Trane Cold Generator CG-SVX044F-EN Installation and operating instructions

Cold Generator™ Compact Chiller
Series
20 to 85 Tons (60 Hz)
R-410A
Installation, Operation, and Maintenance
June 2022 CG-SVX044F-EN
Model CICD
SAFETY WARNING
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.

©2022 Trane CG-SVX044F-EN
Introduction
Read this manual thoroughly before operating or servicing this
unit.
Warnings, Cautions, and Notices
Safety advisories appear throughout this manual as required.
Your personal safety and the proper operation of this machine
depend upon the strict observance of these precautions.
The three types of advisories are defined as follows:
WARNING Indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTIONsIndicates a potentially hazardous
situation which, if not avoided, could
result in minor or moderate injury. It could
also be used to alert against unsafe
practices.
NOTICE Indicates a situation that could result in
equipment or property-damage only
accidents.
Important Environmental Concerns
Scientific research has shown that certain man-made
chemicals can affect the earth’s naturally occurring
stratospheric ozone layer when released to the atmosphere. In
particular, several of the identified chemicals that may affect
the ozone layer are refrigerants that contain Chlorine, Fluorine
and Carbon (CFCs) and those containing Hydrogen, Chlorine,
Fluorine and Carbon (HCFCs). Not all refrigerants containing
these compounds have the same potential impact to the
environment. Trane advocates the responsible handling of all
refrigerants-including industry replacements for CFCs and
HCFCs such as saturated or unsaturated HFCs and HCFCs.
Important Responsible Refrigerant
Practices
Trane believes that responsible refrigerant practices are
important to the environment, our customers, and the air
conditioning industry. All technicians who handle refrigerants
must be certified according to local rules. For the USA, the
Federal Clean AirAct (Section 608) sets forth the requirements
for handling, reclaiming, recovering and recycling of certain
refrigerants and the equipment that is used in these service
procedures. In addition, some states or municipalities may
have additional requirements that must also be adhered to for
responsible management of refrigerants. Know the applicable
laws and follow them.
WARNING
Proper Field Wiring and Grounding
Required!
Failure to follow code could result in death or serious
injury. All field wiring MUST be performed by qualified
personnel. Improperly installed and grounded field
wiring poses FIRE and ELECTROCUTION hazards. To
avoid these hazards, you MUST follow requirements for
field wiring installation and grounding as described in
NEC and your local/state/national electrical codes.
WARNING
Personal Protective Equipment (PPE)
Required!
Failure to wear proper PPE for the job being undertaken
could result in death or serious injury. Technicians, in
order to protect themselves from potential electrical,
mechanical, and chemical hazards, MUST follow
precautions in this manual and on the tags, stickers,
and labels, as well as the instructions below:
• Before installing/servicing this unit, technicians
MUST put on all PPE required for the work being
undertaken (Examples; cut resistant gloves/sleeves,
butyl gloves, safety glasses, hard hat/bump cap, fall
protection, electrical PPE and arc flash clothing).
ALWAYS refer to appropriate Safety Data Sheets
(SDS) and OSHA guidelines for proper PPE.
• When working with or around hazardous chemicals,
ALWAYS refer to the appropriate SDS and OSHA/GHS
(Global Harmonized System of Classification and
Labeling of Chemicals) guidelines for information on
allowable personal exposure levels, proper
respiratory protection and handling instructions.
• If there is a risk of energized electrical contact, arc, or
flash, technicians MUST put on all PPE in accordance
with OSHA, NFPA 70E, or other country-specific
requirements for arc flash protection, PRIOR to
servicing the unit. NEVER PERFORM ANY
SWITCHING, DISCONNECTING, OR VOLTAGE
TESTING WITHOUT PROPER ELECTRICAL PPE AND
ARC FLASH CLOTHING. ENSURE ELECTRICAL
METERS AND EQUIPMENT ARE PROPERLY RATED
FOR INTENDED VOLTAGE.

