Trane Technologies Thermo King T Series User manual

Revision A
June 2020 TTKK 6600448833--11--OOPP--EENN
T-Series
Single and Multi-Temperature Systems
T-1200 , T-1200 Intermodal, T-1000 , T-800 , T-600 , T-560
T-1200 SPECT UM, T-1000 SPECT UM, T-800 SPECT UM
Operator’s Manual

2TK 60483-1-OP-EN
Introduction
This manual is published for informational purposes only and the
information furnished herein should not be considered as all-inclusive or
meant to cover all contingencies. If more information is required, consult
your Thermo King Service Directory for the location and telephone number
of the local dealer.
TThheerrmmoo KKiinngg’’ss wwaarrrraannttyy sshhaallll nnoott aappppllyy ttoo aannyy eeqquuiippmmeenntt wwhhiicchh hhaass
bbeeeenn ““ssoo iinnssttaalllleedd,, mmaaiinnttaaiinneedd,, rreeppaaiirreedd oorr aalltteerreedd aass,, iinn tthhee
mmaannuuffaaccttuurreerr’’ss jjuuddggmmeenntt,, ttoo aaffffeecctt iittss iinntteeggrriittyy..””
MMaannuuffaaccttuurreerr sshhaallll hhaavvee nnoo lliiaabbiilliittyy ttoo aannyy ppeerrssoonn oorr eennttiittyy ffoorr aannyy
ppeerrssoonnaall iinnjjuurryy,, pprrooppeerrttyy ddaammaaggee oorr aannyy ootthheerr ddiirreecctt,, iinnddiirreecctt,, ssppeecciiaall,,
oorr ccoonnsseeqquueennttiiaall ddaammaaggeess wwhhaattssooeevveerr,, aarriissiinngg oouutt ooff tthhee uussee ooff tthhiiss
mmaannuuaall oorr aannyy iinnffoorrmmaattiioonn,, rreeccoommmmeennddaattiioonnss oorr ddeessccrriippttiioonnss
ccoonnttaaiinneedd hheerreeiinn.. TThhee pprroocceedduurreess ddeessccrriibbeedd hheerreeiinn sshhoouulldd oonnllyy bbee
uunnddeerrttaakkeenn bbyy ssuuiittaabbllyy qquuaalliiffiieedd ppeerrssoonnnneell.. FFaaiilluurree ttoo iimmpplleemmeenntt tthheessee
pprroocceedduurreess ccoorrrreeccttllyy mmaayy ccaauussee ddaammaaggee ttoo tthhee TThheerrmmoo KKiinngg uunniitt oorr
ootthheerr pprrooppeerrttyy oorr ppeerrssoonnaall iinnjjuurryy..
There is nothing complicated about operating and maintaining your Thermo
King unit, but a few minutes studying this manual will be time well spent.
Performing pre-trip checks and enroute inspections on a regular basis will
minimize operating problems. A regular maintenance program will also help
to keep your unit in top operating condition. If factory recommended
procedures are followed, you will find that you have purchased the most
efficient and dependable temperature control system available.
All service requirements, major and minor, should be handled by a Thermo
King dealer for four very important reasons:
• They are equipped with the factory recommended tools to perform all
service functions
• They have factory trained and certified technicians
• They have genuine Thermo King replacement parts
• The warranty on your new unit is valid only when the repair and
replacement of component parts is performed by an authorized Thermo
King dealer
Machine Information Policy
Use of this product serves as acceptance of the Thermo King Machine
Information Policy available at: www.europe.thermoking.com. This product

