616 GSR Insert
Owner's Manual
Tested and Listed by
ANSI Z21.88 CSA 2.33

Direct Vent Fireplace Insert

Masonry or Factory Built (Metal) Wood-
Burning Fireplace

Residential or Mobile Home
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
This appliance may be installed in an
aftermarket permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local
codes.
This appliance is only for use with the
type(s) of gas indicated on the rating plate.
A conversion kit is supplied with the
appliance.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Copyright 2012, T.I. $10.00 100-01271_000 4051112
Travis Industries, Inc.
www.travisproducts.com
4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275

2Introduction
© Travis Industries 4051112 100-01271_000
Introduction
We welcome you as a new owner of a 616 GSR Insert. In purchasing this fireplace insert you have joined
the growing ranks of concerned individuals whose selection of an energy system reflects both a concern
for the environment and aesthetics. It is one of the finest home heaters the world over. This manual will
explain the installation, operation, and maintenance of this heater. Please familiarize yourself with the
Owner's Manual before operating your heater and save the manual for future reference. Included are
helpful hints and suggestions that will make the operation and maintenance of your new heater an easier
and more enjoyable experience. We offer our continual support and guidance to help you achieve the
maximum benefit and enjoyment from your heater.
Important Information
No other 616 GSR Insert has the same serial number
as yours. The serial number is below and to the left of
the gas control valve.
This serial number will be needed in case you require
service of any type.
Model: 616 GSR
Serial Number:
Purchase Date:
Purchased From:
Register your warranty online at:
traviswarranty.com
Or, mail your warranty card to:
Travis Industries House of Fire
4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275
Save Your Bill of Sale.
To receive full warranty coverage, you will
need to show evidence of the date you
purchased your heater. Do not mail your Bill
of Sale to us.
We suggest that you attach your Bill of Sale
to this page so that you will have all the
information you need in one place should the
need for service or information occur.
Listing Details
This appliance was listed by Intertek. The listing label is attached to the appliance near the gas control
valve. A copy is shown on page 46.
Massachusetts Approval
This manual has been submitted to the Massachusetts Board of State Examiners of Plumbers and Gas
Fitters.
National Fireplace Institute

Table of Contents 3
© Travis Industries 4051112 100-01271_000
Introduction ......................................................2
Important Information......................................2
Listing Details...................................................2
Features ............................................................6
Installation Options..........................................6
Heating Specifications.....................................6
Dimensions.......................................................6
Electrical Specifications (for blowers)...........6
Fuel....................................................................6
Installation Warnings.......................................7
Packing List......................................................7
Additional Items Required...............................7
Order of Installation.........................................7
Fireplace Requirements ..................................8
Fireplace Clearances to Gas Insert.......................8
Factory-Built (Metal) Wood-Burning Fireplace
Requirements........................................................9
Hearth Requirements.......................................9
Leveling Bolts.................................................10
Electrical Requirements................................11
Clearances......................................................11
Mantel Clearances..............................................11
Gas Line Requirements.................................12
Gas Inlet Pressure..............................................12
Directions for Connecting a Gas Pressure Test
Gauge.................................................................12
Gas Line Installation......................................13
Vent Requirements ........................................14
Altitude Considerations....................................14
Exhaust Restrictor.........................................15
Adjusting the Exhaust Restrictor.........................16
Diffuser Adjustment.......................................17
Adjusting the Diffuser..........................................17
Vent Installation .............................................18
Vent Location......................................................19
Vent Configurations ............................................19
Vent Attachment – Tight Installations..................20
Vent Connector Attachment................................21
Glass Frame Removal and Installation........24
Steps for Finalizing the Installation .............25
Air Shutter Adjustment........................................26
Burner Removal..................................................27
Before You Begin...........................................30
Remote Set-Up...............................................30
Verify the Fan Control Module Is On...................30
Synchronize the Transmitter to the Receiver......30
Starting the Heater for the First Time..........31
Location of Controls......................................31
Direct Operation.............................................32
Accent Lights.................................................33
Continuous/Intermittent Pilot Switch...........34
Remote Operation..........................................34
Display Overview................................................34
Listen for the “Beep” ...........................................34
Manual On-Off / Smart Thermostat / Standard
Thermostat..........................................................35
Mode Controls (Flame, Blower, Light, Comfort
Control)...............................................................36
Flame Height.................................................36
Blower Speed................................................36
Mode Controls (continued)..................................37
Accent lights (Aux) ........................................37
Comfort Control (Rear Burner)......................37
Low Battery Indicator....................................38
Transmitter Batteries...........................................38
Receiver Batteries...............................................38
Child-Proof Feature .......................................38
Power Outages...............................................39
Display Fahrenheit or Celsius ......................39
Normal Operating Sounds ............................39
Normal Operating Odors...............................39
Battery Replacement.....................................40
Receiver Battery Installation ...............................40
Transmitter Battery Installation ...........................40
Accent Light Replacement............................41
Accent Light Installation......................................41
Lower Accent Lights......................................41
Upper Accent Lights......................................41
Yearly Service Procedure .............................43
Replacement Parts ........................................44
Troubleshooting Table..................................44
Wiring Diagram ..............................................45
Safety Label........................................................46
CONDITIONS & EXCLUSIONS......................47
IF WARRANTY SERVICE IS NEEDED:.........47
LP Conversion Instructions..........................48

