Tripp Lite PDUMH30AT User manual

1
Owner’s Manual
Automatic Transfer Switch PDU
Models:
PDUMH30AT, PDUMH30ATNET, PDUMNH30AT2, PDUMH30HVAT,
PDUMH30HVATNET, PDUMNH30HVAT2, PDUMH32HVAT,
PDUMH32HVATNET, PDUMNH32HVAT2
Agency Model Numbers:
AGAC8033 • AGAC8034 • AGAC8110 • AGAC8073 • AG-0150 • AG-0151
Important Safety Instructions 2
Feature Set Overview 4
Installation 4
Mounting the PDU 4
Connecting the PDU 7
Features 8
LED Diagrams 15
Configuration and Operation 19
Automatic Transfer Switch 19
Service 21
Warranty and Product Registration 22
Español 23
Français 45
Русский 67
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.

2
Important Safety Instructions
This manual contains information concerning the proper
installation and use of Tripp Lite’s Rackmount Power Strips.
SAVE THESE INSTRUCTIONS.
Do not connect your power strip to an ungrounded outlet. Do not
use it with extension cords or adapters that eliminate its
connection to ground. Your power strip is designed for indoor use
only. Install it away from heat emitting devices such as radiators
and heat registers. Do not install where excessive moisture or
other conductive contaminants are present. Never install
electrical wiring during a lightning storm.
The power requirement of each device connected to an outlet of
your power strip must not exceed the Outlet Power Rating of your
power strip (see Specifications). The total power requirements of
all devices connected to your power strip must not exceed the
Maximum Load Rating of your power strip (see Specifications).
CAUTION Only those who are properly trained or qualified to use
this device should do so. Anyone who is not trained or qualified
should not use this device unless it is under the supervision of
someone who is properly trained or qualified to do so.
Children must be supervised to ensure that they do not use the
device as a toy.
Never use the device if the cord and plug are damaged; if it is not
working properly, or if it has been dropped or damaged, take it to
an authorized service center for inspection and repair.
If the power cord is damaged, it must be replaced by the
manufacturer, its authorized service agent, or by qualified
personnel in order to avoid a danger.
• The PDU provides the convenience of multiple outlets, but DOES NOT provide surge
or line noise protection for connected equipment.
• The PDU is designed for indoor use only, in a controlled environment, away from
excess moisture, temperature extremes, conductive contaminants, dust or direct
sunlight.
• Keep indoor ambient temperature between 32°F and 104°F (0°C and 40°C).
• The PDU must be installed by a qualified technician only.
• Only those who are properly trained or qualified to use this device should do so.
Anyone who is not trained or qualified should not use this device unless it is under
the supervision of someone who is properly trained or qualified to do so.
• Do not attempt to mount the PDU to an insecure or unstable surface.
• Install in accordance with National Electrical Code standards. Be sure to use the
proper overcurrent protection for the installation, in accordance with the plug/
equipment rating.

Important Safety Instructions
3
• Connect the PDU to an outlet that is in accordance with your local building codes
and that is adequately protected against excess currents, short circuits and earth
faults.
• The electrical outlets supplying power to the equipment should be installed near the
equipment and easily accessible.
• Do not connect the PDU to an ungrounded outlet or to extension cords or adapters
that eliminate the connection to ground.
• Be sure to provide a local disconnect device on any models that are permanently
installed without a plug that is easily accessible.
• Never attempt to install electrical equipment during a thunderstorm.
• Individual equipment connected to the PDU should not draw more current than the
individual PDU’s outlet’s rating.
• The total load connected to the PDU must not exceed the maximum load rating for
the PDU.
• Do not attempt to modify the PDU, input plugs or power cables.
• Do not drill into or attempt to open any part of the PDU housing. There are no user-
serviceable parts inside.
• Do not attempt to use the PDU if any part of it becomes damaged.
• This equipment is not suitable for use in locations where children are likely to be
present.
• Use of this equipment in life support applications where failure of this equipment
can reasonably be expected to cause the failure of the life support equipment or to
significantly affect its safety or effectiveness is not recommended.
• The AC Main tolerance of this equipment is +6/-10%.

1A
2A
4
Installation
Mounting the PDU
The PDU supports 2U rack mounting or surface mounting (e.g. on a wall, on a desk
or under a counter).
Note: The user must determine the fitness of hardware and procedures before mounting. The PDU and
included hardware are designed for common rack and rack enclosure types and may not be appropriate for all
applications. Exact mounting configurations may vary.
2U Rack Mounting
Feature Set Overview
1A Attach the included mounting
brackets to the sides of the PDU
with the included screws.
2A After attaching the brackets,
position the PDU in the rack and
install four user-supplied screws
through the bracket ears and into
the rack rails.
Model Number
Outlet
Control
(Yes/No)?
Outlet LED
Indicator
(Yes/No)?
Shipped with
SNMP Slot
(Yes/No)?
Shipped with
SNMP Card
Installed
(Yes/No)?
PDUMH30AT No No No No
PDUMH30ATNET Yes Yes Yes Yes
PDUMNH30AT2 No No Yes Yes
PDUMH30HVAT No No No No
PDUMH30HVATNET Yes Yes Yes Yes
PDUMNH30HVAT2 No No Yes Yes
PDUMH32HVAT No No No No
PDUMH32HVATNET Yes Yes Yes Yes
PDUMNH32HVAT2 No No Yes Yes

