Treasure Garden AG25TSQ Installation instructions

Assembly and Operation Guide
www.treasuregarden.com
©2021 Treasure Garden, Inc. - All Rights Reserved.
v.05.18.21
AG25T CANTILEVER
AG25T 11.5’ octagon
AG25TSQ 10’ square
WARRANTY:
Treasure Garden warrants this product
(for residential use ONLY) to be free
from defects in original materials and
workmanship for a period of 1 year from
the date of purchase. If a defect in the
original material or workmanship appears
during the warranty period; Treasure
Garden will (at its discretion) repair or
replace the product without charge.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
In many cases, simple problems can
be solved with a replacement part that
can be shipped directly to the dealer for
professional installation / repair.
Tampering with or altering the product will
void warranty.
In the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges for the first year only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped / billed
at your expense.
This warranty gives you specific legal
rights, and you may have other rights
which vary from state to state.
RUST: Rust is a natural part of the aging
process of steel or iron based materials,
and is therefore NOT considered a defect.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect
of reasonable and necessary care are not
covered by this warranty.
Additionally, acts of nature (including but
not limited to wind, hurricanes, tornadoes,
and storms) are not covered by this
warranty.
SAFETY PRECAUTIONS
• To reduce risk of personal injury in which a person is injured or harmed, and/or damage
to personal property, read and follow the Assembly Guide prior to assembling and
operating umbrella and base.
• Close and store the umbrella in windy conditions or when a storm approaches. Never
allow the umbrella to flap in the wind; this could cause personal injury, damage to
personal property, damage to umbrella and/or umbrella canopy. Do not use tilting
function during windy conditions.
• Keep umbrella secured to umbrella base at all times.
• Do not leave open umbrella unattended. If damage occurs, this is not covered by the
warranty.
• When adjusting the umbrella, make sure that no person(s), item(s) or personal property
are close to the umbrella. This is important to prevent injury or material damage.
• Do not allow children to play on or with umbrella or umbrella base.
• When adjusting or assembling the umbrella or umbrella base, make sure fingers, toes
or any other parts of the body are clear from moving parts. Failing to do so many result
in serious injury.

Thank you for purchasing Treasure Garden’s AG25T Cantilever.
Please remove all contents from the package, inspect and review checklist.
Some parts may be included in the styrofoam packaging.
Do not discard any packaging or box until assembly is complete.
CHECKLIST
61
A - (1) 360°Rotating Hub I - (1) Crank Handle
B - (1) Foot Pedal J - (1) Canopy Support Beam
C - (1) Hardware Assembly K - (1) Finial
D - (1) Main Frame L - (1) Canopy
E - (1) Adjustment Knob M - (7) Spring Loaded Rib End Cap
F - (1) Open/Close Mechanism N - (1) Valance (optional)
G - (1) Tilt Mechanism O - (1) Light Adapter (light sold separately)
H - (1) Tilt Degree Scale P - (1) Protective Cover
IMPORTANT:
Prior to assembly it is important to decide on the location of the umbrella.
·Allow ample height to avoid damage to your umbrella during assembly and usage.
·Choose a location that is level and sturdy.
·Avoid any sloping of soft ground.
·Consider a location that will maximize the umbrella’s 360°rotating function. Placing the
umbrella between two entertaining areas is ideal.
CAUTION:
·Fully assembled, the umbrella weighs over 300 lbs. Moving umbrella fully assembled
will increase the risk of damage to your umbrella and/or can cause serious injury. We
recommend a two-person team for assembly and disassembly.
Close Open
Right Left
Open
Max
0˚
Max
K
L
D
N
J
M
O
P
A
B
E
C
6mm Hexagon
Wrench
FG
H
I
CARE AND MAINTENANCE
• When not in use, close and cover umbrella with provided protective cover.
• Allow a wet canopy to dry while in open position, but do not leave unattended.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry place.
After the Winter:
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
Cl Open
Right Left
Open
Max
0˚
Max
(Fig. 13)
(Fig. 14) (Fig. 15)
STEP 6CLOSING UMBRELLA
Position yourself behind umbrella. Insert crank handle into “Open/Close” socket in crank
mechanism (Fig. 13). Turn crank handle counter clockwise until the canopy is closed
(Fig. 14). Turn adjustment knob counter clockwise and slide downward until umbrella is in
closed position. Tie string around canopy to secure canopy. Cover umbrella with provided
protective cover when not in use (Fig. 15). NOTE: Prior to closing ensure that the canopy
is in a level (non-tilt) position. Properly store umbrella when not in use. Close umbrella, tie
string around canopy and cover umbrella with provided protective cover.
TO PROPERLY FOLD CANOPY:
The canopy will last longer if you fold it as it was packed and shipped. This technique is
similar to the way a parachute is folded and is especially important when folding the canopy
for seasonal storage or when left in the closed position for an extended period of time.
Using this technique at all times will significantly extend the life of the canopy.
• When the umbrella has been fully closed, stand in front of the canopy
structure and begin the folding process by pulling out two panels
opposite the main frame. Pull the two panels together and roll tight into
the canopy.
• Once rolled tight, pull adjacent panels out one at a time and fold to the
center, alternating sides until all the panels have been pulled out from
the arms and folded into the center.
• Tie string around canopy and cover umbrella with provided protective
cover.