4Safety Precautions
© Travis Industries 4051112 100-01271_000
IF YOU SMELL GAS:
* Do not light any appliance
* Extinguish any open flame
* Do not touch any electrical switch or plug or unplug anything
* Open windows and vacate building
* Call gas supplier from neighbor's house, if not reached, call fire department
This unit must be installed by a qualified installer to prevent the possibility of an explosion.
Your dealer will know the requirements in your area and can inform you of those people
considered qualified. The room heater should be inspected and cleaned before use and at
least annually by a qualified service person. More frequent cleaning may be required due to
excessive lint from carpeting, bedding material, etc.
The instructions in this manual must be strictly adhered to. Do not use makeshift methods or
compromise in the installation. Improper installation will void the warranty and safety listing.
This heater is either approved for natural gas (NG) or for propane (LP). Burning
the incorrect fuel will void the warranty and safety listing and may cause an
extreme safety hazard. Direct questions about the type of fuel used to your dealer.
Check for a label on the flame adjust knob on the gas control valve (this is the best
place to check). You may also check for a label on the gas control valve body.
Contact your local building
officials to obtain a permit and
information on any installation
restrictions or inspection
requirements in your area.
Notify your insurance company
of this heater as well.
If the flame becomes sooty, dark
orange in color, or extremely tall,
do not operate the heater. Call
your dealer and arrange for
proper servicing.
It is imperative that control
compartments, screens, or
circulating air passageways of
the heater be kept clean and
free of obstructions. These
areas provide the air necessary
for safe operation.
Do not operate the heater if it is
not operating properly in any
fashion or if you are uncertain.
Call your dealer for a full
explanation of your heater and
what to expect.
Do not store or use gasoline or
other flammable liquids in the
vicinity of this heater.
Do not operate if any portion of
the heater was submerged in
water or if any corrosion occurs.
Immediately call a qualified
service technician to inspect the
appliance and to replace any part
of the control system that has
been under water.
Ok
?
Gas







