TRENDnet TC-NT2 User manual

Network Cable Tester
TC-NT2
TC-NT2(V1)/02.26.2013

ENGLISH
Install the battery
1
RJ-11/RJ-45 Cable Test
1. Slide the cover off the TC-NT2 transmitter.
2. Connect and insert the battery.
3. Slide the cover back on to the TC-NT2 transmitter.
1. Connect one end of an RJ-11 or RJ-45 cable to the remote port on the TC-NT2
transmitter. Connect the other end of the RJ-11 / RJ-45 cable to the loopback
port on the TC-NT2 transmitter.
2. Switch the power button to the “On” position.
3. Press the auto (automatic) or test (manual) button.
1
23
POWER / TONE
OFF / ON
TC-NT2
TRANSMITTER
AUTO
TEST

ENGLISH
POWER / TONE
OFF / ON
TC-NT2
TRANSMITTER
AUTO
TEST
2
Remote Testing
Note:
Do NOT use the TC-NT2 for live wire testing. The TC-NT2 is for testing cables only.
Do not connect the TC-NT2 to an Ethernet cable that is connected to a switch,
router, computer, etc. Doing so will damage the device. Ensure the cable being
tested is not connected to a live device.
RJ-45 Cable
1. Connect one end of a RJ-45 cable to the TC-NT2 transmitter. Connect the other
end of the RJ-45 cable into the wall jack.
2. Connect one end of a network cable to the remote port on the TC-NT2 remote
terminator. Connect the other end of the network cable into the patch panel in
your wiring closet.
3. Push the power button on the TC-NT2 transmitter to the “On” position.
4. Press the auto (automatic) or test (manual) button.
TC-NT2
REMOTE
TERMINATOR
Wall Jack
Patch Panel
21
4 3

ENGLISH
TC-NT2
REMOTE
TERMINATOR
POWER / TONE
OFF / ON
TC-NT2
TRANSMITTER
AUTO
TEST
3
BNC Cable (For Ethernet Network Only)
1. Connect one RJ-45 to BNC connector to the remote port on the TC-NT2
transmitter. Connect the other RJ-45 to BNC connector to the loopback port on
the TC-NT2 remote terminator.
2. Connect one end of a BNC cable to the TC-NT2 remote transmitter. Connect the
other end of the BNC cable to the TC-NT2 transmitter.
3. Push the power button on the TC-NT2 transmitter to the “On” position.
4. Press the auto (automatic) or test (manual) button.
11
4 3
2

ENGLISH
TC-NT2
REMOTE
TERMINATOR
POWER / TONE
OFF / ON
TC-NT2
TRANSMITTER
AUTO
TEST
4
Optional Accessory TC-NTUF (Sold Separately)
IEEE 1394 (6-pin) / USB Cable
1. Connect one TC-NTUF to the remote port on the TC-NT2 transmitter. Connect
another TC-NTUF to the loopback port on the TC-NT2 remote terminator.
2. Connect one end of a USB or Firewire cable to the TC-NT2 remote transmitter.
Connect the other end of the USB or Firewire cable to the TC-NT2 transmitter.
3. Switch the power button on the TC-NT2 transmitter to the “On” position.
4. Press the auto (automatic) or test (manual) button.
Firewire
USB
11
2
4 3
11
4 3
TC-NT2
REMOTE
TERMINATOR
POWER / TONE
OFF / ON
TC-NT2
TRANSMITTER
AUTO
TEST
2

ENGLISH
5
LED Status
BNC
Pin 3 is not continuous
(Broken line)
Bad
(Cross
wired)
Bad
(Short)
Bad
(Open)
Pin 3 and 4 are shorted
(Both pins are
contacting each other)
123
PIN OUT
RX
7
4568S
1237
4568S
TX
123
PIN OUT
RX
7
4568S
1237
4568S
TX
123
PIN OUT
RX
7
4568S
1237
4568S
TX
123
PIN OUT
RX
7
4568S
1237
4568S
TX
Pin 3 is wired correctly
Good
123
PIN OUT
RX
7
4568S
1237
4568S
TX
BNC cable is good
Pin 3 and 5 are cross
wired
Shielding
Center Pin

Company Information:
Company Name:
TRENDnet, Inc.
Company Address:
20675 Manhattan Place
Torrance, CA 90501
USA
Product Information:
Product Description:
Network Cable Tester
Model Number:
TC-NT2
Brand Name:
TRENDnet
Technical Standards:
EN 55022: 2010 Class B
EN 61000-3-2: 2006 + A1: 2009 + A2: 2009
EN 61000-3-3: 2008
EN 55024: 2010
Declaration:
I hereby declare that the products and devices mentioned above are consistent with the
standards and provisions of the guidelines.
This product is herewith confirmed to comply with the Directive of 2004/108/EC.
February 26, 2013
Date
Title
Sonny Su
Name
Director of Technology
Signature

Modèle:
Nom Commercial:
Détails du produit:
Détails standard applicable:
Coordonnées du fournisseur:
Nom:
Adresse:
20675 Manhattan Place
Torrance, CA 90501
USA
TRENDnet, Inc.
Déclaration:
Ce produit est conforme à la directive 2004/108/CE.
Déclaration:
Je declare par la présente que les produits et appareils mentionnés ci-dessus sont
conformes aux standards et aux dispositions des directives.
Testeur de câble réseau
TC-NT2
TRENDnet
Nom du produit:
EN 55022: 2010 Class B
EN 61000-3-2: 2006 + A1: 2009 + A2: 2009
EN 61000-3-3: 2008
EN 55024: 2010
February 26, 2013
Date
Title
Sonny Su
Name
Director of Technology
Signature
