TrailFX G9022B User manual

www . T r a il F X . c om
Page 1of 3 Rev 080515
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT.
READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.
DO NOT OVER TORQUE.STANDARD OPERATING LOAD FOR TIGHTEN
BODY MOUNT NUTS & BOLTS VARIES FROM
45
TO
65
FOOT POUND.
60-180 min
[e-mail]
1 866 638 4870
POLISHED STAINLESS STEEL –LIMITED LIFETIME
POWDER COATED BLACK –3 YEARS
PARTS LIST:
Qty
Part Description
Qty
Part Description
2
Upper connecting plate
2
M6×20 Button head bolt
2
Lower connecting plate
2
6mm Flat washer
2
Plastic ring
1
S=4 Wrench
1. Notes:
2. Please read through the instruction carefully before installation and pay attention to protect the surface of your vehicle.
3. Check all fastens at a certain period for safety use.
4. Functions and Features
5. Made from Aluminum with smooth surface, have better anti-corrosion ability
6. Special design offers a nice and distinctive look.
`
Tube Clamp
Part No. G9022B
Fits: Universal tube clamp for 2" Tube
網址：http：//www.winbo4x4.com 網絡實名：銳搏.汽車防撞杠.越野改裝
網址：http：//www.winbo4x4.com 網絡實名：銳搏.汽車防撞杠.越野改裝
Drilling Not
Required
Cutting Not
Required
Parts Pic

www . T r a il F X . c om
Page 2of 3 Rev 080515
網址：http：//www.winbo4x4.com 網絡實名：銳搏.汽車防撞杠.越野改裝
網址：http：//www.winbo4x4.com 網絡實名：銳搏.汽車防撞杠.越野改裝
佛山市順德區東箭汽車用品制造有限公司
WINBO-DONGJIAN AUTO ACCESSORIES MANUFACTURING CO.,LTD
佛山市順德區東箭汽車用品制造有限公司
WINBO-DONGJIAN AUTO ACCESSORIES MANUFACTURING CO.,LTD
Installation Procedures
First step
：
Put the plastic ring on the tube and slide the light tab to the suitable position to make it sit around the plastic rings, see Pic1.
Second step: Install the lights on the tabs see pic2.
Pic2
Pic1

www . T r a il F X . c om
Page 3of 3 Rev 080515
1. Hardware’s are not of correct size.
In GMC / Chevrolet truck model 2006 & up, customer needs to reuse the factory body bolts to install the bracket. If your vehicle is not
GMC / Chevrolet 2006 & up, ensure that holes are not partially covered with any plastic grommet or rust? If it is, remove the plastic
grommet & rust from the thread holes & re-try the installation.
2. Mounting Bracket are not getting Installed properly.
In some cases Illustration images shown in Installation manual may not be the exactly same as per actual vehicle images ,also if Driver /
Passenger side mounting brackets are very identical in the design, suggest referring Parts Identification guide to avoid fitment issue.
3. Products are thumping / rattling after installation.
Ensure that all required mounting brackets / hardware’s are installed & tighten correctly. Suggest using white lithium / regular grease
between the metal to metal contact surfaces.
4. Side Bar is not aligning with vehicle / Step Pads are not aligning with vehicle doors.
Side bar may be interchanged or mounting brackets are not installed at the correct position in the vehicle. Refer Parts identification guide.
5. Missing / Excess Hardware.
Recheck hardware count as per the part list.
6. Product not installing properly.
Ensure make model year, cab length and bed size of your vehicle is listed in the application. All installation steps are followed correctly.
Check out these other TrailFX Products!! www.TrailFX.com
Periodically check the product to ensure all fasteners are tight and components are intact.
Regular waxing is recommended to protect the finish of the product.
Use ONLY Non-Abrasive automotive wax. Use of any soap, polish or wax that contains an abrasive is detrimental and can scratch the
finish leading to corrosion.
Aluminum polish may be used to polish small scratches and scuffs for Stainless Steel finish.
Mild soap may be used to clean the product for both Stainless Steel and Black finish.
Keystone Automotive Operations Inc. (KAO) warrants this product to be free of defects in material and workmanship at the time of purchase by the
original retail consumer. KAO disclaims any other warranties, express or implied, including the warranty of fitness for a particular purpose or an
intended use. If the product is found to be defective, KAO may replace or repair the product at our option, when the product is returned prepaid,
with proof of purchase. Alteration to, improper installation, or misuse of this product voids the warranty. KAO’s liability is limited to repair or
replacement of products found to be defective, and specifically excludes liability for any incidental or consequential loss or damage.
