Treasure Garden UM800xSL Installation instructions

UM800xSL
9’ OC
Starlight Collar Tilt
Assembly and Operation Guide
www.treasuregarden.com
©2018 Treasure Garden, Inc. - All Rights Reserved. 7/18

A - Finial
B - Canopy/Mainframe
C - Bottom Pole
D - Power Cord/Transformer
Note: Use only the Power
Cord/Transformer supplied.
61
Thank you for purchasing Treasure Garden’s Starlight Collar Tilt mbrella.
Please remove all contents from the package, inspect and review checklist.
STARLIGHT COLLAR TILT CHECKLIST
A - B -
C -
WARRANTY:
Treasure Garden warrants this product
(in residential use) to be free from defects
in original materials and workmanship for a
period of 2 years from the date of
purchase. If a defect in the original
material or workmanship appears during
the warranty period; Treasure Garden will
(at its option) repair or replace the product
without charge. Limited warranty against
fabric fading, depending on fabric.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
In many cases, simple problems can be
solved with a replacement part that can be
shipped directly to the dealer for
professional installation/repair.
In the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges on warranted product for the
2 years only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped/billed
at your expense.
This warranty gives you specific legal rights,
and you may have other rights which vary
from state to state.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect of
reasonable and necessary care are not
covered by this warranty.
Additionally, acts of nature (including but not
limited to wind, hurricanes, tornadoes, and
storms) are not covered by this warranty.
S A F E T Y P R E C A T I O N S :
• Close and store the umbrella in windy conditions or when a storm approaches.
Never allow the umbrella to flap in the wind; this could damage the canopy.
• Do not leave open umbrella unattended. If damage occurs, this is not covered
by the warranty.
• When adjusting the umbrella, make sure that no person(s) or item(s) are close to the
umbrella. This is important to prevent injury or material damage.
CARE AND MAINTENANCE:
• When not in use, close and cover umbrella with a protective cover (not included).
• Allow a wet canopy to dry while in open position.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Storage:
• Store in a dry, protective place.
After the Winter:
• Areas subject to turning and sliding can be treated with a non-staining lubricant spray
(silicone-based).
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
S T E P 1 Set Up
Carefully remove umbrella from box. Attach finial to top of canopy/mainframe.
D -

25
Insert bottom pole into canopy/mainframe pole. Line up button with hole and snap into
place.
Connect bottom pole plug to canopy/mainframe plug. Twist plug clockwise
together to secure connection.
S T E P 3 Closing Umbrella
Twist collar in counter-clockwise direction to bring umbrella back to its original upright
position. Turn umbrella off by clicking switch to off position.
Off Switch
To close, turn crank
in counter-clockwise
direction to close
umbrella.
To store umbrella
away, unplug power
supply/transformer
from wall and
umbrella pole.
Repeat Step 1
process in reverse
to store.
Note: During disassembly, it is important to loosen knob of plug inside umbrella poles first,
then remove bottom pole from mainframe/canopy. If not, the wire will be split and result in
damage to lighting.

43
S T E P 2 Operating Umbrella
Crank handle clockwise to open umbrella to its fully open position. To turn umbrella on or off,
press on/off switch located on collar housing.
Turn umbrella in upright position. Insert bottom pole into free standing base or through table
top. Insert power supply/transformer into umbrella pole. Connect other end of power
supply/transformer into wall outlet.
Note: The transformer output power is 12V. It is normal for transformer to get warm after
long period of use. Avoid sun on power supply/transformer to increase lifetime use.
Be sure not to drop transformer. Note: Use only the Power Cord/Transformer supplied.
To tilt, simply twist the collar in clockwise direction.
On/Off Switch

43
S T E P 2 Operating Umbrella
Crank handle clockwise to open umbrella to its fully open position. To turn umbrella on or off,
press on/off switch located on collar housing.
Turn umbrella in upright position. Insert bottom pole into free standing base or through table
top. Insert power supply/transformer into umbrella pole. Connect other end of power
supply/transformer into wall outlet.
Note: The transformer output power is 12V. It is normal for transformer to get warm after
long period of use. Avoid sun on power supply/transformer to increase lifetime use.
Be sure not to drop transformer. Note: Use only the Power Cord/Transformer supplied.
To tilt, simply twist the collar in clockwise direction.
On/Off Switch

25
Insert bottom pole into canopy/mainframe pole. Line up button with hole and snap into
place.
Connect bottom pole plug to canopy/mainframe plug. Twist plug clockwise
together to secure connection.
S T E P 3 Closing Umbrella
Twist collar in counter-clockwise direction to bring umbrella back to its original upright
position. Turn umbrella off by clicking switch to off position.
Off Switch
To close, turn crank
in counter-clockwise
direction to close
umbrella.
To store umbrella
away, unplug power
supply/transformer
from wall and
umbrella pole.
Repeat Step 1
process in reverse
to store.
Note: During disassembly, it is important to loosen knob of plug inside umbrella poles first,
then remove bottom pole from mainframe/canopy. If not, the wire will be split and result in
damage to lighting.

A - Finial
B - Canopy/Mainframe
C - Bottom Pole
D - Power Cord/Transformer
Note: Use only the Power
Cord/Transformer supplied.
61
Thank you for your purchase of Treasure Garden’s Starlight Collar Tilt mbrella.
Please remove all contents from the package, inspect and review checklist.
STARLIGHT COLLAR TILT CHECKLIST
A - B -
C -
WARRANTY:
Treasure Garden warrants this product
(in residential use) to be free from defects
in original materials and workmanship for a
period of 2 years from the date of
purchase. If a defect in the original
material or workmanship appears during
the warranty period; Treasure Garden will
(at its option) repair or replace the product
without charge. Limited warranty against
fabric fading, depending on fabric.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
In many cases, simple problems can be
solved with a replacement part that can be
shipped directly to the dealer for
professional installation/repair.
In the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges on warranted product for the
2 years only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped/billed
at your expense.
This warranty gives you specific legal rights,
and you may have other rights which vary
from state to state.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect of
reasonable and necessary care are not
covered by this warranty.
Additionally, acts of nature (including but not
limited to wind, hurricanes, tornadoes, and
storms) are not covered by this warranty.
S A F E T Y P R E C A T I O N S :
• Close and store the umbrella in windy conditions or when a storm approaches.
Never allow the umbrella to flap in the wind; this could damage the canopy.
• Do not leave open umbrella unattended. If damage occurs, this is not covered
by the warranty.
• When adjusting the umbrella, make sure that no person(s) or item(s) are close to the
umbrella. This is important to prevent injury or material damage.
CARE AND MAINTENANCE:
• When not in use, close and cover umbrella with a protective cover (not included).
• Allow a wet canopy to dry while in open position.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Storage:
• Store in a dry, protective place.
After the Winter:
• Areas subject to turning and sliding can be treated with a non-staining lubricant spray
(silicone-based).
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
S T E P 1 Set Up
Carefully remove umbrella from box. Attach finial to top of canopy/mainframe.
D -

UM800xSL
9’ OC
Starlight Collar Tilt
Assembly and Operation Guide
www.treasuregarden.com
©2018 Treasure Garden, Inc. - All Rights Reserved. 7/18