Safety Precautions 5
© Travis Industries 4051112 100-01271_000
• Do not place clothing or other
flammable items on or near the
heater. Because this heater can be
controlled by a thermostat there is
a possibility of the heater turning on
and igniting any items placed on or
near it.
• Light the heater using the built-in
igniter. Do not use matches or
any other external device to light
your heater.
• Allow the heater to cool before
carrying out any maintenance or
cleaning.
• Viewing glass should only be
removed for service. Any safety
screen or guard removed for
servicing must be replaced prior to
operating the heater. Do not
operate with the glass removed or
damaged. Replacement of the
glass should be done by a licensed
or qualified service person.
• Never remove, replace, modify or
substitute any part of the heater
unless instructions are given in
this manual. All other work must
be done by a trained technician.
Don't modify or replace orifices.
Replace glass with Travis glass
only.
• Operate the heater according to the
instructions included in this manual.
• If the main burners do not start
correctly turn the gas off at the gas
control valve and call your dealer
for service.
• Instruct everyone in the house
how to shut gas off to the
appliance and at the gas main
shutoff valve. The gas main
shutoff valve is usually next to
the gas meter or propane tank
and requires a wrench to shut off.
• This unit is not for use with solid
fuel
• Do not place anything inside the
firebox (except the media).
• If the media becomes damaged,
replace with Travis Industries
media set.
• Do not throw this manual away.
This manual has important
operating and maintenance
instructions that you will need at
a later time. Always follow the
instructions in this manual.
Young children should be carefully
supervised when they are in the
same room as the appliance.
Toddlers, young children and
others may be susceptible to
accidental contact burns. A
physical barrier is recommended if
there are at risk individuals in the
house. To restrict access to a
fireplace or stove, install an
adjustable safety gate to keep
toddlers, young children and other
at risk individuals out of the room
and away from hot surfaces.
• Plug the heater into a 120V
grounded electrical outlet. Do
not remove the grounding plug.
• Don’t route the electrical cord in
front of, over, or under the heater
Travis Industries, Inc. grants
no warranty, implied or stated,
for the installation or
maintenance of your heater,
and assumes no responsibility
of any consequential
damage(s).









This
Manual

6Features and Specifications
© Travis Industries 4051112 100-01271_000
Features
- Works During Power Outages (battery backup system)
- Blowers and Remote Control Included
- Continuous or Intermittent (GreenSmart) Pilot
- Convenient Operating Controls
- Variable-Rate Heat Output
- Accent Lights
Installation Options
Residential or Mobile Home
Fireplace Insert
Masonry or Factory Built (Metal) Wood-
Burning Fireplace
Heating Specifications
Natural Gas Propane
Approximate Heating Capacity (in square feet)* 600 to 2,000 600 to 2,000
Maximum BTU Input Per Hour 39,000 39,000
* Heating capacity will vary with floor plan, insulation, and outside temperature.
Dimensions
Electrical Specifications (for blowers)
Electrical Rating.............................................................120 Volts, 1.8 Amps, 60 Hz (205 watt)
Fuel This heater is shipped in natural gas (NG) configuration but may be converted to propane (LP) using
the LP Conversion Kit (included) and the LP stepper motor (SKU 94400999, sold separately). The
sticker on top of the gas control valve will verify the correct fuel.
* See "Fireplace Requirements"
for minimum fireplace sizing.
24" *
(610mm) *
16" *
(407mm) *
34" *
(864mm) *
Small 42" (1067mm)
Large 44" (1118mm)
Small 30-1/2"
(775mm)
Large 34"
(864mm)
23-5/16" *
(593mm) *

Installation (for qualified installers only) 7
© Travis Industries 4051112 100-01271_000
Installation Warnings
Failure to follow all of the requirements may result in property damage, bodily injury, or even
death.
This heater must be installed by a qualified installer who has gone through a training program
for the installation of direct vent gas appliances.
The installation must conform with local codes or, in the absence of local codes, the National
Fuel Gas Code, ANSI Z223.1/NFPA 54, or the National Gas and Propane Installation Code, CSA
B149.1.
In Manufactured or Mobile Homes must conform with Manufactured Home Construction and
Safety Standard, Title 24 CFR, Part 3280, or, when such a standard is not applicable, the
Standard for Manufactured Home Installations, ANSI/NCSBCS A225.1. This appliance may be
installed in Manufactured Housing only after the home is site located.
The heater is designed to operate on natural gas, or propane (LP).
All exhaust gases must be vented outside the structure of the living-area. Combustion air is
drawn from outside the living-area structure.
Notify your insurance company before hooking up this heater.
The requirements listed below are divided into sections. All requirements must be met
simultaneously. The order of installation is not rigid – the qualified installer should follow the
procedure best suited for the installation.
Packing List
Propane (LP) Conversion Kit

