TriangleTube prestige Use and maintenance manual

WARNING
2007-12 Prestige Control Appl. Supl.
This document is intended to be used by a factory trained and qualified heating
contractor or service technician only.Read all instructions within this document
and within the PRESTIGE Boiler Installation and Maintenance Manual, before pro-
ceeding. It is recommended to follow the procedures in the steps given, skipping
or missing procedural steps could result in severe personal injury, death or sub-
stantial property damage.
prestige
Control Application
Supplement
Revised 1/7/2008

Table of Contents
i
Product and Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Operating Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Program Access of the MCBA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Revising Application Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Domestic Hot Water DHW Application Parameters General Guide . . . . . . . . . . . . 4-5
Domestic Hot Water Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Central Heating CH Application Parameters General Guide . . . . . . . . . . . . . . . . . 13-14
Central Heating Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-25
Parameter Worksheet and Recorded Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-29

Product and Safety Information
1
The following terms are used throughout this manual to
bring attention to the presence of potential hazards or to
important information concerning the product.
Indicates the presence of a hazardous situation
which, if ignored, will result in death, serious injury
or substantial property damage.
Indicates a potentially hazardous situation which, if
ignored, can result in death, serious injury or sub-
stantial property damage.
Indicates a potentially hazardous situation which, if
ignored, may result in minor injury or substantial
property damage.
Indicates special instructions on installation, opera-
tion or maintenance, which are important to the
equipment but not related to personal injury hazards.
Indicates recommendations made by Triangle Tube
for the installers which will help to ensure optimum
operation and longevity of the equipment.
BEST PRACTICES
NOTICE
CAUTION
WARNING
DANGER
DEFINITIONS
IMPORTANT INFORMATION - READ
BEFORE PROCEEDING
This document is intended to be used by a factory
trained and qualified heating contractor or service
technician only. Read all instructions within this doc-
ument and within the PRESTIGE Boiler Installation
and Maintenance Manual, before proceeding. It is
recommended to follow the procedures in the steps
given, skipping or missing procedural steps could
result in severe personal injury, death or substantial
property damage.
WARNING
Triangle Tube reserves the right to modify the technical specifications and components of its product without
prior notice.
NOTICE

2
OPERATING INFORMATION
The Prestige SOLO boiler is controlled by the MCBA
Control module, which is a microprocessor electronic
controller. The MCBA offers various control options
which may be adjusted to the various installation appli-
cations to achieve optimum boiler efficiency and func-
tion.
The MCBA module has the capability to sense the
boiler supply and return water temperature, the flue
gas temperature, the outdoor temperature and the
storage temperature of a SMART / TR Series IDWH or
optional DHW kit (when optional NTC is installed).
The MCBA uses this information to regulate the boil-
er’s on/off operation and modulate the input rate of the
boiler to closely match the required demand of the
heating system.
PROGRAM ACCESS OF THE MCBA
To adjust the factory parameter settings of the Prestige
MCBA the installer must enter into the parameter listing
of the MCBA.
Do not attempt to adjust or revise any parameter
settings except those listed in detail throughout
this manual. A complete listing of factory set-
tings are listed on Page 26 at the end of this
manual if there is doubt or concern that a wrong
setting was revised. Failure to comply could
result in erratic or unreliable operation of the
Prestige boiler.
To enter the parameter listing of the MCBA control, the
installer must enter the activation code as follows:
1. Press and hold the MODE button
2. Continue holding the MODE and press STEP button
until STBY appears and hold both STEP and
MODE buttons for 2 to 3 seconds.
The display should read CODE
3. Release the STEP and MODE buttons on the con-
trol panel.
4. Press STEP once.
WARNING
The display should read C_ XX (XX should be
a random number from 00 to 99)
5. Press the + or - button to change the display num-
ber
C_ XX to read C_05 . Press and release the +
or - to change the display one number at a time.
Press and hold the + or - to rapidly change the dis-
play number.
6. When the display reads C_05 press STORE to
save the activation code. The display
C_05 should
flash when the code is entered and saved.
After the activation code is entered press the MODE but-
ton until the display shows
PARA . At this point the
installer can access the parameters required for appli-
cation.
Once in the parameter mode, press the STEP repeated-
ly to reach the appropriate parameter setting. The dis-
play should show the following sequence, as the STEP
button is press repeatedly:
Press STEP once- 1140
Press STEP x2 - 2_01
Press STEP x3 - 3_01
Press STEP x4 - 4186
Press STEP x5 - P_05
Press STEP x6 - P_06
Etc......
After Parameter 4 the display will continue to show P fol-
lowed by a two-digit number that increases with each
press of the STEP button.
The actual parameter values displayed on the
unit may vary depending on the application. The
parameter sequence will always occur in the
order shown.
Once a particular parameter sequence is reached,
release the STEP button. Wait a second and the display
will show the current setting for that parameter in the
right two display digits.
NOTICE

