Trane Tracer UC600 Installation and operating instructions

BAS-SVX45F-GB
Installation, Operation, and
Maintenance
Tracer®UC600 Programmable Controller
Ordering Number: BMUC600AAA0100011
SAFETY WARNING
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing
of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and
training. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or
serious injury. When working on the equipment, observe all precautions in the literature and on the tags,
stickers, and labels that are attached to the equipment.

© 2016 Trane All rights reserved BAS-SVX45F-GB
Introduction
Warnings, Cautions, and Notices
Safetyadvisoriesappearthroughoutthis manualas required.Yourpersonalsafetyand the proper
operation of this machine depend upon the strict observance of these precautions.
The three types of advisories are defined as follows:
WARNING Indicatesa potentiallyhazardoussituationwhich,if notavoided,couldresultin
death or serious injury.
CAUTIONsIndicatesapotentiallyhazardoussituationwhich,ifnotavoided,couldresultin
minorormoderateinjury.Itcouldalsobeusedtoalertagainstunsafepractices.
NOTICE: Indicates a situation that could result in equipment or property-damage only
accidents.
WARNING
Proper Field Wiring and Grounding Required!
Failure to follow code could result in death or serious injury. All field wiring MUST be
performed by qualified personnel. Improperly installed and grounded field wiring poses FIRE
and ELECTROCUTION hazards. To avoid these hazards, you MUST follow requirements for field
wiring installation and grounding as described in NEC and your local electrical codes. Failure to
follow code could result in death or serious injury.
WARNING
Personal Protective Equipment (PPE) Required!
Installing/servicing this unit could result in exposure to electrical, mechanical and chemical
hazards.
• Before installing/servicing this unit, technicians MUST put on all PPE required for the work
being undertaken (Examples; cut resistant gloves/sleeves, butyl gloves, safety glasses, hard
hat/bump cap, fall protection, electrical PPE and arc flash clothing). ALWAYS refer to
appropriate Material Safety Data Sheets (MSDS)/Safety Data Sheets (SDS) and OSHA
guidelines for proper PPE.
• When working with or around hazardous chemicals, ALWAYS refer to the appropriate MSDS/
SDS and OSHA/GHS (Global Harmonized System of Classification and Labeling of
Chemicals) guidelines for information on allowable personal exposure levels, proper
respiratory protection and handling instructions.
• If there is a risk of energized electrical contact, arc, or flash, technicians MUST put on all PPE
in accordance with OSHA, NFPA 70E, or other country-specific requirements for arc flash
protection, PRIOR to servicing the unit. NEVER PERFORM ANY SWITCHING,
DISCONNECTING, OR VOLTAGE TESTING WITHOUT PROPER ELECTRICAL PPE AND ARC
FLASH CLOTHING. ENSURE ELECTRICALMETERS AND EQUIPMENT ARE PROPERLY RATED
FOR INTENDED VOLTAGE.
Failure to follow instructions could result in death or serious injury.

BAS-SVX45F-GB 3
Introduction
Copyright
This document and the information in it are the property of Trane, and may not be used or
reproduced in whole or in part without written permission. Trane reserves the right to revise this
publicationat anytime,andtomake changes to itscontentwithoutobligationto notifyanyperson
of such revision or change.
Trademarks
All trademarks referenced in this document are the trademarks of their respective owners.
Revision History
BAS-SVX45E-EN:
• Revisions made to “Setting the BACnet Device ID” section.
• Appendix added: Configuring Tracer UC600 for BACnet/IP.
• Terminology change: WCI now called Air-Fi™ Wireless.
• Revisions made to “Configuring the Tracer UC600 with the Tracer TU Service Tool” section.
• PICS appendix removed; Reference the literature in the Other Resources section.
BAS-SVX45D-EN:
• UL864 certified (smoke control systems).
• Wireless support (WCI).
BAS-SVX45C-EN:
• Creating and viewing Schedules.
• Viewing custom graphics.