"Fireplace Altered" tag (attach to the fireplace)
Additional Items Required
Faceplate
3" and 4” Diameter Gas Liner with Termination (Kit – SKU 96200331)
Gas Line Equipment (shutoff valve, pipe, etc.)
Panel Kit
Fireback Kit
Media
Faceplate
LP only: LP Stepper Motor (SKU 94400999)
Order of Installation
1. Run gas line to the fireplace
2. Remove the glass frame.
3. Run vent through fireplace chimney. On larger fireplaces, the vent connector may be left in place. For
smaller fireplaces, remove the vent connector. See “Vent Connector Removal and Installation” for details.
INSTALLATION WARNING: If using a tall vent (over 25’) – you must open the diffuser before
attaching the vent. See “Diffuser Adjustment” for details.
INSTALL THE LIGHT SHIELD (ALL FACES EXCEPT SHADOWBOX). The light shield (shipped
with the face) prevents light from exiting the upper grill area. Install this prior to placing the insert.
4. Place insert into position and attach the gas line and vent.
5. Remove the burner.
NOTE: If using propane (LP), convert the appliance at this time.
6. Install the firebacks.
7. Replace the burner.
8. Install the media (logs, stones - see instructions included with the media).
9. Install the surround panel (see instructions included with surround panel).
10. Replace the glass.
11. Install the face (see instructions included with the face).
12. Follow the instructions under “Finalizing the Installation.”

8Installation (for qualified installers only)
© Travis Industries 4051112 100-01271_000
Fireplace Requirements
Insert must be placed within a code-conforming masonry fireplace or tested and listed factory-built
(metal) wood-burning fireplace. Repair any fireplace damage prior to installation.
Because the insert uses a circulation blower, clean the fireplace, smoke shelf, and chimney prior to
installation.
This heater may be placed in a bedroom. Please be aware of the large amount of heat this appliance
produces when determining a location.
Do not place insulation or any other material on top of the insert. This may block the upper accent
light ventilation, leading to premature bulb failure.
Fireplace Sizing
Minimum Height 24-1/4” (616mm)
Minimum Width 35” (889mm)
Minimum Depth 16-1/2” (420mm)
Hearth Depth (see
“Hearth Requirements”
on the following page
for full details)
12” (305mm)
The gas and electrical line should be installed prior
to installing the heater.
For tight fits (under 28”) see the section
“Removing the Vent Connector”
See “Leveling Bolts” for details on leveling the
heater.
hAttach the “This fireplace has been altered…” plate to the fireplace (use two screws or other
suitable method). You may wish to place it in a location where it will be covered by the surround panels.
Fireplace Clearances to Gas Insert
Side of Insert to Inside of Fireplace ½” (13mm)
Back of Insert to Inside of Fireplace ½” (13mm)
Top of Insert to Inside of Fireplace 5/8” (18mm)
a
b
c
e
f
g
d
h
a
b
c
d
e
f
g

Installation (for qualified installers only) 9
© Travis Industries 4051112 100-01271_000
Factory-Built (Metal) Wood-Burning Fireplace Requirements
NOTE: Any parts that are removed must be removed in a way that would allow them to be re-installed if
the insert is ever removed (removal of rivets or screws is acceptable).
The damper ("A") and grate (with log set) ("B") must be removed (see the illustration below)
The smoke shelf ("C"), internal baffles ("D"), screen ("E"), masonry lining or refractory ("G" & "I"), and
metal or glass doors ("F") may be removed (if applicable)
The fireplace must be permanently marked to
indicate that it has been altered and is no longer
suitable for burning solid fuel (wood), unless the
removed parts are re-installed. Cutting of any
sheet metal parts is prohibited.
The metal floor (“J”) of the firebox may be removed
in certain cases*.
The insulation ("H"), and any structured rigid frame
members must not be removed or altered (side and
top of door frame, side and top of the face of the
fireplace, metal sides, etc.).
The surround panels should not seal ventilation
openings on the fireplace.
*CAUTION: Firebox floor removal is not covered under the appliance safety standard (ANSI Z21.88 CSA 2.33)
used in the safety certification of this appliance. The Intertek safety certification does not apply to this method
of installation. Before installing the appliance using this method, contact the Authority Having Jurisdiction to
determine if this installation is acceptable in your area. The sheet metal base of the fireplace must be left in
place and a minimum ½” cement board sheet placed under the entire length and width of the appliance.
If the factory-built fireplace has no gas access hole(s) provided, an access hole of 1.5 inch (37.5 mm) or
less may be drilled through the lower sides or bottom of the firebox in a proper workmanship like manner.
This access hole must be plugged with non-combustible insulation after the gas supply line has been
installed.
Hearth Requirements
½” of non-combustible material is required underneath the insert
½” of non-combustible material must extend 12” in front of the insert for the full width of the
unit (34”).
RAISED INSERTS: If the insert is raised a minimum of 16” above the flooring (or other
combustible material), a non-combustible hearth is not required in front of the insert.