3
To Change a Parameter Setting
Use the + or - button to change the value on the
display.
Press the STORE button once to save the
change. The display should flash to indicate the
new value is stored.
If a parameter setting is changed from the facto-
ry default and the STORE button is not pressed
to save the setting, the MCBA module will auto-
matically store the setting after 15 minutes.
Ensure all parameters settings are either factory
default or revised based on the application.
Review all parameters settings using the work-
sheet on page 26 when completed and prior to
commission of the boiler. Failure to comply
could result in erratic or unreliable operation of
the Prestige boiler.
Once a parameter setting value has been
revised and stored, if the STEP button is
pressed for the next parameter setting the value
setting of that parameter will appear. The dis-
play will not show P_XX of the next sequential
parameter. The sequence of parameters may be
scrolled through, as the display will roll over
from parameter 42 to parameter 1.
If sequential parameters are being revised and since
the display will not show P_XX of the next sequen-
tial parameter, it is recommend to press and hold
the STEP button to scroll through the entire list of
parameters before making any additional changes
to avoid any potential confusion.
To exit the Code mode press the RESET button
once.
BEST PRACTICES
NOTICE
WARNING
REVISING APPLICATION SETTINGS
The following sections in this manual cover various
parameters settings within the MCBA control that can be
revised based on the particular application in which the
Prestige is installed. The parameter settings may be
combined to provide the optimum application perform-
ance of the Prestige.
The installer should record each revision using the work-
sheet located page 26 in the back of the manual as the
parameter changes are being made. Prior to changing
any parameters the installer should determine what the
application requirements are and determine which
parameter revisions are needed.

4
Parameter Description
Factory
Setting
Minimum
Setting
Maximum
Setting
1
NTC Sensor setting for domestic hot water
applications depending on the setting of
Parameter 35 (storage tank with NTC or storage
tank with aquastat).
140ºF 68ºF 148ºF
Detection setting for DHW request.
See pages 6 and 8 for additional information
2
DHW application selection. Setting of the DHW
Burner Function “ON” or “OFF”. Setting of the
DHW pump function “continuous” or “aquastat
controlled”.
01 00 03
See pages 9 through 11 for additional information
21
The DHW circulator post pump time period
applied after the completion of a DHW request.
Parameter setting is multiplied by 10.2 seconds.
03
x 10.2 sec.
00
x 10.2 sec.
30
x 10.2 sec.
See page 11 for additional information
26
DHW differential setting for detection “ON”.
Setting is applied on storage tank with NTC
sensor applications.
02ºF 02ºF 54ºF
See pages 7 and 8 for additional information
27
DHW differential setting for detection “OFF”.
Setting is applied on storage tank with NTC
sensor applications.
18ºF (-)16ºF 54ºF
See pages 7 through 8 for additional information
29
The time period of blocking the burner function of
a secondary DHW request after a completion of
the initial DHW request. Parameter setting is
multiplied by 10.2 seconds.
00
x 10.2 sec.
00
x 10.2 sec.
30
x 10.2 sec.
See page 11 for additional information
30
The time period of blocking the burner function of
a CH request after a completion of a DHW
request. Parameter setting is multiplied by 10.2
seconds.
00
x 10.2 sec.
00
x 10.2 sec.
30
x 10.2 sec.
See page 12 for additional information
DOMESTIC HOT WATER DHW APPLICATION PARAMETERS GENERAL GUIDE

5
Parameter 35 has multiple parameter settings
available in addition to the settings 12 and 13,
which are outlined in detail in this supplement
guide. DO NOT set Parameter 35 to any other
setting other than 12 or 13. Failure to comply
can result in erratic or unreliable operation of the
Prestige boiler.
WARNING
Parameter Description
Factory
Setting
Minimum
Setting
Maximum
Setting
33
Set value addition for DHW. This value is added
to Parameter 1 to set the operating temperature
of the Prestige during a DHW request. See
pages 6 through 9 for additional information
46ºF 00ºF 54ºF
35
See Warning
Below
Selection of the DHW application. Storage tank
application with NTC sensor (12). Storage tank
with aquastat control application (13).
13 00 29
See pages 6 through 9 for additional information

6
DOMESTIC HOT WATER APPLICATIONS
In all domestic hot water applications the Prestige boiler
will provide a domestic priority feature in which the CH cir-
culator will be blocked from providing heated water to the
space heating zones during a domestic hot water demand.
This feature cannot be adjusted or eliminated from the
MCBA program.
DOMESTIC HOT WATER (SMART/TR
SERIES OR DHW KIT) WITH NTC SENSOR
This application requires the optional NTC sensor kit for
SMART/TR Series Indirect Fired Water Heaters or for
DHW kit. In this application the NTC sensor will monitor
the domestic water storage temperature of the IDWH.
The domestic water storage temperature will determine
the ON/OFF operation of the boiler and the modulation
input of the boiler.
Parameter Adjustments
The first parameter adjustment needed for this applica-
tion is Parameter 35, which sets the MCBA control to
accept the NTC sensor of the IDWH. Follow the steps
given in Program Access Section on page 2 until the dis-
play shows P_35 . Release the STEP button and dis-
play should show the factory setting listed below. Use
the + or - to adjust to the revised setting listed below and
press STORE to save the setting. The display setting will
flash when the setting is stored within the MCBA control.
Parameter 35 has multiple parameter settings
available in addition to the settings 12 and 13. DO
NOT set Parameter 35 to any other setting other
than 12 or 13. Failure to comply can result in errat-
ic or unreliable operation of the Prestige Boiler.
The next parameter adjustment for this application is
Parameter 1, which is accessible during normal opera-
tion and does not require entry into the CODE mode. To
exit the CODE mode, press the RESET button once.
Parameter 1 is the set point temperature for domestic
water storage in the IDWH. The heat request for domes-
tic heating is based on this parameter setting. To adjust
WARNING
the parameter setting press MODE until display shows
PARA . Press STEP once and the display should show
factory setting 1140 . Use the + or - to adjust the setting.
Press STORE to save the setting. The display will flash
when the setting is stored into the MCBA control.
If Parameter 1 is set below 134ºthen it is recommended
that Parameter 33 be reset to a higher setting. The
request for heat is based on the temperature reading of
the DHW NTC sensor and its relationship to Parameter
1. The operating temperature setpoint of the boiler is
based on Parameter 1 + Parameter 33 with a maximum
operating temperature of 194ºF. The burner ON/OFF
and modulation is based on the relationship of the boiler
supply temperature and the sum of Parameter 1 and
Parameter 33.
To adjust the DHW Set Value Addition follow the steps
given in Program Access Section on page 2 until the dis-
play shows
P_33 . Release the STEP button and the
display should show the factory setting. Use the + or -
to adjust to the revised setting and press STORE to save
the setting. The display setting will flash when the set-
ting is stored within the MCBA control
Error Codes
If Parameter 35 is set to 12 and no NTC sensor is con-
nected to the 24 volt terminal strip, DHW T-T connection
on the Prestige, then a “soft” lockout will occur. The dis-
play will show an error code of
b_38 alternating with a
status code of 9.
If Parameter 35 is set to 12 and the NTC for DHW is
short-circuited then a “soft” lockout will occur. The dis-
play will show an error code of b_33 alternating with a
status code of 9.
Parameter Factory Setting Revised Setting
P_35 13 12
Parameter
Factory
Setting
Minimum
Setting
Maximum
Setting
1 140ºF 68ºF 148ºF
Parameter
Factory
Setting
Minimum
Setting
Maximum
Setting
P_33 46ºF 00ºF 54ºF

