TradeQuip 9845 User manual

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
OWNER’S MANUAL
PRODUCT CODE: 9845
24V 1/2" DRIVE CORDLESS IMPACT WRENCH
Battery
Power
Charge
Time
Maximum
Torque
Impact
Rate
No-Load
Speed
LED
Work Light
2x 24V Li
1 Hour
450Nm
0-3,000min
0-2,200min
Yes

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications Page 2
Visit us at www.tqbbrands.com.au
WARNING
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
WARNING
The instructions and warnings contained in this manual should be read and understood before
using or operating this power tool. Do not allow anyone to use or operate this power tool until
they have read this manual and have developed a thorough understanding of how this tool
works. Failure to observe any of the instructions contained in the manual could result in severe
personal injury to the user or bystanders, or cause damage to the power tool and property.
Keep this manual in a convenient and safe place for future reference.
Whilst every effort has been made to ensure accuracy of information contained in this manual,
the TQB Brands Pty Ltd policy of continuous improvement determines the right to make
modifications without prior warning.
CONTENT
WARNING .....................................................................................................................................2
CONTENT ......................................................................................................................................2
SAFETY INSTRUCTIONS .................................................................................................................3
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE..............................................................7
WARRANTY.................................................................................................................................12

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications Page 3
Visit us at www.tqbbrands.com.au
SAFETY INSTRUCTIONS
WARNING
FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL
INJURY.
SAFETY OPERATNG INSTRUCTIONS
The term "power tool" in the warnings refers to your battery-operated
(cordless) power tool.
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the
dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Electrical safety
Power tool charger plugs must match the outlet. Never modify the plug in any way.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
Do not expose this power tool or charger to rain or wet conditions. Water entering a
power tool and charger will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
charger. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
When operating a power tool charger outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.
If operating a power tool charger in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of electric
shock.
Personal safety
Stay alert, watch what you are doing and use common sense when operating this
cordless power tool. Do not use a cordless power tool while you are tired or under
the influence of drugs, alcohol or medication. A moment of inattention whilst
operating cordless power tools may result in serious personal injury.

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications Page 4
Visit us at www.tqbbrands.com.au
Use personal protective equipment. Always wear eye protection. Protective
equipment such as a hearing protection, hand protection and non-skid safety shoes
for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-position before picking
up or carrying the power tool. Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites accidents.
Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
Power tool use and care
Do not force the power tool. Use your power tool for the correct application. The
correct power tool will do the job better and safer at the rate for which it was
designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
Battery tool use and care
Recharge only with the charger specified by the manufacturer. A charger that is
suitable for one type of battery pack may create a risk of fire when used with
another battery pack.
Use power tools only with specifically designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the battery terminals together
may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery pack; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the battery pack may cause
irritation or burns.

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications Page 5
Visit us at www.tqbbrands.com.au
Batteries
Never attempt to open the battery for any reason.
Do not store in locations where the temperature may exceed 45°C.
Charge only at ambient temperatures between 4°C and 45°C.
Charge only using the compatible charger for this battery.
When disposing of batteries, follow the instructions given in the section “Recycling”.
Do not cause short circuits. If connection is made between the positive (+) and
negative (-) terminal directly or via accidental contact with metallic objects, the
battery pack is short circuited and an intense current will flow causing heat
generation which may lead to causing rupture or fire.
Do not heat. If batteries are heated to above 100°C, sealing and insulating separators
and other polymer components may be damaged resulting in electrolyte leakage
and/or internal short circuiting leading to heat generation causing rupture or fire.
Moreover do not dispose of the batteries in fire, explosion and/or intense burning
may result.
Under extreme conditions, battery pack leakage may occur. When you notice liquid
on the battery pack, proceed as follows: Carefully wipe the liquid off using a cloth
while wearing gloves. Avoid skin contact.
In case of skin or eye contact, follow the instructions below:
Immediately rinse with water. Neutralize with a mild acid such as lemon juice or
vinegar.
In case of eye contact, rinse abundantly with clean water for at least 10
minutes. Consult a physician.
Then contact TQB Brands Pty Ltd.
Fire hazard! Avoid short-circuiting the contacts of a detached battery pack. Do not
incinerate the battery pack.