4BAS-SVX45F-GB
Table of Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Smoke Control Support (UUKL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Air-Fi™ Wireless Communications Interface (WCI) Support . . . . . . . . . . . . . . 7
Expansion Module Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Location of LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Hardware Terminations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Agency Listings and Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Additional Ordering Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Dimensions and Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Mounting and Removing the Tracer UC600 Controller . . . . . . . . . . . . . . . . . 13
DIN Unit Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setting Addresses using Rotary Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the BACnet Device ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
BACnet MS/TP Device ID Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Device ID Assignment for BACnet/IP Devices . . . . . . . . . . . . . . . . . . . . . . 17
Device ID Assignment for Wireless Devices . . . . . . . . . . . . . . . . . . . . . . . 17
Rotary Dial Address Settings for Non-Trane Systems . . . . . . . . . . . . . . . 17
Tracer UC600 Pre-power Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Resistive Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Voltage Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Current Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Binary Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Power Budget Check in an Un-powered State . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Calculating AC Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Calculating DC Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Wiring and Powering the Tracer UC600 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
AC Power Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Requirements and Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Wiring and Circuit Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Transformer Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Avoid Equipment Damage! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Terminal Connectors and Tug Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Wiring AC Power to Tracer UC600 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Controller Startup and Power Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

BAS-SVX45F-GB 5
BACnet MS/TP Link Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
BACnet/IP Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Wiring Inputs and Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Providing Low-voltage Power for Inputs/Outputs . . . . . . . . . . . . . . . . . . . . . . 29
Input and Output Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Wiring Universal Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Wiring Binary Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Wiring 0–10 VDC Analog Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Wiring 0–20 mA Analog Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Wiring Variable Resistance Analog Inputs . . . . . . . . . . . . . . . . . . . . . . . . 33
Wiring Trane Zone Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Wiring Analog Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Wiring Binary Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Connecting Pressure Transducer Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Tracer UC600 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
LED Descriptions and Activities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Communication Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Output Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Connection Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Configuring Tracer UC600 with Tracer TU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Starting a Session of TU and Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Connecting Using Tracer SC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Tracer TU Installation and Connection Error Conditions . . . . . . . . . . . . . 44
Upgrading Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Configuring Tracer UC600 and Creating or Editing Points . . . . . . . . . . . . . . 46
Configuring Tracer UC600 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Using Pre-packaged Solutions (PPS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Creating or Editing Points for the UC600 . . . . . . . . . . . . . . . . . . . . . . . . . 47
Placing Points in Out-of-Service Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Creating Points to Monitor Communication and TGP2 Programs . . . . . 49
Creating Points for Timed Override (TOV) and */** Functions . . . . . . . . 50
Monitoring and Viewing the Status of the Tracer UC600 . . . . . . . . . . . . . . . 53
Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Transfer Files (Restore) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Setting Up and Maintaining Schedules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Creating a Weekly Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Changing the Schedule Default Value and Adding Events . . . . . . . . . . . 57
Adding Exceptions to a Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Modifying Exceptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

6BAS-SVX45F-GB
Deleting Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Deleting Exceptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Deleting a Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Custom Graphics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Graphics Best Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Commissioning/Troubleshooting in a Powered State . . . . . . . . . . . . . . . . . . . . . 66
Resistive Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Voltage Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Current Inputs - Methods 1 or 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
24 Vac Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Binary Inputs, 24 Vac Detect- Methods 1 or 2 . . . . . . . . . . . . . . . . . . . . . . . . . 71
Binary Inputs- Based on Analog Output Connection . . . . . . . . . . . . . . . . . . . 71
Open-collector Based Binary Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Voltage Analog Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Current Analog Output- Methods 1 or 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Ground Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Other Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Appendix A: Configuring Tracer UC600 for BACnet/IP . . . . . . . . . . . . . . . . . . . . . 76
Device ID Assignment for Trane BACnet/IP Devices . . . . . . . . . . . . . . . . . . . . 76
Ethernet Network Wiring Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
BACnet/IP Network Configuration on the Tracer SC . . . . . . . . . . . . . . . . . . . . 76
Enabling BBMD Functionality on the IP Network . . . . . . . . . . . . . . . . . . . 77
Setting Up Tracer UC600 BACnet Communication With Tracer TU . . . . . . . 78
Establishing a Direct Connection with Tracer TU . . . . . . . . . . . . . . . . . . . 78
Establishing a Network Connection with Tracer TU . . . . . . . . . . . . . . . . . 79
Configuring IP Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Configuring BACnet Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Setting Up a BDT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Local Network (Firewall) Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Disable HTTP Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Disable Tracer UC600 User Interface (TD7) . . . . . . . . . . . . . . . . . . . . . . . . 82
Declaration of CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