7
During these “soft” lockout conditions the burner function
is blocked for DHW as well as CH request for heat. Only
the CH circulator will respond to a request for heat.
Both error codes will reset automatically when the error
condition is corrected.
During any DHW error condition the Prestige will
continue to maintain normal CH circulator oper-
ation on a CH request for heat, but will block the
burner function for a CH request for heat. The
Prestige will block the burner and DHW circula-
tor operation on a DHW request for heat until the
error condition is corrected.
DHW NTC SENSOR DIFFERENTIAL
The MCBA module has 2 differential settings for the
burner operation when using a NTC for DHW applica-
tions. The first differential setting is Parameter 26
“Detection ON”. This parameter sets the DHW storage
temperature low limit. The burner operation will respond
when the DHW storage temperature drops below the
Parameter 1 setting minus the Parameter 26 setting.
A minimum “Detection ON” parameter setting will create
a quick burner operation response to any domestic
water draws from the storage tank. In contrast, a maxi-
mum “Detection ON” setting will result in a delay
response to domestic draws.
NOTICE
The “Detection ON” setting of Parameter 26
greatly affects the production of domestic hot
water. A minimum setting of Parameter 26 could
result in rapid responses to a DHW request for
heat resulting in a potential scald hazard. It is
strongly recommended that the installer utilizes
a thermostatic mixing valve on the hot water out-
let of the DHW storage tank. Failure to comply
could result in severe personal injury, death or
substantial property damage.
Parameter Adjustments
To adjust DHW NTC sensor differential “DETECTION
ON” value follow the steps given in the Program Access
Section on page 2 until the display shows P_26 .
Release the STEP button and the display should show
the factory setting. Use the + or - to adjust to the revised
setting and press STORE to save the setting. The dis-
play setting will flash when the setting is stored within the
MCBA control.
The second differential setting is Parameter 27
“Detection OFF”. This parameter sets the DHW storage
temperature high limit. The burner operation will cease
when the DHW storage temperature rises above the
Parameter 1 setting plus Parameter 27 setting.
A maximum “Detection OFF” parameter setting will result
in an extended burner firing cycle when responding to
any domestic water draws from the storage tank. This
extended burner firing cycle could result in a final stor-
age temperature of the domestic hot water that is higher
than the desired storage temperature setting.
DANGER
Parameter
Factory
Setting
Minimum
Setting
Maximum
Setting
P_26 02ºF 02ºF 54ºF
Error Code Reason / Correction
b_33
The NTC sensor is “short circuited".
This will also occur if the sensor would
detect a false temperature reading
above 260ºF. Check wiring of the NTC
sensor for proper connections.
b_38
The NTC sensor is open. This will also
occur if the sensor would detect a false
temperature reading of -32ºF. Check
and ensure NTC sensor is properly
wired and connect to the proper
terminals on the Prestige low voltage
terminal strip.