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications Page 6
Visit us at www.tqbbrands.com.au
Chargers
Only use the charger suitable for this tool to charge the battery pack
Never attempt to charge non-rechargeable batteries.
Have defective cords replaced immediately.
Do not expose to water.
Do not open the charger.
Do not probe the charger.
The charger is intended for indoor use only.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the power tool by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the power tool. If the
charger supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications Page 7
Visit us at www.tqbbrands.com.au
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE
1. FEATURES
The Tradequip cordless 1/2" Drive Impact Wrench is one of the most powerful 1/2in.
impact wrenches in its class and offers the best power to size ratio among like
competitors. Featuring a powerful 24V motor and optimized impact mechanism, this
impact driver delivers up to 2,000rpm, 3,000ipm and 450Nm (353ftlb) of fastening torque
for ultimate performance. RedLink™ Intelligence provides optimized performance and
overload protection using total system communication between tool, battery and
charger. The 2.0Ah battery packs deliver more work per charge and longer pack life. The
9845 Cordless 1/2in Drive Impact Wrench features a 1/2in. pin detent anvil for maximum
socket retention, an LED light to illuminate work surfaces, and includes 2 Lithium Ion
2.0Ah batteries, 240V fast charger and carrying case.
2. BEFORE USE
Prior to each use conduct a visual inspection checking for abnormal conditions, such as
damaged, loose, or missing parts. Remove all packaging materials.
Check that the package contents are complete.
Check the power tool, and all accessories for transportation damage.
Keep the packing materials as far as possible till the end of the warranty period.
Dispose of it responsibly, into your local waste disposal recycle system afterwards.

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications Page 8
Visit us at www.tqbbrands.com.au
3. ASSEMBLY
Selecting correct socket
Always use the correct size socket for bolts and nuts. An incorrect size socket will result in
inaccurate and inconsistent fastening torque and /or damage to the bolt or nut.
Installing or removing socket
Always be sure that the tool is switched off and the battery pack is removed before
installing or removing the socket.
To install the socket, push it onto the anvil of the tool until it locks into place. To
remove the socket, simply pull it off.

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications Page 9
Visit us at www.tqbbrands.com.au
4. OPERATION
Charging the battery pack (Fig. 2)
The battery packs for this power tool will be supplied in a low charge condition to
prevent possible problems, therefore, you have to charge the battery pack before first
use.
Note: Batteries will not reach full charge the first time they are charged. Allow several
cycles for the item to fully charge. The battery pack should only be charged indoors.
After normal use, about 1 hour of charging time is required for the battery pack to
be fully charged.
The battery pack will become slightly warm whilst charging, this is normal and does
not indicate a problem.
Do not place the charger in an area of extreme heat or cold. Best is at normal room
temperature.
Charging indication
The battery charger has 2 LED lights (red and green).
Slide the battery pack(5) into the charger(9) as shown in Fig. 2. Make sure there is
proper contact with the charger.
When charging the green LED is constantly lit and the red LED is flashing.
When fully charged both LED lights will be constantly lit.
Inserting and removing the battery pack(Fig. 3)
Remove the battery pack (5) by pressing the battery pack release button (4) and at
the same time pull/slide the battery pack off the battery charger.
To insert the battery pack, push the battery pack onto the contacts of the tool.
Switch on/off (Fig. 4)
The impact wrench is started and stopped by pressing and releasing the ON/OFF
switch trigger (6).
This impact wrench is equipped with an electric brake, when the ON/OFF switch
trigger (6) is released completely, the chuck stops immediately.
Switch lock
The ON/OFF switch trigger (6) can be locked if the forward/reverse knob (2) is in
the centre position. (Fig. 5)
This helps to reduce the possibility of accidental starting when not in use.

