TRENDnet TL2-E284 User manual

TL2-E284
1.01
Quick Installation Guide

English 1
1. Before You Start
2. Hardware Installation 2
3. LEDs 3
4. Configure the Switch 5
1
Troubleshooting 9
Table of Contents
Version 11.05.2010

1. Before You Start
Ÿ
ŸA computer with a network adapter properly installed
ŸCAT-5e or CAT-6 Network Cable
ŸThe surface must support at least 2 Kg (4.4 lbs) for the Switch
ŸThe power outlet should be within 1.8 meters (5.9 feet) of the Switch
ŸMake sure that there is proper heat dissipation from and adequate ventilation around the
Switch
ŸDo not place heavy objects on the Switch
Web Browser: Internet Explorer (6.0 or higher)
Ÿ
ŸMini-GBIC module (e.g. TEG-MGBSX, TEG-MGBS10, TEG-MGBS40, TEG-MGBS80,
TEG-MGBS10D35, TEG-MGBS40D35) for Mini-GBIC slots
EIA standard 19” rack
Package Contents
Ÿ
ŸMulti-Language Quick Installation Guide
ŸCD-ROM (User's Guide)
ŸRS-232 cable (3 m / 9.8 ft.)
ŸPower Cord (1.8 m / 5.9 ft.)
ŸRack Mount Kit
TL2-E284
Installation Requirements
Optional Equipment
1

2
2. Hardware Installation
Note:
Note: The Mini-GBIC slots are shared with port 25 and 26 Gigabit Ethernet ports. When the
Mini-GBIC slots are in use, port 25 and 26 Gigabit Ethernet ports are disabled.
1. Connect the Power Cord to the TL2-E284 and
then to a power outlet.
2. Connect a Cat.5e or Cat.6 RJ-45 network
cable from the computer to an available
Ethernet port on the TL2-E284.
3. Verify that the following panel lights are on:
PWR(Power), SYS(System) and 10M LINK/
ACT, 100M LINK/ACT, 10/100M LINK/ACT or
1000 LINK/ACT.

3
3. LEDs
PWR (Power)
SYS (System)
1000M LINK/ACT
10/100M LINK/ACT
10/100M LINK/ACT
10M LINK/ACT

4
N/A
Green
N/A
Green
Amber
Green
Amber
Ethernet LED (RJ-45)
PWR (Power)
SYS (System)
1000M Link/ACT
100/200Mbps (Half/Full Duplex) Connected (per port)
100/200Mbps (Half/Full Duplex) Data
Transmitting/Receiving (per port)
2000Mbps (Full Duplex) Data Transmitting /
Receiving (per port)
10/20Mbps (Half/Full) or no connection to the port
100/200Mbps (Half/Full), 10/20Mbps (Half/Full),
or no connection to the port
10/20Mbps (Half/Full Duplex) Connected (per port)
10/20Mbps (Half/Full Duplex) or 100/200Mbps
(Half/Full Duplex) Connected (per port)
10/20Mbps (Half/Full Duplex)Data
Transmitting/Receiving (per port)
10/20Mbps (Half/Full Duplex) or 100/200Mbps
(Half/Full Duplex) Data Transmitting/Receiving
(per port)
100/200Mbps (Half/Full), or no connection to the port
2000Mbps (Full), or no connection to the port
Device powered On
Device is ready
Solid
Solid
Solid
Solid
Solid
Off
Solid
Off
Off
Off
Off
Off
Blinking
Blinking
Blinking
Blinking
Green
Device powered Off
Device is not ready
2000Mbps (Full Duplex) Connected (per port)
100M Link/ACT
10M Link/ACT
10/100M Link/ACT
Device Status LED Color
Color
Sequence
Sequence
Definition
Definition
Combo Gigabit Ethernet
(RJ-45) / Mini-GBIC LED Color Sequence Definition

5
4. Configure the Switch
Note:
1. Before the Switch can be configured, a Static IP address must be assigned to your computer's
network adapter in the subnet of 192.168.10.x. Since the Switch's default IP address is
192.168.10.200, make sure no other network devices are assigned an IP address of
192.168.10.200. (Refer to Troubleshooting section on how to configure TCP/IP settings on your
PC.)
2. There are three methods of configuring the TL2-E284: Web Browser, Console Port and Telnet.
1. Using Web Browser
1. Open your web browser, type
http://192.168.10.200 in the Address bar, and
then press Enter.
2. Enter the User name and Password, and then
click Login. By default:
User Name: admin
Password: admin
3. Select the desired options for configuring the
switch.

