Model #: APS2012SW
120V, 2000W PowerVerter APS Inverter/Charger with Pure Sine Wave Output
Highlights
12V DC or 120V AC input; 120V, 50/60 Hz output (hardwired)
2000 watts continuous output, 4000 watts peak output
Selectable 6/60 amp wet/dry cell battery charger
Pure sine wave output
Quiet, high efficiency operation, high surge capacity and low idle current
Seamless transfer switching
Description
Provide Pure Sine Wave power in your fleet vehicle, work truck or utility vehicle with the Tripp Lite APS2012SW. This inverter/charger supplies 2000
watts of continuous 120V AC power. The reliable large transformer design and frequency control powers resistive loads such as refrigerators,
motors, pumps, compressors and laser printers as well as electronic loads like TV’s, Computers, power tool and battery chargers. The 3-stage
charging system will properly charge and maintenance your vehicle battery or separate battery bank. The charge rate is selectable so you can use a
variety of battery sizes as well as multiple batteries to fit your run time requirements.
Applications
Versatile inverter/charger system with seamless transfer switching serves as an automotive inverter for over-the-road trucking, conversion
vans and fleet service vehicles; a standalone alternative power source for off-grid, alternative energy or export applications and as an
uninterruptible power supply (UPS) for items compatible with a 8-12 millisecond transfer time.
Package Includes
APS2012SW Inverter/Charger
Instruction manual with warranty information
Features
Pure sine wave output
Continuous output inverter and high power battery charger
Quiet, high efficiency operation, high surge capacity and low idle current
Supply energy to various loads such as resistive load
Seamless transfer switching
Load sensing adjustable
Unlimited back up time with user supplied batteries
Specifications
OVERVIEW
Intended
Application
Emergency Home Power, Auxillary Vehicle power, UPS backup
OUTPUT

Frequency
compatibility
50 / 60 Hz
Output watts 2000
Continuous output
capacity (watts)
2000
Peak output
capacity (watts)
4000
Output nominal
voltage
120V
Output voltage
regulation
LINE POWER (AC): Maintains 120V nominal sine wave output from line power source. INVERTER POWER (AC):
Maintains sine wave output voltage of 120 VAC (+/-5%).
Output frequency
regulation
50/60 Hz (+/- 0.3 Hz)
Overload protection Includes 15A input breaker dedicated to the charging system and 15A output breaker for AC output loads
Outlet quantity /
type
Hardwire
INPUT
Nominal Input
Voltage(s)
Supported
120V AC
Recommended
Electrical Service
DC INPUT: Requires 12VDC input source capable of delivering 250A for the required duration (when used at full
continuous capacity - DC requirements increase during OverPower and DoubleBoost operation). For automotive
applications, professional hardwire installation with 400A minimum battery system fusing is recommended.
Maximum input
amps / watts
DC INPUT: Full continuous load - 250A at 12VDC. AC INPUT: 27 amps at 120VAC with full inverter and charger load
(8.7A max charger-only / combined input load to support charger and AC output is automatically controllable to
66%-33%-0% based on AC output loading using the charger limiting set points - see manual for setting instructions)
Input connection
type
DC INPUT: Set of 2 DC bolt-down terminals. AC INPUT: Hardwire via built in junction box with cover plate
Voltage
compatibility (VAC)
120
Voltage
compatibility (VDC)
12
BATTERY
Expandable battery
runtime
Runtime is expandable with any number of user supplied wet or gel type batteries
DC system voltage
(VDC)
12
Battery Pack
Accessory
(optional)
98-121 sealed lead acid battery (optional)
Battery recharge
rate
Selectable 6 to 60 amp
VOLTAGE REGULATION
Overvoltage
correction
Overvoltage transfer point - 135V (+/- 3%)
Brownout
correction
Brownout transfer point - 85V (+/- 3%)
LEDS ALARMS & SWITCHES

Alarms Audible Status indicators (see manual)
Switches The inverter provides an RJ-45 port for optional APSRMSW retmote control. RJ-45 port operates with standard RS-485
interface (APSRMSW sold separately)
Front panel LEDs Display inverter status, charger status as well as bettery voltage status
PHYSICAL
Shipping weight
(lbs)
55.6
Shipping weight
(kg)
25.22
Unit Dimensions
(HWD/in)
7.25 x 8.75 x 21.75
Unit Dimensions
(HWD/cm)
18.41 x 22.22 x 55.24
Unit weight (lbs) 49.5
Unit weight (kg) 22.45
Cooling method Multi-speed fan
Material of
construction
Powder coated steel
Receptacle Color Gray
Style Heavy-duty with built-in battery charger
Form factors
supported
Mounting slots enable permanent placement of inverter on any horizontal surface (see manual for additional mounting
information)
ENVIRONMENTAL
Relative Humidity 0-95% non-condensing
Operating
Elevation (ft.)
0-1500 meters -20 - +40 degrees C 1501-3000 meters -20 - +35 degrees C
Operating
Elevation (m)
0-1500 meters -20 - +40 degrees C 1501-3000 meters -20 - +35 degrees C
LINE / BATTERY TRANSFER
Transfer time from
line power to
battery mode
8-12 milliseconds
Low voltage
transfer to battery
power
In AC "auto" mode, inverter/charger switches to battery mode as line voltage drops to 144V (user adjustable to 163,
182, 201V - see manual)
High voltage
transfer to battery
power
In AC "auto" mode, inverter/charger switches to battery mode as line voltage increases to 259V (user adjustable to 264
- see manual)
SPECIAL FEATURES
Appearance gray color
Remote control
capability
Yes
WARRANTY
Product Warranty
Period (U.S. &
Canada)
2-year limited warranty

Product Warranty
Period
(International)
2-year limited warranty
Product Warranty
Period (Mexico)
2-year limited warranty
Product Warranty
Period (Puerto
Rico)
1-year limited warranty
Related Items
Optional Products
Related Model Description Qty.
APSRMSW Inverter Remote Control Module for Tripp Lite Pure Sine Wave Inverter/Chargers 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=5019.
