 2
CONTENT............................................................................................................................................................................................. 2
STANDARD OPERATING PROCEDURE ................................................................................................................................................. 3
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE.................................................................................................................... 4
PARTS LIST........................................................................................................................................................................................... 5
WARRANTY ......................................................................................................................................................................................... 7

Product Code: 2037T
Made in China to TQB Brands Pty Ltd specifications Page 3
Visit us at www.tqbbrands.com.au
WARNING
FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL INJURY
PRE-OPERATIONAL SAFETY CHECKS
Inspect the Hydraulic Workshop Press before each use. Do not use if bent, broken, cracked, leaking or otherwise damaged.
Ensure all bolts and nuts are firmly tightened.
Do not exceed the products rated maximum load capacity. Never apply excessive force to a work piece.
Steel and other materials can shatter, always wear approved impact goggles, heavy duty work gloves and appropriate clothing.
If you detect anything that may indicate imminent structural failure, stop using the hydraulic workshop press immediately
and inspect thoroughly.
Only use this hydraulic workshop press on a surface that is stable, level, dry and non-slippery, and capable of sustaining the
load. Keep the surface clean, tidy and free from unrelated materials and ensure that there is adequate lighting.
Do not use this hydraulic workshop press to compress springs or any other item that could disengage and cause a potential
hazard.
Keep hands and feet away from bed area at all times.
Do not modify any component of this equipment.
Only use this device for the purpose for which it has been designed.
When servicing, use only TradeQuip identical replacement parts. Use of any other parts will void the warranty.
Use the right product for the job. There are certain applications for which the Hydraulic workshop press was designed. Do not
modify the Hydraulic workshop press and do not use the Hydraulic workshop press for a purpose for which it was not
intended.
INTENDED USE
For regular professional straightening, bending & pressing. Removing and installing gears, bearings and bushings.
STANDARD OPERATING PROCEDURE
DO NOT use this machine unless you have been trained and assessed to a competent level in its sate use and operation, and
have been given permission to use this
Safety glasses must be worn when operating this
equipment
Long loose hair must be contained when operating
this equipment
Safety footwear must be worn when operating
this equipment
Close fitting/protective clothing must be worn
when operating this equipment
Rings and jewellery must not be worn when
operating this equipment

Product Code: 2037T
Made in China to TQB Brands Pty Ltd specifications Page 4
Visit us at www.tqbbrands.com.au
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE
1. FEATURES
The TradeQuip Hydraulic Workshop Press is a heavy duty hydraulic press. It is ideal for a variety of workshop applications and
in particular suited to automotive, agricultural or industrial use.
Jobs such as straightening, bending, folding, punching, removing bolts and bearings etc are some of tasks that may be
accomplished by your Hydraulic Workshop Press.
2. ASSEMBLY
Unpacking: after removing the packing material, make sure the product is in perfect condition and that there are no visible
damaged parts. The packaging materials (Polyethylene bags, polystyrene etc.), must be disposed of in an appropriate refuse
collection container. These materials must not be left within the reach of children as they are potential sources of danger.
Identify and lay out parts. Bolt the cross legs to the bottom of the main frames.
Bolt the upper crossbeams to the head of the main frames. Note. If your model has a top and bottom plate which attach
to either side of the frame head, screw the nuts finger tight only at this stage.
Attach the hydraulic ram and pump (according to model) should your model have a separate jack plate, check side of
main frame to locate assembly holes. If you have a choice of left or right attachment, assemble the plate according to
your operational requirement.
Attach the ram unit to the mounting plate or to the appropriate attachment bars incorporated in the main frame using
the bolts provided.
Insert the press platform support pins through the holes in the main frame. Taking firm hold of the platform, tip it into a
diagonal position so that it can be introduced between the mainframe uprights and carefully lower it back to a horizontal
position to rest on the support pins.
WARNING! Take care not to allow the press plate to drop onto the pins and ensure your hands and fingers are clear of the
press plate when lowering.
3. BEFORE USE
Prior to each use conduct a visual inspection by checking for abnormal conditions, such as cracked and damaged, loose, or missing parts.
Installation
Securely attach the press to a flat, firm, level surface taking into account clearance for working pieces.
Before operating the press, purge the hydraulic system in order to eliminate any air that may have built up during transit. Open the
release valve and pump the handle several times and close the release valve. Should the system malfunction at any time, repeating
this process may resolve the problem.
DANGER!
Models are purpose designed to withstand greater loads than the hydraulic units can develop. For safety reasons, always ensure the
workpiece and press tools are secured on the table and will not flex or suddenly “give way” causing danger to operator or the
component. Also ensure you have read and understood safety instructions.
& operating
4. OPERATION
Check that the hydraulic unit is fully closed ready for operating.
Position the bed frame at the required operating height by inserting the support pins into the appropriate holes in the main frame.
Position the heel blocks or press tools to be used onto the bed frame and align beneath the ram. Place workpiece onto the bed frame
or heel blocks and align beneath the ram as required. Note: Care must be taken to ensure a heel block does not fall from the press bed
frame. If necessary hold the configuration in position with clamps.
Operate the pump slowly until the ram is close to or just touching the workpiece.
Before applying real pressure to the workpiece recheck the alignment with the ram and ensure that the workpiece and press tools are
supported in such a way that they cannot flex to breaking point. DO NOT exceed the stroke indicated on the label or the mark on the
piston and do not apply off centre loads.
When work is complete release the pressure using the release valve and the piston and the ram head will retract automatically.
Note: Always keep the piston retracted after use to avoid corrosion
5. STORAGE
This Hydraulic Workshop Press should always be stored in a dry location with the ram and piston fully retracted on a level surface.

