TRAULSEN BLAST CHILLERS
training guide
Models: RBC50, RBC100 and RBC200

Table of Contents
1TRAULSEN RBC50, RBC100 & RBC200 BLAST CHILLER TRAINING GUIDE
One button start
means safe food every cycle!
Page
Programming The Control....................................................... 2
Placing Probes/Loading Pans................................................. 3
Basic Operation....................................................................... 4
Ending the Cycle/Printing........................................................ 5
Care & Cleaning...................................................................... 6
Troubleshooting.......................................................................7
Interior air
temperature
Press to chill BY
PRODUCT
Press to quickly
start a Chill Cycle
Press to access
additional menus
Press to chill
BY TEMP
Press to start
a chill cycle
BY TIME
Time of Day
Main Menu
LEGEND:
Push button to left or right of any feature marked by or to select that feature.
Push button to left or right of any feature marked by or to change value of that feature.
↓↓
↓↓
↓↑↑
↑↑
↑

1. From the Main Menu Screen press MORE, then
SETUP. The display will change to the Password
Screen.
2. From the Select Supervisor Screen, use the UP and
DOWN arrows to the left and right of PASSWORD to
select 57. Press ENTER. The display will change to
the Set Up Screen.
3. From the Set Up Screen press the button to the right
of SYSPAR.
4. The ITEM list will display date and time elements in
the following order.
a) MONTH (JANUARY – DECEMBER)
b) DATE (1 – 311)
c) YEAR (2003 – 2079)
d) DAY OF WEEK (SUNDAY – SATURDAY)
e) HOUR (0 – 23)
f) MINUTE (0 – 59)
g) DLS - Daylight Savings TIme (ENABLED – DISABLED)
e) LOW ALARM (-30 – 0)
5. Press the button to the left of ITEM to select between
the different items. Adjust the VALUE for each ITEM
using the UP and DOWN buttons.
6. Press ENTER to return to the MAIN MENU.
2
Programming the Control
How to Set Correct Date & Time
SYS PAR: SET CLOCK
ITEM:MONTH
VALUE:APRIL
CANCEL ENTER
SYS PAR: SET CLOCK
ITEM:MONTH
VALUE:APRIL
CANCEL ENTER
MAIN MENU AIR 35°F
BY TEMP BY PROD
BY TIME
08:05:01 MORE
MAIN MENU 08:06:01
HOLD PROD PRINT
DEFROST SETUP
BACK
SYS PAR: SET CLOCK
ITEM:YEAR
VALUE:04/14/10
CANCEL ENTER

•Place probes into thickest part of the product.
•With product like chicken the probe should not be placed
where it is touching bone.
•With full pans of product such as casseroles locate the
probe in pan center.
•In all cases probe tip should not touch pan bottom. Use
probe adapters (shown below) with soft products.
Placing Probes/Loading Pans
3TRAULSEN RBC50, RBC100 & RBC200 BLAST CHILLER TRAINING GUIDE
Basic Probe Placement
Proper Probe Placement
Probe 1: Grouped product (2 pans whole roast chicken)
Probe 2: Other Product One (1 pan chicken cutlets)
Probe 3: Other Product Two (1 pan baked beans)
Probes & Multi-Batching
Covering Product
•Covering product is recommended but
not absolutely required.
•If used, plastic wrap/aluminum foil must
be placed in direct contact with product
surface.
•Some starch products are likely to dry
out if not covered (ex. mashed
potatoes, pasta, rice, cous cous, etc.).
•Covering is recommended to prevent
drying if product will not be removed
when done or left inside overnight.
NOTE
Using probes with small size
products (like chicken strips) is
not recommended. See CHILL
BY TIME for correct chilling
method.
Properly placed
Probe
Probe Adapter
Detail
•It is OK to load more than one type of product.
•When loading more than 3 pan levels it will be necessary
to group like products together, using one probe for each
product group (see example at left).
Probe 1
Probe 2
Probe 3

1. After placing product in chiller press BY TIME.
2: Press CHILL.
3: Adjust cycle time using the buttons to the
left and right of CYCLE TIME.
4: Press START.
NOTE:It is necessary to manually verify
and log product temp(s) before and after
chilling in order to complete documentation.
NOTE: If at end of cycle food temp is not
below 40°F chill for additional time by repeating steps 1 thru 4.
1. Load product into chiller.
2. Insert probe(s) and close door.
3. Press EZ START (see figure 1).
NOTE: To manually start a cycle, after Step 2
press BY TEMP - select cycle type
(ex. chill), adjust target temp (if desired)
then press START.
4
Basic Operation
Adding More Products To A Chill Cycle In Progress
1. Place probe in product, close the door.
2. Press ADD/REMOVE.
3. On the control, press the button next to the added probe #.
4. Press ADD/REMOVE.
5. Press CONTINUE.
NOTE: Failure to press CONTINUE will result in inaccurate data.
Starting A Chill Cycle (using EZ Start)
fig. 1
Chilling By Time (use for small, portion size products)
1. Defrost WILL occur automatically every 3-hours while in refrigerated mode.
2. Defrost WILL NOT occur until all probes reach 37°F. The chiller will beep for 20
seconds and a defrost cycle will begin if needed (even with product inside).
3. Food remaining in the chiller WILL remain safe during defrost because:
a) The inside air temperature is approx. 10-14°F, and...
b) Defrost time is generally less than 40-minutes.
4. Chill cycle data WILL be available after defrost. Press: MORE - PRINT, then
select the required probe number, then press RECORD and/or LABEL.
Defrost Notes