TK 60483-1-OP-EN 3
includes a standard feature that collects and shares Machine Information
with Thermo King. Separate terms may apply when a customer has entered
into an agreement with Thermo King. Customers that would like to opt-out
of sharing Machine Information with Thermo King should forward such
inquiries to the email address [email protected].
Software License
The product includes software that is licensed under a non-exclusive, non-
sublicensable, terminable and limited license to use the software as installed
on the product for its intended purpose. Any removal, reproduction, reverse
engineering, or other unauthorized use of the software is strictly prohibited.
Hacking the product or installing unapproved software may void the
warranty. The owner or operator shall not reverse engineer, decompile, or
disassemble the software, except and only to the extent that such activity is
expressly permitted by applicable law notwithstanding this limitation. The
product may include third party software separately licensed as specified in
any documentation accompanying the product or in an about screen on a
mobile application or website that interfaces with the product.
Emer ency Assistance
Thermo Assistance is a multi-lingual communication tool designed to put
you in direct contact with an authorized Thermo King dealer.
TThheerrmmoo AAssssiissttaannccee sshhoouulldd oonnllyy bbee ccoonnttaacctteedd ffoorr bbrreeaakkddoowwnn aanndd rreeppaaiirr
aassssiissttaannccee..
To use this system, you need the following information before you call:
(phone charges will apply)
• Contact Phone Number
• Type of TK Unit
• Thermostat Setting
• Present Load Temperature
• Probable Cause of Fault
• Warranty Details of the Unit
• Payment Details for the epair
Leave your name and contact number and a Thermo Assistance Operator
will call you back. At this point you can give details of the service required
and the repair will be organized.
IInnttrroodduuccttiioonn

4TK 60483-1-OP-EN
Please note that Thermo Assistance cannot guarantee payments and the
service is designed for the exclusive use of refrigerated transporters with
products manufactured by Thermo King Corporation.
General Inquires and Unit Maintenance
For general inquiries please contact your local Thermo King dealer.
Go to www.europe.thermoking.com and select dealer locator for your local
Thermo King dealer.
Or refer to the Thermo King Service Directory for contact information.
IInnttrroodduuccttiioonn

TK 60483-1-OP-EN 5
Customer Satisfaction Survey
Let your voice be heard!
Your feedback will help improve our manuals. The survey is accessible
through any internet-connected device with a web browser.
Scan the Quick esponse (Q ) code or click or type the web address https://
tranetechnologies.iad1.qualtrics.com/jfe/form/SV_2octfSHoUJxsk6x?Q_
CHL=qr&Q_JFE=qdg to complete the survey.
IInnttrroodduuccttiioonn

6TK 60483-1-OP-EN
SSaaffeettyy................................................................................................................ 99
Danger, Warning, Caution, and Notice . . . . . . . . . . . . . . . . . . . . . . . . 9
General Safety Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Automatic Start/Stop Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Battery Installation and Cable outing . . . . . . . . . . . . . . . . . . . . . . . 11
efrigerant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
efrigerant Oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
FirstAid................................................... 14
Safety Decals and Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
emote Start of the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
efrigerant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Do Not Use Ether Starting Aids . . . . . . . . . . . . . . . . . . . . . . . . . . 18
UUnniitt DDeessccrriippttiioonn............................ ........ .. .... ........ .. .... .. ........ .... .. ........ .... .. .. 1199
General Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Engine.................................................... 19
eciprocating Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Extended Life Coolant (ELC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Clutch .................................................... 21
EMI3000.................................................. 21
HMI Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Standard HMI Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Premium HMI Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
T-Series Intermodal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
CYCLE-SENT Y™Start-Stop Controls. . . . . . . . . . . . . . . . . . . . . . . 24
Telematics as Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Table of Contents

