TRENDnet's TE100-S32plus is a high performance, auto-
sensing 32-port NWay rack-mountable Fast Ethernet Switch.
It is designed to eliminate unnecessary traffic and relieve
congestion on critical network paths. With 10/100Mbps NWay
technology, the TE100-S32plus automatically negotiates
between 10Base-T and 100Base-TX network speeds, as well
as half and full duplex modes. The TE100-S32plus also has a
module bay for optional multimode SC type fiber module that
allows connection to another fiber device up to 2Km away (in
full-duplex mode). The auto MDI-II/MDI-X detection on each
port automatically detects and corrects for crossover
connection and allows direct switch-to-switch or switch-to-
hub connection for your networking needs.
TE100-S32plus
32-Port 10/100Mbps NWay Fast Ethernet Switch
BenefitsFeatures
Performance:
Easy Upgrade:
Flexibility:
Expandability:
Cost Effective:
Top performance at an affordable
price.
Current Ethernet workgroups are able
to upgrade to Fast Ethernet by
changing adapters and hubs without
changing switches.
All ports automatically negotiate
10/100Mbps network speed, half/full-
duplex mode, and MDI-II/MDI-X
connector type.
Optional 100Base-FX multimode SC
type module links to other fiber device
up to 2Km in full-duplex mode.
Provide 10/100Mbps of Fast Ethernet
at an affordable rate.
32 10/100Mbps NWay Auto-MDI Ethernet Ports
1 module bay for optional 100Base-FX SC type
connector Fiber Module
Full/Half duplex transfer mode for each port
Store and Forward switching method
Integrated address Look-Up Engine, supports 4k
absolute MAC Address
Supports 1M Bytes RAM for data buffering
Extensive Front Panel Diagnostic LEDs
Broadcast Storm protection
IEEE 802.3x flow control for full-duplex
Back Pressure flow control for half-duplex
Standard 19" rack-mount design
5-Year Warranty
TE100-S32+ (03-07-2005)
TRENDnet
TRENDware, USA
What's Next in Networking

TE100-S32plus:
32-Port 10/100Mbps NWay Fast Ethernet Switch
TE100-S24plus:
24-Port 10/100Mbps NWay Fast Ethernet Switch
TE100-S16plus:
16-Port 10/100Mbps NWay Fast Ethernet Switch
TE100-SFXM:
Multimode SC-Type Connector Fiber Slide-in Module for
TE100-S16/S16plus/S24plus/S32plus
LAN Standards:
IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX
ANS/IEEE 802.3 NWay auto-negotiation
Network Media:
Ethernet: UTP Cat 3, 4, 5, EIA/TIA-568 100 ohm screened
twisted pair (STP), 100 meters max.
Fast Ethernet: UTP Cat 5, EIA/TIA-568 100 ohm screened
twisted pair (STP), 100 meters max.
Fiber Module: 62.5/125u Multimode fiber with SC type
connector 2Km max. (full-duplex)
Protocol:
CSMA/CD
Topology:
Star
Data Transfer Rates:
Ethernet: 10Mbps Half Duplex, 20Mbps Full Duplex
Fast Ethernet: 100Mbps Half Duplex, 200Mbps Full Duplex
•
•
•
•
•
•
•
•
•
Data RAM Buffers:
• 1 M Byte per device
Filtering Address Table:
• 4K entries per device
Diagnostic LEDs:
Power, 10/100Mbps Link/Activity, Collision/Full Duplex,
FX Power: 100~240VAC 50/60Hz, internal Universal
Switching Power
Power Consumption:
40 Watts. Max
Dimensions:
440 x 200 x 44 mm (17.3 x 7.9x 1.73 inch) (W x H x D)
Weight:
3Kg (6.6 lb)
Temperature:
Operating: 0° ~ 50° C (32° ~ 122°F).
Storage: -10° ~ 70° C (14° ~ 158°F)
Humidity:
10% ~ 90% (no-condensing)
Emission:
FCC Class A, CE Mark A, VCCI-A
•
•
•
•
•
•
•
•
