TRENDnet TC-NT2 User manual

Network Cable Tester
TC-NT2
TC-NT2(V1)/02.26.2013
All manuals and user guides at all-guides.com
all-guides.com

E NG LISH
Install the battery
1. Slide the cover off the TC-NT2 transmitter.
2. Connect and insert the attery.
3. Slide the cover ack on to the TC-NT2 transmitter.
RJ-11/RJ-45 Cable Test
1. Connect one end of an RJ-11 or RJ-45 ca le to the remote port on the TC-NT2
transmitter. Connect the other end of the RJ-11 / RJ-45 ca le to the loop ack
port on the TC-NT2 transmitter.
2. Switch the power utton to the “On” position.
3. Press the auto (automatic) or test (manual) utton.
90 BUS
hM.III1.Mk IIIIIIIIIIIIII
1
All manuals and user guides at all-guides.com

Remote Testing
Note:
Do NOT use the TC-NT2 for live wire testing. The TC-NT2 is for testing ca les only.
Do not connect the TC-NT2 to an Ethernet ca le that is connected to a switch,
router, computer, etc. Doing so will damage the device. Ensure the ca le eing
tested is not connected to a live device.
RJ-45 Ca le
1. Connect one end of a RJ-45 ca le to the TC-NT2 transmitter. Connect the other
end of the RJ-45 ca le into the wall jack.
2. Connect one end of a network ca le to the remote port on the TC-NT2 remote
terminator. Connect the other end of the network ca le into the patch panel in
your wiring closet.
3. Push the power utton on the TC-NT2 transmitter to the “On” position.
4. Press the auto (automatic) or test (manual) utton.
Wall Jack
2
E NG LISH
All manuals and user guides at all-guides.com

E NG LISH
BNC Ca le (For Ethernet Network Only)
1. Connect one RJ-45 to BNC connector to the remote port on the TC-NT2
transmitter. Connect the other RJ-45 to BNC connector to the loop ack port on
the TC-NT2 remote terminator.
2. Connect one end of a BNC ca le to the TC-NT2 remote transmitter. Connect the
other end of the BNC ca le to the TC-NT2 transmitter.
3. Push the power utton on the TC-NT2 transmitter to the “On” position.
4. Press the auto (automatic) or test (manual) utton.
©
3
All manuals and user guides at all-guides.com

O tional Accessory TC-NTUF (Sold Se arately)
IEEE 1394 (6-pin) / USB Ca le
1. Connect one TC-NTUF to the remote port on the TC-NT2 transmitter. Connect
another TC-NTUF to the loop ack port on the TC-NT2 remote terminator.
2. Connect one end of a USB or Firewire ca le to the TC-NT2 remote transmitter.
Connect the other end of the USB or Firewire ca le to the TC-NT2 transmitter.
3. Switch the power utton on the TC-NT2 transmitter to the “On” position.
4. Press the auto (automatic) or test (manual) utton.
Firewire
Q— — yjv
1— 1 llllllllll
, L J llllllllll
o
o
o
o" "
---- IJ
LJ 4
E NG LISH
All manuals and user guides at all-guides.com

E NG LISH
LED Status
Good 1 2 3 4 5 6 7 8 S
PIN OUT
2 3 4 5 6 7 8 S
Pin 3 is wired correctly
Bad
(Open)
Bad
(Short)
2 3 4 5 6
PIN OUT
23456
n
23456
re
PIN OUT
23456
Pin 3 is not continuous
(Broken line)
Pin 3 and 4 are shorted
(Both pins are
contacting each other)
Bad
(Cross
wired)
2 3 4 5 6
n
PIN OUT
2 3 4 5 6
n
Pin 3 and 5 are cross
wired
BNC 2 3 4 5 6
PIN OUT
2 3 4 5 6
BNC ca le is good
Shielding
Center Pin
RX
TX
8S
RX
8S
TX
8S
RX
8S
TX
8S
RX
8S
TX
8S
RX
8S
TX
5