BAS-SVX45F-GB 7
Overview
The Tracer®UC600 controller, (PN# BMUC600AAA0100011), is a multi-purpose, programmable,
wireless-compatible device. It is designed to control the following types of equipment:
• Air-handling units (AHUs)
• Rooftop units
• Chillers
• Central heating and cooling plants
• Cooling towers
• Generic input/output (I/O) control
Smoke Control Support (UUKL)
The Tracer UC600 programmable controller is now UL864 certified, making it fully capable of
serving as a component of a UUKL smoke control system along with the Tracer SC system
controller.Formoreinformation,seethe“EngineeredSmoke ControlSystemApplicationsGuide”,
(BAS-APG019).
Air-Fi™ Wireless Communications Interface (WCI) Support
The Air-Fi™ Wireless Communications Interface (WCI) is an alternative to BACnet® wired
communication links. The WCI is a wireless communications component (option) added to Tracer
controllers and is compatible with Tracer UC600. Tracer UC600 firmware must be at V4.00.027 or
higher for compatibility with WCI.
Refer to the following documentation for more information:
•Air-Fi™ Wireless Communications Interface Installation Instructions (X39641264001)
•Air-Fi™ Wireless Installation, Operation, and Maintenance (BAS-SVX40)
•Air-Fi™ Wireless Network Design Best Practices Guide (BAS-SVX55)
Expansion Module Requirements
If additional input or output points are needed, the XM30, XM32, and XM70 expansion modules
can be used. The UC600 controller will support up to 120 combined I/O terminations. See the
“Tracer Expansion Module IOM,” (BAS-SVX46), for application and installation information.

8BAS-SVX45F-GB
Overview
Specifications
Tracer UC600 conforms to the specifications shown in Table 1.
Location of LEDs
Light emitting diodes (LEDs) indicate the operation and communication status of the controller.
TointerprettheTracerUC600LEDsandsafelyoperatetheTracerUC600,see“LEDDescriptionsand
Activities,” p. 38.
For detailed information about wiring communication links, refer to Tracer SC Unit Controller
Wiring Guide (BAS-SVN03) listed in the section, “Other Resources,” p. 75.
.
Table 1. Specifications
Storage
Temperature: -55°C to 95°C
Relative humidity: Between 5% to 95% (non-condensing)
Operating
Temperature: -40°C to 70°C
Humidity: Between 5% to 95% (non-condensing)
Power: Input: 20.4–27.6 VAC (24 VAC, ±15% nominal) 50 or 60 Hz, 26 VA (26 VA plus a maximum of 12 VA for each binary output)
Output: 24 VDC, ±10%, device max load 600 mA
Time Clock: On-board real time clock with 7 day backup
Mounting weight of controller: Mounting surface must support 0.6 kg
Environmental rating (enclosure): IP20
Installation: UL 840: Category 3
Pollution: UL 840: Degree 2
Figure 1. UC600 LEDs
SERVICETOOL
SERVI C E
LINK
ACT
IM C
MBUSLINK
RX
TX
U C 600
ADDRESS
0
1
2
3
4
5
6
7
8
9
x1
0
1
2
3
4
5
6
7
8
9
x10
0
1
2
3
4
5
6
7
8
9
x100
B
O 4 B O 3 B O 2 B O 1
Binary output status
LEDs
Power LED
Ethernet LEDs
Communication status
(Link, MBUS, IMC)
Service button and LED

