Transtector CPX User manual

Thank you for your recent purchase of our surge protection solution.
Your satisfaction with our product and service is important to us.
If you have any questions, comments or concerns, please contact us
at 800.882.9110 or visit our website at www.Transtector.com.
We look forward to continuing to serve your protection needs.
The following modules are suitable for use in hazardous locations, when installed in IP54
enclosure.
Une fois installé dans une enceinte indice de protection IP54, ces modules sont adaptés aux
zones dangereuses.
1000-1402, 1000-1405, & 1000-1464 1000-1117, 1000-1268, 1000-1269, & 1000-1270
Class I Division 2 Groups A,B,C,D T6 Class I Division 2 Groups A,B,C,D T6
Class I Zone 2 AEx nA IIC T6 Gc Class I Zone 2 AEx nA nC IIC T6 Gc
Class I Zone 2 Ex nA IIC T6 Gc Class I Zone 2 Ex nA nC IIC T6 Gc
II 3 G Ex nA IIC T6 Gc II 3 G Ex nA nC IIC T6 Gc
Ex nA IIC T6 Gc Ex nA nC IIC T6 Gc
-40°C ≤ Tamb ≤ +65°C -40°C ≤ Tamb ≤ +65°C
CERTIFICATE NUMBERS: ITS14ATEX48147X IECEx ETL 14.0041X
800.882.9110 | 208.772.8515 | www.transtector.com
1. Important safety instructions. Read and understand all instructions before installing this product.
Save these instructions for future reference.
2. The suppressor will interrupt communications in the event of self-sacrice.
3. Installation shall be performed by qualied electrical technician only.
4. EXPLOSION HAZARD. Do not disconnect while circuit is live or unless the area is known to be free
of ignitable concentrations of ammable gases or vapors.
5. Exposure to some chemicals may degrade the sealing properties of materials used in the gas
discharge tubes.
6. Substitution of any internal component is prohibited and may impair suitability for hazardous
locations.
Avertissement
1. Consignes de sécurité importantes. Veuillez lire et comprendre toutes les consignes avant d’installer
ce produit. Conservez ces consignes pour les consulter plus tard.
2. Le dispositif antiparasite interrompra les communications en cas d’abnégation.
3. L’installation doit uniquement être effectuée par un électricien qualié.
4. RISQUE D’EXPLOSION. Ne débranchez pas le produit si le circuit est sous tension. Débranchez-le
uniquement si vous êtes sûr que la zone est exempte de concentrations inammables de gaz ou de
vapeurs combustibles.
5. L’exposition à certains produits chimiques est susceptible de dégrader les propriétés d’étanchéité des
matériaux utilisés dans les tubes à décharge gazeuse.
6. Le remplacement d’un composant interne est interdit et risque de nuire à son adaptation aux zones
dangereuses.
CPX Wall Mount 4 Unit

Installation Instructions
800.882.9110 | 208.772.8515 | www.transtector.com
2X 1.00
4X
.21
7.00
2X 6.25
.625
1.83
2.00
3.16
1.44
.92
5.50
3.00
2X 1/4-20 STUD
1. Mounting the CPX Chassis: Mount the device as close as possible to
the equipment to be protected using the #10 hardware provided in the
packaging supplies.
2. Wiring the CPX Chassis
Suppressor must be grounded for proper operation!
2.1 Install the ground connection using a dual hole compression lug (hole
size 1/4” x 20 studs on 5/8” CC, suitable for acceptance of 10-4AWG
copper wire), with supplied fasteners, Crimp wire to lug using approved
tools.
2.2 Connect the incoming data lines to the connectors labeled ‘I’ on the
appropriate protection modules (10/100, 10/100 PoE, GbE, GbE/PoE, OR
T1/E1), using the text on the module faceplate as a guide.
2.3 For the equipment to be protected, connect the corresponding lines to
the protection module connector labeled ‘0’.
3. Installing Additional Protection Modules (See Table 1).
3.1 Remove the blank cover from an unpopulated bay in the protection
chassis by removing the mounting screw(s) with a #2 phillips screwdriver.
3.2 Slide the protection module into the open bay such that the mounting
hole(s) on the module faceplate aligns with the threaded hole(s) on the
chassis, and the “I” (input) side at the top. Ensure that the mounting tab(s)
on the protection module seats into the slot(s) on the chassis.
3.3 Re-Install the original mounting screw(s) or use the mounting screw(s)
provided in the packaging supplies for the protection module using a #2
phillips screwdriver.
3.4 Wire the protection module per the instruction given in section 3.
Table 1: CPX Series Protection Module Part Numbers
MODULE P/N PROTECTION MODULE DESCRIPTION
1000-1268 CPX SERIES 10/100BASE-T PROTECTION MODULE
1000-1268-NF CPX SERIES 10/100BASE-T PROTECTION MODULE NO FUSE
1000-1269 CPX SERIES T1/E1 PROTECTION MODULE
1000-1269-NF CPX SERIES T1/E1 PROTECTION MODULE NO FUSE
1000-1270 CPX SERIES 1000BASE-T PROTECTION MODULE
1000-1270-NF CPX SERIES 1000BASE-T PROTECTION MODULE NO FUSE
1000-1117 CPX SERIES 1000BASE-T/PoE PROTECTION MODULE NO FUSE
1000-1402 CPX SERIES 10/100BASE-T/PoE PROTECTION MODULE NO FUSE
1000-1405 CPX DC DEFENDER 48-5
1101-1137 CPX WALL MOUNT 4 UNIT
1000-1464 CPX DC DEFENDER 24
CPX Wall Mount Chassis
1200-448 REV E