25
STEP 1UMBRELLA ASSEMBLY
Two-persons recommended for team lift and to complete assembly.
With base cover in place or mount kit installed, lift umbrella up and insert the main frame
onto the installed rotating hub (Fig. 1). Secure umbrella into place by inserting the (2) bolts
and (2) washers and tighten using 6mm hexagon wrench provided (Fig. 2).
REMOVE ALL PLASTIC PACKAGING MATERIAL FROM ALL PARTS PRIOR TO
OPENING UMBRELLA. CHECK UNDER CANOPY FOR PACKAGING AROUND RIBS.
Your umbrella is now ready for use!
NOTE: REFER TO SEPARATE BASE OR MOUNT KIT MANUAL
FOR BASE ASSEMBLY PRIOR TO PROCEEDING.
(Fig. 1) (Fig. 2)
Foot Pedal
Main Frame
Rotating Hub
360
(Fig. 10)
STEP 4ROTATING UMBRELLA
Place your foot on the foot pedal of the rotating hub and step-on the pedal to release
rotating lock (Fig. 10). Place hands on the main frame and rotate the umbrella frame
in either direction, in 90° increments. To lock position, step off the foot pedal to engage
rotating lock.
(Fig. 11) (Fig. 12)
STEP 5LIGHT ADAPTER FEATURE
To ATTACH Umbrella Light: (sold separately)
Loosen the light adapter built into the umbrella runner by turning counter-clockwise
(Fig. 11). After loosening, pull down light adapter post (Fig. 12) to attach the umbrella light
(sold separately).
To REMOVE Light and CLOSE adapter:
Hold the umbrella light, depress the clamp release button to release the clamp lock.
Remove umbrella light and gently push up the light adapter post back into umbrella runner
and tighten turning clockwise (Fig. 11).
NOTE: It may be necessary to lower umbrella to a reachable height to pull light adapter
down and attach umbrella light. It is not necessary to remove light to close umbrella.
IMPORTANT:
For free standing base applications, it is imperative to install the appropriate base for your
size cantilever. The minimum base weight recommended for the AG25T is 200 lbs.

43
(Fig. 3)
(Fig. 4)
STEP 2OPENING UMBRELLA
Position yourself behind umbrella. In the closed position, turn adjustment knob counter
clockwise (Fig. 3) and slide the adjustment knob upward (Fig. 4). Turn adjustment knob
clockwise to tighten and secure in place.
Right Left
Max
0˚
Max
Close Open
Cl Open
Right Left
Open
Max
0˚
Max
Insert crank handle into “Open/Close” socket in crank mechanism (Fig. 5). Turn crank
handle clockwise until the canopy is fully open (Fig. 6). CAUTION: Stop turning the crank
handle as soon as the umbrella canopy is completely open and the sleeve on the umbrella
center pole has reached its maximum height.
(Fig. 5)
(Fig. 6)
(Fig. 9)
(Fig. 8)
Right Left
Max
0˚
Max
Close Open
Open
(Fig. 7)
STEP 3TILTING UMBRELLA
To Tilt Canopy Vertically:
IMPORTANT: PRIOR TO USING VERTICAL AND HORIZONTAL TILT FEATURE.
To avoid personal injury or damage to the umbrella, make sure the area behind you is clear
and free from any furniture or structure.
Position yourself behind umbrella. Turn adjustment knob counter clockwise (Fig. 7) and
slide car up and downward until desired height and angle is reached (Fig. 8). Tighten the
adjustment knob clockwise to lock its position. NOTE: Do not use tilt function during winds.
To Tilt Canopy Horizontally:
IMPORTANT: PRIOR TO USING VERTICAL AND HORIZONTAL TILT FEATURE.
To avoid personal injury or damage to the umbrella, make sure the area behind you is clear
and free from any furniture or structure.
Insert crank handle into “Right/Left” socket in crank mechanism (Fig. 9). To tilt canopy right,
turn crank handle counter clockwise. To tilt canopy left, turn crank handle clockwise.
NOTE: We do not recommend tilting vertically and horizontally at a maximum tilt degree for a
prolonged period of time. Doing so may result in damage to umbrella.