WARNING
Follow EHS Policies!
Failure to follow instructions below could result in
death or serious injury.
• All Trane personnel must follow the company’s
Environmental, Health and Safety (EHS) policies
when performing work such as hot work, electrical,
fall protection, lockout/tagout, refrigerant handling,
etc. Where local regulations are more stringent than
these policies, those regulations supersede these
policies.
• Non-Trane personnel should always follow local
regulations.
Introduction
CG-SVX044F-EN 3
Copyright
This document and the information in it are the property of
Trane, and may not be used or reproduced in whole or in part
without written permission. Trane reserves the right to revise
this publication at any time, and to make changes to its content
without obligation to notify any person of such revision or
change.
Trademarks
All trademarks referenced in this document are the trademarks
of their respective owners.
Revision History
• Updated Model Number Description chapter.
• Updated table values in the General Data, Electrical Data,
Dimensions and Weights and Installation Mechanical
chapters.
• Minor updates to document.

4CG-SVX044F-EN
Table of Contents
Model Number Descriptions . . . . . . . . . . . . . . . . 5
General Information . . . . . . . . . . . . . . . . . . . . . . . 7
Unit Description . . . . . . . . . . . . . . . . . . . . . . . . 7
General Data . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Pre-Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Dimensions and Weights . . . . . . . . . . . . . . . . . 11
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installation Mechanical . . . . . . . . . . . . . . . . . . . 21
General Installation Information . . . . . . . . . . 21
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Noise Considerations . . . . . . . . . . . . . . . . . . 21
Foundation . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Drainage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Access Restrictions . . . . . . . . . . . . . . . . . . . . 23
Compressor Mounting . . . . . . . . . . . . . . . . . . 23
Direct Mounting . . . . . . . . . . . . . . . . . . . . . . . 23
Unit Leveling . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Typical Water Piping . . . . . . . . . . . . . . . . . . . 23
Avoidance of Short Water Loops . . . . . . . . . 23
Minimum Water Volume for a Process Applica-
tion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Unit Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Installation Electrical . . . . . . . . . . . . . . . . . . . . . 30
General Recommendations . . . . . . . . . . . . . 30
Equipment Grounding . . . . . . . . . . . . . . . . . . 31
Unit Power Wiring . . . . . . . . . . . . . . . . . . . . . 31
Control Power Supply . . . . . . . . . . . . . . . . . . 32
External Contacts and Peripherals . . . . . . . . 32
Controls Interface . . . . . . . . . . . . . . . . . . . . . . . . 33
Unit Controller — General . . . . . . . . . . . . . . . 33
Unit Controller 
Software Installation and Setup . . . . . . . . . . 33
Unit Start-Up Procedures . . . . . . . . . . . . . . . . . .35
Pre-Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Sequence of Operation . . . . . . . . . . . . . . . . . .35
Checking Operating Conditions . . . . . . . . . . .36
System Superheat . . . . . . . . . . . . . . . . . . . . . .36
System Subcooling . . . . . . . . . . . . . . . . . . . . .36
Shut Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Normal Unit Shutdown . . . . . . . . . . . . . . . . . .37
Extended Shutdown Procedure . . . . . . . . . . .37
Unit Restart . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Periodic Maintenance . . . . . . . . . . . . . . . . . . .39
Compressor Maintenance . . . . . . . . . . . . . . . .39
Heat Exchanger Maintenance . . . . . . . . . . . .40
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Appendix A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Appendix B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Piping System Flushing Procedure . . . . . . . .55
Water Treatment Requirements . . . . . . . . . . .55

