Treasure Garden AG5A Installation instructions

AG5A
8.5’
SQ
Cantilever
Assembly and Operation Guide
®
www.treasuregarden.com
©2011 Treasure Garden, Inc. - All Rights Reserved. Initial 7/11

C
F
G
D
E
I
A
Bolts (4)
Washers (4)
Wrench (1)
Allen
Wrench (1)
Screws (2)
H
B
A- Cross Bars (2) E- Crank Lift Handle I- Canopy
B- Rotation Hub F- Main Frame
C- Column G- Adjustment Knob
D- Knob H- VEGA™Light Adapter
WARRANTY:
Treasure Garden warrants this product
(in residential use) to be free from defects
in original materials and workmanship for a
period of 1 year from the date of purchase.
If a defect in the original material or
workmanship appears during the warranty
period; Treasure Garden will (at its option)
repair or replace the product without
charge. Limited warranty of 4 years
against fabric fading.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
In many cases, simple problems can be
solved with a replacement part that can be
shipped directly to the dealer for
professional installation/repair.
In the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges on warranted product for the first
year only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped/billed
at your expense.
This warranty gives you specific legal rights,
and you may have other rights which vary
from state to state.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect of
reasonable and necessary care are not
covered by this warranty.
Additionally, acts of nature (including but not
limited to wind, hurricanes, tornadoes, and
storms) are not covered by this warranty.
Thank you for your purchase of Treasure Garden’s AG5A Cantilever Umbrella.
Please remove all contents from the package, inspect and review checklist.
CAUTION: To reduce personal injury and damage to your AG5A, read and follow this
assembly and operation guide We recommend a two-person team for assembly and
disassembly. Save information for future reference.
REQUIRED FOR ASSEMBLY:
• One (1) 1/2" socket wrench or adjustable wrench.
• Four (4) 50 lb. weights - square stones or concrete weights. (200 lb. total weight
needed for support - weights not included) Stones & weights, standard sizes
can be used up to 20" L x 20" W x 1.5" H.
NOTE: Using the cross bar stand without weights will damage your umbrella
and may cause injury.
SAFETY PRECAUTIONS:
• Close the umbrella in windy conditions or when a storm approaches.
Never allow the umbrella to flap in the wind; this could damage the canopy.
• Do not leave open umbrella unattended. If damage occurs, this is not covered
by the warranty.
• When adjusting the umbrella, make sure that no person(s) or item(s) are close to the
umbrella. This is important to prevent injury or material damage.
CARE AND MAINTENANCE:
• When not in use, close and cover umbrella with a protective cover (sold separately).
• Allow a wet canopy to dry opened up.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry, protective place.
• Any visible defects must be repaired by a professional.
After the Winter:
• Areas subject to turning and sliding can be treated with a non-staining lubricant spray
(silicone-based).
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
61
AG5A CHECKLIST

25
STEP 2 Assemble AG5A Frame
NOTE: Two persons may be needed for the following action.
Lift the AG5A up and insert the main frame into the column until it locks into place (Fig. 4).
Secure the canopy at the same direction with the foot pedal on the rotation hub, and then
loosen the umbrella tie.
(Fig. 4)
STEP 1 Assemble Cross Bar Stand
Assemble the umbrella base by connecting both sections in a cross (Fig. 1). Place the
rotation hub on the connected crossed base and fasten (4) four hexagon bolts with the
hexagon wrench (both supplied) (Fig. 2). Insert the column into the rotation hub and then
fasten (2) two screws with the socket wrench (both supplied) (Fig. 3). Secure umbrella
base with (4) four square stones or concrete weights (weights not included).
IMPORTANT: Cross bar stand will not support umbrella without proper weights.
Using the stand without weights will damage your umbrella.
(Fig. 1)
(Fig. 3)(Fig. 2)
To ATTACH VEGA Umbrella Light:
Loosen the VEGA light adapter built into the umbrella runner by turning counter-clockwise
(Fig. 10). After loosening, pull down light adapter post (Fig. 11) to attach the
VEGA umbrella light (sold separately).
To OPEN and ATTACH VEGA:
Open the VEGA umbrella light by holding firmly with one hand and then depress the clamp
release button with the other hand to release the clamp lock. Open up the VEGA light and
clasp around the light adapter post (Fig. 12). Snap to close (Fig. 13).
To REMOVE VEGA and CLOSE adapter:
Hold the VEGA umbrella light, depress the clamp release button to release the clamp lock.
Remove VEGA umbrella light, and gently push up the light adapter post back into umbrella
runner and tighten turning clockwise (Fig. 10).
(Fig. 10) (Fig. 11)
(Fig. 12) (Fig. 13)
AG5A Features

