Model #: PV600
PowerVerter Ultra-Compact Inverter - Portable Power for All Applications
Highlights
600 watt continuous output; 1200 watt peak output (instantaneous)
Converts 12V DC (battery) power into 110-120V AC (household) power; 3 AC outlets
Installs in minutes (includes integrated mounting feet)
Provides a quiet alternative to generator noise and fumes
Includes "battery saver" low voltage alarm/shutdown
Description
Harness your vehicle's battery to efficiently power appliances, small electronics and office equipment on the road. Continuously supplies up to 600
watts of 120V AC power to 3 AC outlets from any 12V battery. Ultra-compact, lightweight metal case design is among the smallest, most rugged
inverters available.
Applications
Ideal for portable electronics, office equipment, RV and mobile appliances, video game and small entertainment systems, battery chargers
and more
Package Includes
PV600 Ultra-Compact DC-to-AC Inverter
Instruction manual
Features
Provides 120V AC power for a variety of mobile applications
600 watts continuous output power and 1200 watts peak output power (instantaneous)
3 AC outlets
Ultra-compact, extruded aluminum casing stands up to the toughest environments
Cooling fan lengthens inverter service life
Integrated mounting feet provide safe, fixed installation
Low battery alarm/shutdown detects low voltage and shuts down inverter
Overload alarm/shutdown detects wattage overload on inverter outlets and shuts down inverter as a protective measure
DC input terminals assure solid connection to battery with user-supplied cables
Lighted on/off switch shows inverter operations in cramped or dark environments
Specifications
OUTPUT
Frequency
compatibility
60 Hz
Output watts 600W (continuous)/1200W (peak)
Output nominal
voltage
120V

Output voltage
regulation
Maintains PWM sine wave output voltage of 115 V AC (+/- 8 V AC)
Output frequency
regulation
60 Hz (+/- 3 Hz)
Overload protection Via set of 2 40A automotive input fuses
Outlet quantity / type 3 NEMA 5-15R
INPUT
Recommended
Electrical Service
Requires 12V DC input source capable of delivering 64A for the required duration (when used at full capacity). For
automotive applications, professional hardwire installation with 80A battery system fusing is recommended.
Maximum input amps
/ watts
Full continuous load - 64A at 12V DC, No load - 0.95A at 12V DC, Shutdown - 150 microamps
Input connection type Set of 2 DC bolt-down wiring terminals
Input cord length
details
User supplies cabling. Minimum gauges for full load operation: 8 (6 ft max), Two 10 (8 ft max), 6 (10 ft max), 4 (15 ft
max).
Voltage compatibility
(VDC)
12
BATTERY
DC system voltage
(VDC)
12
LEDS ALARMS & SWITCHES
Alarms Dual function alarm indicates overload conditions or low DC input voltage of 10.5V or less.
Switches Lighted on/off power switch
PHYSICAL
Shipping Dimensions
(HWD/in)
4 x 6.5 x 10.25
Shipping Dimensions
(HWD/cm)
10.2 x 16.5 x 26
Shipping weight (lbs) 3
Shipping weight (kg) 1.4
Unit Dimensions
(HWD/in)
2.75 x 5 x 8.25
Unit Dimensions
(HWD/cm)
7 x 12.7 x 21
Unit weight (lbs) 2.5
Unit weight (kg) 1.1
Cooling method Fan
Material of
construction
Aluminum / sheet metal
ENVIRONMENTAL
Relative Humidity 0-95% non-condensing
SPECIAL FEATURES
Appearance Attractive, rugged, metallic gray color inverter system
WARRANTY

Product Warranty
Period (Worldwide)
1-year limited warranty