CG-SVX044F-EN 5
Digits 1 to 4 — Model
CICD= Compact Indoor Chiller
Digits 5 to 7 — Nominal Capacity
020 = 20 Nominal Tons
030 = 30 Nominal Tons
045 = 45 Nominal Tons
055 = 55 Nominal Tons
065 = 65 Nominal Tons
075 = 75 Nominal Tons
085 = 85 Nominal Tons
Digit 8 — Unit Voltage
A = 208 V/60 Hz/3 Phase
B = 230 V/60 Hz/3 Phase
F = 460 V/60 Hz/3 Phase
G = 575 V/60 Hz/3 Phase
Digits 9 — Unit Application
A = Water-Cooled Chiller
B = Compressor Chiller with Remote
Condenser (40°F to 115°F)
D = Compressor Chiller with Remote
Condenser (20°F)
Digit 10 — Refrigeration Style
A = R-410A Scroll
Digit 11 — Number of Circuits
1 = Single Circuit
2 = Dual Circuit
Digit 12 — Efficiency/Capacity
1 = Standard Efficiency
2 = High Capacity Evaporator (Allows
40°F leaving water)
Digit 13 — Design Sequence
0 = Factory Assigned
Digit 14 — Array System
0 = Non-Array System
1 = Array System
Digit 15 — Evaporator Heat
Exchanger Type
0 = Brazed Plate
Digit 16 — Evaporator Fluid Type
0=Water
2 = Ethylene Glycol
3 = Propylene Glycol
Digit 17 — Evaporator Flow
0 = Constant Flow Primary
1 = Variable Flow Primary
Digit 18 — Evaporator Temperature
Range
0 = Standard Cooling 40 to 65°F [5.5 to
18.3°C]
1 = Standard Cooling/Ice Making 20 to
65°F [-6.7 to 18.3°C]
2 = Low Temperature Glycol Process
(10 to 42°F) [-12.2 to 5.5°C]
Digit 19 — Evaporator Control Valves
0 = Manual Balancing Isolating Valves
1 = Motorized Chilled Water Isolating
Valve
Digit 20 — Condenser Heat
Exchanger Type
0 = Brazed Plate
1 = Shell and Tube
5 = Remote Condenser
Digit 21— Condenser Fluid Type
0=Water
2 = Ethylene Glycol
3 = Propylene Glycol
9 = Not Applicable — Compressor-
Chiller
Digit 22 — Condenser Heat Recovery
0 = No Heat Recovery
1 = Full Heat Recovery with Auto
Changeover
Digit 23 — Condenser Corrosion
Resistance
0 = Standard
1 = Cupro-Nickel (Avail. Shell and Tube
Only)
Digit 24 — Condenser Control Valves
1 = Manual Valve
2 = Motorized Head Pressure Control
Valve
Digit 25 — Power Feed
0 = Single Point Power (5 kA Rating)
A = Single Point Power (5 kA Rating) +
Phase and Voltage Monitor
B = Single Point Power (100 kA Rating)
C = Single Point Power (100 kA Rating)
+
Phase and Voltage Monitor
D = Power Feed to Each Unit (5 kA
Rating)
E = Power Feed to Each Unit (5 kA
Rating) + Phase and Voltage
Monitor
F = Power Feed to Each Unit (100 kA
Rating)
G = Power Feed to Each Unit (100 kA
Rating) + Phase and Voltage
Monitor
Digit 26 — Power Connection
0 = Terminal Block
A = Non-Fused Disconnect Switch
B = Fused Disconnect Switch
C = High SCCR Fuse Block
D = Distribution Panel Connection =
Terminal Block;
Module Power Connection = Circuit
Breaker
Digit 27 — Service Options
0 = None
A = LED Lighted Control Cabinet
Digit 28 — Panel Ampere Rating
0 = None
D = 250 Amp
E = 400 Amp
F = 600 Amp
G = 800 Amp
H = 1200 Amp
Digit 29 — Control Style
0 = Manager Subordinate Controller
with Single Controller per Array
A = Supervisory Array Controller with
Controller per Module
B = Non-Array, Single Unit Controller
Digit 30 — Local Unit Controller
Interface
0 = Keypad with Dot Pixel Display
B = 15.4-in. Color Touchscreen
Digit 31 — Remote BMS Interface
(Digital Comm)
0 = None
2 = Lon Talk®
4 = BACnet® MS/TP
5 = BACnet® IP
6=MODBUS®
8 = Johnson N2
Digit 32 — Blank
0 = Blank
Digit 33 — Blank
0 = Blank
Digit 34 — Refrigeration Options
1 = Active Freeze Protection (All
Circuits)
2 = Hot Gas Bypass (All Circuits)
Digit 35 — Refrigeration Accessories
0 = Moisture Indicating Sight Glass
A = Moisture Indicating Sight Glass +
Compressor Isolation Valves
B = Moisture Indicating Sight Glass +
Replaceable Core Filter Driers
C = Moisture Indicating Sight Glass +
Replaceable Core Filter Driers +
Compressor Isolation Valves
Digit 36 — Water Connection
0 = Grooved Pipe Connection, Standard
Header Length
A = Grooved Pipe Connection,
Extended Header Length
D = No Header Piping (Heat
Exchangers Only)
Digit 37 — Water Side Pressure
0 = 150 psi
A = 300 psi
Model Number Descriptions