43
Adjustment
Knob
Crank Lift
Handle
Slider
Adjustment
Knob
(Fig. 5)
STEP 7 360° Rotating Hub Swivel
Place your foot on the foot pedal of the rotating hub and step-on the pedal to release
rotating lock (Fig. 7). Place hands on the main frame (Fig. 8) and rotate the umbrella frame
in either direction, in 90° increments (Fig. 9). To lock position, step off the foot pedal to
engage rotating lock.
STEP 3 Opening AG5A
In the closed position (see below), turn the crank lift handle clockwise and slide
the adjustment knob upward until the canopy is fully opened and the slider is at the top
most position (Fig. 5). Now the umbrella is ready to use.
STEP 5 Adjusting AG5A Height and Tilt
Loosen the adjustment knob counter-clockwise (Fig. 6) to adjust height and tilt. Slide the
adjustment knob up or down to adjust the umbrella to your desired height and angle.
Tighten the adjustment knob clockwise to lock its position.
STEP 4 Closing AG5A Canopy
Slide the adjustment knob downward and turn the crank handle counter-clockwise
until the canopy is fully closed.
CLOSED OPENED
Adjustment
Knob
Adjustment
Knob
(Fig. 6)
(Fig. 7)
(Fig. 8)(Fig. 9)

43
Adjustment
Knob
Crank Lift
Handle
Slider
Adjustment
Knob
(Fig. 5)
STEP 7 360° Rotating Hub Swivel
Place your foot on the foot pedal of the rotating hub and step-on the pedal to release
rotating lock (Fig. 7). Place hands on the main frame (Fig. 8) and rotate the umbrella frame
in either direction, in 90° increments (Fig. 9). To lock position, step off the foot pedal to
engage rotating lock.
STEP 3 Opening AG5A
In the closed position (see below), turn the crank lift handle clockwise and slide
the adjustment knob upward until the canopy is fully opened and the slider is at the top
most position (Fig. 5). Now the umbrella is ready to use.
STEP 5 Adjusting AG5A Height and Tilt
Loosen the adjustment knob counter-clockwise (Fig. 6) to adjust height and tilt. Slide the
adjustment knob up or down to adjust the umbrella to your desired height and angle.
Tighten the adjustment knob clockwise to lock its position.
STEP 4 Closing AG5A Canopy
Slide the adjustment knob downward and turn the crank handle counter-clockwise
until the canopy is fully closed.
CLOSED OPENED
Adjustment
Knob
Adjustment
Knob
(Fig. 6)
(Fig. 7)
(Fig. 8)(Fig. 9)