8
Parameter Adjustments
The first parameter adjustment for IDWH aquastat con-
trol application is Parameter 35. Follow the steps given
in Program Access Section on page 2 until the display
shows P_35 . Release the STEP button and thedisplay
should show the factory setting list below. Use the + or
- to adjust to the revised setting and press STORE to
save the setting. The display will flash when the setting
is stored in the MCBA control.
Parameter 35 has multiple parameter settings
available in addition to the settings 12 and 13. DO
NOT set Parameter 35 to any other setting other
than 12 or 13. Failure to comply can result in
erratic or unreliable operation of the Prestige
Boiler.
The next parameter adjustment for this application is
Parameter 1 and Parameter 33. Parameter 1 is acces-
sible during normal operation and does not require entry
into the CODE mode. To exit the CODE mode, press
the RESET button once.
Parameter 1 and Parameter 33 combine to create the
boiler operating temperature limit during a heat request
for DHW. The operation of the burner on/off is con-
trolled by the IDWH aquastat. The modulation of the
burner is based on the current boiler temperature and
its relationship to the temperature limit established by
Parameter 1 plus Parameter 33.
If Parameter 1 is set below 134ºF then it is recom-
mended that Parameter 33 be reset to a higher setting.
The request for heat is based on the DHW aquastat
closing an end switch which is connected directly to the
24V low voltage terminal of the Prestige. The operating
temperature set point of the Prestige boiler is based on
Parameter 1 + Parameter 33 with a maximum operating
temperature of 194ºF. The burner modulation is based
on the relationship of the boiler supply temperature and
the sum of Parameter 1 and Parameter 33.
WARNING
The “Detection OFF” setting of Parameter 27
greatly affects the production of domestic hot
water. A maximum setting of Parameter 27 could
result in excessive domestic storage tempera-
ture resulting in a potential scald hazard. It is
strongly recommended that the installer utilize a
thermostatic mixing valve on the hot water out-
let of the DHW storage tank. Failure to comply
could result in severe personal injury, death or
substantial property damage.
To adjust DHW NTC sensor differential “DETECTION
OFF” value follow the steps given in Program Access
Section on Page 2 until the display shows
P_27 .
Release the STEP button and the display should show
the factory setting. Use the + or - to adjust to the revised
setting and press STORE to save the setting. The dis-
play setting will flash when the setting is stored within the
MCBA control
FROST / FREEZE PROTECTION OF THE
IDWH
This feature is only available when the storage tank tem-
perature is controlled by a NTC sensor. If the NTC sen-
sor senses a domestic storage tank temperature of 38ºF
then the Prestige will active the DHW burner and circu-
lator function. The burner will operate at minimum input
rate and the circulator will energize until the NTC sensor
senses 50ºF. At that point the boiler will shut off the
DHW burner function and DHW circulator. This feature
is always active even if the DHW operation is placed into
an OFF mode (See Parameter 2 DHW Burner /
Circulator Function Setup, page 9).
DOMESTIC HOT WATER (SMART OR TR
SERIES) WITH AQUASTAT CONTROL
This application is the standard factory setup of the
MCBA control. In this application the Prestige uses the
aquastat of the SMARTor TR Series Indirect Fired
Water Heaters to initiate a request for heat.
DANGER
Parameter Factory Setting Revised Setting
P_35 13 13
Parameter
Factory
Default Setting
Minimum
Setting
Maximum
Setting
1 140ºF 68ºF 148ºF
Parameter
Factory
Setting
Minimum
Setting
Maximum
Setting
P_27 18ºF (-)16ºF 54ºF

Error Codes
If Parameter 35 is set to 12 (DHW - Storage Tank with
NTC Sensor) and a DHW aquastat is connected to the
Prestige 24 volt terminal strip connections for DHW, then
a “soft” lockout will occur. The display will show an error
code of
b_33 or b_38 alternating with a status code of
9 depending on the status of the aquastat.
The error code display on the Prestige will
switch from error code b_33 to error code b_38
if the IDWH aquastat is adjusted from a “closed”
to “open” position. The error code display on
the unit will not switch from an error code b_38
to an error code b_33 when the aquastat is
adjusted from an “open” to “closed” position.
DHW BURNER / CIRCULATOR FUNCTION
SETUP
The type of DHW/boiler operation can be revised to the
application requirements. The Prestige offers 4 different
DHW/Boiler Function setup modes. Those function
setups are defined as:
-OFF In this mode the Prestige will NOT recognize
any request for a “call for heat” from a DHW aquas-
tat or NTC sensor. This mode shuts down the DHW
NOTICE
operation, both burner and DHW circulator function,
of the Prestige control. The Prestige will maintain
all CH operation, both burner and CH circulator
function, with no domestic priority in this mode.
-ON In this mode, factory setting, the Prestige burn-
er and DHW circulator will operate in a response to
a “call for heat” by the IDWH. This request can be
either a NTC sensor or DHW aquastat. There is
domestic priority over central heating in this mode.
-OFF + Pump Continuous In this mode of opera-
tion the Prestige will block the burner operation dur-
ing a request for “call for heat” from a NTC sensor
or DHW aquastat. The DHW circulator will remain
energized at all times even during a CH request for
heat. The Prestige will maintain all CH operation,
both burner and CH circulator function, with no
domestic priority feature.
-ON + Pump Continuous The Prestige will main-
tain continuous circulation on the DHW circulator
and will provide burner function when a request for
heat is generated by the NTC sensor for DHW or by
the DHW aquastat. The Prestige will provide
domestic priority by blocking the CH circulator func-
tion during a DHW request for heat.
When determining the type of DHW operation,
especially those applications with continuous
pump feature the installer should install a ther-
mostatic mixing valve on the outlet of the
domestic tank to prevent a potential scalding
hazard. Failure to comply could result in a
scalding hazard causing severe personal injury,
death or substantial property damage.
Parameter Adjustments - OFF Mode
The parameter adjustment to set the DWH operational
option to OFF can be done either through the STBY
mode during normal operation or by entering into the
CODE mode.
When the unit is in normal operation and in the STBY
mode, press MODE button once to enter PARA. Press
STEP button twice to Parameter 2. Press - button to
adjust to the following revised setting and press STORE
to save the setting.
DANGER
Parameter
Factory
Setting
Minimum
Setting
Maximum
Setting
33 46ºF 0ºF 54ºF
9
Error Code Reason / Correction
b_33
Parameter 35 is set as 12 (DHW Type -
Storage tank with NTC Sensor) and
the IDWH aquastat is in "CLOSED"
position. Reset Parameter 35 to 13.
b_38
Parameter 35 is set as 12 (DHW Type-
Storage Tank with NTC Sensor) and
the IDHW aquastat is in "OPEN"
position. Reset Parameter 35 to 13
Parameter Factory Setting Revised Setting
2 2_01 2_00

