Transition Networks S8TB User Guide
33672 Rev. A www.transition.com Page 1of 9
S8TB
8-Port 10/100/1000BASE-T
Compact Switch
User Guide
33672 Rev. A

Transition Networks S8TB User Guide
33672 Rev. A www.transition.com Page 2of 9
Regulatory Approvals
•FCC Class B
•CE
•EN55022 Class B
Canadian EMI Notice
This Class A digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numerique de la classe A respecte toutes les exigences du Reglement sur le materiel brouilleur du
Canada.
European Notice
Products with the CE Marking comply with both the EMC Directive (2004/108/EC) and the Low Voltage Directive
(2006/95/EC) issued by the Commission of the European Community Compliance with these directives imply
conformity to the following European Norms:
EN55022 (CISPR 22) - Radio Frequency Interference
EN60950 (IEC950) - Product Safety
S8TB - 8-Port 10/100/1000BASE-T Compact Switch User Guide, PN 33672 Rev. A
Record of Revisions
Rev.
Date
Description
A
12/14/15
Initial release.
To Contact Transition Networks
For prompt response when calling for service information, please have the following information ready:
Product serial number and revision
Date of purchase
Vendor or place of purchase
You can reach Transition Networks technical support via E-mail at [e-mail]
Transition Networks
10900 Red Circle Drive
Minnetonka, MN 55344
United States of America
Telephone: [phone]
Fax: [phone]
http://www.transition.com
info@ Transition.com
© Copyright 2015 Transition Networks.All rights reserved.

Transition Networks S8TB User Guide
33672 Rev. A www.transition.com Page 3of 9
Contents
Regulatory Approvals ..............................................................................................................................................2
Record of Revisions.................................................................................................................................................2
1. Introduction...........................................................................................................................................................4
Features..................................................................................................................................................................4
Package Contents...................................................................................................................................................4
Ethernet Switching Technology...............................................................................................................................5
2. Hardware Description...........................................................................................................................................6
Physical Dimensions...............................................................................................................................................6
LED Indicators.........................................................................................................................................................6
LED Indicator Descriptions..................................................................................................................................6
Power On ................................................................................................................................................................6
3. Troubleshooting....................................................................................................................................................7
Incorrect connections..............................................................................................................................................7
Diagnosing LED Indicators .....................................................................................................................................7
4. Technical Specifications......................................................................................................................................8

Transition Networks S8TB User Guide
33672 Rev. A www.transition.com Page 4of 9
1. Introduction
The S8TB is a compact 8-port 10/100/1000Base-T Ethernet switch that can be used to build high-performance
switched workgroup networks. This switch is a store-and-forward device that offers low latency for high-speed
networking. The S8TB is targeted at workgroup, department or backbone computing environment at SME (small,
medium enterprise) business.
The S8TB features a “store-and-forward“ switching scheme which allows the switch to auto-learn and store
source address on the 8K-entry MAC address table.
Features
•Conforms to IEEE 802.3, 802.3u. 802.3ab, 802.3az, and 802.3x
•8 10/100/1000 Base-T RJ-45 Ethernet ports
•Auto-MDIX on all ports
•N-Way Auto-Negotiation supported
•Store-and-Forward switching architecture
•Non-blocking full wire speed
•Backplane Bandwidth 16 Gbps
•Embedded 128k bytes memory buffer
•8K MAC address table
•Up to 9K byte Jumbo Frame
Package Contents
Unpack the contents of the S8TB packaging and verify them to the checklist below.
•One S8TB Switch
•One Documentation Post card
•Four Rubber Feet
•Four Sponges
•One Wall Mount Kit (two brackets)
Compare the contents of your S8TB package with the standard checklist above. If any item is missing or
damaged, please contact your local dealer for service. Save the packaging materials for possible future use.

Transition Networks S8TB User Guide
33672 Rev. A www.transition.com Page 5of 9
Ethernet Switching Technology
Ethernet Switching Technology dramatically boosted the total bandwidth of a network, eliminated congestion
problems inherent in Carrier Sense Multiple Access with Collision Detection (CSMA/CD) protocol, and greatly
reduced unnecessary transmissions.
With this revolutionized networking, the system is capable of: First, allows two-way, simultaneous transmissions
over the same port (Full-duplex) to essentially double the bandwidth. Second, reduces the collision domain to a
single switch-port to eliminate the need for carrier sensing. Third, uses the store-and-forward technology’s
approach of inspecting each packet to intercept corrupt or redundant data, and eliminates unnecessary
transmission that slows the network. In addition, the system employs address learning to replace the inefficient
method of constant broadcasting to every node in search of the correct receiving port.
Auto-negotiation regulates the speed and duplex of each port, based on the capability of both devices. Flow-
control allows transmission from a 100Mbps node to a 10Mbps node without loss of data. Auto-negotiation
and flow-control may require disablement for some networking operations involves legacy equipment. Disabling
the auto-negotiation is accomplished by fixing the speed or duplex of a port.
Ethernet Switching Technology supplied higher performance at costs lower than other solutions. Wider bandwidth,
no congestion, and the reduction in traffic are reasons why the Ethernet Switch is replacing expensive routers and
inefficient hubs as the ultimate networking solution. Switching brought a whole new way of thinking to networking.