43
(Fig. 3)
(Fig. 4)
STEP 2OPENING UMBRELLA
Position yourself behind umbrella. In the closed position, turn adjustment knob counter
clockwise (Fig. 3) and slide the adjustment knob upward (Fig. 4). Turn adjustment knob
clockwise to tighten and secure in place.
Right Left
Max
0˚
Max
Close Open
Cl Open
Right Left
Open
Max
0˚
Max
Insert crank handle into “Open/Close” socket in crank mechanism (Fig. 5). Turn crank
handle clockwise until the canopy is fully open (Fig. 6). CAUTION: Stop turning the crank
handle as soon as the umbrella canopy is completely open and the sleeve on the umbrella
center pole has reached its maximum height.
(Fig. 5)
(Fig. 6)
(Fig. 9)
(Fig. 8)
Right Left
Max
0˚
Max
Close Open
Open
(Fig. 7)
STEP 3TILTING UMBRELLA
To Tilt Canopy Vertically:
IMPORTANT: PRIOR TO USING VERTICAL AND HORIZONTAL TILT FEATURE.
To avoid personal injury or damage to the umbrella, make sure the area behind you is clear
and free from any furniture or structure.
Position yourself behind umbrella. Turn adjustment knob counter clockwise (Fig. 7) and
slide car up and downward until desired height and angle is reached (Fig. 8). Tighten the
adjustment knob clockwise to lock its position. NOTE: Do not use tilt function during winds.
To Tilt Canopy Horizontally:
IMPORTANT: PRIOR TO USING VERTICAL AND HORIZONTAL TILT FEATURE.
To avoid personal injury or damage to the umbrella, make sure the area behind you is clear
and free from any furniture or structure.
Insert crank handle into “Right/Left” socket in crank mechanism (Fig. 9). To tilt canopy right,
turn crank handle counter clockwise. To tilt canopy left, turn crank handle clockwise.
NOTE: We do not recommend tilting vertically and horizontally at a maximum tilt degree for a
prolonged period of time. Doing so may result in damage to umbrella.

25
STEP 1UMBRELLA ASSEMBLY
Two-persons recommended for team lift and to complete assembly.
With base cover in place or mount kit installed, lift umbrella up and insert the main frame
onto the installed rotating hub (Fig. 1). Secure umbrella into place by inserting the (2) bolts
and (2) washers and tighten using 6mm hexagon wrench provided (Fig. 2).
REMOVE ALL PLASTIC PACKAGING MATERIAL FROM ALL PARTS PRIOR TO
OPENING UMBRELLA. CHECK UNDER CANOPY FOR PACKAGING AROUND RIBS.
Your umbrella is now ready for use!
NOTE: REFER TO SEPARATE BASE OR MOUNT KIT MANUAL
FOR BASE ASSEMBLY PRIOR TO PROCEEDING.
(Fig. 1) (Fig. 2)
Foot Pedal
Main Frame
Rotating Hub
360
(Fig. 10)
STEP 4ROTATING UMBRELLA
Place your foot on the foot pedal of the rotating hub and step-on the pedal to release
rotating lock (Fig. 10). Place hands on the main frame and rotate the umbrella frame
in either direction, in 90° increments. To lock position, step off the foot pedal to engage
rotating lock.
(Fig. 11) (Fig. 12)
STEP 5LIGHT ADAPTER FEATURE
To ATTACH Umbrella Light: (sold separately)
Loosen the light adapter built into the umbrella runner by turning counter-clockwise
(Fig. 11). After loosening, pull down light adapter post (Fig. 12) to attach the umbrella light
(sold separately).
To REMOVE Light and CLOSE adapter:
Hold the umbrella light, depress the clamp release button to release the clamp lock.
Remove umbrella light and gently push up the light adapter post back into umbrella runner
and tighten turning clockwise (Fig. 11).
NOTE: It may be necessary to lower umbrella to a reachable height to pull light adapter
down and attach umbrella light. It is not necessary to remove light to close umbrella.
IMPORTANT:
For free standing base applications, it is imperative to install the appropriate base for your
size cantilever. The minimum base weight recommended for the AG25T is 200 lbs.