10
The unit can also be place into the OFF mode when the
unit is in normal operation without entering the PARA
mode. In the STBY mode press and hold for approxi-
mately 2 seconds the - button. The panel display should
flash a d followed by a display of dOFF .
This method of using the - button to place the
DWH application in the OFF mode only controls
the burner operation. If the current parameter
setting is set for continuous pump operation the
DHW circulator will continue operating in a con-
tinuous pump mode. To alter both DHW burner
and circulator function the parameter setting
must be revised in the PARA mode.
The parameter adjustment of Parameter 2 in the CODE
mode is accomplished by following the steps given in
Program Access Section on page 2 until the display
shows 2_ XX. Use the + or - to adjust to the revised set-
ting listed below and press STORE to save the setting.
Parameter Adjustments - ON Mode
The Prestige is in factory set to this mode. However, the
parameter adjustment to set the DHW operational option
to ON can be done either through the STBY mode dur-
ing normal operation or by entering into the CODE
mode.
When the unit is normal operation and in the STBY
mode, press MODE button once to enter PARA. Press
STEP button twice to Parameter 2. Press + or - button
to adjust to the revised setting listed below and press
STORE to save the setting.
The unit can also be placed into the ON mode when the
unit is in the OFF mode operation without entering the
PARA mode. In the STBY mode press and hold for
approximately 2 seconds the - button. The panel display
should flash a d followed by a display of d XXX . with
XXX indicating the current boiler temperature.
NOTICE
Returning the unit to the ON mode using the -
button will restore the burner function in
response to a “call for heat” request by the
IDWH. If the unit is in a continuous pump func-
tion the circulator will remain in that mode
unless the parameter setting is revised in the
PARA mode.
The parameter adjustment of Parameter 2 in the CODE
mode is done by following the steps given in Program
Access Section on page 2 until the display shows
2_ XX . Use the + or - to adjust to the revised setting and
press STORE button to save the setting.
Parameter Adjustments - OFF + Continuous Pump
Mode
The parameter adjustment to set the DHW operational
function option to OFF + Continuous Pump can be
done either through the STBY mode during normal oper-
ation or by entering into the CODE mode.
When the unit is in normal operation and in the STBY
mode, press mode button once to enter PARA. Press
STEP button twice to Parameter 2. Press + or - button
to adjust to the revised setting listed below and press
STORE to save the setting.
The parameter adjustment of Parameter 2 in the CODE
mode is done by following the steps given in Program
Access Section on page 2 until the display shows
2_ XX . Use the + or - to adjust to the revised setting and
press STORE to save the setting.
NOTICE
Parameter Factory Setting Revised Setting
2 2_01 2_00
Parameter Factory Setting Revised Setting
2 2_01 2_01
Parameter Factory Setting Revised Setting
2 2_01 2_02
Parameter Factory Setting Revised Setting
2 2_01 2_02

If the unit is currently set in an ON + Continuous
Pump mode, the unit can be placed in an OFF +
Continuous Pump mode by pressing and hold-
ing the - button for approximately 2 seconds.
The panel display should flash a d followed by a
display of
dd
ddOO OOFF FFFF FF
.
Parameter Adjustments - ON + Continuous Pump
Mode
The parameter adjustment to set the DHW operational
function option to ON + Continuous Pump can be done
either through the STBY mode during normal operation
or by entering into the CODE mode.
When the unit is in normal operation and in the STBY
mode, press MODE button once to enter PARA. Press
STEP button twice to Parameter 2. Press + or - button
to adjust to the revised setting listed below and press
STORE to save the setting.
The parameter adjustment of Parameter 2 in the CODE
mode is done by following the steps given in Program
Access Section on page 2 until the display shows
2_ XX . Use the + or - to adjust to the revised setting,
listed below and press STORE to save the setting.
If the unit is currently set in an OFF +
Continuous Pump mode, the unit can be placed
in an ON + Continuous Pump mode by pressing
and holding the - button for approximately 2 sec-
onds. The panel display should flash a d fol-
lowed by a display of
dd
dd
XXX , with XXX indicating
the current boiler temperature.
NOTICE
NOTICE
11
DOMESTIC HOT WATER APPLICATION
PUMP SETUP
At the completion of a DHW request for heat the amount
of time for post pump activity can be determine. The
post pump feature allows the stored heat within the boil-
er to be absorbed in the Domestic Tank, thus preventing
any potential overheating of low temperature space
heating applications.
When utilizing and adjusting the allowable time
for DHW post pump activity it is strongly recom-
mended that a thermostatic mixing valve with
anti-scald feature be installed on the hot water
outlet of the domestic tank. Failure to comply
could result in a scalding hazard causing severe
personal injury, death or substantial property
damage.
Parameter Adjustments
The parameter adjustment for DHW post pump activity is
Parameter 21. Follow the steps given in Program
Access Section on page 2 until the display shows P_21 .
Release the STEP button and display should show the
factory setting. Use the + or - to adjust to the revised
setting and press STORE to save the setting.
The parameter setting is multiplied by 10.2 sec-
onds for the actual setting. For example the fac-
tory setting is 3 and the actual time period of the
post pump cycle is 30.6 seconds.
NOTICE
DANGER
Parameter Factory Setting Revised Setting
2 2_01 2_03
Parameter
Factory
Setting
Minimum
Setting
Maximum
Setting
21
03
x 10.2 sec.
00
x 10.2 sec.
30
x 10.2 sec.
Parameter Factory Setting Revised Setting
2 2_01 2_03

