Trane CXAJ065 Installation and operating instructions

April 2020 PKGP-SVX18B-EN
Confidential and proprietaryTrane information
Installation, Operation and Maintenance
Modular Air-cooled Water Chiller
(Heat Pump)
R410A
CXAJ/CGAJ065~130
SAFETY WARNING
Only qualified personnel should install and service the equipment.The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
690152850003

2 PKGP-SVX18B-EN
Foreword
We hope that you read this manual carefully before
installation and use, understand all the functions and
characteristics of the air conditioning unit, and install,
operate and maintain the air conditioning unit in
accordance with the manual, so as to ensure the normal
and reliable operation of the air conditioning unit and
avoid failure caused by improper operation.
This manual is the customer’s property and is used
in conjunction with the unit. Please put it back in the
technical data bag after installation and keep it properly.
The manual contains“Confirmation Sheet of Installer's
Request for Commissioning”, which is used to
verify that all necessary installation steps have been
completed.This confirmation sheet cannot replace the
contents of this manual. Read this manual carefully
before installing the unit, and be sure to follow it!
This manual may not cover all situations encountered
during the installation of the air-conditioning units.
Please contactTrane’s local sales office if more
detailed information is required or customers’
specific questions are not addressed in this manual.
The contents of the manual will be changed with the
improvement of machines from time to time without
prior notice.
All installation procedures of the air conditioning unit
shall comply with the national and local regulations
and it shall be installed by professionals "WARNING"
and "NOTICE" will be given in the manual where
appropriate. In order to ensure the personal safety and
the normal operation of the unit, please read these
contents carefully and follow them strictly, as each of
which is extremely important.
Contents
Foreword …………………………………………2
Safety Precautions ………………………………3
Unit Introduction ………………………………5
Nomenclature ………………………………… 5
Performance Data …………………………… 6
Dimensions …………………………………… 8
Application Range …………………………… 9
Unit Installation ……………………………… 10
Inspection before Installation …………… 10
Unloading and Hoisting Requirements 10
Selection of Installation Location ……… 11
Requirements for Installation Space…… 11
Installation of Water System …………… 14
WaterTreatment Requirements ………… 18
Electrical Installation………………………… 19
Safety Precautions ………………………… 19
Electrical Wiring …………………………… 19
Electrical Specification …………………… 20
Electrical Circuit Diagram………………… 21
Pilot Run ……………………………………… 24
Inspection before Start-up ……………… 24
Unit Setting ………………………………… 25
Unit Operation ……………………………… 27
Startup Step………………………………… 27
Long-time Shutdown……………………… 27
System Start-up after Long-time Shutdown
27
System Protection ………………………… 27
Module Control System …………………… 30
System Introduction ……………………… 30
Modular controller ………………………… 30
Unit Address Dial Code Distribution …… 34
Functions of Modular controller………… 35
Building Control System …………………… 40
Troubleshooting ……………………………… 41
Fault Codes ………………………………… 41
Common Faults and Handling Methods 42
Maintenance and Service…………………… 45
Environmental Safety Warning …………… 48

PKGP-SVX18B-EN 3
Safety Precautions
D WARNING —There will be a risk of serious damage to the air conditioning unit or casualty if
the manual is not strictly followed.
D NOTICE —If the manual is not strictly followed, there will be a risk of light or moderate damage
to the air conditioning unit, property damage, personal injury or environmental
pollution. It also provides useful help information which may be beneficial to the
operation of the unit or to the service life extension of the unit. However, it does not
indicate that the help information is optimal or directly related to the improvement
of unit operation.
D WARNINGS
• All installation procedures of the air-conditioning unit shall conform to the national and local regulations.
• For the installation of the equipment, please consult with the local sales office. Professional technicians with the
installation certificate of air conditioning unit shall be required to install the air conditioning unit. Users shall not
install, repair or move the air conditioning unit. If the users construct by themselves, leakage, electric shock or fire
may be caused.
• Before installation or maintenance, lock the power supply and the cut-off switch of the unit in the power-off state
to avoid personal injury caused by electric shock or contact with a moving part.
• Please set up a dedicated circuit.The fluctuation of voltage supply shall not exceed 10% of the rated voltage.The
power supply line must be separated from the welding transformer, which will cause large voltage fluctuation.
• Professional electricians with certificates shall be required to strictly carry out installation operations in accordance
with the national power standards and the regulations of the local power department, inspect whether the line
capacity meets the requirements and whether the power line is loose or damaged.
• The cover plate of the electric cabinet must be firmly installed to prevent dust, water and other foreign matters
from entering.The electrical part must be moisture-proof and away from water source, or it will cause electric
shock, fire and other accidents.
• Please use the fuse with correct current strength. Do not use temporary substitutes, such as a piece of wire.This
may not only damage the unit itself, but also cause fire.
• The power supply and electric auxiliary heating power supply of the unit must be equipped with leakage
protection devices, and the earth wire must be connected, otherwise there will be injuries or even casualties and
other accidents in the absence of protection.
• All electric auxiliary heating wires shall be connected in accordance with the wiring diagram. Directly energizing
the electric auxiliary heating wires will lead to the failure of some control functions of the unit and damage the
unit.
• Please strictly follow the wiring diagram in this manual. Incorrect wiring or manual wiring change will cause unit
failure, damage or personal safety.
• When cleaning the unit, do not sprinkle water directly on the unit, which may cause electric shock.
• Cut off all power supplies before contacting the wiring device.
• Before maintenance, please confirm that the unit is in the power-off state.
• Maintenance can only be carried out by professional maintenance personnel. For maintenance and repair, contact
Trane sales office. Improper maintenance and repair may result in water leakage, electric shock or fire.
• Do not use flammable materials (e.g. hairspray or pesticides) near this product. Do not clean the product with
organic solvents such as paint thinner.
• Cracks, electric shock or fire may be caused if organic solvents are used.
• Optional accessories shall be installed by professionals. Be sure to use the optional accessories designated by the
company. Improper.
• Do not use unqualified refrigerants, refrigerant substitutes or refrigerant additives. Incorrect use method or use of

