Trek 2022 CHECKPOINT SL Operating manual

2022 CHECKPOINT SL/SLR
SERVICE MANUAL SUPPLEMENT

2022 Checkpoint SL/SLR
1
Safety
WARNING
Properly tighten hardware
Always tighten hardware to the specied torque.
Over-tightening hardware could deform or break the
hardware or components. Under-tightening hardware
could cause hardware or components to become loose.
Either situation could damage the bicycle and result in
injury to the rider.
WARNING
Reapply threadlocker
All reused-fasteners with pre-applied threadlocker must
be cleaned with isopropyl alcohol and have new thread-
locker applied before re-assembly. If threadlocker is not
applied, the fasteners may loosen which could damage
the bicycle and result in injury to the rider.
Legend
Apply grease
Do not apply grease
Apply threadlocker
Nm Torque
Zip tie
Contents
Safety Brake/shift routing —
mechanical
Brake routing — eTap Brake/shift routing —
Di2
T47 bottom bracket
Headset and fork IsoSpeed — SL IsoSpeed — SLR Storage door Frame guards
Chainkeeper Accessories — SL Accessories — SLR Specications
Copyright 2021 Trek Bicycle Corporation All Rights Reserved

2022 Checkpoint SL/SLR
2
Brake/shift routing — mechanical
1
2
3
4
5
2-3Nm
6.5Nm
max
6
7
8
9




NOTE: Tighten the front derailleur
bolt (5) to the manufacturer’s
specications.
1 Rear derailleur hanger — W524188
2 Rear derailleur hanger bolts — W524884
3 Housing grommets — W330578
4Front derailleur washer — W531901
5Front derailleur bolt — W543903
6Front derailleur cable
7Rear derailleur cable
8Front brake hose
9Rear brake hose
10 Dropper post cable
Route the brake hoses
1. Connect the calipers to the brake hoses.
2. Route the rear brake hose through the grommet (3).
Route both brake hoses as shown.
3. Attach the calipers to the chainstay and fork. Do not
fully torque the mounting bolts until the calipers are
aligned correctly.

2022 Checkpoint SL/SLR
3
Brake/shi routing — mechanical (continued)
Route the shift cables
1. Mark the rear shift cable with a marker. You will
need to tell the cables apart when you assemble the
headset.
2. Route the front derailleur shift cable through the
grommet (3). Route both shift cables through the
frame as shown.
3. Attach the derailleurs to the bicycle.
4. Connect the shift cables to the derailleurs.
5. Zip tie the shift cables and rear brake hose to the
outside of the storage door frame.




Dropper post cable routing (SL only)
Cut out a hole in the outer dimple on the back of the
routing cap grommet. Route the dropper post cable to the
handlebars as shown below.
NOTE: A dropper post is not compatible with the SLR
model due to the seat mast system.




10
10

2022 Checkpoint SL/SLR
4
Brake routing — eTap
7
4
3
8
1
2-3Nm
2




5
6
6.5Nm
max
NOTE: Tighten the front derailleur
bolt (6) to the manufacturer’s
specications.
1 Rear derailleur hanger — W524188
2 Rear derailleur hanger bolts — W524884
3 Plug — W330578
4 Housing grommet — W330578
5Front derailleur washer — W531901
6Front derailleur bolt — W543903
7Front brake hose
8Rear brake hose
9Dropper post cable
Route the brake hoses
1. Connect the calipers to the brake hoses.
2. Route the rear brake hose through the grommet (4).
Route both brake hoses as shown.
3. Attach the calipers to the chainstay and fork. Do not
fully torque the mounting bolts until the calipers are
aligned correctly.
4. Zip tie the rear brake hose to the outside of the
storage door frame.





2022 Checkpoint SL/SLR
5
Brake routing — eTap (continued)
Dropper post cable routing (SL only)
NOTE: A dropper post is not compatible with the SLR
model due to the seat mast system.




9
9

2022 Checkpoint SL/SLR
6
Brake/shi routing — Di2
4
9
10
2-3Nm
11
56
7
3
2
1
6.5Nm
max




8
3Nm
NOTE: Tighten the front derailleur
bolt (6) to the manufacturer’s
specications.
1 Rear derailleur hanger — W524188
2 Rear derailleur hanger bolts — W524884
3 Di2 exit grommet — 600208
4 Housing grommets — W330578
5Front derailleur washer — W531901
6Front derailleur bolt — W543903
7Battery holder and cable guide — 588188
8Screws (M4x9mm) — 588188
9Front brake hose
10 Rear brake hose
11 Di2 wires
Route the brake hoses
1. Connect the calipers to the brake hoses.
2. Route the rear brake hose through the grommet (3).
Route both brake hoses as shown.
3. Attach the calipers to the chainstay and fork. Do not
fully torque the mounting bolts until the calipers are
aligned correctly.