12
DOMESTIC HOT WATER APPLICATION -
DHW REQUEST FOR HEAT SETUP
At the completion of a DHW request for heat, the amount
of time for delay in reacting to a secondary DHW request
for heat can be determined. The “blocking” time feature
prevents potential short cycling of the boiler burner and
extends the life of the blower/ burner components.
During the blocking period the burner will not fire in
response to a secondary DHW. Only the DHW request
for heat circulator will begin circulating at the start of the
secondary DHW request for heat.
Long “blocking” time will effect the production of
domestic hot water and can result in the lack of
domestic hot water delivery for the application.
Parameter Adjustments
The parameter adjustment for DHW “blocking” time is
Parameter 29. Follow the steps given in Program Access
Section on page 2 until the display shows P_29 .
Release the STEP button and display should show the
factory setting. Use the + or - to adjust to the revised
setting and press STORE to save the setting.
The parameter setting is multiplied by 10.2 sec-
onds for the actual setting. For example if the
parameter setting is 03 and the actual time peri-
od of the “blocking” time is 30.6 seconds.
NOTICE
NOTICE
DOMESTIC HOT WATER APPLICATION -
DHW TO CH REQUEST FOR HEAT SETUP
At the completion of a DHW request for heat, the amount
of time for burner delay in reacting to a CH (space heat-
ing) request for heat can be determined. The “blocking”
time feature in conjunction with the DHW post pump
cycle may prevent any potential overheating of a low
temperature CH system. This blocking time period does
not affect the production of domestic hot water.
If the parameter setting is 00 (OFF setting for this func-
tion feature) and the burner is firing at the completion of
a DHW request for heat, then the burner will remain fir-
ing and the CH circulator will begin pumping. If there is
a blocking time setting, the burner will shut down for that
period, while the CH pump will circulator to the system.
Long “blocking” times may affect the comfort
level of the occupants in certain CH zones.
Parameter Adjustments
The parameter adjustment for DHW to CH “blocking”
time is Parameter 30. Follow the steps given in Program
Access Section on page 2 until the display shows
P_30 . Release the STEP button and display should
show the factory setting. Use the + or - to adjust to the
revised setting and press STORE to save the setting.
The parameter setting is multiplied by 10.2 sec-
onds for the actual setting. For example if the
parameter setting is 03 and the actual time peri-
od of the “blocking” time is 30.6 seconds.
A 00 setting of this parameter places the feature
in an OFF condition.
NOTICE
NOTICE
NOTICE
Parameter
Factory
Setting
Minimum
Setting
Maximum
Setting
30
00
x 10.2 sec.
00
x 10.2 sec.
30
x 10.2 sec.
Parameter
Factory
Setting
Minimum
Setting
Maximum
Setting
29
00
x 10.2 sec.
00
x 10.2 sec.
30
x 10.2 sec.

13
CENTRAL HEATING (CH) APPLICATION PARAMETER GENERAL GUIDE
Parameter Description
Factory
Setting
Minimum
Setting
Maximum
Setting
3
CH application selection. Setting of the CH “ON” or
“OFF”. Setting of the CH pump function “continuous”
or “aquastat controlled”.
01 00 03
See pages 19 through 21 for additional information
4
CH boiler operating temperature set point. This is the
maximum operating temperature.
186ºF 86ºF 194ºF
See page 15 for additional information
5
CH boiler operating temperature set point. This is the
minimum allowable operating temperature during the
warmest outdoor temperature when using the
optional outdoor sensor
86ºF 60ºF 140ºF
See page 15 for additional information
6
The minimum outdoor temperature setting when
using the optional outdoor sensor
00ºF (-)04ºF 50ºF
(outdoor
sensor
required)
See page 21 for additional information
7
The maximum outdoor temperature setting
when using the optional outdoor sensor
64ºF 60ºF 78ºF
(outdoor
sensor
required)
See page 21 for additional information
8
The minimum outdoor temperature to initiate the frost
protection mode on the boiler
(-)22ºF (-)22ºF 50ºF
(outdoor
sensor
required)
See page 22 for additional information
10
(outdoor
sensor
required)
T4 Block Temperature setting. If the boiler is
operating based on outdoor temperature, the
heat request is completed if the calculated
operating temperature limit is based on outdoor
temperature is less the Blocking temperature.
32ºF 32ºF 140ºF
See page 22 for additional information
11
Boost feature set point. Use to compensate the
calculated operating temperature.
00
minutes
00
minutes
30
minutes
(outdoor
sensor
required)
See pages 22 through 24 for additional information
12
Parallel shift setting. When using the optional
outdoor sensor this setting is a setback feature.
00ºF 00ºF 144ºF
(outdoor
sensor
required)
See page 24 for additional information

14
Parameter Description
Factory
Setting
Minimum
Setting
Maximum
Setting
20
Post pump feature setting for the CH circulator
supplied with the boiler.
01
minutes
00
(10 seconds)
99
minutes
See page 24 for additional information
28
Blocking time setting between a completed CH
request for heat and a secondary request.
03
x 10.2 sec.
00
x 10.2 sec.
30
x 10.2 sec.
See page 25 for additional information.
34
Selection of CH application type based on
the response for heat. Room thermostat,
Outdoor temperature, external controller.
00 00 05
(See
WARNING
Below)
See pages 15 through 18 for additional information
38
Boiler hold temperature setting. Maintains a
minimum boiler temperature.
32ºF 32ºF 176ºF
See page 25 for additional information
CENTRAL HEATING (CH) APPLICATION PARAMETERS GENERAL GUIDE
Parameter 34 has multiple parameter settings
available in addition to the settings 00,01, 04 and
05, which are outlined in detail in this supple-
ment guide. DO NOT set Parameter 34 to any
other setting other than 00, 01, 04 or 05. Failure
to comply can result in erratic or unreliable oper-
ation of the Prestige boiler.
WARNING

