Transtector CB Series User manual

Thank you for your recent purchase of our surge protection solution.
Your satisfaction with our product and service is important to us.
If you have any questions, comments or concerns, please contact us
at 800.882.9110 or visit our website at www.transtector.com.
We look forward to continuing to serve your protection needs.
800.882.9110 | 208.772.8515 | www.transtector.com
1. IMPORTANT SAFETY AND INSTRUCTIONS
2. Read and understand all instructions before installing this product.
Save these instructions for future reference.
CB SERIES

800.882.9110 | 208.772.8515 | www.transtector.com
CB SERIES
1. This product is intended to protect DC power bus circuits. Be
sure that the surge suppressor is installed on the correct DC power
bus voltage service. Be sure to disconnect all power before instal-
lation.
2. The unit must be installed in parallel across the DC power bus,
from the “live” polarity to “return”. Refer to the schematic diagram 1
for the typical electrical layout.
3. As shown in Diagram 2, the unit can be installed directly into a
1A, ‘BULLET” style connected DC bus “live” side, but be sure to
connect the second suppressor electrode to the “return” of the DC
power system.
4. The bullet terminals can be removed to reveal #10-32 studs
to allow direct, hardwire mounted using ring lugs or related type
hardware connections to the “live” and “return” DC power. Refer to
gure 2 for mechanical dimensions.
5. The CB module can be panel mounted using the #6-32 inserts
(or M3 inserts for metric units ) on the front of the unit. Refer to
gure 2 for mechanical dimensions.
6. The unit is provided with LED’s on the front face to show that the
power is applied and the suppressor is operational. In the event of
powe failure or suppressor failure, a set of dry contacts will change
state to allow for remote monitoring and annunciation. The contacts
positions are identied on the side of the CB product.
