Trane BAYCOVR112 Assembly instructions

ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES
DO NOT APPLY WITH SQUARE TO ROUND ADAPTOR KITS
IMPORTANT —This Document is customer property and is to remain with this unit. Please return to service information
pack upon completion of work.
Installer’s Guide
Models: BAYCOVR112 for *TC*, *WC*, *YC*, *DC**018-60
BAYCOVR118 for *TC*, *WC*, *YC*, *DC**018-60
WARNING:
HAZARDOUS VOLTAGE - DISCONNECT POWER BEFORE SERVICING
18-HE72D1-3B-EN
Duct Shroud Cover Kit (for Horizontal Ducts)
Kit Contents:
1 - Left Side
1 - Right Side
1 - Top
6 - #10 x 3/4” - Self drilling screws
Inspection:
Check carefully for any shipping damage. This must be reported to and claims made against the transportation
company immediately. Any missing parts should be reported to your supplier at once and replaced with authorized
parts only.
INSTALLATION:
1. Attach the left and right sides to the top using the #10 x 3/4” screws provided. See Figure 1.
2. Dig two trenches between the unit and the building large enough to insert the bottom edge of each side of
the cover.
3. Loosen up the screws above the horizontal openings on the unit cabinet base. Slide the top of the duct
shroud with the “U” shaped openings underneath the lip where the screws have been loosened, re-tighten
the screws.
4. Attach the other side of the duct shroud to the building structure using eld supplied #10 x 3/4” screws.
NOTE: * indicates an alpha character.

Installer’s Guide
Loosen the 3 screws on the unit so
you can slide the duct cover into
place.
22”
44”
20.875”
A
DUCT SHROUD COVER DIMENSION "A"
12"BAYCOVR112
18"BAYCOVR118
Attach sides to top using
3 screws on each side.
Figure 1. Shroud Assembly and Dimensions