BAS-SVX45F-GB 9
Overview
Hardware Terminations
Tracer UC600 supports the following hardware terminations:
• Temperature sensors (resistive and thermistor)
• Linear inputs 0–20 mA, such as humidity sensors
• Linear inputs 0–10 VDC, such as indoor air-quality sensors
• Linear outputs 0-20 mA, such as variable frequency drives
• Linear outputs 0–10 VDC, such as accuators for dampers and valves
• Pulse outputs, such as electric heat or humidifier control
• Binary outputs, such as fan start/stop
• One 3-wire pressure transducer input
Table 2. UC600 device connections
Input/Output type Quantity Types Range Notes
Universal input
8
Thermistor 10kΩ – Type II, 10kΩ–Type III, 2252Ω – Type II, 20kΩ– Type IV,
100kΩ
Resistive (Setpoint) 100Ω– 1MΩ
RTD Balco™ (Ni-Fe), 1kΩ; 375 (Pt),
385 (Pt), 1kΩ
Current 0–20 mA (linear)
Voltage 0–20 VDC (linear)
Binary Dry contact
Pulse Width Accumulator Minimum 20 ms, opened or closed
Universal Input/Analog
Output Configure using any combination of analog or binary inputs/analog outputs
6
Thermistor 10kΩ – Type II, 10kΩ–Type III, 2252Ω – Type II, 20kΩ– Type IV,
100kΩThe UC600 provides 600 mA of DC power for 0–
20 mA inputs and/or outputs, and to power
expansion modules. See the power budget
table “Power Budget Check in an Un-powered
State,” p. 21.
Inputs
Resistive (setpoint) 100Ω –1MΩ
RTD Balco™ (Ni-Fe), 1kΩ; 375 (Pt),
385 (Pt), 1kΩ
Current 0–20 mA (linear)
Voltage 0–20 VDC (linear)
Binary Dry contact
Pulse Width Accumulator Minimum 20 ms, opened or closed
Outputs
Current 0–20 mA @16 V
Voltage 0–10 VDC @20 mA
Pulse 12.5ms to 1 second (12.5ms resolution), 1 second to 60 seconds
(0.5 second resolution)
Binary output 4 Relay (form A) wet 24 VAC, 0.5A maximum Ranges are given per contact.
Pressure input 1 3-wire 0–5 inwc. Pressure input supplied with 5 VDC. Designed for
Kavlico™ pressure transducers.
Point total 19

10 BAS-SVX45F-GB
Overview
Agency Listings and Compliance
This section lists compliance with Conformity European (CE) and Underwriters Laboratories (UL)
standards for the UC600 controller:
• UL916 PAZX, Open Energy Management Equipment
• UL94-5V, Flammability
•CEMarked
• FCC Part 15, Subpart B, Class B Limit
• UL864 Smoke Control
• BTL Listing—Advanced Application Profile (B-AAC)
Additional Ordering Options
Additional ordering options are available for the UC600:
• Tracer TD7 Operator Display (order number: X13651571010)
• TD7 Sealed Ethernet cable (for wet environments) (order number: X19070632020)
• TD7 Display Portable Carry Case (order number: X18210613010)
• TD7 Mounting Bracket (flat surface, fixed position) (order number: X05010511010)
• Tracer XM30 expansion module (order number: X13651537010)
• Tracer XM32 expansion module (order number: X13651563010)
• Tracer XM70 expansion module (order number: X13651568010)
• Tracer BACnet Term (2 pack) (order number X1365152401)
• Power Supply 24VAC to 1.4A 24 VDC for XM modules exceeding UC600 power budget
(order number: X1365153801)
• IMC Harness (order number: S3090059462)
Required Tools
A 3 mm flat-bladed screwdriver is required to perform functions such as setting rotary addressing
switches,tighteningorlooseningscrewterminals,andremovingorrepositioningthecontrolleron
DIN rail.

BAS-SVX45F-GB 11
Overview
Dimensions and Clearances
Figure 2. Controller dimensions
A O 6
UI 14
A O 5
UI 13
A O 4
UI 12
A O 3
UI 11
A O 2
UI 10
A O 1
UI 9
B O 4 B O 3 B O 2 B O 1
RELAYS 0 . 5 A MAX
IM C
1
IM C
P 1
UI 8
UI 7
UI 6 UI 5
UI 4
UI 3
UI 2 UI 1
IMC
+
24
VDC
LINK
OUT
+
24
VDC
+
24
VDC
OUT
24
VAC
MBUS
OUT
24
VAC
XFMR
24
VAC
SERVICETOOL
SERVI C E
LINK
ACT
IM C
MBUSLINK
RX
TX
U C 600
ADDRESS
0
1
2
3
4
5
6
7
8
9
x1
0
1
2
3
4
5
6
7
8
9
x10
0
1
2
3
4
5
6
7
8
9
x100
B
O 4 B O 3 B O 2 B O 1
215.9 mm width (12 DIN units)*
44 mm
101.6 mm
55 mm
* DIN Standard 43 880
Built-in Equipment for Electrical Installations,
Overall Dimensions and Related Mounting
Dimensions.
One DIN unit = 18 mm