TK 60483-1-OP-EN 7
Further Communication Capabilities . . . . . . . . . . . . . . . . . . . . . 24
Defrost ................................................... 25
Engine Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Unit Protection Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Pharma................................................... 27
MMaannuuaall PPrreettrriipp IInnssppeeccttiioonn ((BBeeffoorree SSttaarrttiinngg tthhee
UUnniitt)) ................ .... .. ........ .. .... ........ .. .... ........ .. .... .. ........ .... .. ........ .... .. ........ .... .. .... 3300
OOppeerraattiinngg IInnssttrruuccttiioonnss .. .. .... .. .... ........ .. .... ........ .. .... .. ........ .... .. ........ .... .. .. 3333
TS -3 Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Basic HMI Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Display .............................................. 33
Keys and LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Turning the Unit On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
The Standard Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Premium HMI Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
TT--SSeerriieess IInntteerrmmooddaall ...................................... 45
AAllaarrmm CCooddeess.. .. .. ........ .. .... ........ .. .... ........ .. .... .. ........ .... .. ........ .... .. ........ .... .. .... 4477
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
LLooaaddiinngg aanndd EEnnrroouuttee IInnssppeeccttiioonnss .. .. .. .... .. .... .... ...... .... .. ........ .... .. .... 4488
Inspecting the Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Enroute Inspections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
SSppeecciiffiiccaattiioonnss .................. ........ .... .. ........ .... .. ........ .. .... ........ .. .... ........ .. .... .... 5522
Engine.................................................... 52
Fuses..................................................... 53
Electrical Control System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
TTaabbllee ooff CCoonntteennttss

8TK 60483-1-OP-EN
Electric Heater Strips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Standby Power equirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
efrigeration System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
TracKing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
WWaarrrraannttyy.. .. .... .. .... ...... .... .... .. ........ .... .. ........ .. .... ........ .. .... ........ .. .... ........ .. .... .. .. 5577
MMaaiinntteennaannccee IInnssppeeccttiioonn SScchheedduullee .. .. ...... .. .... ........ .. .... .. ........ .... .. .. 5588
Inspection and Service Intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
SSeerriiaall NNuummbbeerr LLooccaattiioonnss .... .. .. ........ .. .... .. ........ .... .. ........ .... .. ........ .. .... .. 5599
eeccoovveerr eeffrriiggeerraanntt.... .. ...... .... .... ...... .... .... .. ........ .. .... ........ .. .... ........ .. .... .. 6611
TTaabbllee ooff CCoonntteennttss

TK 60483-1-OP-EN 9
Safety
Dan er, Warnin , Caution, and Notice
Thermo King®recommends that all service be performed by a Thermo King
dealer and to be aware of several general safety practices.
Safety advisories appear throughout this manual as required (refer to
examples below). Your personal safety and the proper operation of this unit
depend upon the strict observance of these precautions.
DDAANNGGEE
EExxaammppllee!!
Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WWAA NNIINNGG
EExxaammppllee!!
Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CCAAUUTTIIOONN
EExxaammppllee!!
Indicates a potentially hazardous situation which, if not avoided, could
result in minor or moderate injury and unsafe practices.
NN TTIICCEE
EExxaammppllee!!
Indicates a situation that could result in equipment or property-damage
only accidents.

10 TK 60483-1-OP-EN
General Safety Practices
DDAANNGGEE
iisskk ooff IInnjjuurryy!!
Keep hands and loose clothing clear of fans and belts at all times when the
unit is operating with the doors open.
WWAA NNIINNGG
iisskk ooff IInnjjuurryy!!
Do not apply heat to a closed cooling system. Before applying heat to a
cooling system, drain it. Then flush it with water and drain the water.
Antifreeze contains water and ethylene glycol. The ethylene glycol is
flammable and can ignite if the antifreeze is heated enough to boil off the
water.
WWAA NNIINNGG
iisskk ooff IInnjjuurryy!!
Temperatures above 120 degrees F (50 degrees C) can cause serious burns.
Use an infrared thermometer or other temperature measuring device
before touching any potentially hot surfaces.
CCAAUUTTIIOONN
SShhaarrpp EEddggeess!!
Exposed coil fins can cause lacerations. Service work on the evaporator or
condenser coils is best left to a certified Thermo King technician.
SSaaffeettyy