4 PKGP-SVX18B-EN
unqualified refrigerants, refrigerant substitutes or refrigerant additives will cause damage to the unit and various
safety risks. Please select qualified refrigerant or call 8008208676 to purchase qualified refrigerant. All technicians
operating refrigerants must be certified, and be familiar with and strictly comply with the relevant technical
requirements, laws and regulations regarding the use, handling, recovery and recycling of refrigerants.
• No open flames are allowed when the refrigerant leaks. If the air conditioning unit fails to refrigerate or heat
properly, the refrigerant may leak. ContactTrane sales office at this time.
• The refrigerant used in the air conditioning unit and will not leak in normal conditions. In case of indoor refrigerant
leakage, toxic gases will be produced after the refrigerant is in contact with the flame of heater, electric furnace
and stove. Please extinguish the fire of the burning appliances, ventilate the room and contactTrane sales office.
• When the unit is repaired in case of refrigerant leakage, please operate the machine after the maintenance
personnel confirm that the leakage repair is completed.
• Do not start the air conditioning unit when the panel or protective net is removed. Rotating parts in the air
conditioning unit may injure people or other articles.
• Prevent objects, such as sticks, sand or stones, from entering the air inlet or outlet grid.The fan rotates at high
speed and is very dangerous. Special care must be taken of children.
• The strength of ordinary air conditioner support may not be suitable for this product. Please choose the support
according to the weight design of the unit.The support with insufficient bearing strength will cause great safety
accidents and hidden dangers.
• In the seasons with frequent use of air conditioning unit and if the machine stops using for a short period of time
in winter, please keep the machine in the power-on state to ensure that the machine can be normally ant freezing.
Otherwise, the machine may be frozen to be out of service.
• If the system is powered on for the first time or used after the power supply is cut off for a long time, it shall be
powered on for 24 hours before starting up, so as to ensure that the unit is fully preheated, otherwise it may cause
the burning of compressor.
• In the season when the air conditioning unit is not used for a long time, please cut off the main power supply of
the system to extend the service life of the unit and save electrical energy.
D NOTICES
• Do not touch the fins of the heat exchanger. Otherwise, it may damage the fins to cause the reduction of machine
performance or cut fingers.
• After the installation, the air tightness test shall be carried out on the pipeline to check whether the pipeline leaks.
• Do not touch the refrigerant pipeline during or immediately after the operation of the unit. When the air
conditioning unit runs, the pipeline may be very hot or cold, leading to burn or frostbite.
• Do not sit on the direct air duct for a long time. Long-time sitting on the direct air port not good for your health.
Special attention should be paid when you sleep or there is an infant, the elderly or the sick in the room.
• Do not place the heating device or other heat sources under or near the air conditioning unit.The machine body
will be deformed after being heated.
• Whenever you operate the unit, make sure the air filter is properly installed. Otherwise, dirt may enter into the
internal moving parts and cause damage.
• Do not block or cover the inlet or outlet grid.This may cause performance degradation and affect the normal
running ability.
• The chassis of the outdoor unit is provided with a defrosting waterspout ensure the smooth water drainage of the
unit.
• It is recommended that the snow shade be installed for the outdoor unit to ensure the better operation of the
machine on snowy days. installation may cause water leakage, electric shock and fire.