Model Number Descriptions
6CG-SVX044F-EN
Digit 38 — Water Strainer(s)
0 = None
A = Chilled Water Flow Wye Strainer
B = Chilled Water Wye Strainer with
Installation Kit
C = Condenser Water Flow Wye
Strainer
D = Condenser Water Wye Strainer
with Installation Kit
E = Chilled and Condenser Water
Nominal Flow Wye Strainer
F = Chilled and Condenser Water Wye
Strainer with Installation Kit
Digit 39 — Water Accessories
0 = Chilled Water Flow Switch
A = Condenser Water Flow Switch
B = Analog Water Temperature Gauge
C = Analog Water Pressure Gauge
D = Chilled Water Flow Switch +
Condenser Water Flow Switch
E = Chilled Water Flow Switch +
Analog Water Temperature Gauge
F = Chilled Water Flow Switch +
Analog Water Pressure Gauge
G = Chilled Water Flow Switch +
Condenser Water Flow Switch +
Analog Water Temperature Gauge
H = Chilled Water Flow Switch +
Condenser Water Flow Switch +
Analog Water Pressure Gauge
J = Chilled Water Flow Switch +
Analog Water Temperature Gauge
+ Analog Water Pressure Gauge
K = Chilled Water Flow Switch +
Condenser Water Flow Switch +
Analog Water Temperature Gauge
+ Analog Water Pressure Gauge
Digit 40 — Blank
0 = Blank
Digit 41 — Sound Attenuator
0 = None
A = Compressor Sound Blankets
B = Factory Sound Enclosure Cabinet
C = Compressor Sound Blankets +
Factory Sound Enclosure Cabinet
Digit 42 — Unit Mounting
0 = None
A = Neoprene Pads
B = Leveling Kit
C = Casters/Wheels
D = Neoprene Pads and Casters
Wheels
E = Neoprene Pads and Leveling Kit
Digit 43 — Exterior Finish and
Shipping Splits
0 = Standard Paint, Each Module
Packaged Separately
B = Custom Paint, Each Module
Packaged Separately
Digit 44 — Shipping Options
A = Framed Crate with Plastic Wrap
(Non-Shrink)
D = Fully Enclosed Crate
Digit 45 — Warranty
0 = Standard Warranty
Digit 46 — Special Options
0=None
X = With Specials

CG-SVX044F-EN 7
General Information
Unit Description
Model CICD Cold Generator™Compact Series water-cooled
chillers are designed for installation on a prepared surface in
a suitable, weatherproof location above freezing (32°F). Each
unit consists of one or two independent refrigerant circuits, two
scroll compressors, a single or dual circuited brazed plate
evaporator, a single or dual circuited brazed plate or shell-and-
tube condenser and control box with integral control panel—all
mounted on a common frame.
Each unit is a completely assembled package that is factory-
piped, wired, leak-tested, dehydrated, charged and run-tested
for proper control operation before shipment. Water inlet and
outlet openings are covered before shipment. CICD units are
shipped with an operating charge of refrigerant and oil.
General Data
Table 1. General data
Size 20 30 45 55 65 75 85
Compressor
Quantity 2 2 2 2 2 2 2
Nominal Tons @ 60 Hz tons 10/10 15/15 20/20 25/25 30/30 30/40 40/40
Compressor Sound Data dbA 81 84 89 89 92 93.1 94
Compressor Sound Data with Sound Blankets Only(a)
(a) Compressor manufacturer sound power is given at rated compressor AHRI conditions measured in free space for tandem compressor sets.
dbA 75 78 85 85 88 89.1 90
Evaporator
Water Storage gal 910 11 12 13 14 14
Minimum Flow gpm 30 30 40 45 55 60 75
Maximum Flow gpm 150 150 245 245 250 275 275
Brazed Plate Condenser
Water Storage gal 10 11 11 12 13 14 14
Minimum Flow gpm 50 50 70 85 105 115 135
Maximum Flow gpm 150 150 245 245 250 275 275
Shell and Tube Condenser
Water Storage gal 9 9 9 9 10 10 12
Minimum Flow gpm 35 35 60 60 85 85 105
Maximum Flow gpm 150 150 245 245 250 250 250