TK 60483-1-OP-EN 11
Automatic Start/Stop Operation
CCAAUUTTIIOONN
iisskk ooff IInnjjuurryy!!
The unit can start and run automatically any time the unit is turned on. Turn
the Microprocessor On/Off switch Off before doing inspections or working
on any part of the unit. Please note that only Qualified and Certified
personnel should attempt to service your Thermo King unit.
Battery Installation and Cable Routin
WWAA NNIINNGG
HHaazzaarrdd ooff EExxpplloossiioonn!!
An improperly installed battery could result in a fire, explosion, or injury. A
Thermo King approved battery must be installed and properly secured to
the battery tray.
WWAA NNIINNGG
HHaazzaarrdd ooff EExxpplloossiioonn!!
Improperly installed battery cables could result in a fire, explosion, or
injury. Battery cables must be installed, routed, and secured properly to
prevent them from rubbing, chaffing, or making contact with hot, sharp, or
rotating components.
SSaaffeettyy

12 TK 60483-1-OP-EN
WWAA NNIINNGG
FFiirree HHaazzaarrdd!!
Do not attach fuel lines to battery cables or electrical harnesses. This has
the potential to cause a fire and could cause serious injury or death.
WWAA NNIINNGG
PPeerrssoonnaall PPrrootteeccttiivvee EEqquuiippmmeenntt ((PPPPEE)) eeqquuiirreedd!!
A battery can be dangerous. A battery contains a flammable gas that can
ignite or explode. A battery stores enough electricity to burn you if it
discharges quickly. A battery contains battery acid that can burn you.
Always wear goggles or safety glasses and personal protective equipment
when working with a battery. If you get battery acid on you, immediately
flush it with water and get medical attention.
WWAA NNIINNGG
HHaazzaarrdd ooff EExxpplloossiioonn!!
Always cover battery terminals to prevent them from making contact with
metal components during battery installation. Battery terminals grounding
against metal could cause the battery to explode.
CCAAUUTTIIOONN
HHaazzaarrddoouuss SSeerrvviiccee PPrroocceedduurreess!!
Set all unit electrical controls to the OFF position before connecting battery
cables to the battery to prevent unit from starting unexpectedly and causing
personal injury.
NN TTIICCEE
EEqquuiippmmeenntt DDaammaaggee!!
Do not connect other manufacturer’s equipment or accessories to the unit
unless approved by Thermo King. Failure to do so can result in severe
damage to equipment and void the warranty.
SSaaffeettyy

TK 60483-1-OP-EN 13
Refri erant
Although fluorocarbon refrigerants are classified as safe, use caution when
working with refrigerants or in areas where they are being used.
DDAANNGGEE
HHaazzaarrddoouuss GGaasseess!!
efrigerant in the presence of an open flame, spark, or electrical short
produces toxic gases that are severe respiratory irritants which can cause
serious injury or possible death.
DDAANNGGEE
eeffrriiggeerraanntt VVaappoorr HHaazzaarrdd!!
Do not inhale refrigerant. Use caution when working with refrigerant or a
refrigeration system in any confined area with a limited air supply.
efrigerant displaces air and can cause oxygen depletion, resulting in
suffocation and possible death.
WWAA NNIINNGG
PPeerrssoonnaall PPrrootteeccttiivvee EEqquuiippmmeenntt ((PPPPEE)) eeqquuiirreedd!!
efrigerant in a liquid state evaporates rapidly when exposed to the
atmosphere, freezing anything it contacts. Wear butyl lined gloves and
other clothing and eye wear when handling refrigerant to help prevent
frostbite.
SSaaffeettyy