C
B
F
I
D
E
A












G




H

J

10 Installation (for qualified installers only)
© Travis Industries 4051112 100-01271_000
Leveling Bolts
This heater includes front and rear leveling bolts to accommodate fireplaces with a step-down firebox.
NOTE: To access the rear leveling bolts, remove the burner (see page 48).
The leveling bolt holes are shown below.
1. Remove the cover and gasket to access the rear leveling bolt.

Installation (for qualified installers only) 11
© Travis Industries 4051112 100-01271_000
Electrical Requirements
Plug the power cord into a grounded 120 Volt outlet (do not remove the grounding pin).
The appliance, when installed, must be electrically grounded in accordance with local codes or, in the
absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical
Code, CSA C22.1.
Clearances
Due to the high temperature of the heater, it should be located out of traffic and away from furniture and draperies.
Minimum
Clearances
k Sidewall to Insert 6"
153mm
l Side Facing
(non-combustible) 5"
127mm
m Top Facing*
(non-combustible) 35.5"
902mm
n 12” Mantel*
(combustible or
non-combustible)
36.5"
928mm
n 4” Mantel*
(combustible or
non-combustible)
33"
839mm
p Hearth Extension
to the Front 12"
305mm
x Extension onto
Hearth 0"
0mm
* Measured from the base of the insert.
NOTE: the non-combustible top facing
must extend 35.5” (902mm) above the
base of the insert or to the bottom of the
mantel (whichever is less).
Mantel Clearances
The maximum mantel depth is 12” (305mm).
NOTE: The combustible area above the facing must not protrude more than 3/4" (20mm) from the facing.
If it does, it is considered a mantel and must meet the mantel requirements listed in this manual.
Side
Wall
Co
mbustible or Non-Combus tible Ma ntel
Comb
ustible Top Facing
Non-Combustible
Facing
l
k
x
n
m
p
Mantel Height
Above Base of Insert (n)
36"(915mm)
35"(889mm)
34"(864mm)
33"(839mm)
37"+(940mm+)
32"(813mm)
31"(788mm)
0"
1" (26mm)
2" (51mm)
8" (204mm)
7" (178mm)
6" (153mm)
5" (127mm)
4" (102mm)
3" (77mm)
9" (229mm)
10" (254mm)
11" (280mm)
12" (305mm)
Maximum Mantel Depth

