Ethan Hardtop Grill Gazebo
Assembly Instruction
Model Number: L-GG069PST-D
SKU:2721828

Congratulations on your purchase of our SUNJOY Ethan hardtop grill gazebo. Our
clear, easy to follow, step-by-step instructions will guide you through the assembly
process from start to finish.
IMPORTANT:
1. When installing and assembling your gazebo, it is recommended that two or more adults
are involved.
2. Do not use the gazebo during an electrical storm, as there is a remote chance of getting
struck by lightning.
3. Do not climb on top of the gazebo. Falling off the gazebo can result in serious injury,
possibly even death.
4. Do not leave the gazebo assembled when there is a risk of high wind, as possible
damage will occur to the structure.
5. Do not use lanterns that contain open flames.
6. This package contains small items and plastic bags that should be kept away from
children.
7. Ensure that all connectors & poles are firmly secured in position fully. It is important to do
so before use so as to avoid collapsing or damage to the item, which could result in injury.
USE & CARE:
1. This gazebo is not a permanent structure. The steel top should never be left on during
periods of extended or heavy rain nor any inclement weather where high winds or wind
gusts can occur. If left up, damage to the gazebo and surroundings can occur.
2. Do not repack your gazebo until completely dry.
3. Steel components for garden accessories and furniture are treated with rust inhibiting
paint that protects them from rust. However, due to the nature of steel, surface oxidation
(rusting) will occur if this protective coating is scratched. This is a natural process. To
minimize this condition, it is recommended that care be taken when assembling and
handling the product in order to prevent the paint from being scratched. Surface rust can be
removed easily using a very light application of common cooking oil. If surface oxidation
(rusting) occurs and no measures are taken to correct it, the oxidation may start dripping
onto the deck or patio, which may cause damaging stains that may be difficult to remove.

Post Screen 1
4
A1
Post Screen 2
4
A2
Long Beam
2
B
Short Beam
2
C
Big Canopy Oblique
Beam
4
D
Big Canopy Middle
Beam
4
E
Small Canopy Oblique
Beam
4
F
Big Canopy Frame
Long side
2
G1
Big Canopy Frame
Short side
2
G2
Small Canopy
Connector
1
H
Oblique Beam
Connector
4
I1
Middle Beam
Connector
4
I2
Hook
1
J
Big Canopy Oblique
Beam Cover Plate
4
K1
Small Canopy Oblique
Beam Cover Plate
4
K2
Small Canopy Cover
Plate
1
K3
Big Canopy Middle
Beam Cover Plate
4
K4
Small Canopy Long
Side Down Tube
2
L1
Small Canopy Short
Side Down Tube
2
L2
Parts List

Big Canopy Long Side
Left Beam
2
M1
Big Canopy Long Side
Right Beam
2
M2
Big Canopy Long Side
Left Down Tube
2
M3
Big Canopy Long Side
Right Down Tube
2
M4
Big Canopy Short
Side Left Beam
2
N1
Big Canopy Short
Side Right Beam
2
N2
Big Canopy Short Side
Left Down Tube
2
N3
Big Canopy Short Side
Down Tube
2
N4
Table top
2
O1
Clapboard
2
O2
Connect Plate
4
P
Fencing Ornamental
8
Q
Base
4
R1
Decorative cover
12
R2
Big Canopy Short Side
Cover plate(upper)
2
T1
Big Canopy Short Side
Cover Plate(lower)
2
T2
Big Canopy Long Side
Left Cover plate(small)
2
T3
Big Canopy Long Side
Right Cover
plate(small)
2
T4

Big Canopy Long Side
Left Cover plate(big)
2
T5
Big Canopy Long Side
Right Cover plate(big)
2
T6
Small Canopy Cover
plate(small)
2
U1
Small Canopy Cover
plate(big)
2
U2
AA
M6*15 Bolt
76 PCS
BB
M6 Washer
88 PCS
CC
M6*25 Bolt
12 PCS
Z
M6 Wrench
2 PC
Hardware Pack 1

Fig.2: Put the decorative cover (R2) on the Square tube of post screen, then use bolt (AA) and washer (BB) to fasten it.
Fig.3: Use bolt (AA) and washer (BB) to fasten long and short beam (B, C) on the assembled post screen.
Fig.4: Use bolt (AA) and washer (BB) to attach oblique beam connector (I1) on post screen (A1, A2).
Fig.1:Use bolt(CC) and washer(BB) to fasten post screen（A1.A2）together.
Hardware Pack 2
AA
M6*15 bolt
32 PCS
BB
M6 washer
112 PCS
DD
M6*55 bolt
20 PCS
EE
M6 nut
20 PCS
FF
M6*15 bolt
40 PCS
Fig.5: Use bolt (AA) and washer (BB) to fasten middle beam connector (I2) with long side, short side beam (B,
C) tightly.
Fig.6: Use bolt (AA) and washer (BB) to fasten fencing ornamental (Q) the post screen.
Fig.7:用螺栓（AA）和垫片(BB)把围栏装饰(Q)上端紧锁在立柱屏风上。