2B
3B
3B
Installation
1B
5
Wall Mounting (not applicable to series AG-0151 for PDUMH32HVAT,
PDUMNH32VAT2 or PDUMH32HVATNET)
1B Attach one of the supplied
mounting brackets to the wall with
user-supplied screws. Make sure
screws and any other hardware
are appropriate for the surface
type.
2B Attach a mounting bracket to the
PDU with the included screws.
3B Place the PDU on the wall-
mounted bracket and secure the
PDU to the bracket and wall as
shown.

1C
2C
Installation
6
Surface Mounting
1C Attach the included mounting
brackets to the sides of the PDU
with the included screws.
Note: If you need to change the orientation
of the PDU to match the mounting surface,
rotate the mounting brackets in 90°
increments as required before attaching.
2C Mount the PDU to a stable surface
by inserting four user-supplied
screws through the bracket ears
and into appropriate mounting
holes. Make sure the mounting
surface and screws are capable of
supporting the combined weight of
the PDU and any attached
equipment cords.
3C Attach Cord Retention Brackets
(Optional): Attach the cord
retention brackets to the PDU with
the included screws.
3C

Installation
1
To UPS
To UPS A
B
7
Connecting the PDU
Note: The PDU includes two input power cords: Primary and Secondary. They should be connected to two
separate AC power sources.
1Connect PDU Input Plugs: Connect
the Primary input plug Ato a preferred
source of grounded AC power (120V
for PDUMH30AT, PDUMNH30AT2 &
PDUMH30ATNET; 200-240V for
PDUMH30HVAT, PDUMNH30HVAT2,
PDUMH30HVATNET, PDUMH32HVAT,
PDUMNH32HVAT2 &
PDUMH32HVATNET), such as a
Tripp Lite SmartOnline®UPS System.
Under normal operating conditions, the
PDU will distribute AC power from the
Primary input source. Connect the
Secondary input plug Bto an
alternative source of grounded AC
power (120V for PDUMH30AT,
PDUMNH30AT2 & PDUMH30ATNET;
200-240V for PDUMH30HVAT,
PDUMNH30HVAT2,
PDUMH30HVATNET, PDUMH32HVAT,
PDUMNH32HVAT2 &
PDUMH32HVATNET), For proper ATS
(automatic transfer switch) function, do
not plug the Secondary input into the
same power source as the Primary
input. The PDU will distribute AC power
from the Secondary input only if the
Primary input becomes unavailable due
to an outage or power quality problem.
(See Configuration and Operation
section for more information about the
ATS function.)

Installation
2
3
PDUMH30AT Model Shown
8
PDUMH30AT
Model
Shown
2Connect Equipment to the PDU: Do
not exceed the total load rating of the
PDU or output load bank. The
connected equipment load will be
displayed on the digital load meter in
amperes.
3Cord Retention (Optional): If you
connected the cord retention brackets
to the PDU, attach each equipment
power cord to a cord retention bracket
by looping the cord and securing it to
an attachment point with one of the
included cable ties. Make sure that
each power cord can be unplugged
from the PDU without removing the
cable tie.

Bank 1
Bank 2
Output Breaker
Bank 1 Output Breaker
Bank 2
Config Port
20A Max load per bank
Outlet type C19/16A, C13/10A
Primary
Input
Secondary
Input
Bank
1
Bank
2
Bank 1
Bank 2
Output Breaker
Bank 1 Output Breaker
Bank 2
Config Port
20A Max load per bank
Outlet type C19/16A, C13/10A
Primary
Input
Secondary
Input
Bank
1
Bank
2
4
4
7
7
6
6
PDUMH30HVAT
PDUMH32HVAT
1
1
2
2
3
3
3
5
5
Bank 1
Bank 2
Output Breaker
Bank 1 Output Breaker
Bank 2
Config Port
20A Max load per bank
Outlet type C19/16A, C13/10A
Primary
Input
Secondary
Input
Bank
1
Bank
2
3 3
PDUMH30AT
1
2
3
56
7
8
8
4
9
Features

Features
Bank 1
Bank 2
PDUMH30ATNET
PDUMNH30AT2
PDUMH30HVATNET
2 1
2
1
195
2
3
3
3
3
3
4
4
4
3
37
3
5
5
6
6
7
7
8
8
8
6
9
9
10
