TRENDnet TPL-202E - Powerline Fast EN Bridge User manual

The Powerline 10/100 Mbps Ethernet Bridge transforms existing
power lines in your home or small office into a high-speed network
solution. The Powerline Ethernet bridge meets Home Plug 1.0
compatibility, ensures privacy through 56-bit Data Encryption, and
supports data rates of up to 85Mbps. Included software measures
data performance and enhances network security.
TPL-202E (v1.0R)
85Mbps Powerline Fast Ethernet Bridge
TPL-202E
rev:02.02.2007
• Up to 85Mbps High-Speed Data Transfer Rate over Powerlines
• Allows Concurrent Shared Internet Access across existing Electrical Outlets
• Fully HomePlug 1.0 Turbo Compliant
• Supports 56-bit Data Encryption Security
• Compatible with Windows 98SE, ME, 2000 and XP Operating Systems
• Connect to a Network using Existing Powerlines with Wall-Plugged design
• Supports up to 16 Clients per Network with range of up to 300 meters
• Supports Plug & Play and Easy Installation
• 3-Year Warranty
FEATURES

Interface
Weight
Frequency Band
Modulation
Speed
Supported OS
Nodes
Encryption
Humidity
Consumption
Temperature
Power Source
Certifications
• IEEE 802.3, IEEE 802.3u
• 0% to 90% (Non-Condensing)
• 10/100Mbps Auto-MDIX RJ45 Port
• 56-bit DES with key management
• FCC, CE
• 4.5 ~ 21 MHZ
• OFDM
• Powerline: Up to 85Mbps
• Up to 16 client notes
• Input: 100~240V AC, 50/60 Hz
• 74 x 100 x 35 mm (2.9 x 4 x 1.3 inches)
• 140g (5 oz.)
• 0° ~ 40° C (32° ~ 104° F)
• 2.5 watts (max.)
• RJ45: 10/100Mbps
• Windows 98SE/ME/2000/XP
• Power, HomePlug, Ethernet
LED
Dimension (L x W X H)
Standards
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
85Mbps Powerline Fast Ethernet Bridge
TPL-202E (v1.0R)
RELATED PRODUCTS
PACKAGE CONTENTS
TPL-210AP 85Mbps Powerline Wireless Access Point
• Utility CD-ROM
• TPL-202E
• Multi-Language Quick Installation Guide
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
SPECIFICATIONS
• RJ-45 Cable (1.8m)
10/100Mbps
Powerline
54Mbps Wireless
Outlet
Workstation with
Wireless PCI Adapter
(TEW-423PI)
Notebook with
Wireless PC Card
(TEW-421PC)
85Mbps Powerline
Wireless Access Point
(TPL-210AP)
Outlet
85Mbps Powerline
Fast Ethernet Bridge
(TPL-202E)
Workstation with
Fast Ethernet PCI Adapter
(TE100-PCIWN)
4-Port Cable/DSL
Broadband Router
(TW100-S4W1CA)
85Mbps Powerline
Fast Ethernet Bridge
(TPL-202E)
Internet
Cable/DSL
Modem
Outlet
• HomePlug 1.0 Turbo
• Power Prongs