2022 Checkpoint SL/SLR
7
Brake/shi routing — Di2 (continued)
Di2 wiring diagram
Battery
Front derailleur
Junction A
(charging port)
Junction B
Rear derailleur

2022 Checkpoint SL/SLR
8
T47 bottom bracket
Install the bottom bracket
1. Apply grease to the threads on both sides of the
frame.
2. Using your hands, thread the bottom bracket onto
the frame.
NOTICE: Do not start tightening the bottom bracket
with a tool. Dirt and other contaminants can
damage the threading.
3. Use the proper tool to torque both sides to
specication (see the Tool and spline compatibility
table below).
4. If necessary, add spacers before installing the cranks
(see the Spacers required table at the top right).
Spacers required
The table below contains bottom bracket/crank
combinations that require spacers. Your bicycle may have
other combinations that do not require spacers.
Crank Bottom bracket
Spacers required
Drive
side
Non-drive
side
Shimano CeramicSpeed
24mm 0.5mm 0.5mm
SRAM DUB SRAM DUB 2-3mm —
GXP Wheels MFG 1.0mm —
non-driveside
washer
driveside
washer
SRAM GXP cranks
only
Tool and spline compatibility
Tool Praxis Unior Park Tool Wheels Mfg CeramicSpeed
Model
Part number
TP-2400
594148
TP-3028
594147
1671.T47
1043614
BBT-47
568922
BBTOOL-48-44
589307 —
Bottom bracket
manufacturer
Praxis 24mm X X
30mm X X
Wheels MFG X
SRAM DUB X X
Chris King X X
Ceramic-
Speed
24mm X X X
GXP X

2022 Checkpoint SL/SLR
9
Headset and fork
3
2
4
5
1
1 Spacer (5mm) — 5253930
2 Frame routing cap — W5253579
3 Frame routing cap grommet — W5253580
4 Headset split ring — W5266050
5Headset bearings — W540243
6Front derailleur cable
7Rear derailleur cable
8Front brake hose
9Rear brake hose
Install the headset
1. Clean the steerer tube using isopropyl alcohol.
2. Grease both bearings (5), the fork crown race, and
the inside of the head tube as shown to the left.
3. Insert the fork into the head tube.
TIP: Support the fork with a table during the
assembly.
4. Route the shift cables and brake hoses through
the split ring (4) as shown below (see pages 2-7 for
different routing examples).
Mechanical routing example
6
7
8
9
4
5. Complete the headset assembly as shown to the left.
NOTE: If cutting the steerer tube, cut 2mm above
the stem. Make sure the stem is in its nal position
with the required spacers underneath. The 2mm of
clearance is required to hold the 5mm spacer (1)
above the stem in place.

2022 Checkpoint SL/SLR
10
IsoSpeed — SL
2
1
3
4
6
7
8
9
5
1 Bolt
kit W569265
2 Wave washer
3 Washer
4Flanged bushing
5Cylindrical bushing
6Nut
7Cap, non-driveside (as shown) — 5253577
8 Cap, driveside (as shown) — 5253576
9 Grommet — W5253578
Install the IsoSpeed
1. Carefully remove the IsoSpeed covers (7, 8) with a
paint-safe plastic pry bar.
2. Remove the bolt (1), nut (6), and washers.
3. Use a 50/50 isopropyl alcohol/water mix to clean the
nut threads (6), bolt threads (1), and the inside of the
bushings (4, 5).
4. Apply threadlocker to the nut threads.
6

2022 Checkpoint SL/SLR
11
5. Apply grease to the bolt and nut as shown below.
NOTICE: Do not apply grease to the threads.
6
1
6. Place the washers on the bolt. Tighten the nut to
8Nm while securing the bolt with a wrench as shown
below.
8Nm
7
.
8
8
.
0
8
.
2
6
3 2
1
7. Re-install the IsoSpeed covers.
8. Allow the assembly to cure for 24 hours at room
temperature (72°F/22°C).
IsoSpeed — SL (continued)