14 TK 60483-1-OP-EN
Refri erant Oil
Observe the following precautions when working with or around refrigerant
oil:
WWAA NNIINNGG
PPeerrssoonnaall PPrrootteeccttiivvee EEqquuiippmmeenntt ((PPPPEE)) eeqquuiirreedd!!
Protect your eyes from contact with refrigerant oil. The oil can cause serious
eye injuries. Protect skin and clothing from prolonged or repeated contact
with refrigerant oil. To prevent irritation, wash your hands and clothing
thoroughly after handling the oil. ubber gloves are recommended.
First Aid
EEFF IIGGEE AANNTT
•EEyyeess:: For contact with liquid, immediately flush eyes with large amounts
of water and get prompt medical attention.
•SSkkiinn:: Flush area with large amounts of warm water. Do not apply heat.
emove contaminated clothing and shoes. Wrap burns with dry, sterile,
bulky dressing to protect from infection. Get prompt medical attention.
Wash contaminated clothing before reuse.
•IInnhhaallaattiioonn:: Move victim to fresh air and use Cardio Pulmonary
esuscitation (CP ) or mouth-to-mouth resuscitation to restore
breathing, if necessary. Stay with victim until emergency personnel
arrive.
•FFrroosstt BBiittee:: In the event of frost bite , the objectives of First Aid are to
protect the frozen area from further injury, warm the affected area
rapidly, and to maintain respiration.
EEFF IIGGEE AANNTT OOIILL
•EEyyeess:: Immediately flush with large amounts of water for at least 15
minutes. Get prompt medical attention.
•SSkkiinn:: emove contaminated clothing. Wash thoroughly with soap and
water. Get medical attention if irritation persists.
SSaaffeettyy

TK 60483-1-OP-EN 15
•IInnhhaallaattiioonn:: Move victim to fresh air and use Cardio Pulmonary
esuscitation (CP ) or mouth-to-mouth resuscitation to restore
breathing, if necessary. Stay with victim until emergency personnel
arrive.
•IInnggeessttiioonn:: Do not induce vomiting. Immediately contact local poison
control center or physician.
EENNGGIINNEE CCOOOOLLAANNTT
•EEyyeess:: Immediately flush with large amounts of water for at least 15
minutes. Get prompt medical attention.
•SSkkiinn:: emove contaminated clothing. Wash thoroughly with soap and
water. Get medical attention if irritation persists.
•IInnggeessttiioonn:: Do not induce vomiting. Immediately contact local poison
control center or physician.
BBAATTTTEE YY AACCIIDD
•EEyyeess:: Immediately flush with large amounts of water for at least 15
minutes. Get prompt medical attention. Wash skin with soap and water.
EELLEECCTT IICCAALL SSHHOOCCKK
Take IMMEDIATE action after a person has received an electrical shock. Get
quick medical assistance, if possible.
The source of the shock must be quickly stopped, by either shutting off the
power or removing the victim. If the power cannot be shut off, the wire
should be cut with an non-conductive tool, such as a wood-handle axe or
thickly insulated cable cutters. escuers should wear insulated gloves and
safety glasses, and avoid looking at wires being cut. The ensuing flash can
cause burns and blindness.
If the victim must be removed from a live circuit, pull the victim away with a
non-conductive material. Use wood, rope, a belt or coat to pull or push the
victim away from the current. DO NOT TOUCH the victim. You will receive a
shock from current flowing through the victim’s body. After separating the
victim from power source, immediately check for signs of a pulse and
respiration. If no pulse is present, start Cardio Pulmonary esuscitation
(CP ). If a pulse is present, respiration might be restored by using mouth-to-
mouth resuscitation. Call for emergency medical assistance.
AASSPPHHYYXXIIAATTIIOONN
Move victim to fresh air and use Cardio Pulmonary esuscitation (CP ) or
mouth-to-mouth resuscitation to restore breathing, if necessary. Stay with
victim until emergency personnel arrive.
SSaaffeettyy

16 TK 60483-1-OP-EN
Safety Decals and Locations
Operation
The Operation decal is located on your HMI or rear remote controller (if
fitted). This decal gives you the information to access/download your unit
operator manual and other supporting documentation and in many
supported languages.
Fi ure 1. Operation Decal
SSaaffeettyy

TK 60483-1-OP-EN 17
Remote Start of the Unit
CCAAUUTTIIOONN
iisskk ooff IInnjjuurryy!!
The unit can start and run automatically any time the unit is turned on. Turn
the Microprocessor On/Off switch Off before doing inspections or working
on any part of the unit. Please note that only Qualified and Certified
personnel should attempt to service your Thermo King unit.
Decals located behind service door.
NNoottee:: nly present on units fitted with TK TracKing Telematic's installed.
Refri erant
efrigerant decal located on frame inside door.
F Gas decal indicates that this equipment Contains fluorinated greenhouse
gases.
SSaaffeettyy