Thank you for purchasing Treasure Garden’s AG25T Cantilever.
Please remove all contents from the package, inspect and review checklist.
Some parts may be included in the styrofoam packaging.
Do not discard any packaging or box until assembly is complete.
CHECKLIST
61
A - (1) 360°Rotating Hub I - (1) Crank Handle
B - (1) Foot Pedal J - (1) Canopy Support Beam
C - (1) Hardware Assembly K - (1) Finial
D - (1) Main Frame L - (1) Canopy
E - (1) Adjustment Knob M - (7) Spring Loaded Rib End Cap
F - (1) Open/Close Mechanism N - (1) Valance (optional)
G - (1) Tilt Mechanism O - (1) Light Adapter (light sold separately)
H - (1) Tilt Degree Scale P - (1) Protective Cover
IMPORTANT:
Prior to assembly it is important to decide on the location of the umbrella.
·Allow ample height to avoid damage to your umbrella during assembly and usage.
·Choose a location that is level and sturdy.
·Avoid any sloping of soft ground.
·Consider a location that will maximize the umbrella’s 360°rotating function. Placing the
umbrella between two entertaining areas is ideal.
CAUTION:
·Fully assembled, the umbrella weighs over 300 lbs. Moving umbrella fully assembled
will increase the risk of damage to your umbrella and/or can cause serious injury. We
recommend a two-person team for assembly and disassembly.
Close Open
Right Left
Open
Max
0˚
Max
K
L
D
N
J
M
O
P
A
B
E
C
6mm Hexagon
Wrench
FG
H
I
CARE AND MAINTENANCE
• When not in use, close and cover umbrella with provided protective cover.
• Allow a wet canopy to dry while in open position, but do not leave unattended.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry place.
After the Winter:
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
Cl Open
Right Left
Open
Max
0˚
Max
(Fig. 13)
(Fig. 14) (Fig. 15)
STEP 6CLOSING UMBRELLA
Position yourself behind umbrella. Insert crank handle into “Open/Close” socket in crank
mechanism (Fig. 13). Turn crank handle counter clockwise until the canopy is closed
(Fig. 14). Turn adjustment knob counter clockwise and slide downward until umbrella is in
closed position. Tie string around canopy to secure canopy. Cover umbrella with provided
protective cover when not in use (Fig. 15). NOTE: Prior to closing ensure that the canopy
is in a level (non-tilt) position. Properly store umbrella when not in use. Close umbrella, tie
string around canopy and cover umbrella with provided protective cover.
TO PROPERLY FOLD CANOPY:
The canopy will last longer if you fold it as it was packed and shipped. This technique is
similar to the way a parachute is folded and is especially important when folding the canopy
for seasonal storage or when left in the closed position for an extended period of time.
Using this technique at all times will significantly extend the life of the canopy.
• When the umbrella has been fully closed, stand in front of the canopy
structure and begin the folding process by pulling out two panels
opposite the main frame. Pull the two panels together and roll tight into
the canopy.
• Once rolled tight, pull adjacent panels out one at a time and fold to the
center, alternating sides until all the panels have been pulled out from
the arms and folded into the center.
• Tie string around canopy and cover umbrella with provided protective
cover.

Assembly and Operation Guide
www.treasuregarden.com
©2021 Treasure Garden, Inc. - All Rights Reserved.
v.05.18.21
AG25T CANTILEVER
AG25T 11.5’ octagon
AG25TSQ 10’ square
WARRANTY:
Treasure Garden warrants this product
(for residential use ONLY) to be free
from defects in original materials and
workmanship for a period of 1 year from
the date of purchase. If a defect in the
original material or workmanship appears
during the warranty period; Treasure
Garden will (at its discretion) repair or
replace the product without charge.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
In many cases, simple problems can
be solved with a replacement part that
can be shipped directly to the dealer for
professional installation / repair.
Tampering with or altering the product will
void warranty.
In the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges for the first year only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped / billed
at your expense.
This warranty gives you specific legal
rights, and you may have other rights
which vary from state to state.
RUST: Rust is a natural part of the aging
process of steel or iron based materials,
and is therefore NOT considered a defect.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect
of reasonable and necessary care are not
covered by this warranty.
Additionally, acts of nature (including but
not limited to wind, hurricanes, tornadoes,
and storms) are not covered by this
warranty.
SAFETY PRECAUTIONS
• To reduce risk of personal injury in which a person is injured or harmed, and/or damage
to personal property, read and follow the Assembly Guide prior to assembling and
operating umbrella and base.
• Close and store the umbrella in windy conditions or when a storm approaches. Never
allow the umbrella to flap in the wind; this could cause personal injury, damage to
personal property, damage to umbrella and/or umbrella canopy. Do not use tilting
function during windy conditions.
• Keep umbrella secured to umbrella base at all times.
• Do not leave open umbrella unattended. If damage occurs, this is not covered by the
warranty.
• When adjusting the umbrella, make sure that no person(s), item(s) or personal property
are close to the umbrella. This is important to prevent injury or material damage.
• Do not allow children to play on or with umbrella or umbrella base.
• When adjusting or assembling the umbrella or umbrella base, make sure fingers, toes
or any other parts of the body are clear from moving parts. Failing to do so many result
in serious injury.
