TRENDnet TFM-560E User manual

TRENDware's TFM-560P/TFM560E is the latest in
communication innovation. The TFM-560P/TFM560E is a
K56flex and V.90 ultra fast 56Kbps data/fax modem that
provides users with the highest possible data communication
rates, reliable error-free transmissions, and widespread
interoperability with other users. The TFM-560P/TFM560E also
supports Group 3 fax send and receive functions. This
fax/modem complies with the PCMCIA Type II slot standard and
is ideal for on-the-go notebook users.
Communication software is included free with the TFM-
560P/TFM560E for quick and easy startup. The TFM-
560P/TFM560E is also compatible with all communication
software capable of utilizing the Hayes 'AT'-command set.
TFM-560E
High Performance PCMCIA Fax Modem
PCMCIA 2.1/JEIDA 4.1 compliant
High performance 16C550A compatible UART
Hayes 'AT'-command compatible
Advanced Plug and Play technology to run with Windows
95/98/ME/2000/XP
Data and fax software for Windows included
Automatic sleep mode to extend PC battery life
RJ-11 cable with internal DAA for direct connection to the
telephone wall socket
High speed 56Kbps data and 14.4Kbps fax communication
Industry standard protocol for data compression and error
correction
5 Year Warranty
FEATURES
TFM-560E (11-17-2002)
TRENDnet
TRENDware, USA
What's Next in Networking

SPECIFICATIONS
TFM-560E
High Performance PCMCIA Fax Modem
TFM-560E
High Performance PCMCIA Fax Modem
Operating Protocol:
• K56flex (56,000 bps)
• V.34bis (33,600 bps)
• V.34 (28,800 to 2,400 bps)
• V32bis (14,400/12,000/9,600/
7,200 bps);
• V.32 (9,600/4,800 bps)
• V.22bis (2,400 bps)
• V.23 (1,200 TX/75 RX bps)
• V.22/Bell 212A (1,200 bps)
• V.21/Bell 103 (300bps)
Error Correction Protocol:
• V.42 and MNP Class 2 to 4
Data Compression Protocol:
• V.42bis and MNP Class 5
Fax Compatibility:
• EIA Class 1 fax commands
• Group 3 send and receive
• ITU-T V.17 up to 14,400 bps
• ITU-T V.29 up to 9,600 bps
• ITU-T V.27ter up to 4,800 bps
• ITU-T V.21 Channel 2
up to 300 bps
Dialing Capability:
• DTMF tone; Rotary pulse
Operating Modes:
• Asynchronous full duplex
• Manual/automatic answer
Flow Control:
• Hardware CTS/RTS
• Software XON/XOFF
Receive Sensitivity:
• -40 dBn
Transmit Level:
• Permissive -10 (±) 1 dBm
Line Interface:
• RJ-11, 2-wire dial-up
Typical Power Consumption:
• Operation: 640mW;
• Sleep mode: 80mW
Diagnostic:
• Power-up self-test; Local analog
loopback test; Local analog
loopback with self-test; Local
digital loopback test; Remote
digital loopback test; Remote
digital loopback with self-test
Software Control Interface:
• Hayes compatible AT
command set
Call Progress Monitoring:
• Dial tone; Busy tone
• Ringback detection
Dimension:
• Comply with PCMCIA Type II;
3.37" x 2.128" x 0.197"
(85.6mm x 54mm x 5mm)
Weight:
• 35g
PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
TEM-560T: PCMCIA Ethernet (TP) +
56Kbps Fax Modem
TFM-560P: PCMCIA 56K (V.90) High
Speed Fax Modem (Lucent Chipset)
TFM-560E: PCMCIA 56K (V.90) High
Speed Fax Modem (Lucent Chipset)
TEM100-56: PCMCIA 10/100Mbps Fast
Ethernet + 56Kbps Fax Modem Card
ORDERING INFORMATIONORDERING INFORMATION
