System Requirements
Application
TK-207K
User’s Guide
Utility CD-ROM
2 Sets of USB KVM Cables
Type A USB keyboard
Type A USB mouse
VGA or SVGA Compatible Monitor
Windows 98/ME/2000/XP/2003, Linux, or Mac O.S.
Package Content
1. Before You Start
English
1
2-Port USB
KVM Switch
(TK-207K)
PC 1 PC 2
LCD Monitor
USB Keyboard USB Mouse
All manuals and user guides at all-guides.com

1. Turn off both computers and their
peripherals, and disconnect all
power cords.
3. Use the provided KVM cables to
connect your PC to your KVM
switch.
2. How to Connect
English
2
2. Connect the shared keyboard,
monitor, and mouse to the KVM
Switch's console port.
Note: The TK-207K USB KVM Switch does not require any drivers or software.
All manuals and user guides at all-guides.com

5. Press the face panel button on the
KVM Switch to select the second
computer.
Your installation is now complete.
English
3
4. Turn ON the first computer and
wait until startup completes.
PC 1
PC 2
6. Turn ON the second computer and
wait until startup completes.
All manuals and user guides at all-guides.com

Note: For PC switching, you can use the face-panel buttons of the KVM Switch,
a hot-key command sequence via keyboard, or the Client Switch Utility
(Windows only). For more detail on the Client Switch Utility, please consult the
Client Switch Utility manual on the CD-ROM.
After pressing the ScrLk key, you have 2 seconds to press the ScrLk key
again. If you do not press a key within 2 seconds, the switch will exit hot-key
mode.
3. Operation
English
4
Face-Panel Buttons
Hot-Key Command Sequence
Press the corresponding face-panel
button to select your PC.
Universal Hot-Key Command
Command Hot-Keys Description
Select PC ScrLk ScrLk
+Select the active PC channel,
PC Channel 1 or PC Channel 2.
All manuals and user guides at all-guides.com
all-guides.com

Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
Q5:
A5:
Where is the power supply? I did not find one in the box.
The TK-207K does not require a power supply. It draws power from
your computer's USB connection. As long as your KVM switch is connected to
the USB port, it will receive the necessary power to function.
I have the KVM switch connected properly, but my keyboard and mouse don't
work.
Please make sure your USB port is working properly by testing it with your
other USB devices. Once you confirm that the USB port is functional, please
reboot your computers, and try to use the KVM switch again.
Can I connect and disconnect the USB cables while the computers are turned
on?
Yes, you can connect or disconnect the USB cables while the computers are
turned on because the USB interface is Plug-and-Play and Hot-Pluggable.
Will the KVM switch remember the keyboard settings between computers?
Yes, the KVM switch will remember the keyboard settings when switching
between your computers. (i.e.: Cap lock, Num key, etc.)
How do I switch from one computer to another with the KVM switch?
PC User: Push Buttons, Hot-Key Commands or Client Switch Utility
Mac User: Push Buttons
Linux User: Universal Hot-Key Commands
