TRENDnet TEG-S2620i User manual

H/W: V1.0R
TEG-S2620i
Quick Installation Guide

Table of Contents
English ......................................................................................................
Troubleshooting ........................................................................................
1
1
3
2
6
1. Before You Start
2. Hardware Installation ........................................................................
3. Configure the Switch .........................................................................
................................................................................
Table of Contents
Version 05.08.2008

System Requirements
Optional Equipment
Application
Package Contents
1. Before You Start
English
1
?
?Multi-Language Quick Installation
Guide
?User's Guide CD-ROM
?RS-232 cable
?Power Cord
?Rack Mount Kit
TEG-S2620i
?
?Acomputer with a network adapter properly installed
?TCP/IP protocol
?One RJ-45 network cable
Web Browser: Internet Explorer (5.5 or higher)
?
?Mini-GBIC module (e.g. TEG-MGBSX, TEG-MGBS10, TEG-MGBS40,
TEG-MGBS80, TEG-MGBS10D3_D5,TEG-MGBS40D3_D5) for Mini
GBIC slots
EIAstandard 19” rack
1000MbpsRS-232 Console 10/100Mbps
Console Terminal
RS-232 8-Port 100Base-FX Layer 2
Managed Switch with Mini GBIC Slot
(TEG-S811Fi)
Virtual LAN
26-Port 10/100Mbps Layer 2 Switch with
Gigabit Ethernet Ports and Mini-GBIC Slots
(TEG-S2620i)
Virtual LAN
Network Servers

2. Hardware Installation
English
2
2. Connect a RJ-45 network cable
from the computer to an available
Ethernet port on the TEG-S2620i.
3. Verify that the following panel lights
are on: POWER and LINK/ACT.
1. Connect the Power Cord to
the TEG-S2620i and then to a
power outlet. Then press on the
switch to power up the
TEG-S2620i.

English
3
3. Configure the Switch
Note: It is recommended that you configure the Switch from a wired computer.
Before the Switch can be configured, a Static IP address must be assigned to
your computer's network adapter in the subnet of 192.168.223.x. Since the
Switch's default IP address is 192.168.223.100, make sure no other network
devices are assigned an IP address of 192.168.223.100. (Refer to
Troubleshooting section on how to configure TCP/IPsettings on your PC.)
Web Browser
1. Open your web browser, type
http://192.168.223.100 in the
Address bar, and then press Enter.
3. Select the desired options for
configuring the SNMP switch.
2. Enter the User Name and
Password, and then click OK.
By default:
User Name: admin
Password: 123

English
4
HyperTerminal
2. Go to Start -> Programs ->
Accessories -> Communications ->
HyperTerminal.
3. Enter a name, choose an icon and
then click OK.
4. Select the correct COM port (e.g.
COM1, COM2) and then click OK.
1. Connect the RS-232 cable from a
serial port on your Windows PC to
the console port on your computer.

English
5
6. Press Enter.
5. Enter the following, click Apply
and then click OK:
Bits per second: 115200
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
Your configuration is now complete.
For detailed information regarding the TEG-S2620i's configuration and
advanced settings, please refer to the Troubleshooting section, User's Guide
CD-ROM, or TRENDnet's website at http://www.trendnet.com.
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
7. Enter the User Name and
Password, and then hit Enter.
By default:
User Name: admin
Password: 123

6
Troubleshooting
Q1: How do I configure TCP/IP settings on my computer?
Q2:
A2:
A3:
A3:
: I typed http://192.168.223.100 in my Internet Browser's Address Bar, but an error message
says “The page cannot be displayed.” How can I get into the TEG-S2620i's web configuration
page? First, check your hardware settings again by following the instructions in section 2.
Second, make sure the POWER and LINK/ACT lights are lit. Third, make sure the TCP/IP
settings are configured properly (see Q1). Fourth, since the Switch's default IP address is
192.168.223.100, make sure that no other network devices are assigned an IP address of
192.168.223.100.
If my network's IP is different than the Switch's range, what should I do?
You should still configure the Switch first.After all the settings are applied, go to the
Switch's configuration page, click onAdministrator, click IP & Management Mode and change
the IP address of the Switch to match your network's IP.
What are the default port settings for configuring the Switch through the console port
using HyperTerminal?
Bits per Second: 115200; Data bits: 8; Parity: None; Stop bits: 1; Flow control: None.
If you still encounter problems or have any questions regarding the TEG-S2620i, please contact
TRENDnet's Technical Support Department.
Q3:
Q4:
1. Go into the Control Panel, double-click the Network
Connections icon, and then right-click the Local Area
Connection icon and then click Properties.
2. Click Internet Protocol (TCP/IP) and then click
Properties. Then click on Use the following IP
address, and make sure you assign your network
adapter an IP address in the subnet of 192.168.223.x.