25
STEP 2 Assemble AG5A Frame
NOTE: Two persons may be needed for the following action.
Lift the AG5A up and insert the main frame into the column until it locks into place (Fig. 4).
Secure the canopy at the same direction with the foot pedal on the rotation hub, and then
loosen the umbrella tie.
(Fig. 4)
STEP 1 Assemble Cross Bar Stand
Assemble the umbrella base by connecting both sections in a cross (Fig. 1). Place the
rotation hub on the connected crossed base and fasten (4) four hexagon bolts with the
hexagon wrench (both supplied) (Fig. 2). Insert the column into the rotation hub and then
fasten (2) two screws with the socket wrench (both supplied) (Fig. 3). Secure umbrella
base with (4) four square stones or concrete weights (weights not included).
IMPORTANT: Cross bar stand will not support umbrella without proper weights.
Using the stand without weights will damage your umbrella.
(Fig. 1)
(Fig. 3)(Fig. 2)
To ATTACH VEGA Umbrella Light:
Loosen the VEGA light adapter built into the umbrella runner by turning counter-clockwise
(Fig. 10). After loosening, pull down light adapter post (Fig. 11) to attach the
VEGA umbrella light (sold separately).
To OPEN and ATTACH VEGA:
Open the VEGA umbrella light by holding firmly with one hand and then depress the clamp
release button with the other hand to release the clamp lock. Open up the VEGA light and
clasp around the light adapter post (Fig. 12). Snap to close (Fig. 13).
To REMOVE VEGA and CLOSE adapter:
Hold the VEGA umbrella light, depress the clamp release button to release the clamp lock.
Remove VEGA umbrella light, and gently push up the light adapter post back into umbrella
runner and tighten turning clockwise (Fig. 10).
(Fig. 10) (Fig. 11)
(Fig. 12) (Fig. 13)
AG5A Features

C
F
G
D
E
I
A
Bolts (4)
Washers (4)
Wrench (1)
Allen
Wrench (1)
Screws (2)
H
B
A- Cross Bars (2) E- Crank Lift Handle I- Canopy
B- Rotation Hub F- Main Frame
C- Column G- Adjustment Knob
D- Knob H- VEGA™Light Adapter
WARRANTY:
Treasure Garden warrants this product
(in residential use) to be free from defects
in original materials and workmanship for a
period of 1 year from the date of purchase.
If a defect in the original material or
workmanship appears during the warranty
period; Treasure Garden will (at its option)
repair or replace the product without
charge. Limited warranty of 4 years
against fabric fading.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
In many cases, simple problems can be
solved with a replacement part that can be
shipped directly to the dealer for
professional installation/repair.
In the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges on warranted product for the first
year only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped/billed
at your expense.
This warranty gives you specific legal rights,
and you may have other rights which vary
from state to state.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect of
reasonable and necessary care are not
covered by this warranty.
Additionally, acts of nature (including but not
limited to wind, hurricanes, tornadoes, and
storms) are not covered by this warranty.
Thank you for your purchase of Treasure Garden’s AG5A Cantilever Umbrella.
Please remove all contents from the package, inspect and review checklist.
CAUTION: To reduce personal injury and damage to your AG5A, read and follow this
assembly and operation guide We recommend a two-person team for assembly and
disassembly. Save information for future reference.
REQUIRED FOR ASSEMBLY:
• One (1) 1/2" socket wrench or adjustable wrench.
• Four (4) 50 lb. weights - square stones or concrete weights. (200 lb. total weight
needed for support - weights not included) Stones & weights, standard sizes
can be used up to 20" L x 20" W x 1.5" H.
NOTE: Using the cross bar stand without weights will damage your umbrella
and may cause injury.
SAFETY PRECAUTIONS:
• Close the umbrella in windy conditions or when a storm approaches.
Never allow the umbrella to flap in the wind; this could damage the canopy.
• Do not leave open umbrella unattended. If damage occurs, this is not covered
by the warranty.
• When adjusting the umbrella, make sure that no person(s) or item(s) are close to the
umbrella. This is important to prevent injury or material damage.
CARE AND MAINTENANCE:
• When not in use, close and cover umbrella with a protective cover (sold separately).
• Allow a wet canopy to dry opened up.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry, protective place.
• Any visible defects must be repaired by a professional.
After the Winter:
• Areas subject to turning and sliding can be treated with a non-staining lubricant spray
(silicone-based).
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
61
AG5A CHECKLIST

AG5A
8.5’
SQ
Cantilever
Assembly and Operation Guide
®
www.treasuregarden.com
©2011 Treasure Garden, Inc. - All Rights Reserved. Initial 7/11