General Information
8CG-SVX044F-EN
Unit Components
Figure 1. Unit components
Detachable
Water
Header Frame
Easily Accessible
Condenser for
Easy Cleaning
Brazed Plate or
Shell and Tube
Condenser
Locking Door
OFF/AUTO Switch,
RUN Light, ALARM
Light
Keypad or
Touchscreen
Controller
Display
Single or Dual
Refrigeration
Circuit(s)
Manual or Motorized
Balancing/Isolation
Valves
Standard or
Replaceable Core
Filter Drier(s)

CG-SVX044F-EN 9
Pre-Installation
To protect against loss due to damage incurred in transit,
complete the following checklist upon receipt of the unit. A
more in depth list is included with the packing list adhered to
the side of the shipping crate.
• Inspect the individual pieces of the shipment before
accepting the unit. Check for obvious damage to the unit or
packing material.
• Inspect the unit for concealed damage as soon as possible
after delivery and before it is stored. Concealed damage
must be reported within 15 days.
• If concealed damage is discovered, stop unpacking the
shipment. Do not remove damaged material from the
receiving location. Take photos of the damage, if possible.
The owner must provide reasonable evidence that the
damage did not occur after delivery.
• Notify the carrier’s terminal of the damage immediately, by
phone and by mail. Request an immediate, joint inspection
of the damage with the carrier and the consignee.
• Notify the Trane sales representative and arrange for
repair. However, do not repair the unit until damage is
inspected by the carrier’s representative.
After completing the inspection checklist, identify the unit with
the unit nameplate, packing list and ordering information. The
unit nameplate is mounted inside the control box.
See “Model Number Descriptions,” p. 5 for additional data that
can be found on the nameplate.
Check all items against the shipping list. Verify that it is the
correct unit and that it is properly equipped. If optional
neoprene pads (or other ship-loose items) are ordered, they
are secured in place on the shipping skid or inside the unit
control box.
This Installation, Operation and Maintenance manual, the
Controls IOM, checklists and other pertinent documents can
also be found in the unit control box. Be sure to read all of this
literature before installing and operating the unit.

10 CG-SVX044F-EN
Electrical Data
Table 2. Electrical data
Size Rated Voltage
Compressor Wiring
Qty
# of
Refrigerant
Circuits
Nominal
Tons
RLA
(each)
LRA
(each)
Minimum
Circuit
Ampacity
Max Fuse
Size
Recommended Dual
Element Fuse Size
20
200-230/60/3
21 or 2 10/10
39 267 88 125 100
460/60/3 19 142 42 60 50
575/60/3 15 103 35 50 40
30
200-230/60/3
21 or 2 15/15
48 351 108 150 125
460/60/3 25 197 56 80 60
575/60/3 22 135 50 70 60
45
200-230/60/3
21 or 2 20/20
67 485 151 200 175
460/60/3 33 215 74 100 80
575/60/3 26 175 59 80 70
55
200-230/60/3
21 or 2 25/25
82 560 185 250 225
460/60/3 40 260 89 125 100
575/60/3 29 210 65 90 70
65
200-230/60/3
21 or 2 30/30
109 717 245 350 250
460/60/3 51 320 114 150 125
575/60/3 38 235 87 125 100
75
200-230/60/3
21 or 2 30/40
109/122 717/1010 261 300 300
460/60/3 51/68 320/344 136 200 150
575/60/3 38/46 235/327 95 125 110
85
200-230/60/3
21 or 2 40/40
122 1010 274 350 300
460/60/3 68 344 153 200 175
575/60/3 46 327 102 125 125
Notes:
1. Use copper conductors only.
2. Local codes may take precedence.
3. Voltage Utilization Range: ± 10% of rated voltage. Rated voltage (use range): 200-230/60/3 (180-253), 460/60/3 (414-506), 575/60/3 (517-632).