6
Note:
A terminal program such as HyperTerminal is required to configure the switch via the Console Port.
The instructions shown below demonstrates how to configure the Switch on a Windows PC using
HyperTerminal.
2. Using the Console Port
2. Go to Start Ž Programs Ž Accessories Ž
Communications Ž HyperTerminal
1. Connect the RS-232 cable from a serial port on
your PC to the console port on the switch.
4. Select the correct COM port
(e.g. COM1, COM2) and then click OK.
3. Enter a name, choose an icon and then click
OK.

7
6. Press the Enter Key.
7. Enter the User Name for login. Then press the
Enter. Then Enter the Password and then
press Enter.
By default
login: admin
Password: admin
If you do not see the login prompt, please
power cycle the switch by unplugging the
power cord, wait 15 seconds and then plug it
back in.
5. Enter the following, click Apply and then
click OK.
Bits per second: 115200
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
The Telnet function may or may not be included with your computer's operating system. For
instructions on how to enable Telnet in Windows 7/Vista, please refer to the Troubleshooting
section.
3. Using Telnet
1. Click the Windows / Start icon on the bottom
left hand corner and click All Programs.

8
2. Click Accessories and then click Command
Prompt.
3. Type in telnet 192.168.10.200. Then press the
Enter key.
4. Enter the User Name for login. Then press the
Enter. Then Enter the Password and then
press Enter. By default
login : admin
Password: admin
If you do not see the login prompt, please
power cycle the switch by unplugging the
power cord, wait 15 seconds and then plug it
back in.
Configuration is now complete
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
For detailed information regarding the TL2-E284 configuration and advanced settings, please
refer to User's Guide included on the Utility CD-ROM, or TRENDnet's website at
http://www.trendnet.com.

1. How do I configure TCP/IP settings on my computer?
Troubleshooting
1. Go into the Control Panel, click Network and Internet,
click Network and Sharing Center, click Change
Adapter Settings and then right-click the Local Area
Connection icon and then click Properties.
Windows 7
Windows Vista
Windows XP / 2000
1. Go into the Control Panel, click Network and Internet,
click Network and Sharing Center, click Manage
Network Connections and then right-click the Local
Area Connection icon and then click Properties.
1. Go into the Control Panel, double-click the Network
Connections icon and then right-click the Local Area
Connection icon and then click Properties.
2. Click Internet Protocol Version 4(TCP/IPv4) and then
click Properties. Then click on Use the following IP
address, and make sure you assign your network
adapter an IP address in the subnet of 192.168.10.x.
2. Click Internet Protocol Version (TCP/IP) and then click
Properties. Then click on Use the following IP
address, and make sure you assign your network
adapter an IP address in the subnet of 192.168.10.x.
2. Click Internet Protocol Version 4(TCP/IPv4) and then
click Properties. Then click on Use the following IP
address, and make sure you assign your network
adapter an IP address in the subnet of 192.168.10.x.
9

2. I typed http://192.168.10.200 in my Internet Browser's Address Bar, but an error message
says “The page cannot be displayed.” How can I get into the TL2-E284's web configuration
page?
1. Check your hardware settings again by following the instructions in section 2.
2. Make sure the PWR(Power), SYS(System) and Link/ACT lights are lit.
3. Make sure your network adapter’s TCP/IP settings are configured properly (see Q1).
4. Since the Switch's default IP address is 192.168.10.200, make sure that no other network
devices are assigned an IP address of 192.168.10.200.
3. If my switch's IP is different than the network’s subnet, what should I do?
You should still configure the Switch first. After all the settings are applied, go to the Switch's
configuration page, click on Administrator, click IP & Management Mode and change the IP
address of the Switch to match your network's IP.
4. What are the default port settings for configuring the Switch through the console port
using HyperTerminal?
Bits per Second: 115200; Data bits: 8; Parity: None; Stop bits: 1; Flow control: None.
5. I changed the IP address of the switch, but I forgot it. How do I reset my TL2-E284?
Follow the instructions below:
1. Take a pin or paper clip and press the reset button on the front of the switch
2. Wait 15 seconds then let go.
The default IP address of the switch is 192.168.10.200. The default user name and password
is admin.
6. How do I enable Telnet on my Windows 7/Vista computer?
Follow the instructions below:
Windows 7
1. Go to Control panel and click Programs.
2. Click Turn Windows features on or off.
3. Check the box next to Telnet client and then click OK.
4. Please wait while Windows enables Telnet.
Windows Vista
1. Go to Control Panel and click on Classic View.
2. Click on Programs and Features.
3. Click Turn Windows features on or off.
4. Check the box next to Telnet Client and then click OK.
5. Please wait while Windows enables Telnet.
If you still encounter problems or have any questions regarding the TL2-E284 please contact
TRENDnet's Technical Support Department.