Transition Networks S8TB User Guide
33672 Rev. A www.transition.com Page 6of 9
2. Hardware Description
This section mainly describes the hardware of the 8-port 10/100/1000Base-T Switch, and gives a physical and
functional overview of the Switch.
Physical Dimensions
The physical dimension of the 8-port 10/100/1000Base-T Switch is 165mm x 32.5mm x 100 mm (W x H x D).
LED Indicators
The LED Indicators gives real-time information of systematic operation status. The following table provides
descriptions of LEDs status and their meaning.
LED Panel
LED Indicator Descriptions
LED Status Description
Steady Green Port connection on 1000Mbps
LK/ACT Steady Amber Port connection on 10/100Mbps
Off Port disconnect
Power On
Connect the power cord to the power socket on the rear panel of the Switch.
Connect the other side of power cord to the power outlet.
The power rating of the switch is AC voltage ranging from 100-240VAC, frequency 50~60Hz.

Transition Networks S8TB User Guide
33672 Rev. A www.transition.com Page 7of 9
3. Troubleshooting
This section is intended to help you solve the most common problems on the S8TB switch.
Incorrect Connections
•Faulty or loose cables
Look for loose or obviously faulty connections. If they appear to be OK, make sure the connections are snug.
If that does not correct the problem, try a different cable.
•Non-standard cables
Non-standard and mis-wired cables may cause numerous network collisions and other network problem, and can
seriously impair network performance. A category 5-cable tester is a recommended tool for every 100Base-TX
network installation.
RJ-45 ports: Use unshielded twisted-pair (UTP) or shield twisted-pair (STP) cable for RJ-45 connections: 100Ω
Category 3, 4 or 5 cable for 10Mbps connections or 100Ω Category 5 cable for 100Mbps connections.
Also be sure that the length of any twisted-pair connection does not exceed 100 meters (328 feet).
•Improper Network Topologies
It is important to make sure that you have a valid network topology. Common topology faults include excessive
cable length and too many repeaters (hubs) between end nodes. In addition, you should make sure that your
network topology contains no data path loops. Between any two end nodes, there should be only one active
cabling path at any time. Data path loops will cause broadcast storms that will severely impact your network
performance.
Diagnosing LED Indicators
The switch can be easily monitored through panel indicators, which describe common problems you may
encounter, to assist in identifying problems and where you can find possible solutions.
See the section “LED Indicators” on page 6above.

Transition Networks S8TB User Guide
33672 Rev. A www.transition.com Page 8of 9
4. Technical Specifications
This section provides the specifications of the S8TB switch, and the following table lists these specifications.
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE802.3x Duplex Flow Control
IEEE802.3az EEE
Protocol
CSMA/CD
Technology
Store and Forward switching architecture
Cable Connections
RJ-45 (10BASE-T): Category 3,4,5 UTP/STP
RJ-45 (100BASE-TX): Category 5 UTP/STP
RJ-45 (1000BASE-T): Category 5,5e or enhanced UTP/STP
Network Rate
10/100/1000 Mbps Auto-negotiation
Jumbo Frames
9K Bytes
MAC Address Table
8K-entry
Memory Buffer
128K bytes
LED Indicators
Per port: Link/Activity
Backplane
16Gbps
Case
Metal
Operating Temp.
0 deg. C to 40 deg. C (32 deg. F to 104 deg. F)
Operating Humidity
10% to 90% (Non-condensing)
Storage Temp.
-40 deg. C to +70 deg. C (-40 deg. F to +158 deg. F)
Power Supply
100-240 VAC, 50~60Hz
Power Consumption
3.5 Watts max.
Dimensions
165mm x 32.5mm x 100 mm (W x H x D)
EMI
FCC Class B, CE
Safety
LVD
Warranty
Limited Lifetime Warranty