12 Installation (for qualified installers only)
© Travis Industries 4051112 100-01271_000
Gas Line Requirements
MASSACHUSETTS INSTALLATIONS - WARNING:
THIS PRODUCT MUST BE INSTALLED BY A LICENSED PLUMBER OR GAS FITTER WHEN INSTALLED WITHIN THE
COMMONWEALTH OF MASSACHUSETTS.
OTHER MASSACHUSETTS CODE REQUIREMENTS:
Flexible connector must not be longer than 36 inches.
Shutoff valve must be a “T” handle gas cock.
Only direct vent sealed combustion products are approved for bedrooms or bathrooms.
Fireplace dampers must be removed or welded in the open position prior to the installation of a fireplace insert or gas log.
A carbon monoxide (CO) detector is required in the same room as the appliance.
The gas line must be installed in accordance with all local codes, if any; if not, follow ANSI 223.1 and
the requirements listed below.
A manual shutoff valve is required within 3’ of the heater. It should be placed upstream of the flex line
(if used) and may be installed behind the access door inside the heater. ).
The heater and gas control valve must be disconnected from the gas supply piping during any
pressure testing of that system at test pressures in excess of 1/2 psig. For pressures under 1/2 psig,
isolate the gas supply piping by closing the manual shutoff valve.
Leak test all gas line joints and the gas control valve prior to and after starting the heater.
This heater is designed either for natural gas or for propane (but not for both). Check the sticker on
the top of the gas control valve to make sure the correct fuel is used (see illustration on page 4).
Installation must be performed by a qualified installer, service agency or the gas supplier (In
Massachusetts a licensed plumber/gas-fitter).
Gas Inlet Pressure Standard Input Pressure
Natural Gas 7" W.C. (1.74 kPA)
Propane 13" W.C. (2.73 kPA)
If the pressure is not sufficient, make sure the piping used is large enough, the supply regulator is
adequately adjusted, and the total gas load for the residence does not exceed the amount supplied.
The supply regulator (the regulator that attaches directly to the residence inlet or to the propane tank)
should supply gas at the suggested input pressure listed above. Contact the local gas supplier if the
regulator is at an improper pressure.
Directions for Connecting a Gas Pressure Test Gauge
The gas control valve (shown to the left) has two accessible ports for testing
line pressure and output pressure. Loosen the brass screw on either test port
and place a 5/16” i.d. rubber or plastic tubing over the tapered test port.
Connect the tubing to the test gauge.
WARNING: The brass screw must be tightened after testing to prevent gas
leakage.
Input pressure
Output pressure

Installation (for qualified installers only) 13
© Travis Industries 4051112 100-01271_000
Gas Line Installation
Route the included flex tube through the hole in the left side of the insert and out the front as shown below.
Bend the flex tube up as shown below.
Attach the included gas shutoff valve to the end of the flex tube and gas inlet as shown below. Position so
the valve is on the right as shown.
Leak-test all gas line connections.

14 Installation (for qualified installers only)
© Travis Industries 4051112 100-01271_000
Vent Requirements
Travis Industries manufactures a
vent kit specifically for this insert
(sku 96200331). It includes 30’
(10M) of vent, hose clamps, and a
prairie cap. The flashing on the cap
is 18” (458mm) by 18” (458mm).
The gas appliance and vent system must be vented directly to the outside of the building, and never
be attached to a chimney serving a separate solid fuel or gas-burning appliance. Each direct vent
gas appliance must use its own separate vent system.
Make sure the exhaust pipe on the heater connects to the exhaust portion of the cap. The
illustrations below show how the flex liners should be attached.
The exhaust vent must reline the entire length of the chimney and terminate above the chimney top
Be careful not to crimp or rupture the liner when bending it into chimney offsets
When installed, the vent must meet all of the vent manufacturer's requirements
Use the following vent:
4” UL 441 or 1777 Gas Liner for Exhaust, 3” UL 441 or 1777 Gas Liner for Air Inlet
Simpson Duravent 6-5/8” to 3” & 4” Co-Linear Adapter and Flashing (Travis Part # 98900124).
Simpson Duravent High-Wind Vertical Termination Cap (46DVA-VCH) or Prairie Cap
Altitude Considerations
This heater has been tested at altitudes ranging from sea level to 6,000 feet (1,800 M). In this testing
we have found that the heater, with its standard orifice, burns correctly with just an air shutter
adjustment.
Failure to adjust the air shutter properly may lead to improper combustion which can create a safety
hazard. Consult your dealer or installer if you suspect an improperly adjusted air shutter.
















M
ax. Ht. 40' (12.2M)
M
in. Ht. 8' (2.5M)
Exhaust
Max. 2'
(610mm)
offset
Inlet
Exhaust
(4
”
dia.)
Inlet
(3
”
dia.)