18 TK 60483-1-OP-EN
Do Not Use Ether Startin Aids
Fi ure 2. Do Not Use Ether Startin Aids (Near En ine)
SSaaffeettyy

TK 60483-1-OP-EN 19
Unit Description
General Description
The T- Series units are one-piece, front-mounted, diesel powered cooling
and heating systems designed for straight trucks. The condensing portion of
the unit is mounted on to the front of a truck cargo box with the evaporator
portion protruding into the box. The unit uses Chlorine free refrigerant.
The T-Series SPECT UM™unit is a microprocessor based transport
temperature control system that uses the TS /TS -3 Truck HMI to manage
system functions. The unit is a self-powered multi-temperature unit for
straight trucks. The condensing unit mounts on the front of the truck cargo
compartment. emote evaporators are used to control temperatures in up to
three individual cargo compartments. The unit uses Chlorine free refrigerant.
The basic models provide the following:
MMooddeell 3300:: Cooling and hot gas heating on engine operation.
MMooddeell 5500:: Cooling and hot gas heating on engine operation and electric
standby operation. Electric evaporator heaters are optional.
En ine
Engine power for the T-1200 and T-1000 is a three cylinder, TK376/
TK376U, a special clean and quiet diesel engine rated at 18.8 continuous
horsepower (14.0 kW) at 2200 PM, 18.9 continuous horsepower (14.1 kW) at
2250 PM, and 19.6 continuous horsepower (14.6 kW) at 2425 PM.
Engine power for the T-600 , T-800 and T-800 is provided by the engine
TK370 rated at 14.5 continuous horsepower (10.8 kW) at 2250 PM.
Engine power for the T-560 /T-Dairy is provided by the engine TK270 rated
at 10.0 continuous horsepower (7.5 kW) at 2300 PM. A belt drive system
transfers energy to the compressor, unit fans and alternator.
Engine power for the T-800 SPECT UM is provided by the engine TK370
rated at 14.5 continuous horsepower (10.8 kW) at 2250 PM.
Engine power for the T-1200 SPECT UM and T-1000 SPECT UM, and UT-
Series is a three cylinder, TK376/TK376U, a special clean and quiet diesel
engine rated at 18.8 continuous horsepower (14.0 kW) at 2200 PM, 18.9
continuous horsepower (14.1 kW) at 2250 PM, and 19.6 continuous
horsepower (14.6 kW) at 2425 PM.
These Truck units comply with 2016/1628 EU regulation (or N MM Stage V).
To determine if an engine is N MM Stage 5 compliant, the engine model

20 TK 60483-1-OP-EN
shall be stated on the engine serial plate (located on the engine itself). See
below an example of engine serial plate.
Fi ure 3. En ine Serial Plate for NRMM Compliance
Reciprocatin Compressor
The T-1200 unit features the X430P, 4-cylinder reciprocating compressor
with 30.0 cu. in. (492 cc) displacement.
The T-1000 features the X426, 4-cylinder reciprocating compressor with
25.9 cu in (424 cc) displacement.
The T-600 and T-800 feature the X214, 2 cylinder reciprocating
compressor with 13.92 cu in (229 cc) displacement.
Extended Life Coolant (ELC)
ELC (Extended Life Coolant) is standard equipment. The maintenance
interval for ELC is five years or 12,000 hours. A nameplate on the coolant
expansion tank identifies units with ELC. The new engine coolant, Chevron
Extended Life Coolant, is ED in color instead of the previous G EEN or
BLUE-G EEN colored conventional coolants.
NN TTIICCEE
SSyysstteemm CCoonnttaammiinnaattiioonn!!
Do not add “G EEN” or “BLUE-G EEN” conventional coolant to cooling
systems using “ ED” Extended Life Coolant, except in an emergency. If
conventional coolant is added to Extended Life Coolant, the coolant must
be changed after 2 years instead of 5 years.
UUnniitt DDeessccrriippttiioonn