CG-SVX044F-EN 11
Dimensions and Weights
Dimensions
Figure 2. CICD unit dimensions, brazed plate condenser

Figure 3. CICD unit array dimensions, brazed plate condenser
Dimensions and Weights
12 CG-SVX044F-EN

Figure 4. CICD unit dimensions, shell and tube condenser
31 1/2"
16 3/4"
76"
Evap Out
27 1/4"
6" Cond In
Evap In
38"
Cond
Out
56 3/4"
60 5/8"
60"
Customer connections
6" S/40 pipe
1 3/8" 45" 8 3/4"
7/8"
Footprint
59 7/8"
29 3/4"
3/4" 6 x
PANEL
2x 29 3/4"
31 1/2"
POWER
CONTROL
WIRE ENTRY
SHELL and TUBE
CONDENSER
BRAZED PLATE
EVAPORATOR
Dimensions and Weights
CG-SVX044F-EN 13

Figure 5. CICD unit array dimensions, shell and tube condenser
Dimensions and Weights
14 CG-SVX044F-EN

Figure 6. CICD unit dimensions, remote condenser
31 1/2"
FRAME
32"
HEADER
16 3/4"
76"
Evap Out
27 1/4"
Evap In
56 3/4"
PANEL
60"
CONTROL
Customer
connections
6" S/40 pipe
POWER
WIRE ENTRY
BRAZED PLATE
EVAPORATOR
1 3/8" 45" 8 3/4"
29 3/4"
7/8"
4 3/4"
Footprint
6 x
3/4"
59 7/8"
7/8"
31 1/2"
Dimensions and Weights
CG-SVX044F-EN 15

Figure 7. CICD unit array dimensions, remote condenser
Dimensions and Weights
16 CG-SVX044F-EN

Dimensions and Weights
CG-SVX044F-EN 17
Clearances
Notes:
•Clearance of 42 inch is required in front of chiller to other
electrically grounded parts.
•Two units facing each other or other live parts require a
clearance of 48 inch.
•36 inch clearance is recommended above the chiller.
•See Figure 9 and Figure 10, p. 18 for recommended
clearance requirements for array installations.
Figure 8. Clearance — CICD single chiller application (all condenser options)

5HFRPPHQGHG
0LQ

5HFRPPHQGHG
0LQ

5HFRPPHQGHG


Figure 9. Clearance — CICD array chiller application (all condenser options)
24"
Recommended
3/4" Min.
36"
Recommended
42"
3/4" Min.
36"
Recommended
Figure 10. Clearance needed to remove chiller from array— 
CICD array chiller application (all condenser options)
24"
Recommended
3/4" Min.
36"
Recommended
3/4" Min.
36"
Recommended
53"
Dimensions and Weights
18 CG-SVX044F-EN

Figure 11. Single point power distribution panel dimensions

:

7<3


+
8VHFKDUWEHORZWR
GHWHUPLQHSDQHOVL]H
$UUD\6LQJOH3RLQW3RZHU
3RZHU
'LVWULEXWLRQ
3DQHO6L]HV
&KLOOHU
0RGXOH
LQ$UUD\
&KLOOHU
0RGXOH
LQ$UUD\
1RWH
&RQWDFW\RXUORFDO7UDQHUHSUHVHQWDWLYHLIDUUD\WRWDODPSVH[FHHGVDPSV
Dimensions and Weights
CG-SVX044F-EN 19

Dimensions and Weights
20 CG-SVX044F-EN
Weights
Table 3. CICD unit weights
Shipping Weight Operating Weight
Brazed Plate
Condenser
Shell-and-Tube
Condenser Remote Condenser
Brazed Plate
Condenser
Shell-and-Tube
Condenser Remote Condenser
Size lbs kg lbs kg lbs kg lbs kg lbs kg lbs kg
20 1326 601 1467 665 1069 485 1525 692 1688 766 1168 530
30 1495 678 1760 798 1205 547 1720 780 2025 919 1320 599
45 1775 805 1970 894 1420 644 2040 925 2265 1027 1550 703
55 1795 814 1970 894 1410 639 2065 937 2265 1027 1545 701
65 2230 1012 2640 1197 1770 803 2565 1163 3035 1377 1940 880
75 2235 1014 2640 1197 1775 805 2570 1166 3035 1377 1945 882
85 2487 1128 2925 1327 1963 890 2860 1297 3362 1525 2152 976
