TRENDnet’s TEG-S41SX Copper Gigabit Switch delivers
small office networks a quick boost of copper gigabit speed
and Mini-GBIC flexibility to meet immediate bandwidth
demand. The switch includes four 10/100/1000Mbps Copper
Gigabit Ethernet ports and one Mini-GBIC module slot for fiber
connectivity to Server(s) or high-end workstations.
TRENDnet’s known reliability and affordability make this a
great entry-level switch for growing networks.
TEG-S41SX
5-Port 10/100/1000Mbps Copper Gigabit Switch with Mini-GBIC
BENEFITSFEATURES
Easy Upgrade:
Expandability:
Performance:
Cost-Effectiveness:
Ethernet workgroups are able to
upgrade to Fast Ethernet by changing
adapters and a hub without changing
switches
Expand the connection distance with
optional GBIC fiber modules
Provides non-blocking high
performance with internal switch
controller
The TEG-S41SX presents Gigabit
Ethernet at an affordable rate
4 x 10/100/1000Mbps Auto-Negotiation and Auto-
MDIX Fast Ethernet Ports
1 x 1000Mbps Mini-GBIC Port for Optional LC
type Gigabit Fiber Module
Full/Half-Duplex Transfer Mode for each Port
(only Full Duplex Mode for 1000Mbps)
Store and Forward Switching Architecture
Integrated address Look-Up Engine with 4K
absolute MAC address table
Supports 1M RAM Data Buffering
IEEE 802.3x Flow Control for Full Duplex Mode
Back Pressure Flow Control for Half Duplex Mode
Extensive diagnostic LED’s on the Front Panel
5-Year Warranty
TEG-S41SX (10-28-2004)
TRENDnet
TRENDware, USA
What's Next in Networking

RELATED PRODUCT
To Order Please Call:
1-888-326-6061
TEG-S41SX: 5-Port 10/100/1000Mbps Copper Gigabit Switch
w/ Mini-GBIC
TEG-2224WS: 28-Port (24 10/100, 2 10/100/1000, 2 Mini-
GBIC) Smart Switch
TEG-2248WS: 52-Port (48 10/100, 2 10/100/1000, 2 Mini-
GBIC) Smart Switch
NETWORKING SOLUTIONS
SPECIFICATIONS
TEG-S41SX
5-Port 10/100/1000Mbps Copper Gigabit Switch with Mini-GBIC
TEG-S41SX
5-Port 10/100/1000Mbps Copper Gigabit Switch with Mini-GBIC
Standards:
• IEEE 802.3 10Base-T, IEEE 802.3u
100Base-TX, IEEE 802.3ab 1000Base-T,
IEEE 802.3z 1000Base-SX/LX, IEEE
802.3x Full Duplex Flow Control
Network Media:
• Ethernet: UTP/STP Cat. 3, 4, 5
• Fast Ethernet: UTP/STP Cat. 5
• Gigabit: UTP/STP Cat. 5
Protocol /Topology:
• CSMA/CD, Star
LAN Ports:
• 4 x 10/100Mbps Auto Negotiation,
Auto-MDIX Fast Ethernet Ports 1 x
1000Mbps Mini-GBIC Port for Optional
Mini-GBIC Module
Address Table:
• 4K Entries
Data RAM Buffer:
• 1Mbit
Data Transfer Rate:
• Ethernet: 10Mbps/20Mbps
(Half-Duplex/Full-Duplex)
• Fast Ethernet: 100Mbps/200Mbps
(Half-Duplex/Full-Duplex)
• Gigabit Ethernet: 2000Mbps (Full-Duplex)
Diagnostic LEDs:
• Per Unit: Power
• Per Fast Ethernet: Link/ACT
• Per Cooper Gigabit Port: Link/ACT,
1000M, 100M
• Per Mini-GBIC Gigabit Port: Link/ACT,
1000M
Power/Consumption:
• 7.5V 1.5A External Power Adapter / 7.6
watts (max)
Dimensions (W x D x H):
• 171 x 98 x 29 mm
( 6.7 x 3.85 x 1.14 inches)
Weight:
• 0.5kg (1.02lbs)
Temperature:
• Operating : 0° ~ 40° C (32° ~ 104° F)
• Storage: -10° ~ 70° C (14? ~ 158° F)
Humidity:
• 10% ~ 90% (no-condensing)
Certifications:
• FCC Class A, CE Class A
TRENDnet is a registered trademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this
document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit ____________________
http://www.TRENDNET.com.
©
Copyright TRENDware International, Inc. 2004. All Rights Reserved.
TRENDware International, Inc.
3135 Kashiwa Street
Torrance, CA. 90505. USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.TRENDNET.com
ORDERING INFORMATION
TRENDnet
TRENDware, USA
R
Servers with
Copper Gigabit PCI Adapter
(TEG-PCITXM2)
LC Type Cable
Workstations with
Copper Gigabit PCI Adapter
(TE100-PCITXR)
5-Port Copper Gigabit Switch
with Mini GBIC
(TEG-S41SX)
Mini GBIC
(TEG-MGBSX)
Mini GBIC
(TEG-MGBSX)
1000Mbps