1. When a probe reaches target temp (37°F)
an alarm will sound for 30-seconds. The
display the will continuously flash DONE.
2. Press the button alongside the probe
flashing DONE.
3. The print menu will appear. Press...
- RECORD to receive a paper printout.
4. Repeat for additional probes.
5. Press NONE when complete to select next
probe or return to Main Menu (after last
probe).
6. Properly sanitize probes prior to next use.
Ending The Cycle/Printing
5TRAULSEN RBC50, RBC100 & RBC200 BLAST CHILLER TRAINING GUIDE
Printing
Paper
Cycle
Data
Printout
PRINT PROBE #1
RECORD
NONE
1. Remove the control cover or open printer access door on RBC50 (see figure 1).
2. Remove the paper spindle and discard the empty paper roll (see figure 2).
3. Open feed roller tension arm by gently pulling this down and forward (see figure 3).
4. Place a new paper roll onto the spindle and set this in the paper cradle. Note paper must be
loaded with thermal side facing up.
5. Feed paper up through the open feed roller tension arm (see figure 4).
6. Close feed roller tension arm and push paper through the slot in the control cover.
7. Replace control cover (close printer access door on RBC50).
NOTE: Replacement paper should be ordered using your division’s normal supplies
replenishment procedures.
Changing The Printer Paper
fig. 1 fig. 2 fig. 3 fig. 4
Folding paper into a
point as shown here
facilitates loading.

6
Care & Cleaning
Probes
Interior/Exterior
Condenser
1. Remove probes by turning the
circular locking ring which
secures these inside the chiller.
2. Wash/sanitize probes.
NOTE:Probes can be
immersed in water during
cleaning.
3. Allow probes to air dry before
replacing in chiller.
1. Disconnect power supply.
2. Clean both interior and exterior with a soft cloth as you
would any other stainless steel surface.
3. Do not...
•Use cleansers containing chlorine.
•Clean with anything abrasive.
•Hose off the blast chiller.
Cleaning the condenser is critical to insuring proper
performance and long compresor life.
1. Disconnect power supply.
2. Lift-up or remove louvers covering coil location:
•RBC50: Front/Left (see figure 1)
•RBC100: Bottom/Left
•RBC200: Front/Top
3. Wipe coil fins clear of any dust or debris present using
a dry shop cloth or pot brush.
4. Replace louvers.
5. Restore power.
fig. 1

4401 Blue Mound Road, Fort Worth, TX 76106 •[phone] • www.traulsen.com
TR99999
Kroger version
rev. 06/10)
Troubleshooting
7TRAULSEN RBC50, RBC100 & RBC200 BLAST CHILLER TRAINING GUIDE
PROBLEM: Upon starting a chill cycle, probe temp(s) displayed appear cooler
than expected (i.e. cooked temperature).
a. Product temp within cooked batches vary. Verify actual product temp with
thermometer (using same probed piece).
b. Probe placed incorrectly. Relocate probe per instructions on page 3.
c. Very small product (ex. chicken tender). Use chill by time (see page 4).
d. Product held too long at room temp prior to chilling. Verify actual product temp
with thermometer (using same probed piece).
PROBLEM: Defrost appears to have occured before chill cycle completion.
Defrost will not occur until all food probes have reached target temp and displayed DONE.
a. Chiller completed chill cycle for all probes. Retrieve cycle data after defrost.
PROBLEM: Control displays “Defrost sensor warning.”
Coil did not defrost to target temp, usually the result of too much ice build-up from either:
a. Previous chill cycle was very long and/or very large product load.
b. Starting a new chill cycle close to the regularly scheduled time when the chiller would
automatically defrost.
c. Product releasing much moisture during chilling. Cover product (see page 3).
d. A combination of 2 or more of the above issues.
PROBLEM: Incorrect date/time shown on display and/or printouts.
a. Incorrect time and/or date setting. Correct date and/or time settings.
PROBLEM: Cannot print probe data after chill cycle, or probe data on printout
appears incorrect (i.e. time and/or temperature differ from actual start time and/or
product temperature).
a. Product (probe) added to active chill cycle incorrectly (i.e. failure to press
ADD/REMOVE and/or CONTINUE).
PROBLEM: Product freezing.
a. Previously chilled product not removed and new chill cycle started. Remove DONE
product before starting a new chill cycle.
b. Chill cycle By Time set for too long. Reduce chill time.
c. High water content product (ex. soup). Use SOFTCHILL.
d. High water content food chilled uncovered. Cover food prior to chilling.
PROBLEM: Extended or unsafe chill times.
a. Excessive product load. Reduce product loaded.
b. Product too large or loaded too deep in pans. Reduce product size or depth.
c. Too much ice on evaporator coil. Cover product (if not already) and/or run manual
defrost prior to next chill cycle.
© 2010 Traulsen. All rights reserved.
