Trinity 888 ZW 15 User manual

SmartCode™
Electronic Deadbolt with
Z-Wave Technology
PRODUCT GUIDE
OVERVIEW
Pocket fishing for your keys is over! The Smart Code™Electronic Deadbolt with Z- Wave Technology
enables you to securely lock and unlock your home from anywhere,send guest access codes,
monitor lock activity, and connect to other smart home devices at anytime through your Alarm.com
app. With one touch locking, the Smart Code™Electronic Deadbolt provides you with convenience
as well as security.
Venetian Bronze
Trinity Wiring and Security Solutions |C o p y r i g h t © 2 0 1 9 A l a r m. c o m. A l l r i g h t s r e s e r v e d . pg1

OTHER FINISHES OFFERED
Lifetime Polished Brass
Trinity Wiring and Security Solutions |C o p y r i g h t © 2 0 1 9 A l a r m. c o m. A l l r i g h t s r e s e r v e d . pg2
Satin Nickel

INCLUDED MATERI ALS
•Latch
•Interior/ Exterior Assembly
•Strike
•Keys
•Batteries
•Alexa
•SmartThings
•Vera
•Wink
DEVICE BENEFITS DEVICE FEATURES
•Up to 30 user access codes for family and
guests plus master code feature for added
security
•Secured keyless entry convenience
•Motorized deadbolt enable t rue remote
locking and unlocking
•Replaces existing deadbolt with just a
screwdriver
•No hard wiring needed
•Z- W ave Plus Certified with the Z - W ave 500
chipset
•Extended wireless range and superior
128 -bit wireless encryption
•5digit keypad with dedicated lock button
•One touch locking
•Lock Button is Backlit for 30 seconds
•Fits standard doors
•Drill and pick resistant backup keyway with
Bump Guard™protection
•Audit trail logging stores access history in
the lock memory
•Incorrect code protection with audible
alarm
•Adapter Ring
•Mounting Plate
•Smart Key Tool
•Fasteners
IMPORTANT THINGS TO KNOW
Trinity Wiring and Security Solutions |C o p y r i g h t © 2 0 1 9 A l a r m. c o m. A l l r i g h t s r e s e r v e d . pg3
COMPATIBLE TECHNOLOGIES
Exterior Doors
The SmartCode Electronic Deadbolt can be
installed on exterior doors only.
Installation
An exterior door cannot include both adoor
lever and aSmartCode Electronic Deadbolt.

SMARTCODE DEADBOLT AT AGLANCE
STATUS LED
The Status LED blinks every 6seconds to communicate whether the door is locked or unlocked.
feature in on by default.
This
Blinking Green:Unlocked
Blinking Amber: Locked
Blinking Red: Low Battery
Solid Red: Unsuccessful door handling process
Turn Stats LED On/ Off:
1. Press Program button once.
2. Press button “A” once.
3. Press button “ 1 - 2 ” multiple times if
needed to reach desired state.
4. Press Lock button once.
Trinity Wiring and Security Solutions |C o p y r i g h t © 2 0 1 9 A l a r m. c o m. A l l r i g h t s r e s e r v e d . pg4

IMPORTANT SAFEGUARDS
Itis recommended that you add and delete all user codes through your smart home control
system. If your system does not allow this, codes may be added directly to the lock as shown here.
Programming Timeout
During programming, i f no button is pressed for five seconds, the system will time out ( indicated by
three beeps and ared flashing lock button ) , and you will need to restart the procedure.
Master Code
For enhanced security, amaster code may be used when adding and deleting user codes.
1 . Make sure the door is open.
Press the Program button once.
2 . Enter used code. Atotal of
30 user codes may be
programmed.
3 . Press Lock button.
4 . W hat l ights and sounds does the lock produce?
Lock button flashes green once with one Lock button f lashes three t imes with three beeps
beep
Progra m m ing was s uc c es s ful. Progra m m ing was uns uc ces s ful.
Mak e s ure not to paus e for more than 5 s ec onds during
program ming.
Mak e s ure the us er code i s not a duplic ate and that it i
sbetween 4and 8digits during your next attem pt.
Mak e s ure the loc khas room for an additional code. I f
al l us er c ode pos i t ions are f i l led, delete a c ode to m ake
room for this one.
Trinity Wiring and Security Solutions |C o p y r i g h t © 2 0 1 9 A l a r m. c o m. A l l r i g h t s r e s e r v e d . pg5