Fig.8: Use bolt (AA) and washer (BB) to fasten big canopy frame short side (G2) with big canopy frame long
side (G1).
Fig.9: Use bolt (AA) and washer (BB) to fasten big canopy oblique beam (D) with assembled big canopy
frame.
Fig.10:用螺栓(DD)、垫片(BB)和螺母(EE)把大顶斜梁(D)下端固定在斜梁下连接件(I1)上。
Fig.11:用螺栓(AA)和垫片(BB)把大顶中梁(E)上端固定在大顶框上。
Fig.12: Attach big canopy middle beam (E) on the middle beam connector (I2) use bolt (DD), washer (BB)
and nut (EE)
Fig.13:。Attach hook (J) on the small canopy connector (H).
Fig.14: Attach the upper side of small canopy oblique beam (F) on small connector (H), use bolt (DD),
washer (BB) and nut (EE).
Fig.15:Attach small canopy oblique beam (F) on the big canopy frame use bolt (AA) and washer (BB).

BB
M6 washer
90 PCS
AA
M6*15 bolt
8 PCS
JJ
M6*35 bolt
16PCS
FF
M6*15 bolt
32 PCS
GG
M6*35 bolt
24 PCS
II
M6*45 bolt
2 PCS
HH
￠8*180 stake
8 PCS
Hardware Pack 3
Fig.16: Attach small canopy long, short down tube (L1, L2) on the lower side of small canopy oblique beam (F)
using bolt (FF) and washer (BB).
Fig.17: Attach one end of connector plates of big canopy small beam (N2, M1, M2, N1) on big canopy oblique
beam (D), using bolt FF) and washer(BB).
Fig.18: Attach one end connector of big canopy small beam (N2, M1, M2, N1) on big canopy middle beam (E),
using bolt (FF) and washer (BB).
Fig.19: Attach one end connector of big canopy down tube (N3,N4,M3,M4) on big canopy middle beam (E),
using bolt(FF) and washer(BB).
Fig.20: Attach big canopy long side, short side down
tube (N3, N4, M3, M4) on the lower part of big
canopy oblique beam (D), using bolt (FF) and
washer (BB).

Fig.21:Attach small canopy cover plate (U1, U2) on small canopy oblique beam (F) using bolt (FF) and washer (BB).
Fig.22: Use bolt (GG) and washer (BB) to fasten small canopy oblique beam cover plate (K2) on the small canopy.
Fig.23: Use bolt (II) and washer (BB) to fasten small canopy cover plate (K3) on the small canopy.
Fig.24: As shown in figure, assemble the big canopy cover plate according to the numbers shown in assembly
drawing.
Fig.25: Insert the assembled upper cover plate into the slot of big canopy long side (G1) and big canopy short side
(G2).
Fig.26: Attach big canopy cover plate (T1,T2,T3,T5) on the big canopy oblique beam (D) using bolt (FF) and
washer(BB).

Your Ethan grill gazebo is now ready for use.
Please do not return this product to the store. For technical assistance on assembly or
replacement parts call Sunjoy Industries at 1(866) 578-6569 from 8:00 AM to 8:00 PM EST
or Email [e-mail] or visit www.sunjoyonline.com to place your order or
fax your parts replacement order form together with your purchase receipt to 1 (740)
283-3549 for assistance. Made in China
Fig.27: Attach the big canopy cover plate (T3, T4, T5, T6) on the big canopy middle beam (E) using bolt (FF) and
washer (BB).
Fig.28: Use bolt (GG) and washer (BB) to fasten Big Canopy Middle Beam Cover Plate (K4) on the Big Canopy
Middle Beam
Fig.29: Use bolt (AA) and washer(BB) to fasten Big Canopy Oblique Beam Cover Plate (K1) on the Big Canopy
Oblique Beam(D)
Fig.30: Use bolt (AA) and washer (BB) to fasten tabletop (O1) on the post screen.
Fig.31: Use bolt (JJ) and washer (BB) to fasten clapboard (O2) on the post screen.
Fig.32: Attach the assembled gazebo on the lawn using
stake (HH).
