Tripp Lite PowerVerter APS512 Configuration guide

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: APS512
PowerVerter APS Inverter/Charger - Reliable Power Source for Uninterruptible Emergency Backup Applications
Highlights
12V DC input; 120V AC output; 2 outlets
500 watts continuous output
1000 watts peak surge output for an extended period
Advanced battery charger
Fast load switching with less transfer time
Description
Tripp Lite's APS512 3-function DC-to-AC inverter with auto line-to-battery transfer and integrated charging system serves as an extended run UPS,
a standalone power source or an automotive inverter. Supplies up to 500 watts of continuous 120V AC power to 2 AC outlets from any 12V battery or
automotive DC source. When AC cable is connected to a live wall socket, commercial power passes through to connected equipment and the
battery set is recharged via 3 stage, 18 amp charging system. In UPS mode, the APS system responds to blackouts and brownouts with an
uninterrupted transfer to battery-derived AC output. Includes a set of high current DC input terminals for simple installation (user supplies batteries
and cabling). Reliable large transformer design with efficient PWM sine wave output and frequency control powers resistive electronic loads or large
inductive motors, compressors and other items with high current needs on startup. Supports an unlimited amount of runtime with any number of
user-supplied batteries connected. Highly adaptable to a variety of applications and site conditions with adjustable charger settings for wet/gel
battery types and selectable line to battery power transfer voltages.
PowerVerter APS Inverters accommodate "peak surge" demands by delivering more output power than their continuous rating. Compare the
"Continuous" and "Peak Surge" wattage ratings, and you'll find PowerVerter Plus Inverters supply up to double their output to easily handle
equipment start up and motor cycling requirements. A DoubleBoost feature provides up to 200% of the continuous output for up to 10 seconds,
providing the extra power needed to cold start heavy-duty tools and equipment. An OverPower feature delivers up to 150% of the continuous output
for up to 1 hour.
Applications
Extended Run UPS - Configure as a UPS for long-term battery support of telecom systems, security alarms, computer systems and
various other motorized and electronic loads.
Standalone Power - Alternative power source for use in off-grid, backwoods, alternative energy and export applications where commercial
power is not continuously available.
Automotive - Connect to an automotive electrical system to run power tools, computers, electronic test equipment, home entertainment and
other AC appliances in fleet service vehicles, over-the-road trucks, campers, RVs, minivans and more.
Package Includes
APS512 Inverter/Charger
Instruction manual with warranty information
Features
Functions as an extended run UPS system, standalone power source and automotive inverter
Includes AC input cord and auto-transfer to enable battery charging and automatic UPS support for blackouts & brownouts
500 watts continuous output power; provides up to twice this rating for momentary startup of inductive loads
Battery runtime is dependent upon the size and number of user-supplied 12-volt batteries used

2 outlets; 6-ft. AC power cord; DC input terminals for 12V battery connection
Converts 12 volt DC to 120 volt AC
Frequency control for operating stability
Advanced 18 amp, 3-stage battery charger and selector switch for gel or wet cell batteries
Resettable circuit breaker protects APS against system overload
Switch allows user to select between off, auto-invert and charge-only settings
6 diagnostic LEDs indicate AC present, on battery, overload, & battery voltage level (high, medium, & low)
Configuration switches to allow the user to select the high and low voltage for the unit to automatically transfer from AC power to battery
backup
Coated internal circuit boards offer continuous operation in humid environments (0-95%, non condensing)
3.5mm port for connecting remote switch (User supplies plug, cable and switch - see manual)
Allows unlimited runtime capability by allowing the use any number of user-supplied batteries
Specifications
OUTPUT
Frequency
compatibility
60 Hz
Output watts Continuous - 500 watts, Overpower (up to 1 hour) - 750 watts, Double-Boost wattage (up to 10 seconds) - 1000 watts
Output nominal
voltage
AC OUTPUT: 120V AC nominal, DC CHARGER OUTPUT (DC): 12V DC nominal
Output voltage
regulation
LINE POWER (AC): Maintains 120V nominal sine wave output. INVERTER POWER (AC): Maintains PWM sine
wave output voltage of 120 VAC (+/-5%). DC CHARGER OUTPUT (See battery recharge rate section)
Output frequency
regulation
60 Hz (+/- 0.3 Hz)
Overload protection Circuit breaker
Outlet quantity / type Includes 2 AC outlets (NEMA 5-15R)
INPUT
Recommended
Electrical Service
DC INPUT: Requires 12V DC input source capable of delivering 50A for the required duration (when used at full
continuous capacity). For automotive applications, professional hardwire installation with 100A battery system fusing
is recommended. AC INPUT
Maximum input
amps / watts
DC INPUT: Full continuous load - 50A at 12VDC, No load - 2.2A at 12V DC. AC INPUT: 8 amps at 120V AC with full
inverter and charger load
Input connection type DC INPUT: Set of 2 DC input wingnut terminals. AC INPUT: NEMA 5-15P input plug
Voltage compatibility
(VAC)
120
Voltage compatibility
(VDC)
12
BATTERY
Expandable battery
runtime
Runtime is expandable with any number of user supplied wet or gel type batteries
DC system voltage
(VDC)
15
Battery Pack
Accessory (optional)
98-121 sealed lead acid battery (optional)
Battery recharge rate Includes 20 amp DC charging system
LEDS ALARMS & SWITCHES
Switches Lighted on/off power switch, plus 2 conductor 3.5 mm port for connecting remote switch - user supplies switch,
3.5mm plug and cable.

Front panel LEDs Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7
levels reported). See manual for sequences.
PHYSICAL
Shipping
Dimensions (HWD/in)
11.5 x 8.75 x 9.375
Shipping
Dimensions
(HWD/cm)
29.2 x 22.22 x 23.8
Shipping weight (lbs) 16.8
Shipping weight (kg) 7.6
Unit Dimensions
(HWD/in)
6.75 x 6.5 x 9.75
Unit Dimensions
(HWD/cm)
17.1 x 16.5 x 24.8
Unit weight (lbs) 16
Unit weight (kg) 7.3
Cooling method Convection
Material of
construction
Polycarbonate
ENVIRONMENTAL
Relative Humidity 0-95% non-condensing
LINE / BATTERY TRANSFER
Transfer time from
line power to battery
mode
4-6 milliseconds
Low voltage transfer
to battery power
User configurable to 75V, 90V, 95V & 105V
High voltage transfer
to battery power
User configurable to 135V, 145V
SPECIAL FEATURES
Appearance Black color
WARRANTY
Product Warranty
Period (Worldwide)
1-year limited warranty
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=177.