Installation (for qualified installers only) 15
© Travis Industries 4051112 100-01271_000
Exhaust Restrictor
Set the exhaust restrictor to the required position as shown in the table below.
NOTE: The exhaust restrictor position is determined by laboratory testing, optimum position may vary slightly.
Restrictor Settings
Traditional Logs Restrictor Settings
Driftwood Logs Restrictor Settings
Stones
Natural Gas Short Vent
(25’ or less) #3 (stock) #1 #2
Natural Gas Tall Vent
(25’ or more) #3 (stock) #3 (stock) #3 (stock)
Propane Short Vent
(25’ or less) #1 #1 #2
Propane Tall Vent
(25’ or more) #3 (stock) #3 (stock) #4
Restrictor adjustment should only be done by a qualified installer.

16 Installation (for qualified installers only)
© Travis Industries 4051112 100-01271_000
Adjusting the Exhaust Restrictor
Loosen the 4 screws holding the exhaust restrictor in place using a ¼” nutdriver.
Slide the exhaust restrictor to the desired position. The photo below shows the exhaust restrictor in
position #1.

Installation (for qualified installers only) 17
© Travis Industries 4051112 100-01271_000
Diffuser Adjustment
Adjusting the Diffuser
Adjust the restrictor to the setting described in the table below.
Diffuser
Natural Gas Short Vent
(25’ or less)
Closed (stock)
Natural Gas Tall Vent
(25’ or more)
Open
Propane Short Vent
(25’ or less)
Closed (stock)
Propane Tall Vent
(25’ or more)
Open
The diffuser must be adjusted before attaching the vent (it is attached to the vent connector and is
concealed once the vent is installed). Use a screwdriver or pliers to bend the diffuser to a vertical position.
Diffuser Closed (stock) Diffuser Open

18 Installation (for qualified installers only)
© Travis Industries 4051112 100-01271_000
Vent Installation
Secure the vent to the insert and termination kit using screws.
NOTE: The appliance will slow down within 5 to 10 minutes due to the bi-metallic closing time. The
restrictor position is based on laboratory testing. The optimum position may vary slightly.
Inlet
Exhaust
Duravent
Chimney Liner
Termination Kit
3" (76mm) dia.
4" (102mm) dia.

Finalizing the Installation 19
© Travis Industries 4051112 100-01271_000
Vent Location
An Exhaust Restrictor is built into the appliance to adjust the flow rate of exhaust gases. This
ensures proper combustion for all vent configurations. Depending upon the vent configuration, you
may be required to adjust the restrictor position. See “Exhaust Restrictor” on page 15.
Vent Configurations
Inlet














Z.C. (Metal) Wood-Burning Fireplace
Inlet & Exhaust Re-Line
(recommended)





























































































Exhaust Only Re-Line
(not recommended)
Direct Vent Cap
Recommended Block-Off
Plate (non-combustible
metal and/or insulation).
Prevents odors from
chimney entering room.
6-5/8" to 3" & 4" Colinear
Adapter & Flashing


















A block-off plate must
seal the intake to the
chimney space. This
way air is drawn down
the chimney for
combustion air.
Block-Off Plate
(non-combustible
materials)
NOTE: You may use either re-line configuration with a masonry or zero-clearance fireplace.
Inlet
Masonry Fireplace
Any cracks or
damage inside the
chimney must be
repaired.
Exhaust Exhaust

20 Finalizing the Installation
© Travis Industries 4051112 100-01271_000
Vent Attachment – Tight Installations
The vent connector is shipped attached to the insert, but must be removed to facilitate tight
installations. See the directions below for installation.
1. Route the flex vent through the chimney from above (leave an extra 3' at the top). Make sure the flex
is thoroughly stretched.
2. Remove the vent connector from the unit and attach it to the flex vent (see the instructions on the
following page).
3. Pull on the flex vent until the vent connector is at the same height as the insert. Temporarily attach
the flex vent to the top of the chimney (leave extra slack).
4. Slide the insert into place, guiding the vent connector into the guides on top of the insert.
5. Attach the vent connector to the appliance (see the following page for details).
6. Remove any excess slack in the flex line and attach the vent termination.
4





















































































































3


































































































































































































2
1






5







































































































6








2
