Product Data
Belimo CCV provide optimum control of hot and/or chilled water flow in
various heating and cooling applications such as variable air volume
terminals, fan coil units, reheat coils, and perimeter heating systems.
Belimo water valves consists of either a 24 volt floating point control or
an analog (2-10Vdc) control actuator offered in 2-way or 3-way flow
pattern. 3-way valve provides flow control in mixing applications. They
are designed so the actuator can be removed from valve without
removing valve from piping.
December 2021 ACC-SVN258A-EN
Installation Instructions
Belimo Characterized
Control Valves (CCV)
Belimo B2 and B3 Series

4
7
5
6
Specifications
Supply Voltage: 24Vac, 50-60Hz
Power Consumption:1VA
Control Type: 24Vac 3-wire floating point or 2-10Vdc analog
Nominal 90° Valve Open Cycle Time: 90s @ 60Hz, 108s @ 50Hz
Electrical Termination: 8” plenum rated cable with AMP 172166-1 3-
position connector
Operating Ambient Temperature: -30 to 50°C (-22 to 122°F)
Minimum and Maximum Fluid Temperature: 0 to 94°C (32 to 201°F)
Shipping and Storage Temperature: -40 to +80°C (-40 to 176°F)
Atmosphere: Non-corrosive, non-explosive
Close Off Pressure: 1.38 mPa (200 psi)
Rated Body Pressure: 4.14 mPa (600 psi)
Valve Body: Brass
Valve Ball: Chrome plated brass
Valve Ball Seals: PTFE+5% graphite
Valve Ball Stem: Nickel plated brass
Actuator Cover: Fire-retardant GRPA6-230
Actuator Chassis: Reinforced nylon GRPA6-230
Actuator Gear: GRPA6-230 + Brass HPb59-1 + iron-base powder
metallurgy
Flow Characteristics: Linear, Equal Percentage
Note: The specifications above are nominal and conform to generally
acceptable industry standards. Belimo or Trane is not responsible for
damages resulting from misapplication or misuse of its products.
Table 1. Modulating CCV - 3-wire floating point
Type X-Code Kv Cv Thread Pressure (Mpa)
Close off Rated Body
2-way
X15333105010 0.26 0.30
1/2” NPT 1.4 4.14
X15333105020 0.40 0.46
X15333105030 0.69 0.80
X15333105040 1.03 1.20
X15333105050 1.64 1.90
X15333105060 2.59 3.00
X15333105070 4.05 4.70
3-way
X15333106010 0.26 0.30
1/2” NPT 1.4 4.14
X15333106020 0.40 0.46
X15333106030 0.69 0.80
X15333106040 1.03 1.20
X15333106050 1.64 1.90
X15333106060 2.59 3.00
X15333106070 4.05 4.70
Table 2. Modulating CCV - 2-10Vdc analog
Type X-Code Kv Cv Thread Pressure (Mpa)
Close Off Rated Body
2-way
X15333107010 0.26 0.30
1/2” NPT 1.4 4.14
X15333107020 0.40 0.46
X15333107030 0.69 0.80
X15333107040 1.03 1.20
X15333107050 1.64 1.90
X15333107060 2.59 3.00
X15333107070 4.05 4.70
3-way
X15333108010 0.26 0.30
1/2” NPT 1.4 4.14
X15333108020 0.40 0.46
X15333108030 0.69 0.80
X15333108040 1.03 1.20
X15333108050 1.64 1.90
X15333108060 2.59 3.00
X15333108070 4.05 4.70
Dimensions and Positions
Figure 1. Valve dimensions
2.38
4.00`.03
2.45
3.31
2.63
8.00`1.00
2.39
1.29
4.55`.03
PORT A
PORT B
PORT AB
2
Figure 2. Flow pattern
Installation
WARNING
Hazardous Voltage!
Failure to disconnect power before servicing could result in death or serious
injury.
Disconnect all electric power, including remote disconnects before servicing.
Follow proper lockout/tagout procedures to ensure the power can not be
inadvertently energized. Verify that no power is present with a voltmeter.
1. Read instructions carefully. Failure to follow them could damage the
product or cause hazardous condition.
2. Check ratings given in instructions and on product to make sure the
product is suitable for your application.
3. Installer must be a trained and experienced service technician.
4. See Figure 1 for actuator dimensions, and Figure 3 for exploded view.
5. Always conduct a thorough check-out when installation is completed.
6. While not necessary to remove the actuator from the body, it can be
removed for ease of installation. The orientation of the actuator must
be set as shown in Figure 2.
7. An extra 4 inches (101 mm) head clearance above the actuator is
required to remove the actuator.
Note: For trouble-free operation of the product, good installation
practice must include initial system flushing, chemical water treatment,
and the use of a 50 micron (or finer) system side stream filter(s).

Figure 3. Valve - exploded view
Figure 4. Installation guidelines
8 9
10
The manual lever on the actuator is used as a position indicator and as
a manual opener for putting the valve in full open position to allow initial
system flushing.
Do not use boiler additives, solder flux, and wetted materials. These are
petroleum based or contain mineral oil, hydrocarbons, or ethylene
glycol acetate. Compounds which can be used, with minimum 50%
water dilution are diethylene glycol, ethylene glycol, and propylene
glycol (antifreeze solution).
Plumbing
In mixing applications the valve is installed with inlet to A, bypass to B
and outlet through AB.
For 2-way or 3-way control, mount the valve directly in the tube or pipe.
Do not grip actuator while making and tightening up plumbing
connections. Hold valve body in your hand or attach adjustable spanner
across hexagonal or flat faces of valve body. If assembling valve train on
a bench, take care not to deform body with vice. Excess jaw force can
deform body.
Installing Replacement Actuator
Note: Installation of a new actuator does not require draining the
system, provided the valve body remain in the pipeline.
1. Check replacement part number and voltage ratings for match with
old device.
2. Disconnect power supply before servicing to avoid electrical shock or
equipment damage.
3. Disconnect lead wires to actuator. Where appropriate, label wires for
rewiring.
4. Remove the screw attaching actuator to valve.
5. Install new actuator by matching the positions of the square shaft and
actuator stem.
6. Match locating pins to mating holes.
7. Screw actuator to valve body hand tight.
8. Reconnect lead wires.
9. Restore power and check-out operation.
Manual Operation
The valve can be manipulated to any position manually as required. To
manually operate the valve, simultaneously press the manual button
and rotate the lever to the desired position (see Figure 5). The manual
open position may be used for filling, venting and draining the system,
or for opening the valve in case of power failure. The valve and actuator
will return to the automatic position when power is restored.
Figure 5. Manual operation
Do NOT rotate the
lever before pressing
the button.
Wiring
One controller is required to operate each valve. A common controller
may be used with isolation relays between each actuator. Actuator
interaction can result otherwise. Figure 6 shows single unit wiring
connections. Port “A” open and closed denote valve open and closed
positions respectively.
Figure 6. Wiring diagram
3-Wire Floating Analog

©2021 Trane
Trane has a policy of continuous product and product data improvement and reserves the right to change
design and specifications without notice. We are committed to using environmentally conscious print
practices.
Trane - by Trane Technologies (NYSE: TT), a global climate innovator - creates comfortable,
energy efficient indoor environments for commercial and residential applications. For more
information, please visit trane.com or tranetechnologies.com.
ACC-SVN258A-EN 04 Dec 2021
(NEW)