15
CENTRAL HEATING (CH) APPLICATION
PARAMETERS GENERAL GUIDE
CH OPERATIONAL TEMPERATURE
SETTING - HIGH AND LOW LIMIT
The boiler high operating limit is adjustable to meet the
required system design temperature. This boiler limit
setting does not affect the operating temperature limit
when the unit is in DHW heating mode.
This high limit setting is the maximum CH temperature
setting on the coldest design temperature day when
using outdoor reset; see Outdoor Reset Control section
on page 20. The setting of the high limit can be done in
the STBY operating mode or by entering into the access
code of the control.
Parameter Adjustment
When the unit is in normal operation and in the STBY
mode, press MODE button once to enter PARA. Press
STEP button four times to Parameter 4. Press the + or
- button to adjust to the revised setting and press
STORE to save the setting. The display will flash when
the new setting is stored into the module.
The parameter adjustment of Parameter 4 in the CODE
mode is done by following the steps given in Program
Access Section on page 2 until the display shows
4 XXX . Use the + or - to adjust to the revised setting and
press STORE to save the setting.
The boiler low operating limit is adjustable to meet the
required system temperature. This low temperature limit
is the boiler operating temperature during the warmest
design temperature day when using outdoor reset; see
Outdoor Reset Control section on page 20. The setting
of the limit can only be done by entering into the access
code of the control.
Parameter Adjustment
The parameter adjustment of Parameter 5 in the CODE
mode is done by following the steps given in Program
Access Section on page 2 until the display shows
5_ XX . Use the + or - to adjust to the revised setting and
press STORE to save the setting.
CH APPLICATION FUNCTION SETTING -
ROOM THERMOSTAT
The CH heat request to the boiler and to control the
burner and CH circulator function can be accomplished
through the closed contacts of a room thermostat. This
request for heat can also be completed by the closing of
the boiler X-X or T-T contacts of a standard zone panel
relay.
This function, parameter 34, is the factory setting of the
MCBA module and can only be revised by entering the
access code mode.
Parameter Adjustment
The parameter adjustment of Parameter 34 in the CODE
mode is done by following the steps given in Program
Access Section on page 2 until the display shows
P_34 . Use the + or - to adjust to the revised setting and
press STORE to save the setting.
For additional parameter settings, which relate to CH
type - Room Thermostat reference:
System Temperature Design Curve - requires the
use of an outdoor sensor:
-Outdoor Minimal Design Temperature Minimum
(Parameter 6) page 21.
-Outdoor Maximum Design Temperature
Maximum (Parameter 7) on page 21
Parameter
Factory
Setting
Minimum
Setting
Maximum
Setting
4 186ºF 86ºF 194ºF
Parameter
Factory
Setting
Minimum
Setting
Maximum
Setting
4 186ºF 86ºF 194ºF
Parameter
Factory
Setting
Minimum
Setting
Maximum
Setting
5 86ºF 60ºF 140ºF
Parameter Factory Setting Revised Setting
P_34 00 00

16
Boiler Operating Temperature
- Boiler Operating Temperature High Limit
(parameter 4) on page 15
- Boiler Operating Temperature Low Limit (param-
eter 5) on page 15
Boiler Operational Function Options :
-Burner and CH Circulator Function Options
(Parameter 3) on pages 19 through 21.
- CH Circulator Post Operation (Parameter 20) on
page 24
- CH Heat Request Blocking Time (Parameter 28)
on page 25
Application / System Options:
- Burner Blocking Temperature (Parameter 10) on
page 22
- System Boost Feature (Parameter 11) on page
22-24
CH APPLICATION FUNCTION SETTING -
OUTDOOR TEMPERATURE
The CH operating temperature is controlled and estab-
lished by the use of an outdoor sensor measuring the
outdoor temperature. In this application the Prestige can
maintain constant flow through the system and maintain
a constant request for heat. The burner function is
based on the outdoor temperature reading and its rela-
tionship to the maximum and minimum allowable oper-
ating temperature in Parameters 4 and 5. This applica-
tion requires the use of a 12k NTC sensor, reference
Triangle Tube’s Outdoor Sensor Kit, connected to the
appropriate 24V terminals on the Prestige.
The use of a room thermostat is not required typ-
ically in this application. The room thermostat
has no control over the CH burner function or
the CH circulator function. The room thermostat
does provide other application options such as
Parallel Shift / Night Setback.
To operate the Prestige under this application mode sev-
eral Parameters must be revised to establish the
required operating temperatures for the application. To
configure the MCBA control to react based on the out-
door temperature, Parameter 34 must be revised
accordingly and any corresponding parameters will be
defined in detail in later sections.
NOTICE
40
80
120
160
200
Min.
86
3G^ ,
,
,
,
Min. 60
3G^
)GRI[RGZKJ(UORKX
5VKXGZOTM:KSVKXGZ[XK
6GXGSKZKX
9KZ6UOTZ
6GXGSKZKX
9KZ6UOTZ
'JP[YZGHRK8GTMK
6GXGSKZKX
'JP[YZGHRK8GTMK
6GXGSKZKX
5[ZJUUX:KSVKXGZ[XK
=GXSKX )UURKX
(UORKX
:KSVKXGZ[XK
,
Fig. 1: Setting the Boiler Operating Limits