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications Page 10
Visit us at www.tqbbrands.com.au
Direction of rotation (Fig. 6)
To select forward rotation, release the ON/OFF switch trigger (6) and push the
forward/reverse knob (2) to the left side of the tool.
To select reverse rotation, push the forward/reverse knob (2) to the right side of
the tool.
When the forward/reverse knob (2) is in centre position, the ON/OFF switch trigger
(6) is locked.
Variable speed
This tool has a variable speed ON/OFF switch trigger (6) that delivers higher speed
and torque with increased trigger pressure.
Speed is controlled by the amount of pressure on the ON/OFF switch trigger (6).
5. INSPECTION
Prior to each use conduct a visual inspection checking for abnormal conditions, such
as cracked welds, leaks, and damaged, loose, or missing parts.
The cordless impact wrench shall be maintained in accordance with the maintenance
instructions. No alterations or modifications shall be made to this cordless impact
wrench.
Inspections shall be performed in accordance with this owner’s manual.
The cordless impact wrench must be inspected immediately if it is believed to have
been subjected to abnormal load or shock.
Owners and /or operators should be aware that repair of this product may require
specialised equipment and knowledge (refer to maintenance section).
6. STORAGE
This cordless impact wrench should always be stored in a dry location.
Always REMOVE THE BATTERY PACK for storage.
Thoroughly clean the whole machine and its accessories.
Store it out of the reach of children, in a stable and secure position, in a cool and dry
place, avoid too high and too low temperatures.
Protect it from exposure to direct sunlight. Keep it in the dark, if possible.
Don’t keep it in plastic bags to avoid humidity build-up.

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications Page 11
Visit us at www.tqbbrands.com.au
7. MAINTENANCE
Always REMOVE THE BATTERY PACK before clean or repair.
Always be sure that the tool is switched off and battery pack is removed before
performing any inspection ,maintenance or cleaning.
Keep the ventilation slots of the machine free from dust and dirt to prevent
overheating of the engine.
Regularly clean the machine housing with a soft cloth, preferably after each use. If
the dirt does not come off, use a soft cloth moistened with soapy water.
Never use solvents such as petrol, alcohol, ammonia water, etc. These solvents may
damage the plastic parts.
8. SERVICE & REPAIR
Any cordless impact wrench found damaged in any way, or found to be worn or operates
abnormally should be removed from service until repaired by an authorised service agent.
Owners and / or operators should be aware that repair of this product may require
specialised equipment and knowledge. Only authorised parts, labels, decals shall be used
on this equipment. Annual inspection of the cordless impact wrench is recommended
and can be made by an authorised repair facility to ensure that your equipment is in
optimum condition and that the equipment has the correct decals and safety labels
specified by the manufacturer.

Product Code: 9845
Made in China to TQB Brands Pty Ltd specifications Page 12
Visit us at www.tqbbrands.com.au
WARRANTY
Tradequip products have been carefully tested and inspected before shipment and are
guaranteed to be free from defective materials and workmanship for a period of 12 months
from the date of purchase except where tools are hired out when the guarantee period is
ninety days from the date of purchase.
Should this piece of equipment develop any fault, please return the complete tool to your
nearest authorised warranty repair agent or contact TQB Brands Pty Ltd Warranty team –
[email protected].
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee does not apply to
normal wear and tear, nor does it cover any damage caused by misuse, careless or unsafe
handling, alterations, accident, or repairs attempted or made by any personnel other than the
authorised TQB Brands Pty Ltd repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its
terms are not authorised.
Your TQB Brands Pty Ltd guarantee is not effective unless you can produce upon request a
dated receipt or invoice to verify your proof of purchase within the 12 month period.
Consumer Guarantee
Our goods come with a guarantee that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for any
other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
