Transtector ACP Hardwire Series User manual

Thank you for your recent purchase of our surge protection solution.
Your satisfaction with our product and service is important to us.
If you have any questions, comments or concerns, please contact us
at 800.882.9110 or visit our website at www.SmithsPower.com.
We look forward to continuing to serve your protection needs.
800.882.9110 | 208.772.8515 | www.transtector.com
1. IMPORTANT SAFETY INSTRUCTIONS
2. Read and understand all instructions.
3. SAVE THESE INSTRUCTIONS
ACP Hardwire Series

800.882.9110 | 208.772.8515 | www.transtector.com
ACP Hardwire Series
4.5 Wiring the ACP 200BWM
4.5.1 Line to Neutral Protection using the ACP 200BWM Connect
the source 240Vac phase wire to the terminal marked L1. Connect
the source neutral wire to the terminal marked L2/N. The terminals
marked NC are not used.
4.5.2 Line to Line Protection using the ACP 200BWM: Connect a
120Vac phase wire to the terminal marked L1. Connect a second
120Vac phase wire to the terminal marked L2/N. The terminals
marked NC are not used.
1. These products are intended for use only on 15A 120Vac & 10A or
15A 240Vac circuits as specied in Section 4.
2. Warning! Disconnect power upstream from the device when wiring
to avoid shock hazard.
3. Mounting the ACP Hardwire Series: See Figure 1.
4. Wiring the ACP Hardwire Series
4.1 Wiring the ACP 100BW3 & 100BWN3: Connect the source
120Vac phase wire to the terminal marked LINE. Connect the
phase wire of the equipment to be protected to the terminal
marked LOAD. Connect the source and equipment neutral wires
to either terminal marked NEUTRAL. The provided NEUTRAL
connections are internally bonded within the suppressor.
4.2 Wiring the ACP 100BW3R: Follow the directions from
Section 4.1 for phase wiring. The provided relay contacts are
rated for 20Vac and 1 amp. When the suppressor is functional,
the COM and NC relay contact are connected under energized
conditions. In the event of suppressor failure, the state of the
relay will change causing he COM and NO contacts to be
connected under energized conditions.
4.3 Wiring the ACP 200BW3: Connect the source 240Vac phase
wire to the terminal marked LINE. Connect the phase wire of the
equipment to be protected to the terminal marked LOAD. Connect
the source and equipment neutral wires to either terminal
marked neutral.
4.4 Wiring the ACP 200BWN3: This product is intended for
international use only on 10A 240Vac circuits. See Section 4.3
for phase wiring.
1200-139 REV E
mm
5.75"
146.05
mm
2.25"
69.85
CLEARANCE FOR NO. 8 SCREW
FIGURE 1
MOUNTING DIMENSIONS ACP HARDWIRE SERIES
mm
mm
0.4"
10.16
0.37"
9.40