SYSTEM ALERTS
ALERT REASON SOLUTION
Lock button flashes
once with one beep*.
One incorrect code
entered.
Re-enter code.
Lock button flashes
red 3 t imes with 3
beeps*.
No user code
program m ed.
Program at least one
user code.
Programming t imeout
after five seconds.
Attempt programming
procedure again.
Unsuccessful
program m ing.
Lock button flashes
red 15 times with 15
beeps*.
Three incorrect codes
entered within one
minute.
Re-enter code after 60
second keypad
lockout.
Lock button f lashes
red with fast beeping
sound for 3to 4
seconds.
Low battery. Replace batteries.
Lock button flashes
green with continuous
beeping sound for 2
seconds.
Door jammed while
attempting to lock.
Manually re-lock door.
Ifneeded, reposition
strike.
DELETING ASINGLE USER CODE
Note: All codes may be deleted at once i f the master code is enabled.
I f no button is pressed for 5seconds, the system will time out, and you will need to restart the
procedure.
1. Press Program button once.
2. Press Lock button once.
3. Enter user code to be deleted.
4. Press Lock button once.
5. Re-enter user code.
6. Press Lock button once.
If unsuccessful: Make sure to enter the same valid code in steps 3and 5 .
Trinity Wiring and Security Solutions |C o p y r i g h t © 2 0 1 9 A l a r m. c o m. A l l r i g h t s r e s e r v e d . pg6

1 . Press Program
button once.
2 . Press button “A”
once.
3. Press button “5-6”
multiple t imes i f needed
to reach desired state.
Green lock button:
Feature is enabled
Red lock button:
Feature is disabled.
4 . Press Lock button
once.
AUTO-LOCK
MUTE/UNMUTE AUDIO
Audio is on by default.
Turn Auto-Lock On/Off Change Auto-Lock Time Delay
1. Press Program
button once.
2 . Press button “A”
once.
1 . Press program
button once.
2 . Press button “A”
once.
3. Press button “3-4”
multiple t imes if
needed to reach
desired state.
4 . Press Lock button
once.
3 . Press button
“9-0” once.
4 . Press
button once
that
corresponds
to desired
time of day:
“1 - 2 ” 3 0 sec.
“3 - 4 ” 6 0 sec.
“5 - 6 ” 9 0 sec.
“7- 8 ” 120 sec.
“9- 0 ” 180 sec.
5 . Press Lock
button once.
Auto-lock automatically re -locks the door after unlocking. This feature is set to 30 seconds and is
turned off by default.
Trinity Wiring and Security Solutions |C o p y r i g h t © 2 0 1 9 A l a r m. c o m. A l l r i g h t s r e s e r v e d . pg7

MANUAL DOOR HANDLING
FACTORY RESET
Afactory reset will delete all codes associated with the lock, and i t will remove i t from your smart
home system.
If needed, the door handling process can be initiated manually. This is useful if the lock is being
moved to adifferent color.
1 . Remove battery pack. 2 . Press and HOLD the
Program button while
reinserting the battery
pack. Release button
once battery pack is
installed. The status LED
will flash red and green.
3 . Press the Program button
once more.
4 . The latch bolt will extend and
retract to learn the orientation
of the door.
The Status LED will indicate
success or failure.
5. Success: LED flashes green
Failure: LED remains solid red
I f the Status LED indicates a
failure, see the online
Programming and
Troubleshooting Guide or call
Technical Support.
1 . Remove battery pack. 2 . Press and HOLD the
Program button while
reinserting the battery
pack. Keep holding the
button for 30 seconds
until the lock beeps
and the status LED
flashes red.
2 . Press the Program button
once more. When the LED
flashes green and you hear
one beep, the lock has
been reset.
4 . After afew seconds, the lock will initiate the
door handing process, and the latch bolt will
extend and retract to learn the orientation of the
door.
Trinity Wiring and Security Solutions |C o p y r i g h t © 2 0 1 9 A l a r m. c o m. A l l r i g h t s r e s e r v e d . pg8

IMPORTANT SAFEGUARDS
1. Read all instructions in their entirety.
2. Familiarize yourself with all warning and caution statements.
3. Remind all family members of safety precautions.
4. Protect your user codes and master code.
5. Dispose of used batteries according to local laws and regulations.
CAUTION:Prevent unauthorized entry.Since anyone with access to the back panel can
change the user codes, you must restrict access to the back panel and routinely check the
user codes to ensure they have not been altered without your knowledge.The use of a
master code can help protect your system' ssettings .
WARNING: This Manufacturer advises that no lock can provide complete security by i
tself. This lock may be defeated by forcible or technical means, or evaded by entry
elsewhere on the property. No lock can substitute for caution, awareness of your
environment, and common sense. Builder' shardware is available in multiple performance
grades to suit the application. In order to enhance security and reduce risk, you should
consult aqualified locksmith or other security professional.