Product Code: 2037T
Made in China to TQB Brands Pty Ltd specifications Page 5
Visit us at www.tqbbrands.com.au
6. MAINTENANCE
Check all fittings are tight before each use.
Lubricate all joints and moving parts with light oil at regular intervals.
Always keep the press clean, dry, and protected from harsh conditions.
Regularly check the hydraulic oil level by removing the oil filler nut on top of the reservoir. Should you need to top up or replace the
oil ensure you use good quality hydraulic jack oil. Then replace and tighten the oil filler nut. NOTE an excess of oil will render the press
inoperative.
Use only appropriate good quality hydraulic jack oil. DO NOT use brake fluid. Contact your local distributor for details.
Always purge the system to remove any air.
7. SERVICE & REPAIR
Any Hydraulic Workshop Press found damaged in any way, or found to be worn or operates abnormally should be removed from service
until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product may require specialised
equipment and knowledge. Only authorised parts, labels and decals shall be used on this equipment. Annual inspection of the Hydraulic
workshop press is recommended and can be made by an authorised repair facility to ensure that your equipment is in optimum condition
and that the equipment has the correct decals and safety labels specified by the manufacturer.
PARTS LIST
Part #
Description
QTY
Part #
Description
QTY
1
Base cross legs
2
24
Pulley
1
2
Stabiliser plates
4
25
Heel Block
2
3
Main Post Uprights
2
26
Ram Unit
1
4
Bottom Brace Plates
2
27
Upper Brace Plates
2
5
Bed Frame Pins
2
28
Pump Handle
4
19
Winch
1
29
Hydraulic Pump
1
23
Bed Frame
1
39
Pressure Gauge
1

Product Code: 2037T
Made in China to TQB Brands Pty Ltd specifications Page 6
Visit us at www.tqbbrands.com.au
Part #
Description
QTY
1
Knob
1
2
Pin 5x24
1
3
Release Valve
1
4
O-ring
1
5
Ball Valve
5
6
Handle Bracket
1
7
Pin
3
8
Joint Pole
1
9
Pole Seat
1
10
Piston
1
11
J-Ring
1
12
Pump Housing
1
13
Base
1
14
Bolt M8x12
4
15
Spring
2
16
Ball Valve
2
17
Ball Seat
2
18
Spring Safety Valve
2
19
Screw Safety
2
20
Nut MB
4
21
Cover
1
22
O-Ring
1
23
Reservoir
1
24
Oil Gasket
1
25
O-Ring
1
26
Stay Bar
4
27
Air Pump
1
28
Spring
2
29
O-Ring
2
30
Bolt
3
31
O-Ring
1
32
Washer
1
Part #
Description
QTY
1
Pressure Head
1
2
Spring Plate
1
3
Guide Sleeve
1
4
Locking Screw M8x10
1
5
Piston Rod
5
6
O-Ring Kit
1
7
Piston Head
3
8
O-Ring Kit
1
9
Piston Seal Ring
1
10
O-Ring Kit
1
11
Nut M42x1.5
1
12
Cylinder Assembly
1
13
Extension Spring
2
14
Soleplate
1
15
Permanent Pole
1
16
Extension Spring Bolt
2
17
Tie-in
1
18
Nut
1
19
Rectangle Ring Kit
1
20
Bolt M20x25
1

Product Code: 2037T
Made in China to TQB Brands Pty Ltd specifications Page 7
Visit us at www.tqbbrands.com.au
WARRANTY
TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective
materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the
guarantee period is ninety days from the date of purchase.
Should this piece of equipment develop any fault, please return the complete tool to your nearest authorised warranty repair
agent or contact TQB Brands Pty Ltd Warranty team –[e-mail].
If upon inspection it is found that the fault occurring is due to defective materials or workmanship, repairs will be carried out free
of charge. This guarantee does not apply to normal wear and tear, nor does it cover any damage caused by misuse, careless or
unsafe handling, alterations, accident, or repairs attempted or made by any personnel other than the authorised TQB Brands Pty
Ltd repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised.
Your TQB Brands Pty Ltd guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your
proof of purchase within the 12 month period.
Consumer Guarantee
Our goods come with a guarantee that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have
the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
All images and illustrations shown are for reference purposes only. All information, specifications and illustrations in this manual are based on
the latest information available at the time of publication and are subject to change without notice. The information in this manual is periodically
revised to ensure the latest information is included. Download the latest version of this manual and other related technical documentation from
www.tqbbrands.com.au.