2022 Checkpoint SL/SLR
12
IsoSpeed — SLR
8
1
2
3
4
5
6
9
10
11
7
Seatmast sub-assembly
12
1 Seatmast
2 Side cover, non-driveside (as shown) — 5256900
3 Side cover, driveside (as shown) — 5256899
4 Grommet — W5256901
5Clip — 5256904
6 Bumper — 5256904
7Flanged bushings — 5256074
8Nut
kit 5271110
9 Bolt
10 Wave washer
11 Flat washer
12 Cylindrical bushing
Install the IsoSpeed
1. Carefully remove the IsoSpeed covers (2, 3) with a
paint-safe plastic pry bar.
2. Remove the bolt (9), nut (8), and washers.
3. Use a 50/50 isopropyl alcohol/water mix to clean the
nut threads (8), bolt threads (9), and the inside of the
bushings (7, 12).
4. Apply threadlocker to the nut threads.
8

2022 Checkpoint SL/SLR
13
5. Apply grease to the bolt and nut as shown below.
NOTICE: Do not apply grease to the threads.
9 8
6. Install the hardware as shown on page 12.
7. Re-install the IsoSpeed covers.
8. Allow the assembly to cure for 24 hours at room
temperature (72°F/22°C).
IsoSpeed — SLR (continued)

2022 Checkpoint SL/SLR
14
Storage door
1
3
2
1.2Nm
4
1 Storage door kit — 5256900
2 Mount screws
3 Bolt (M5x8mm) — 596823
4 Bolt (M5x16mm) — 596821

2022 Checkpoint SL/SLR
15
Frame guards
2
1.2Nm
3
1
1 Chainstay frame guard — W5253575
2 Button head screws — 1042535
3Down tube guard — 5253574

2022 Checkpoint SL/SLR
16
Chainkeeper
Adjust the chainkeeper
1. Shift to the lowest gear (largest rear cassette cog) and inner chainring.
2. Loosen the top screw on the chainkeeper.
3. Rotate the loose piece so there is 1mm of horizontal clearance to the chain.
4. Tighten the top screw.
1mm
W566021
3Nm
Adjust clearance
Clearance

2022 Checkpoint SL/SLR
17
Accessories — SL
Water bottle cage adapters
For frames 54cm or larger, you can t three water bottle
cages in the frame triangle using the adapters.
5
23
1Fender mount bolts — 317700
2Bolt (M5x8mm) — 596823
3Bolt (M5x16mm) — 596821
4Frame bag
5Water bottle cage adapters — W5271627
Mounting inserts
All mounting inserts are M5x0.8.
Rack, fenders, and frame bag
NOTE: Use only steel fasteners to attach racks, bags, and
fenders. Do not use aluminum fasteners as they are not
rated for these loads.
Rear fender Front fender
4
1
Rack

2022 Checkpoint SL/SLR
18
Accessories — SLR
Water bottle cage adapters
For frames 54cm or larger, you can t three water bottle
cages in the frame triangle using the adapters.
5
23
1Fender mount bolts — 317700
2Bolt (M5x8mm) — 596823
3Bolt (M5x16mm) — 596821
4Frame bag
5Water bottle cage adapters — W5271627
Mounting inserts
All mounting inserts are M5x0.8.
Fenders and frame bag
NOTE: Use only steel fasteners to attach fenders and bags.
Do not use aluminum fasteners as they are not rated for
these loads.
4
1
Rear fender Front fender

2022 Checkpoint SL/SLR
19
Specifications
SL SLR
Rear hub OLD 142mm 142mm
Seat post OD 27.2mm
Seat post clamp ID 31.9mm
Seatmast ID 30mm
Upper fork steerer tube OD 28.6mm 28.6mm
Lower fork steerer tube OD 38.1mm 38.1mm
Bottom bracket type/width T47/85.5mm T47/85.5mm
Brake rotor diameter min/max 140/160mm 140/160mm
Chainline (1x) 45mm
(SRAM)
45mm
(SRAM)
Chainline (2x)
45mm
(SRAM)
45mm
(SRAM)
43.5
(Shimano)
43.5
(Shimano)
Chainring max (1x) 46t (SRAM) 46t (SRAM)
Chainring
max (2x)
Small 37t 37t
Large 50t 50t
Tire width max 700c
(without fenders)
45mm (1.8”) 45mm (1.8”)
Tire width max 650b
(without fenders)
53.5mm
(2.1”)
53.5mm
(2.1”)
Fender compatible — rear Yes Yes
Fender compatible — front Yes Yes
Rack mount compatible Yes No
Dropper post compatible Yes No
Headset bearing dimensions (W540243)
51mm
5mm
6.5mm
3
6
°
40mm