12 BAS-SVX45F-GB
Overview
Figure 3. DIN rail clearances
101.6 mm
Controller Height
50.8 mm
Wiring Space Between Controllers (see note) 180 mm
Centerline to Centerline
Represents Terminal Connector
Note: Allow a minimum of 50.8 mm wiring
space between controllers, sides of
controllers, and bottom of cabinet.

BAS-SVX45F-GB 13
Installation
This section describes how to install Tracer UC600 onto a DIN rail and set rotary switches.
Mounting and Removing the Tracer UC600 Controller
The Tracer UC600 controller should be properly mounted on a DIN rail.
To mount or remove the controller from the DIN rail, follow the illustrated instructions inFigure 4
and Figure 5, p. 14. If using a DIN rail from another manufacturer, follow the recommended
installation procedures that accompany it.
Important: When mounting the controller in a control cabinet, provide adequate spacing
between modules to allow for ventilation and heat dissipation.
NOTICE:
Avoid Equipment Damage!
Do not use excessive force to install the controller on the DIN rail. Excessive force could
result in damage to the enclosure.
Figure 4. Mounting the Tracer UC600
To mount the controller:
1. Hook device over top of DIN rail.
2. Gently push on lower half of device in
thedirection of arrowuntilthe release
clip clicks into place.
Table 1. DIN unit width measurements
Device Device Width (mm) DIN Unit Width
(1 unit = 18 mm)
Tracer SC system controller 143.6 mm 8
Tracer UC400 controller 143.6 mm 8
Tracer UC600 controller 215.9 mm 12
Tracer UC800 controller 71.6 mm 4
Tracer XM30 expansion module 53.6 mm 3
Tracer XM32 expansion module 71.6 mm 4
Tracer XM70 expansion module 215.9 mm 12
PM014 power supply module 107.6 mm 6
Tracer BACnet terminator 35.6 mm 2
DIN Unit Width
The following table provides DIN unit width measurements for Trane devices.

14 BAS-SVX45F-GB
Installation
Figure 5. Removing the Tracer UC600
To remove or reposition the controller:
1. Disconnect all connectors before removing or repositioning.
2. Insert screwdriver into slotted release clip and gently pry upward with the screwdriver to
disengage the clip.
3. While holding tension on the clip, lift device upward to remove or to reposition.
4. If repositioned, push on the device until the release clip clicks back into place tosecure the
device to DIN rail.

BAS-SVX45F-GB 15
Installation
Setting Addresses using Rotary Switches
Therearethreerotaryswitches onthefrontofthe TracerUC600forthepurposeofdefining a three-
digit address when it is installed on a BACnet communications network. The three-digit address
setting is used as both the rotary switch value and the BACnet device ID.
For Trane BACnet MS/TP systems, the rotary switch value must be between 1 and 127. Although
“0,0,0,” is a valid BACnet address, Trane reserves this address for the Tracer SC controller. For non-
Trane systems, see “Rotary Dial Address Settings for Non-Trane Systems,” p. 17. All device
addresses on the BACnet MS/TP link must be unique.
• Before powering up Tracer UC600, set the rotary switch value as shown in Figure 6.
• If the Tracer UC600 was previously powered up, do the following if you wish to make changes:
– Make the preferred changes to the rotary switch value as illustrated in Figure 6.
– Power down the Tracer UC600; when re-powered the new rotary switch value should be
active.
• For controllers that are connected through BACnet/IP, or wireless via ZigBee™, valid unit
controller rotary switch values can range from 001 to 999.
Note: Valid rotary switch values used with the Tracer UC600 are 001 to 120 for BACnet MS/TP.
Figure 6. Setting rotary switch values
0
5
1
3
6
2
9
4
8
7