PKGP-SVX18B-EN 5
Unit Introduction
Nomenclature
Model C X A J 0 6 5 5 B
123456789
Additional options 1 H S F R A M A A
10 11 12 13 14 15 16 17 18
Maintenance code C X A J 0 6 5 5 B 1 H S F R A M A A
12345678910 11 12 13 14 15 16 17 18
Digit 1 C = Chiller
Digit 2 X = Heat pump
G = Cooling only
Digit 3 A = Air cooled
Digit 4 J = Modular type
Digit 5,6,7 Model (cooling capacity)
065 (65kW)
130 (130kW)
Digit 8 Voltage/Hertz/Phase
5 = 380V/50Hz/3PH
Digit 9 Design Sequence
B = R410A
Digit 10 Fan speed
1 = Single speed
Digit 11 Energy efficiency
N = Standard efficiency
H = High efficiency
Digit 12 Controller
S = Modular controller (units ≥ 2)
U = Unit controller (unit = 1)
N = None
Digit 13 Service Sequence
F = 6th time
Digit 14 Ambient temperature
R = Standard
Digit 15 Connector option
A = Without 2 pcs. of DN125 rubber connectors
B = With 2 pcs. of DN125 rubber connectors
Digit 16 BMS interface
M = Modbus component
N = NONE
Digit 17 Refrigerant charged
A = Without
B = With
Digit 18 Option
A = Default
B=Special requirement

6 PKGP-SVX18B-EN
Unit Introduction
Performance Data
Standard-efficiency Model (N type)
Model CXAJ065 CXAJ130 CGAJ065 CGAJ130
Cooling
Rated Cooling Capacity kW 65 130 65 130
Rated Input Power kW 21.6 43.20 21.6 43.20
Rated Operating Current A 42.0 81.0 42.0 81.0
Heating
Rated Heating Capacity kW 67 137 - -
Rated Input Power kW 21 41.00 - -
Rated Operating Current A 41.5 74.0 - -
Max.
Operating
Max. Input Power kW 29.2 60 29.2 60
Max. Current A 55 120 55 120
Compressor
Category Hermetic scroll
No. Pieces 2 2 2 2
Rated Cooling Power kW 10.1 20.0 10.1 20.0
Rated Cooling Current A 19.2 38.0 19.2 38.0
Rated Heating Power kW 9.5 19.0 - -
Rated Heating Current A 18.5 34.0 - -
Refrigerant Category R410A
Charge kg 13 12.5*2 13 12.5*2
Water Side
Category of Heat Exchanger High-efficiency shell-tube heat exchanger
Rated Water Flow CMH 11.2 22.4 11.2 22.4
Water Pressure Drop kPa 60 70 60 70
Connections mm DN125 DN125 DN125 DN125
Air side
Category of Heat Exchanger High-efficiency fin-coil heat exchanger
Fan No. Pieces 2 2 2 2
Rated Input Power of Fan kW 0.75 1.5 0.75 1.5
Rated Current of Fan A 2.1 3.96 2.1 3.96
Air Flow CMH 12000 20000 12000 20000
Unit
Power Supply V/PH/Hz 380/3N~/50
Noise dB(A) 69 70 69 70
Net Weight kg 710 1050 710 1050
Operating Weight kg 780 1150 780 1150
Dimension
Length mm 2145 2400 2145 2400
Width mm 1000 1200 1000 1200
Height mm 2155 2380 2155 2380

PKGP-SVX18B-EN 7
Unit Introduction
High-efficiency Model (H type)
Model CXAJ065 CXAJ130 CGAJ065 CGAJ130
Cooling
Rated Cooling Capacity kW 65 130 65 130
Rated Input Power kW 21.0 40.9 21.0 40.9
Rated Operating Current A 40.5 78.0 40.5 78.0
Heating
Rated Heating Capacity kW 67 137 - -
Rated Input Power kW 21.5 40.00 - -
Rated Operating Current A 41 71.0 - -
Max.
Operating
Max. Input Power kW 29.2 57.2 29.2 57.2
Max. Current A 55.0 98.2 55.0 98.2
Compressor
Category Hermetic scroll
No. Pieces 2 4 2 4
Rated Cooling Power kW 9.2 9.2 9.2 9.2
Rated Cooling Current A 18 18 18 18
Rated Heating Power kW 9.1 9.1 - -
Rated Heating Current A 18 18 - -
Refrigerant Category R410A
Charge kg 15 15*2 15 15*2
Water Side
Category of Heat Exchanger High-efficiency shell-tube heat exchanger
Rated Water Flow CMH 11.2 22.4 11.2 22.4
Water Pressure Drop kPa 60 70 60 70
Connections mm DN125 DN125 DN125 DN125
Air side
Category of Heat Exchanger High-efficiency fin-coil heat exchanger
Fan No. Pieces 2 2 2 2
Rated Input Power of Fan kW 0.75 1.5 0.75 1.5
Rated Current of Fan A 2.1 3.96 2.1 3.96
Air Flow CMH 12000 20000 12000 20000
Unit
Power Supply V/PH/Hz 380/3N~/50
Noise dB(A) 69 70 69 70
Net Weight kg 730 1150 730 1150
Operating Weight kg 800 1250 800 1250
Dimension
Length mm 2145 2400 2145 2400
Width mm 1000 1200 1000 1200
Height mm 2155 2380 2155 2380
1. The cooling capacity is measured in the conditions of water outlet at 7℃and air inlet at the ambient temperature
of 35℃.
2. The heating capacity is measured in the conditions of water outlet at 45℃and air inlet at the ambient dry bulb
temperature of 7℃and the wet bulb temperature of 6℃.

