Tripp Lite PowerVerter APS1524 Installation and operation manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model Number: APS1524
PowerVerter APS Inverter/Charger - Reliable Power Source for Uninterruptible Emergency Backup Applications
Highlights
24V DC input; 120V AC output
Hardwired
1500 watts continuous output
3000 watts peak output for an extended period
Advanced battery charger
Fast load switching with less transfer time
Description
Tripp Lite's APS1524 3-function DC-to-AC inverter with auto line-to-battery transfer and integrated charging system serves as an extended run UPS,
a standalone power source or an automotive inverter.
PowerVerter APS Inverters accommodate "peak surge" demands by delivering more output power than their continuous rating. PowerVerter APS
Inverters supply up to double their output to easily handle equipment start up and motor cycling requirements. A DoubleBoost feature provides up to
200% of the continuous output for up to 10 seconds, providing the extra power needed to cold start heavy-duty tools and equipment. An OverPower
feature delivers up to 150% of the continuous output for up to 1 hour. When hardwire input AC cable is energized, commercial power passes through
to connected equipment and the battery set is recharged via 3 stage, 10/30 amp selectable charging system. In UPS mode, the APS system
responds to blackouts and brownouts with an uninterrupted transfer to battery-derived AC output. Includes a set of high current DC input terminals
for simple installation (user supplies batteries and cabling). Reliable large transformer design with efficient PWM sine wave output and frequency
control powers resistive electronic loads or large inductive motors, compressors and other items with high current needs on startup. Supports an
unlimited amount of runtime with any number of user-supplied batteries connected. Highly adaptable to a variety of applications and site conditions
with adjustable charger settings for wet/gel battery types and selectable line to battery power transfer voltages.
Applications
Extended Run UPS - Configure as a UPS for long-term battery support of telecom systems, security alarms, computer systems and
various other motorized and electronic loads.
Standalone Power - Alternative power source for use in off-grid, backwoods, alternative energy and export applications where commercial
power is not continuously available.
Automotive - Connect to an automotive electrical system to run power tools, computers, electronic test equipment, home entertainment and
other AC appliances in fleet service vehicles, over-the-road trucks, campers, RVs, minivans and more.
Package Includes
APS1524 Inverter/Charger
Instruction manual with warranty information
Features
Functions as an extended run UPS system, standalone power source and automotive inverter
Includes hardwire AC input and auto-transfer to enable battery charging and automatic UPS support for blackouts and brownouts
1500 watts continuous output power; 2250 watts power for up to an hour; 3000 watts peak power for up to 10 seconds
Battery runtime is dependent upon the size and number of user-supplied batteries in 24V configuration
Hardwire input and output connections supported, DC input terminals for 24V battery connection

Hardwire input and output connections supported, DC input terminals for 24V battery connection
Converts 24V DC to 120V AC
Frequency control for operating stability
Advanced 10/30 amp selectable, 3-stage battery charger and selector switch for gel or wet cell batteries
Resettable circuit breaker protects APS against system overload
Switch allows user to select between off, auto-invert and charge-only settings
6 diagnostic LEDs indicate AC present, on battery, overload, & battery voltage level (high, medium, & low)
Configuration switches to allow the user to select the high and low voltage for the unit to automatically transfer from AC power to battery
backup
Coated internal circuit boards offer continuous operation in humid environments (0-95%, non condensing)
RJ45 port allows connection of APS remote switch (part# APSRM4)
Allows unlimited runtime capability by allowing the use any number of user-supplied batteries
Specifications
OUTPUT
Frequency
compatibility
60 Hz
Output watts Continuous - 1500 watts, Overpower (up to 1 hour) - 2250 watts, Double-Boost wattage (up to 10 seconds) - 3000 watts
Output nominal
voltage
AC OUTPUT: 120VAC nominal, DC CHARGER OUTPUT (DC): 24VDC nominal
Output voltage
regulation
LINE POWER (AC): Maintains 120V nominal sine wave output. INVERTER POWER (AC): Maintains PWM sine wave
output voltage of 120 VAC (+/-5%). DC CHARGER OUTPUT (See battery recharge rate section)
Output frequency
regulation
60 Hz (+/- 0.3 Hz)
Overload
protection
Includes 15A input breaker dedicated to the charging system and 15A output breaker for AC output loads
Outlet quantity /
type
Hardwire AC output
INPUT
Recommended
Electrical Service
DC INPUT: Requires 24VDC input source capable of delivering 70A for the required duration (when used at full
continuous capacity). For automotive applications, professional hardwire installation with 125A minimum battery system
fusing is recommended.
Maximum input
amps / watts
DC INPUT: Full continuous load - 70A at 24VDC. AC INPUT: 26 amps at 120VAC with full inverter and charger load
Input connection
type
DC INPUT: Set of 2 DC bolt-down terminals. AC INPUT: Hardwire via built in junction box with cover plate
Voltage
compatibility (VAC)
120
Voltage
compatibility (VDC)
24
BATTERY
Expandable
battery runtime
Runtime is expandable with any number of user supplied wet or gel type batteries
DC system voltage
(VDC)
30
Battery Pack
Accessory
(optional)
98-121 sealed lead acid battery (optional)

Battery charge Includes selectable 9 / 36 amp DC charging system with selectable profiles for vented wet cell and sealed gel cell
batteries. Optional use battery equalize charge function equalizes the charge level when used with multiple batteries
(see manual for detailed charger information).
LEDS ALARMS & SWITCHES
Switches 3 position on/off/remote switch enables simple on/off power control plus "auto/remote" setting that enables distant on/off
control of the inverter system when used in conjunction with optional APSRM4 accessory when used in inverter mode.
In AC uninterruptible power mode, "auto/remote" setting enables automatic transfer from line power to battery power -
to maintain continuous AC power to connected loads.
Front panel LEDs Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7
levels reported). See manual for sequences.
PHYSICAL
Shipping
Dimensions
(HWD/in)
13.5 x 15 x 21.5
Shipping
Dimensions
(HWD/cm)
34.3 x 38.1 x 54.6
Shipping weight
(lbs)
27
Shipping weight
(kg)
12.3
Unit Dimensions
(HWD/in)
7.25 x 8.5 x 16
Unit Dimensions
(HWD/cm)
18.4 x 21.6 x 40.6
Unit weight (lbs) 26.6
Unit weight (kg) 12.1
Cooling method Fan
Material of
construction
Polycarbonate
Form factors
supported
Mounting slots enable permanent placement of inverter on any horizontal surface (see manual for additional mounting
information)
ENVIRONMENTAL
Relative Humidity 0-95% non-condensing
LINE / BATTERY TRANSFER
Transfer time from
line power to
battery mode
4-6 milliseconds
Low voltage
transfer to battery
power
User configurable to 75V, 85V, 95V & 105V
High voltage
transfer to battery
power
User configurable to 135V, 145V
SPECIAL FEATURES
Appearance Black color
Load Sensing Optional load sense function enables automatic inverter shutoff and startup as connected equipment is powered off
and on. Front panel load sense potentiometer can be set to shutoff or turn on inverter power in response to loads of any
level, up to 150 watts.

WARRANTY
Product Warranty
Period (Worldwide)
1-year limited warranty
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
http://www.tripplite.com/sku/APS1524.