A O 6
UI 14
A O 5
UI 13
A O 4
UI 12
A O 3
UI 11
A O 2
UI 10
A O 1
UI 9
B O 4 B O 3 B O 2 B O 1
RELAYS 0 . 5 A MAX
IM C
1
IM C
P 1
UI 8 UI 7 UI 6 UI 5 UI 4 UI 3 UI 2 UI 1
IMC
+
24
VDC
LINKOUT
+
24
VDC
+
24
VDC
OUT
24
VAC
MBUS
OUT
24
VAC
XFMR
24
VAC
SERVICETOOL
SERVI C E
LINK
ACT
IM C MBUSLINK
RX
TX
U C 600
ADDRESS
0
1
2
3
4
5
6
7
8
9
x1
0
1
2
3
4
5
6
7
8
9
x10
0
1
2
3
4
5
6
7
8
9
x100
B
O 4 B O 3 B O 2 B O 1
ADDRESS
0
1
2
3
4
5
6
7
8
9
x1
0
1
2
3
4
5
6
7
8
9
x10
0
1
2
3
4
5
6
7
8
9
x100
This example illustrates the
rotary switches after addresses
have been set.
Use a 3 mm flathead
screwdriver to set rotary
switches. Dial rotates either
direction.
Important: Each Tracer UC600 device on the BACnet link must have a unique rotary switch value, otherwise,
communication problems will occur.

16 BAS-SVX45F-GB
Installation
Setting the BACnet Device ID
The BACnet device ID uniquely identifies each BACnet device. It can range from 0 to 4194303.
Device IDs cannot be sharedamong devices on the same network. Each Tracer UC600 operates as
a device and requires its own device ID, which defaults to the rotary switch value settings.
There are three ways that the BACnet device ID can be set on the Tracer UC600:
• After powering up Tracer UC600 for the first time, the Tracer UC600 device ID will match the
rotary switch value.
• When installing a Tracer UC600 on a Tracer SC, the Tracer SC will assign the BACnet device ID
based on the Tracer SC rotary address, the link number on which it is installed, and the Tracer
UC600 rotary switch value. For example, the Tracer SC will create a BACnet device ID of 101030
under the following conditions:
– TherotarydialsonTracerUC600aresetto30(0,3,0),whichisalsoknownastherotaryswitch
address.
– The Tracer SC rotary switch value is “0,1,0”.
– The Tracer UC600 is installed on link 1.
• Soft set the BACnet device ID by using the Tracer TU service tool or the Tracer BACnet Setup
tool.
Important: The TracerUC600 BACnetdevice ID defaults to the value of the rotary switchesif the
BACnet device ID has not been soft set. If a device ID has been soft set, the rotary
switches are no longer representative of the BACnet device ID.
Note: When integrating Tracer UC600 with third party vendors refer to Tracer UC600 Protocol
Implementation Conformance Statement (PICS), (BAS-PRG010).
BACnet MS/TP Device ID Assignment
Each unit controller must have a unique BACnet device ID. Tracer SC automates the process by
calculating a unique device ID for each unit controller and then saving the device ID to memory in
each device.
BACnet MS/TP device IDs are calculated using the following three sets of values:
• The Tracer SC rotary switch value (1 to 419)
• The Tracer SC BACnet MS/TP link number (1 to 2)
• The unit controller rotary switch value(1 to 127)
The three values are joined together to form the BACnet device ID for the unit controller.
The following example in Table 3 illustrates this process.
Table 3. Calculating the BACnet device ID
Tracer SC rotary switch value (21) 021
Tracer SC BACnet MS/TP link number (1) 1
Unit controller rotary switch value (38) 038
BACnet Device ID: 211038 0211038