8 PKGP-SVX18B-EN
Unit Introduction
Dimensions
CX(G)AJ065
2145
1987
613
1521
927
727
2038
DN125
951
2155
856
1000
ޅૐૐDŽඤDž຤ఇፇ
႙
ఁᅭ዆ૐଉ KW KW
ఁᅭ዆ඤଉ
ຕଉ
უ໫A
ܮۨۉୁ
A
܂ገۉୁ
A
ࠀ୲
KW
KW
A
A
უ໫B
ۉᇸ:ۉუ VHz
ೕ୲ ၎ຕ
ሎႹ၌უ૰:຤֨ MPaMPa
ૐ௃֨
ࡽ
ૐඐ຤ୁଉ m3/h m3/h
ૐ۳຤ୁଉ
ૐ௃؊࠺ଉ kg dB(A)
ሯำ kg
ፇዘଉ
༬ଳۙဣཥDŽዐࡔDžᆶ၌ࠅິ
50
Outlet pipe is at near control box side, and inlet pipe is at far side of control box.
C(G)XAJ130
2380
275
2105
1521
2400
81
3
1200
800
1200
837
2293
90 90
ፇ৊຤๖ᅪ཮
൩Ӏቷُ๖ᅪ཮૶থ຤࠶
৊຤຤
ۉၒ
࠶ኖ݀ഗ ݣ຤
༵๖ǖኟ๫ۉၒDŽፑྺ຤Ljᆸྺ৊຤Dž
When facing to the electric cabinet.The left water pipe is outlet pipe, and the right water pipe is inlet pipe.

PKGP-SVX18B-EN 9
Unit Introduction
Application Range
Voltage range
The maximum allowable fluctuation range of supply voltage is 10%.
Temperature range
Item Range of Application
Range of unit operating ambient
temperature
Cooling: 18~48℃(High efficiency),
18~46℃(Standard efficiency),
Heating: -15~25℃
Range of unit operating water
temperature
Cooling: 5~15℃
Heating: 30~50℃
Range of controller operating
ambient temperature 0~45℃
Relative humidity ＜90%

10 PKGP-SVX18B-EN
Unit Installation
Inspection before Installation
1. Whether the nameplate of the unit is consistent with
the model in the order;
2. Whether all the accompanying documents for the
unit are available;
3. Whether the accessories of the unit are consistent
with the items listed in the packing list;
4. Upon receipt of the unit, please carefully inspect
whether the unit is damaged in transit. If any, please
record it on the delivery note, notify the final carrier
in writing within 72 hours and notify the localTrane
sales office at the same time.
Unloading and Hoisting
Requirements
Please handle the unit to its installation position by
using a forklift, crane or hoist with appropriate tonnage.
During handling, keep the machine horizontal, and
avoid damage to the unit due to reckless operation.
Unit Hoisting Diagram
Sling
Lifting angle
Packaging baseplate
Unit
Hoisting Diagram
and Instructions
Ensue safety.
Handle with care.
Inspection before hoisting
Hoisting
1. Inspect whether the unit periphery and the
fixed parts are intact.
2. Inspect whether the unit and the packaging
baseplate are intact.
Suggestion: remove the packaging baseplate to
hoist for fear of drop.
1. Hoisting operation shall be performed by the personnel
with hoisting qualification.
2. Thread the sling into 4 lifting eyes at the top of the unit.
3. The sling shall have enough capacity of bearing the unit weight.
4. The sling tying length shall be suitable, and the sling lifting angle
shall be more than 45 degrees.
D Warning
During hoisting, ensure stable hoisting of the outdoor unit, and avoid uneven weight distribution of the unit. If the
center of gravity is on the side of the compressor, trial operation should be performed before hoisting. Observe
whether the sling is tied tightly and whether the unit is at the risk of toppling. When hoisting, rise slowly and evenly
to prevent the unit from tipping over and ensure the safety of people around!