17
In this application mode the domestic priority
function will remain, resulting in the CH circula-
tor being blocked and the boiler operating tem-
perature will reset to Parameter 1 plus Parameter
33.
Parameter Adjustment
The parameter adjustment of Parameter 34 in the CODE
mode is done by following the steps given in Program
Access Section on page 2 until the display shows
P_34 . Use the + or - to adjust to the revised setting,
listed below and press STORE to save the setting.
To control the burner and CH circulator function when in
this Heat Request - Outdoor Sensor mode the installer
has 2 options:
-Option 1 is to install a summer / winter switch in
parallel to the outdoor sensor on the 24 volt ter-
minals. The switch would create a false outdoor
temperature that would block the CH burner and
CH circulator function. Domestic hot water
would remain functional and would respond to
any request for heat from the IDWH.
-Option 2 is to reference the section on Burner
Blocking Temperature and revise the parameter
setting accordingly.
It is important that the installer references the
section regarding the Burner Blocking
Temperature. The consideration and implemen-
tation of this operating feature will prevent the
need of a summer / winter switch.
For additional parameter setting, which relate to CH
type -Outdoor Temperature reference:
System Temperature Design Curve:
- Outdoor Minimal Design Temperature Minimum
(Parameter 6) on page 21.
-Outdoor Maximum Design Temperature
Maximum (Parameter 7) on page 21.
BEST PRACTICE
NOTICE Boiler Operating Temperature:
- Boiler Operating Temperature High Limit
(Parameter 4) on page 15.
- Boiler Operating Temperature Low Limit
(Parameter 5) on page 15.
Boiler Operational Function Options :
- Burner and CH Circulator Function Options
(Parameter 3) on page 19 through 21.
- CH Circulator Post Operation (Parameter 20) on
page 24.
- CH Heat Request Blocking Time (Parameter 28)
on page 25.
Application / System Options:
- Burner Blocking Temperature (Parameter 10) on
page 22.
- System Boost Feature (Parameter 11) on page
22 and 24.
-Parallel Shift / Night Setback (Parameter 12) on
page 24.
If an outdoor sensor is not properly connected to the
Prestige low voltage terminals and Parameter 34 is
revised to Heat Request - Outdoor Sensor as outlined
in this section, the unit will operate at the temperature
limit established in Parameter 4. The operating temper-
ature of the Prestige cannot be calculated without sens-
ing the outdoor temperature.
CH APPLICATION FUNCTION SETTING - 0
TO 10V EXTERNAL CAPACITY WITH AM4
INTERFACE
This application is generally for multiple boilers in which
there is an external boiler control to stage the boilers and
control the burner modulation. In this application the
external controller will control the burner modulation
based on the system load requirements.
The external controller will provide a 0 to 10V analog
input to the Prestige AM4 interface module based on the
time to meet the system load requirements. The initial
analog input of 1.8V or less will indicate the minimum
load. An analog input of 10V will indicate the maximum
load requirements. The actual function of the external
controller will vary from manufacturer to manufacturer.
To operate the Prestige under this application mode sev-
eral parameters must be revised to establish the
Parameter Factory Setting Revised Setting
P_34 00 01

18
required operating temperatures for the application. To
configure the MCBA control to react based on the output
signal of an external controller Parameter 34 must be
revised accordingly and any corresponding parameters
will be defined in detail in later sections.
Parameter Adjustment
The parameter adjustment of Parameter 34 in the CODE
mode is done by following the steps given in Program
Access Section on page 2 until the display shows
P_34 . Use the + or - to adjust to the revised setting,
listed below and press STORE to save the setting.
For additional parameter setting, which relate to CH type
0 - 10V External Capacity with AM4 Interface reference:
- Boiler Operating Temperature High Limit
(Parameter 4) on page 15
- Boiler Operating Temperature Low Limit
(Parameter 5) on page 15
Boiler Operational Function Options:
-Burner and CH Circulator Function Options
(Parameter 3) on page 19 through 21
- CH Circulator Post Operation (Parameter 20) on
page 24.
-CH Heat Request Blocking Time (Parameter 28)
on page 25.
CH APPLICATION FUNCTION SETTING - 0
TO 10V EXTERNAL TEMPERATURE WITH
AM4 INTERFACE
This application is generally for multiple boilers in which
there is an external boiler control to stage the boilers and
control the burner modulation. In this application the
external controller will control the burner modulation
based on the system temperature requirements.
The external controller will provide a 0 to 10V analog
input to the Prestige based on the system temperature
to meet the load requirements. An analog input of 0V
will indicate the minimum system temperature of 32ºF
and an analog input of 10V relates to a maximum sys-
tem temperature of 212ºF. Because these tempera-
tures are outside the normal operating limits of the
Prestige, the minimum and maximum system tem-
perature must be set using Parameter 4 and 5. The
actual function of the external controller will vary from
manufacturer to manufacturer.
To operate the Prestige under this application mode,sev-
eral parameters must be revised to establish the
required operating temperatures for the application. To
configure the MCBA control to react based on the output
signal of an external controller Parameter 34 must be
revised accordingly and any corresponding parameters
will be defined in detail in later sections.
Parameter Adjustment
The parameter adjustment of Parameter 34 in the CODE
mode is done by following the steps given in Program
Access Section on page 2 until the display shows
P_34 . Use the + or - to adjust to the revised setting,
listed below and press STORE to save the setting.
For additional parameter setting, which relate to CH type
0 - 10V External Capacity with AM4 Interface reference:
Boiler Operating Temperature:
- Boiler Operating Temperature High Limit
(Parameter 4) on page 15.
- Boiler Operating Temperature Low Limit
(Parameter 5) on page 15.
Boiler Operational Function Options:
-Burner and CH Circulator Function Options
(Parameter 3) on page 19 through 21.
-CH Circulator Post Operation (Parameter 20) on
page 24.
- CH Heat Request Blocking Time (Parameter 28)
on page 25.
Parameter Factory Setting Revised Setting
P_34 00 05
Parameter Factory Setting Revised Setting
P_34 00 04