BAS-SVX45F-GB 17
Installation
Device ID Assignment for BACnet/IP Devices
For devices communicating over BACnet/IP, Tracer SC calculates the device ID using the BACnet
network number for Ethernet 1 and the unit controller rotary switch value. For more details about
Tracer UC600 and the BACnet/IP protocol, see “Appendix A: Configuring Tracer UC600 for BACnet/
IP,” p. 76
The following example in Table 4 illustrates this process.
Device ID Assignment for Wireless Devices
For devices connecting over a wireless network, Tracer SC calculates the device ID using the
BACnet network number and the rotary switch value of the wireless device.
The following example in Table 5 illustrates this process.
Rotary Dial Address Settings for Non-Trane Systems
The Max Master value defines the maximum allowable MAC address (rotary setting)on an MSTP
link. The rotary switch address is present in each device on the MSTP link. When the last
communicating device on the MSTP link polls for the Max Master MAC address with no response,
the token rotation will be restricted on the MSTP link.
For non-Trane systems, the Max Master value must be greater than the unique address settings
from the rotary dials. Although 999 is possible from the dials, the maximum allowed number by
BACnet is 127.
The Max Master is not adjustable in Tracer systems. For example, if the rotary switch address is
101 and the front-end system has a Max Master value of 100, the device will not be discovered.
Many systems have a minimum BACnet device ID value. Ensure that the device ID is greater than
this value.
Table 4. Calculating the BACnet/IP device ID
BACnet network number Eth port 1 (1) 1
Unit controller rotary switch value (42) 042
BACnet/IP Device ID: 01042 01042
Table 5. Calculating the wireless device ID
BACnet network number of Tracer SC wireless network (13) 13
Wireless unit controller rotary switch value (001) 001
Wireless unit controller Device ID set by Application SC: 13001 130001

18 BAS-SVX45F-GB
Tracer UC600 Pre-power Checks
To avoid equipment damage, a pre-power check for inputs and outputs is recommended before
applying power to the Tracer UC600.
Before applying power, check for the following:
• All thermistors; check for 10K by using a digital multimeter (DMM).
• Thumbwheels; range between 189Ωand 890Ω.
• Binary outputs; check for any dead shorts.
• Analog outputs; verify that AC voltage is not present and that the load does not have 24 VAC
or 230 VAC.
This section provides illustrations and methods of how to check the Tracer UC600 points before
connection has been made and power applied. The step numbers in each illustration correspond
to the information in each table. (Refer to Table 2, p. 9 for a list of device connections.)
Note: Theillustrationsinthesection,“Commissioning/TroubleshootinginaPoweredState,”p. 66
show the location of the UC600.
Resistive Inputs
Checkout Procedure Measurement Expected Value
Step 1 Measure AC voltage across the resistive termination. VAC ≈ 0.0 V
AC voltage will affect further measurement.
Step 2 Measure DC voltage across the resistive termination. VDC ≈ 0.0 V
DC voltage will affect further measurement.
Step 3 Measure the resistance across the resistive termination. Compare the measured resistance with the expected value based on the manufacturer’s
specification and current conditions.

BAS-SVX45F-GB 19
Tracer UC600 Pre-power Checks
Voltage Inputs
Current Inputs
The sensor sources voltage and is powered.
Checkout Procedure Measurement Expected Value
Step 1 Measure AC voltage across the voltage input. VAC ≈ 0.0 V
AC voltage will affect further measurement.
Step 2 Measure DC voltage across the voltage termination. Compare the measured voltage with the
expected value based on the manufacturer’s
specification and current conditions.
The sensor sources 4-20 mA and is powered.
Checkout Procedure Measurement Expected Value
Step 1 Measure AC voltage across the current input. VAC ≈ 0.0 V
AC voltage will affect further measurement.
Step 2 Measure DC voltage across the current input. VDC ≈ 0.0 V.
DC voltage will affect further measurement.
Step 3 Measure the DC current across the current input. Compare the measured current with the expected value based on the manufacturer’s
specification and current conditions.

20 BAS-SVX45F-GB
Tracer UC600 Pre-power Checks
Binary Inputs
Checkout Procedure Measurement Expected Value
Step 1 Measure AC voltage across the resistive termination. VAC ≈ 0.0 V
AC voltage will affect further measurement.
Step 2 Measure DC voltage across the resistive termination. VDC ≈ 0.0 V
DC voltage will affect further measurements.
Step 3 Measure the resistance across the resistive termination. contact open = infinity (∞)
contact closed = shorted (0Ω)
