SATA HDD Enclosure
Transcend Information Inc.
1
Description
This device is designed to expedite exchanging huge
amounts of data between Transcend StoreJet®and any
desktop or notebook computer.
System Requirements
•Desktop or notebook computers with USB port
•One of following operating systems:
Windows2000/XP/Vista, Mac OS 9.0 or above
Linux Kernel 2.4.2 or above
Placement
A
B
C
Features
•Hi-Speed USB 2.0 compliant and USB 1.1 backwards
compatible
•Easy Plug and Play installation
•Ultra-Portability
•High transfer rate up to 480 Mbits per second
•Additional software pack: StoreJet®elite (helps you manage
your data)
•OneTouch Auto-Backup function
•Security: Protect your HDD and data with password
•Powered via the USB port. No external power or battery
needed
•LED indicates power on and data access
•Recommended operating temperature: 5°C ~ 55°C
Dimensions
Side Millimeters Inches
A 134.00 ±1.00 5.276 ±0.04
B 80.80
±1.00 3.181 ±0.04
C 18.80 ±1.00 0.740 ±0.04
Ordering Information
Transcend P/N Capacity
TS160GSJ25M 160GB
TS250GSJ25M 250GB
TS250GSJ25M-R 250GB
TS320GSJ25M 320GB
TS320GSJ25M-R 320GB
TS500GSJ25M 500GB
TS500GSJ25M-R 500GB

S
S
St
t
to
o
or
r
re
e
eJ
J
Je
e
et
t
t®
®
®
2
2
25
5
5 m
m
mo
o
ob
b
bi
i
il
l
le
e
e
SATA HDD Enclosure
Transcend Information Inc.
2
Block Diagram

S
S
St
t
to
o
or
r
re
e
eJ
J
Je
e
et
t
t®
®
®
2
2
25
5
5 m
m
mo
o
ob
b
bi
i
il
l
le
e
e
SATA HDD Enclosure
Transcend Information Inc.
3
Pinouts
Pin No. Pin Name
01 VCC
02 USB-
03 USB+
04 VSS
Pin Identification
Symbol Function
USB- USB differential signal
USB+ The pairs are used to transmit
Data/Address/Command
VCC USB Cable Power Detector
VSS Ground
Specifications
Above technical information is based on industry standard data and tested to be reliable. However, Transcend makes no warranty, either expressed or
implied, as to its accuracy and assumes no liability in connection with the use of this product. Transcend reserves the right to make changes in
specifications at any time without prior notice.
Environment
Storage Media 2.5 inch SATA Hard Disk
Temperature Operation 5 ℃to 55 ℃
Storage
-20 ℃to 60 ℃
Power Supply USB DC 5 Volt
Power Consumption 1090mA (Max.)
Size (L x W x H) 134.00mmx80.80mmx18.80mm
Weight With Hard Drive 206g
Certificates CE, FCC, BSMI
